2006 Peugeot 206 CC Dag Owner's Manual

33
-Audio equipment and telematics
01-01-2006
RADIO
Notes on radio reception
Your car radio is subject to
phenomena which do not affect
domestic radio sets. Both AM (MW/
LW) and FM reception are subject to
various forms of interference. This
is no reflection on the quality of the
equipment, but is due to the nature of
the signals and the way in which they
are transmitted.
On MW/LW, interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the
result of increasing distance from
the transmitter, deflection of the
signals by obstacles (mountains,
hills, buildings, etc.), or of being in
an area which is not covered by a
transmitter. Selecting radio mode
Automatic station search
Automatic volume correction
This function enables the volume to
be automatically adjusted depending
on the level of noise produced by the
speed of the vehicle.
Press buttons
H or I to switch the
function on or off. Press button
O.
Press button O briefly
to select wavebands
FM1, FM2, FMast and
AM.
Briefly press button J or L to search
for the station immediately above or
below. By continuing to press the
button in the direction selected, you
will obtain continuous scrolling of the
frequency.
The scrolling stops at the first station
found as soon as the button is
released.
If the TA traffic programme is
selected, only stations broadcasting
this type of programme are selected.
Selecting a waveband
Manual station search
Press the "MAN" button.
Briefly press button J or L to
increase or decrease the frequency
displayed.
By continuing to press the button
in the direction selected, you will
obtain continuous scrolling of the
frequency.
The scrolling stops at the first station
found as soon as the button is
released.
Pressing the "MAN" button again
returns you to automatic station
search.
Manual storing of stations in the
memory
Select the station required.
Press one of the buttons "1" to "6"
for more than two seconds.
The sound stops then becomes
audible again, confirming that the
station has been stored in the
memory.
Searching for a station occurs first
in
"LO" sensitivity (selection of
the most powerful transmitters)
during scanning of the waveband,
then in "DX" sensitivity (selection
of the weakest and most distant
transmitters).
To make a direct search in "DX"
sensitivity, press button J or L twice.

33
-Audio equipment and telematics
01-01-2006
RADIO
Notes on radio reception
Your car radio is subject to
phenomena which do not affect
domestic radio sets. Both AM (MW/
LW) and FM reception are subject to
various forms of interference. This
is no reflection on the quality of the
equipment, but is due to the nature of
the signals and the way in which they
are transmitted.
On MW/LW, interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the
result of increasing distance from
the transmitter, deflection of the
signals by obstacles (mountains,
hills, buildings, etc.), or of being in
an area which is not covered by a
transmitter. Selecting radio mode
Automatic station search
Automatic volume correction
This function enables the volume to
be automatically adjusted depending
on the level of noise produced by the
speed of the vehicle.
Press buttons
H or I to switch the
function on or off. Press button
O.
Press button O briefly
to select wavebands
FM1, FM2, FMast and
AM.
Briefly press button J or L to search
for the station immediately above or
below. By continuing to press the
button in the direction selected, you
will obtain continuous scrolling of the
frequency.
The scrolling stops at the first station
found as soon as the button is
released.
If the TA traffic programme is
selected, only stations broadcasting
this type of programme are selected.
Selecting a waveband
Manual station search
Press the "MAN" button.
Briefly press button J or L to
increase or decrease the frequency
displayed.
By continuing to press the button
in the direction selected, you will
obtain continuous scrolling of the
frequency.
The scrolling stops at the first station
found as soon as the button is
released.
Pressing the "MAN" button again
returns you to automatic station
search.
Manual storing of stations in the
memory
Select the station required.
Press one of the buttons "1" to "6"
for more than two seconds.
The sound stops then becomes
audible again, confirming that the
station has been stored in the
memory.
Searching for a station occurs first
in
"LO" sensitivity (selection of
the most powerful transmitters)
during scanning of the waveband,
then in "DX" sensitivity (selection
of the weakest and most distant
transmitters).
To make a direct search in "DX"
sensitivity, press button J or L twice.

34 -Audio equipment and telematics
01-01-2006
Automatic storing of FM stations
in the memory (autostore)Press button O down
for more than two
seconds.
Your radio automatically stores the
six stations with the strongest signal
in FM . These stations are stored in
the FMast waveband.
If it is not possible to find 6 stations,
the remaining memories are empty.RDS
Using the RDS (Radio Data
System) function on FM
Radio Data System allows you to
continue listening to the same station
whatever frequency it is using for the
region you are going through. Traffic information programme
RDS station following
The display indicates the name of
the station selected. When the RDS
function is active, the radio continually
searches for the transmitter which
transmits the station selected with
the best reception. Press the
"TA" button
to switch the function
on or off.
The multifunction display will show:
- "TA" if the function is selected,
- "(TA)" if the function is selected but
not available.
Any traffic information flash will be
given priority, whatever source you
are listening to (radio, CD or CD
changer).
If you wish to interrupt a message,
press the "TA" button; this switches
the function off.
Briefly press the
"RDS"
button to
switch the function on
or off.
The multifunction display will show:
- "RDS" if the function is selected,
- "(RDS)" if the function is selected
but not available.
Recalling stations stored in the
memory
For each waveband, briefly press
one of the buttons
"1" to "6" to recall
the corresponding station. Note : the volume of traffic
information announcements is
independent of the volume of
normal radio listening. You can
adjust it using the volume button.
The setting will be stored and will
be used when the next messages
are broadcast.

35
-Audio equipment and telematics
01-01-2006
Regional following mode (REG)
When they are part of a network,
certain stations broadcast regional
programmes in the various areas
they serve. With regional following
mode you can keep listening to the
same programme.
Press the
"RDS" button for more
than two seconds to switch the
function on or off.
PTY function
This allows you to listen to stations
broadcasting a specific type of
programme (news, culture, sport,
rock etc.).
With FM selected,
press the "TA" button
for more than two
seconds to switch this
function on or off. To search for a
PTY programme:
- select the PTY function,
- briefly press button J or L to scroll
down the list of the various types of
programmes offered,
- when the programme of your choice is displayed, keep button
J or L pressed for more than two
seconds to carry out an automatic
search (after an automatic search
the PTY function is switched off).
In PTY mode the different types
of programmes can be stored
in memory. To do this, press the
preselection buttons "1" to "6" for
more than two seconds. Briefly press
the corresponding button to recall
the type of programme stored in the
memory. EON system
This connects stations which are part
of the same network. It enables the
broadcasting of traffic information or
a
PTY programme by a station that
is part of the same network as the
station to which you are listening.
This service is available when
you have selected the TA traffic
information programme or the PTY
function.

36 -Audio equipment and telematics
01-01-2006
Shuffle (RDM)
When the CD player is selected,
keep button N pressed for two
seconds. The tracks will be played
in random sequence. Pressing the
button again for two seconds returns
you to normal play.
Shuffle mode is de-activated each
time the audio equipment is switched
off.
The use of copied com-
pact discs may cause
malfunctions.
Insert circular compact
discs only.
In the cabriolet position, remember
to remove the compact discs from
your player (risk of theft).COMPACT DISC
Selecting CD mode
After insertion of a
disc, printed face
upwards, the player
starts automatically.
If a disc is already inserted, press
button N.
Ejection of a disc Press button D to
eject the disc from the
player. Press button
J to select the next
track.
Press button L to return to the start
of the current track or to select the
previous track.
Selecting a track
Accelerated play
Keep button
J or L pressed for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.

37
-Audio equipment and telematics
01-01-2006
Selecting a disc Accelerated play
Keep button
J
or L pressed for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Press button M.
CD CHANGER
Selecting CD changer mode
Selecting a track
Press button J to select the next
track.
Press button L to return to the start
of the current track or to select the
previous track.
Press one of the buttons
"1" to "5" on
the radio to select the corresponding
disc.
The use of copied
compact discs may cause
faults.
Insert circular compact
discs only.
5 CD CHANGER*
* According to country.
This is located in the glove box. It
holds up to 5 discs.
To load the changer, insert the discs
with the printed side upwards.
To remove a disc, press and hold one
of the buttons
"1" to "5" .
Shuffle (RDM)
When the CD changer is selected,
keep button
M pressed down for two
seconds. The tracks will be played
in random sequence. Pressing the
button again for two seconds returns
you to normal play.

38 -Audio equipment and telematics
01-01-2006
Presentation
Your 206 CC is fitted with a JBL audio
system, designed specifically for the
vehicle's passenger compartment.
At the heart of the system, a 240
Watt multifunction amplifier (1),
incorporated in the subwoofer in
the boot, independently controls 8
high acoustic definition speakers
and the subwoofer.This system makes it possible to
obtain optimum reproduction and
distribution of the sound in the
vehicle, in the two configurations
of the passenger compartment:
Coupé and Cabriolet.The speakers are located:
- in the front door pillars: two
Tweeters (2) for reproduction of
the treble (high frequencies).
- in the front doors: two Woofers (3)
for reproduction of the bass (low
frequencies).
- in the rear panels: two Tweeters (4)
fitted in two Woofers (5) for a bal-
ance of frequencies and sound
which fills the passenger compart-
ment.
- in the boot: one Subwoofer (6)
incorporating two special woofers for reproduction of the bass and ex-
treme bass (very low frequencies)
throughout the passenger compart-
ment.
You will appreciate the dynamics
and depth of the JBL system,
noticing that the sound fills the
vehicle perfectly.
AUDIO SYSTEM
Adjustment in CD and Radio
mode
The basic functions remain those of
the audio equipment.
No additional adjustment is required.
However, to benefit fully from your
JBL audio system, you are advised to
adjust the AUDIO functions (BASS,
TREB, FAD, BAL) to position " 0 "
(zero) and the Loudness (LOUD) to
the " ON " position for the CD mode
or to the " OFF" position for the radio
mode.

39
-
Audio equipment and telematics
01-01-2006
The remote control
Pointing this at the screen enables
the information contained in the
various menus to be selected.THE SATELLITE NAVIGATION
SYSTEM
Introduction
The satellite navigation system
guides you to the destination of your
choice by means of vocal and visual
instructions.
The heart of the system lies in the
use of a map database and a GPS
system. The latter enables your
position to be located by means of
several satellites.
The satellite navigation system
consists of the following
components:
- the remote control,
- the display,
- the control unit,
- the last voice message recall
control,
- the CD ROM,
- the multifunction aerial.
Some functions or services
described may vary depending on
the CD-ROM version or the country
where the vehicle is sold.
menu : this button allows access
to the main menu. It can be
used at any time.
esc : escape button
"Short press": cancels the current operation and
returns to the previous
screen.
"Press for more than 2 seconds": returns to the
welcome screen.
This button can be used in any menu. It is inactive
during guidance.
mod : mode button
"Short press": changes between date, navigation,
radio and permanent
locating.
val : Validation button
Confirms the function selected.
A special compartment in the glove
box permits storage of the remote
control.
Reference of the 2 batteries:
1.5 volts type LR03.
Direction arrows:
These enable you to move around the
screen and thus select a function.
On the welcome screen only, the
up and down arrows enable the
brightness of the screen to be
adjusted.
The right and left arrows enable
the complete name of the road to
be displayed temporarily, during
guidance, if the name exceeds the
capacity of the screen.
