2006 SAAB 9-5 technical data

89 Saab 9-5 Audio System
Radio _______________ 93
CD player ____________ 99
CD changer




________ 100
MP3 player ___________ 102
Portable player




_____ 104
General functions _____ 105
Sound system ________ 107
Technical data ________ 108
Antennas ____________ 109
Error codes __________ 112
Security lock _________ 112
IB3867

Asterisk means: equipment not fitted in all cars
(can depend on model variant, engine variant,
market specification, options or accessories).
Saab 9-5 Audio System
95usM06.book Page 89 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

108 Saab 9-5 Audio SystemTechnical data
Specifications in accordance with EIA Interim Standard.
THD = Total Harmonic Distortion
Tone controls
Bass _____________ ±8 dB at 100 Hz
Treble ____________ ±8 dB at 16 kHz
Power output
Prestige ________ 200 W
150 W at 1% THD
and 13.5 V
Radio module
Radio system ______ PLL frequency syn-
thesizer tuner.
Number of presets
FM/AM/XM


__ 6 x 6
Frequency range
FM ____________ 87.7 - 107,9 MHz
AM ____________ 530 - 1710 kHzTuning steps
Automatic tuning __ FM 200 kHz
AM 10 kHz
Manual tuning ____ FM 200 kHz
AM 10 kHz
Frequency range (FM) 40 – 11000 Hz
±1 dB
Distortion (FM) _____ < 0.5%
CD player and
CD changer
1-bit system and 8 x
oversampling
Frequency range ___ 20 – 20000 Hz
±1 dB
Distortion _________ <0.005%
Dynamics _________ >85 dB
CD changer capacity: 6 discs
95usM06.book Page 108 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

220 Car care and technical informationMaxi fusesThe Maxi fuses are housed in the fuse box
under the hood. These fuses can be
checked in the same way as the other fuses.
The Maxi fuses are designed to protect the
car’s electrical system from being dam-
aged. Each Maxi fuse protects a number of
electrical circuits and functions and there-
fore has a higher rating (amperage) than the
standard fuses. No spare Maxi fuses are
supplied with the car.
DICE / TWICEDICE = Dashboard Integrated Central Elec-
tronics
TWICE = Theft-Warning Central Electronics
DICE and TWICE are electronic control
modules that monitor and control a variety
of functions:
DICE controls (among other things):
 Front lights and interior lighting
 Instrument illumination
 Intermittent wiper operation
 Electric heating of rear window and door
mirrors
 Cooling fans
TWICE controls (among other things):
 Central locking.
 Car alarm (Anti-theft system)
 Engine immobilizer
 Autochecking of lights.
 Electric heating of rear seat
 Safety belt reminder
 Electrically adjustable passenger seatThe DICE and TWICE control modules are
linked to a data bus, which is basically an
information carrier that allows information to
be exchanged between all the control mod-
ules and components connected to the bus.
If a fault occurs in any of these components,
diagnostic faults codes are set in the rele-
vant control module, which facilitates fault
diagnosis. We recommend that you contact
an authorized Saab dealer.
The scan tool connector for fault diagnosis
is located under the instrument panel on the
drivers side.
NOTICEIf a Maxi fuse blows, it means that there is
a major fault in the electrical system.
Have the car checked without delay by a
workshop. We recommend that you con-
tact an authorized Saab dealer.
IB1795
Maxi fuses under the hood 95usM06.book Page 220 Thursday, November 17, 2005 8:59 AM
ProCarManuals.com

273 Index
Index
