2006 Peugeot 407 C Dag Owner's Manual

Accesses64 -
THE ALARM
This provides two types of surveillance:
- exterior protection: it sounds if
a door, the boot or the bonnet is
opened.
- interior protection: it sounds if the
volume inside the passenger com-
partment changes (breaking of a
window or a movement inside the
vehicle). When the alarm is triggered, the siren
sounds and the direction indicator lights
flash for approximately thirty seconds.
After triggering, the alarm remains
set, ten times in succession.
On the eleventh time it will become
inactive again, until the next cycle of
disarming then setting of the alarm.
Warning:
if button A indicator light
flashes rapidly, the alarm has been
triggered while you were away from
your vehicle.
Incorrect operation
When the ignition is switched on, if
button A lights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have
the system checked.
Remote control failure, alarm
set
 Unlock the doors with the key and
open the door. The alarm is trig-
gered.
 Switch on the ignition. The alarm
is disarmed.
* According to country.
Setting the alarm
 Switch off the ignition and get out
of the vehicle.
 Set the alarm, by locking or dead-
locking using the remote control
(button A indicator light flashes
once per second).
If you wish to lock or deadlock your
vehicle without setting the alarm, lock
it (one turn of the key) or deadlock
it (a second turn within five seconds
maximum) using the lock.
Automatic activation*
The alarm is activated automatically
two minutes after the last closure of a
door or the boot.
In order to avoid accidental triggering
of the alarm when a door or the boot
is opened, it is essential to press the
unlocking button on the remote control
again.
Before setting the alarm, en-
sure that all of the accesses
(doors, bonnet, boot) are
closed correctly.
Disarming
Unlock the vehicle with the remote
control key.
The alarm is disarmed, indicator
light A goes out when the ignition is
switched on.
To set the alarm with exterior
protection only
If, while you are away from the vehicle,
you wish to leave a window partially
open or a pet inside the vehicle, you
should choose exterior protection only.
 Switch off the ignition,
 In the next ten seconds, press
button A until the indicator light is
on continuously,
 Get out of the vehicle,
 Set the alarm by locking or dead-
locking using the remote control
(button A indicator light flashes
once a second).

65Accesses-
ELECTRIC WINDOWS
1 - Driver’s electric window switch.
2 - Passenger’s electric
window switch. Automatic operation:
To open or close the window, press
or pull the switch fully: the window
opens or closes completely when
the switch is released. Pressing the
switch again stops the movement of
the window.
The electric window switches remain
operational for approximately one
minute after the key has been removed
from the ignition.
Once this time has elapsed, the electric
windows will not operate. To reactivate
them, switch the ignition on again.
Safety auto-reverse
When the window rises and meets
an obstacle, it stops and immediately
partially lowers again.
In the event of unwanted opening of
the window on closing, press the switch
until the window opens completely, then
pull the switch immediately until the
window closes. Continue to hold the
switch for approximately one second
after the window has closed.
The safety auto-reverse function is
not active during this operation.
REINITIALISATION OF THE
WINDOWS
Following reconnection of the battery,
the safety auto-reverse function must
be reinitialised: the safety auto-reverse
function is not active during these
operations.
- lower the window completely, then
raise it, it will rise in steps of a few
centimetres each time the switch is
pressed. Repeat the operation until
the window closes completely,
- continue to press the switch for at least one second after reaching
this position, window closed.
Always remove the key from
the ignition when leaving
the vehicle, even for a short
time.
In the event of contact during operation
of the windows, you must reverse the
movement of the window. To do this,
press the switch concerned.
When the driver operates the pas-
senger electric window switch, he
must ensure that no one is prevent-
ing correct closing of the window.
The driver must ensure that the pas-
sengers use the electric windows
correctly.
Be aware of children when operating
the windows.
Manual operation:
To open or close the window, press
or pull the switch gently. The win-
dow stops as soon as the switch is
released.

Accesses66 -
DOORS
Opening the doors from
outside
Opening the doors from
inside
Locking/unlocking from the
inside
 Press the button.
This allows the doors and the boot to
be locked or unlocked.
To make it easier to open the door,
the window lowers automatically by
a few centimetres.
It rises and adjusts automatically on
closing to guarantee perfect sealing.
Before carrying out any work
which requires disconnection
of the battery, lower the win-
dows to permit opening and
closing of the doors.
In the event of a battery cut-off or if
the automatic lowering fails (window
iced up for example), it is still pos-
sible to open the doors. However, it
is imperative that the doors are not
slammed when closed.
The safety auto-reverse is inopera-
tive during the automatic raising of
the windows.
Contact your PEUGEOT dealer as
soon as possible.
When using a high pressure washer
on your vehicle, it is recommended
that the end of the gun is kept at least
50 cm away from the windows and
door seals. If the vehicle has been locked
or deadlocked using the key
or the remote control, the
button is inoperative.
In this case, use the key or the remote
control to unlock.
Unlocking from the doors
You can unlock from the inside by
operating a door opening control.
If the "Access to the vehicle" function is
activated via the multifunction display
menu, opening:
- the driver’s door, unlocks the door
concerned.
- the passenger door, unlocks the
doors and the boot.

67Accesses-
MANUAL LOCKING
(EMERGENCY MODE)
Driver’s door
Insert the key in the lock to lock or
unlock the door.
Passenger door
To lock, insert the key in the control
located on the edge of the door then
push to the left.
Automatic central locking of the
doors
The doors and boot can lock auto-
matically while driving (speed above
6 mph [10 km/h]).
You can activate or deactivate this
function by pressing and holding the
button.
BOOT
To open the boot, press the push button
and raise the tailgate.
Tailgate release
This enables the tailgate to be unlocked
in the event of a central locking fault.
- Fold back the rear seats to gain
access to the lock from inside the
boot,
- Insert a small screwdriver into hole A
of the lock to unlock the tailgate.
Note:
driving with the doors
locked may make access to
the passenger compartment
by the emergency services
more difficult in an emergency.
If the permanent locking of
the boot is activated, opening
is only possible by pressing
the remote control button.

67Accesses-
MANUAL LOCKING
(EMERGENCY MODE)
Driver’s door
Insert the key in the lock to lock or
unlock the door.
Passenger door
To lock, insert the key in the control
located on the edge of the door then
push to the left.
Automatic central locking of the
doors
The doors and boot can lock auto-
matically while driving (speed above
6 mph [10 km/h]).
You can activate or deactivate this
function by pressing and holding the
button.
BOOT
To open the boot, press the push button
and raise the tailgate.
Tailgate release
This enables the tailgate to be unlocked
in the event of a central locking fault.
- Fold back the rear seats to gain
access to the lock from inside the
boot,
- Insert a small screwdriver into hole A
of the lock to unlock the tailgate.
Note:
driving with the doors
locked may make access to
the passenger compartment
by the emergency services
more difficult in an emergency.
If the permanent locking of
the boot is activated, opening
is only possible by pressing
the remote control button.

Accesses68 -
SUNROOF*
To tilt the roof: press and hold part
A of the switch.
To open the roof in sliding mode:
tilt the sunroof, then press part A of
the switch briefly.
To close it in sliding mode: press
part B of the switch briefly .
To close it in tilt mode: press and
hold part B of the switch.
Safety auto-reverse
When the sunroof is sliding closed
and meets an obstacle, it stops then
partially opens again. Pressing the locking button
on the remote control key for
more than 2 seconds closes
the sunroof in sliding mode.
The sunroof remains tilted.
To close the sunroof completely,
press and hold part B of the switch
before getting out of the vehicle.
Always remove the key from
the ignition when leaving
the vehicle, even for a short
time.
Always ensure that the sunroof is
closed correctly before leaving the
vehicle.
In the event of contact during closing in
tilt mode, you must reverse the move-
ment of the roof. To do this, press the
switch concerned.
When the driver closes the roof in tilt
mode, he must ensure that no one
is preventing correct closing of the
roof.
The driver must ensure that the pas-
sengers use the sunroof correctly.
Be aware of children when operating
the roof.
Notes:

In the event of unwanted opening of
the roof on closing (for example, in
the presence of ice), press and hold
part B of the switch, within the two
seconds which follow the triggering
of the safety auto-reverse, until the
sunroof closes completely.
Following reconnection of the bat-
tery or in the event of a malfunction,
press and hold part B of the switch,
the sunroof slides "step by step" un-
til it closes. Continue to press the
switch for approximately one sec-
ond after closing.
The safety auto-reverse function
is not active during these opera-
tions. Shutter
The sunroof shutter is manual.
To open it, slide it rearwards using
the handle.
To close it, slide it forwards using the
handle.
Do not open the sunroof immediately
after a shower or immediately after
washing the car
.
* During the year.

69Accesses-
FILLING WITH FUEL
The fuel filler flap is electric, you can
only open it by pressing button A.
Button A is deactivated auto-
matically from 6 mph (10 km/h).
When filling with fuel, the
engine must be switched
off with the ignition off: Operating fault
A fuel gauge fault is indicated by the
fuel level indicator needle returning
to zero.
Contact a PEUGEOT dealer.
Fuel warning
 Turn the cap to the left.
 Remove the cap and hang the end
on the hook located on the inside
of the flap.
A label affixed to the inside of the fuel
filler flap indicates which type of fuel
to use.
When you fill your tank, do not con-
tinue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
The capacity of the tank is approx-
imately 67 litres.
 After filling the tank, screw on the
cap and close the fuel filler flap.
Ensure that the fuel filler flap is closed
correctly. When this warning light
comes on in certain driving
conditions and depending
on the engine, the distance
which can be travelled with
the fuel remaining may be
less than 30 miles (50 kilometres).
Note: should you run out of fuel, you
must add at least 6 litres.

Visibility70 -
LIGHTS STALK
Front and rear lights (ring A)

Turn ring A to the position required
Lights off
Side lights
Dipped/main beam head-
lamps
Lights on
With the ignition and the automatic
lights function switched off, on open-
ing the driver’s door a buzzer sounds
to warn you that you have left your
lights on.
Front and rear fog lamps (ring B)
 Turn ring B forwards to switch on
and backwards to switch off. The
position is confirmed by the light
on the instrument panel.
Front fog lamps (one
press)
These operate with the side lights,
dipped headlamps or main beam
headlamps.
Rear fog lamps (two presses)
These operate with the side lights
and the front fog lamps, or with the
dipped or main beam headlamps.
Left: downwards.
Right: upwards
Direction indicators (flashers) If you forget to return the di-
rection indicator to its normal
position, the volume of the
audible signal will increase,
if you are driving at a speed greater
than 45 mph (70 km/h).
Parking lights*
The side lights are lit on the side the
traffic is on for a few hours.
With the engine switched off and
within 45 seconds maximum, place
the indicator lights stalk on the traffic
side (for example: for parking on the
right; switching on of the lights on the
left). This is indicated by an audible
signal and lighting of the correspond-
ing direction indicator on the instru-
ment panel for a few seconds.
If the parking lights are ac-
tivated when your vehicle
switches to economy mode,
they will remain on. However,
you cannot activate the parking lights
if your vehicle is already in economy
mode.
Dipped/main beam change
 Pull the stalk fully towards you.
* According to version.
