2006 TOYOTA PRIUS steering wheel

148
The vehicle stability control system
helps provide integrated control of the
systems such as antilock brake sys-
tem, brake assist system, hybrid system
control, etc. This system automatically
controls the brakes and hybrid system
to help prevent the vehicle from skid-
ding when cornering on a slippery road
surface or operating steering wheel
abruptly.
This system activates when the vehicle
speed is more than about 15 km/h (9
mph).CAUTION
Do not rely exclusively on the ve-
hicle stability control system. Even
if the vehicle stability control sys-
tem is operating, you must always
drive carefully and attentively to
avoid death or serious injury. Reck-
less driving will result in an unex-
pected accident. If the slip indicator
light flashes, sounding an alarm,
special care should be taken while
driving.
Only use tires of specified size. The
size, manufacturer, brand and tread
pattern for all 4 tires should be the
same. If you use tires other than
specified, or mixed types or size,
the vehicle stability control system
may not function correctly. When
replacing the tires or wheels, con-
tact your Toyota dealer. (See
“Checking and replacing tires” on
page 407.)
25p115a
Slip indicator light
If the vehicle is going to skid during driv-
ing, the slip indicator light blinks and an
alarm sounds intermittently. Special care
should be taken while driving.
The slip indicator light blinks in the follow-
ing conditions also.
The vehicle tires are racing. Utmost
care is required when driving.
When the anti−lock brake system is
operating. See “Brake system” on page
325 for details.
Vehicle stability control
system

171
26p030c
Ty p e 3
AUTOMATIC TRANSITION
The function returning to the previous
screen from the audio or air conditioner
screen is selectable. Select “ON” or
“OFF” and then touch “OK”.
ON:The previous screen automatically re-
turns from the audio or air condition-
er screen 20 seconds after the end
of audio or air conditioner screen op-
eration.
OFF: The audio or air conditioner screen
remains on. BACKGROUND COLOR
Select the desired background color
and touch “OK”.
Handsfree system allows you to make
or receive a call without taking your
hands off the steering wheel by con-
necting your cellular phone.
This system supports Bluetooth. Bluetooth
is a wireless data system by which you
can call without your cellular phone being
connected with a cable or placed on a
cradle.
If your cellular phone does not support
Bluetooth, this system cannot function.
CAUTION
While you are driving, do not use a
cellular phone or connect the Blue-
tooth phone.
NOTICE
Do not leave your cellular phone in
the vehicle. The temperature indoor
may be high and damage the phone.
Handsfree system

172
INFORMATION
In the following conditions, the sys-
tem may not function.
The cellular phone is turned off.
The current position is outside the
communication area.
The cellular phone is not connected.
The cellular phone has a low bat-
tery.
27p333
By pushing the telephone button above,
you can receive a call or hang up with-
out taking your hands off the steering
wheel.
27p334
You can use the microphone above
when talking on the phone.

175
FCC ID: BABBT003A
IC ID: 2024BBT003A
MADE IN JAPAN
This device complies with Part 15 of the
FCC Rules and RSS −210 of the IC
Rules. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause harmful interference, and
(2) This device must accept any inter-
ference received, including interference
that may cause undesired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
CAUTION: Radio Frequency Radiation
Exposure
This equipment complies with FCC radi-
ation exposure limits set forth for uncon-
trolled equipment and meets the FCC
radio frequency (RF) Exposure Guide-
lines in Supplement C to OET65. This
equipment has very low levels of RF
energy that it deemed to comply without
maximum permissive exposure evalua-
tion (MPE). But it is desirable that it
should be installed and operated with at
least 20cm and more between radiator
and person’s body (excluding extremi-
ties; hands, wrists, feet and legs).
Colocation: This transmitter must not
be co− located or operated in conjunction
with any other antenna or transmitter.(a)Entering a Bluetooth phone
To use the handsfree system, you
need to enter your phone into the sys-
tem. Once you have registered it, you
can make a handsfree call.
1. Push the “INFO” button to display the “Information” screen.
27p181
2. Touch the “Telephone” switch to dis-play “Telephone” screen.
You can also push the
button of the
steering wheel to display this screen when
the vehicle is stopped.

180
Each time you touch “ ”, an inputted
digit is deleted.
When you touch “
”, the number you
called last is inputted.
Touch “
” or push the button of the
steering wheel.
(ii) By phone book
You can call by phone book data which
is transferred from your cellular phone.
The system has one phone book. You
can register up to 1000 numbers.
This cannot be operated while you are
driving.
27p193
Touch the desired key to input the tele-
phone number.
1. Touch the “Phone Book” switch to display “Phone Book” screen.
27p194
2. Select the desired number from the
list.

181
27p195
Touch “” or push the button of the
steering wheel.
(iii) By dialed numbers
You can call by dialed number. The
system memorizes up to 5 dialed num-
bers. If it is over 5, the oldest number
is deleted.
This cannot be operated while you are
driving.
27p196
1. Touch the “Call Log” switch to dis- play “Outgoing Calls” screen.
27p197
When you call by phone book, the
name (if registered) is displayed.
When you call the same number con-
tinuously, only the newest number is
registered.
2. Select the desired number from the list.

182
27p198
Touch “” or push the button of the
steering wheel.
(iv) By received calls
You can call by received calls. When
a call is received, the system memo-
rizes up to 5 numbers. If it is over 5,
the oldest number is deleted.
This cannot be operated while you are
driving.
27p196
1. Touch the “Call Log” switch to dis- play.
27p199
2. Touch the “Incoming Calls” switch todisplay “Incoming Calls” screen.

183
27p200
When a telephone number registered in
the phone book is received, the name
and the number are displayed.
Received calls which you did not an-
swer are also memorized in the system
and “Abs. ” is displayed on the left
side of the number.
Unnoticed telephone number such as a
public telephone is not memorized in
the system.
3. Select the desired number from the list.
27p198
Touch “” or push the button of the
steering wheel.
An international phone call may not be
made depending on the cellular phone
which you have.
(v) By speed dial
You can call by registered telephone
number which you selected from a
phone book, dialed numbers and re-
ceived calls. (See page 191 for regis-
tering the speed dial.)
27p201
1. Touch the “Speed Dial” switch to display “Speed Dial” screen.
