2006 TOYOTA RAV4 sensor

’06 Rav4_U (L/O 0601)
80
2005 RAV4 from Jan. ’06 Prod. (OM42620U)
This warning light system monitors the
airbag sensor assembly, front airbag sen-
sors, side and curtain shield airbag sen-
sors, curtain shield airbag sensors, driv-
er ’s seat position sensor, driver ’s seat belt
buckle switch, “AIRBAG ON” indicator
light, “AIRBAG OFF” indicator light, front
passenger ’s seat belt buckle switch, seat
belt pretensioner assemblies, inflators, in-
terconnecting wiring and power sources.
(For details, see “Service reminder indica-
tors and warning buzzers” on page 127 in
Section 1−6.)
If either of the following conditions occurs,
this indicates a malfunction of the airbags
or seat belt pretensioners. Contact your
Toyota dealer as soon as possible.
The light does not come on when the
ignition key is turned to the “ON” posi-
tion or remains on for more than 6
seconds.
The light comes on while driving.
The SRS warning light and “AIRBAG OFF”
indicator light will come on if there is a
malfunction in the front passenger occu-
pant classification system.
In the following cases, contact your Toyota
dealer as soon as possible:
Any of the SRS side airbags and cur-
tain shield airbags have been inflated.
The portion of the doors (shaded in the
illustration) was involved in an accident
that was not severe enough to cause
the SRS side airbags and curtain
shield airbags to inflate.
The surface of the seats with the side
airbag (shaded in the illustration) is
scratched, cracked, or otherwise dam-
aged.
The portion of the front, center and
roof side garnish containing the curtain
shield airbags inside (shaded in the
illustration) is scratched, cracked, or
otherwise damaged.
NOTICE
Do not disconnect the battery cables
before contacting your Toyota dealer.

’06 Rav4_U (L/O 0601)
126
2005 RAV4 from Jan. ’06 Prod. (OM42620U)
3. Trip meter reset knob—Resets the twotrip meters to zero, and also change
the meter display.
To change the meter display, quickly
push and release the knob. The meter
display changes in the order from the
odometer to trip meter A to trip meter
B, then back to the odometer each
time you push.
To reset the trip meter A to zero, dis-
play the meter A reading, then push
and hold the knob until the meter is
set to zero. The same process can be
applied for resetting the trip meter B.
The displayed temperature ranges from
−40 C ( −40 F) up to 50 C (122 F).
The key must be in the “ON” position.
If an abnormality exists in the connection
of the outside air temperature sensor,
“ −− C” will appear on the display. If
“ −− C” appears on the display, contact
your Toyota dealer.
When the outside air temperature falls be-
low 3 C (37F) while driving, the tempera-
ture display flashes to indicate that the
outside air temperature is becoming low.
However, if the temperature is already
3 C (37 F) or below, the display does not
flash when ignition is turned on.
Outside temperature display

’06 Rav4_U (L/O 0601)
133
2005 RAV4 from Jan. ’06 Prod. (OM42620U)
When the “ABS” warning light is on (and
the brake system warning light is off), the
anti−lock brake system does not operate
so that the wheels could lock up during
a sudden braking or braking on slippery
road surfaces.
If either of the following conditions
occurs, this indicates a malfunction
somewhere in the components moni-
tored by the warning light. Contact your
Toyota dealer as soon as possible to
service the vehicle.
The light does not come on when the
ignition key is turned to the “ON” posi-
tion, or remains on.
The light comes on while you are driv-
ing.
A warning light turning on briefly during
operation does not indicate a problem.
CAUTION
If the “ABS” warning light remains on
together with the brake system warn-
ing light, immediately stop your ve-
hicle at a safe place and contact your
Toyota dealer.
In this case, not only the antilock
brake system will fail but also the
vehicle will become extremely unsta-
ble during braking.
(i) Open Door Warning Light
This light remains on until all the side
doors and back door are completely
closed. (j) SRS Warning Light
This indicator comes on when the igni-
tion key is turned to the “ON” position.
If goes off after about 6 seconds. This
means the SRS airbags and seat belt
pretensioners are operating properly.
This warning light system monitors the
airbag sensor assembly, front airbag sen-
sors, side and curtain shield airbag sen-
sors, curtain shield airbag sensors, driv-
er ’s seat position sensor, driver ’s seat belt
buckle switch, “AIRBAG ON” indicator
light, “AIRBAG OFF” indicator light, front
passenger ’s seat belt buckle switch, seat
belt pretensioner assemblies, inflators, in-
terconnecting wiring and power sources.
If any of the following conditions occurs,
this indicates a malfunction of the airbags
or seat belt pretensioners. Contact your
Toyota dealer as soon as possible.
The light does not come on when the
ignition key is turned to the “ON” posi-
tion or remains on for more than 6
seconds.
The light comes on while driving.

’06 Rav4_U (L/O 0601)
285
2005 RAV4 from Jan. ’06 Prod. (OM42620U)
CAUTION
Do not overestimate the antilock
brake system: Although the antilock
brake system assists in providing ve-
hicle control, it is still important to
drive with all due care and maintain
a moderate speed and safe distance
from the vehicle in front of you, be-
cause there are limits to the vehicle
stability and effectiveness of steering
wheel operation even with the anti
lock brake system on.
If tire grip performance exceeds its
capability, or if hydroplaning occurs
during high speed driving in the rain,
the antilock brake system does not
provide vehicle control.
Antilock brake system is not de-
signed to shorten the stopping dis-
tance: Always drive at a moderate
speed and maintain a safe distance
from the vehicle in front of you.
Compared with vehicles without an
antilock brake system, your vehicle
may require a longer stopping dis-
tance in the following cases:
Driving on rough, gravel or snow
covered roads.
Driving with tire chains installed.
Driving over the steps such as the
joints on the road.
Driving on roads where the road
surface is pitted or has other differ-
ences in surface height.
Install all 4 tires of specified size at
appropriate pressure: The antilock
brake system detects vehicle speeds
using the speed sensors for respec-
tive wheels’ turning speeds. The use
of tires other than specified may fail
to detect the accurate turning speed
resulting in a longer stopping dis-
tance.
For the U.S.A.
For Canada

’06 Rav4_U (L/O 0601)
399
2005 RAV4 from Jan. ’06 Prod. (OM42620U)
ENGINE COMPARTMENT (No.2)1. AMP 30 A: Audio system
2. AM2 30 A: Starting system
3. IG2 15 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system
4. HAZ 10 A: Emergency flashers
5. ETCS 10 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system
6. AM22 7.5 A: No circuit
7. EFI NO.1 10 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system
8. EFI NO.2 10 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system
9. EFI MAIN 20 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system, “EFI NO.1”, “EFI NO.2”
fuses
10. HORN 10 A: Horn
11. A/F 20 A (3.5 L V6 [2GRFE] engine only): A/F sensor
12. P/I 50 A: “EFI MAIN”, “HORN”, “A/F”
fuses 13. ABS2 30 A:
Anti−lock brake system,
traction control system, vehicle stability
control system, “AUTO LSD” system,
downhill assist control system, hill −start
assist control system
14. ABS1 50 A: Anti−lock brake system,
traction control system, vehicle stability
control system, “AUTO LSD” system,
downhill assist control system, hill −start
assist control system
15. EMPS 60 A: Electric power steering
system
16. MAIN 80 A: “HEAD MAIN”, “ECU −B2”,
“RSE” fuses
17. ALT 120 A (without towing package) or 140 A (with towing package):
“ABS 1”, “ABS 2”, “RDI”, “CDS”,
“FAN1”, “FAN2”, “AC INV”, “TOWING”,
“HTR”, “DEICER” fuses
