2006 NISSAN MURANO check engine

the proper equipment and to have it
installed.
Trailer lights should comply with federal and/or
local regulations. For assistance in hooking up
trailer lights, contact a NISSAN dealer or repu-
table trailer dealer.Trailer brakesIf your trailer is equipped with a braking system,
make sure it conforms to federal and/or local
regulations and that it is properly installed.
WARNING
Never connect a trailer brake system
directly to the vehicle brake system.Pre-towing tips
Be certain your vehicle maintains a level
position when a loaded and/or unloaded
trailer is hitched. Do not drive the vehicle if it
has an abnormal nose-up or nose-down con-
dition; check for improper tongue load, over-
load, worn suspension or other possible
causes of either condition.
Always secure items in the trailer to prevent
load shifts while driving.

Load the trailer so approximately 60% of the
trailer load is in the front half and 40% is in
the back half.

Check your hitch, trailer tire pressure, vehicle
tire pressure, trailer light operation, and trailer
wheel lug nuts every time you attach a trailer
to the vehicle.

Be certain your rear view mirrors conform to
all federal, state or local regulations. If not,
install any mirrors required for towing before
driving the vehicle.
Trailer towing tipsIn order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability, and braking per-
formance will be somewhat different than under
normal driving conditions.

Always secure items in the trailer to prevent
load shift while driving.

Avoid abrupt starts, acceleration or stops.

Avoid sharp turns or lane changes.

Always drive your vehicle at a moderate
speed. Some states or provinces have spe-cific speed limits for vehicles that are towing
trailers. Obey the local speed limits.

When backing up, hold the bottom of the
steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small corrections and back
up slowly. If possible, have someone guide
you when you are backing up.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so,
first block the wheels and apply the parking
brake, and then move the selector lever into
the P (Park) position. If you move the selector
lever to the P (Park) position before blocking
the wheels and applying the parking brake,
transmission damage could occur.

When going down a hill, shift into a lower
gear and use the engine braking effect.
When going up a long grade, downshift the
transmission to a lower gear and reduce
speed to reduce chances of engine overload-
ing and/or overheating.

If the engine coolant rises to an extremely
high temperature when the air conditioning
system is on, turn off the air conditioner.
Coolant heat can be additionally vented by
opening the windows, switching the fan con-
trol to high and setting the temperature con-
9-22
Technical and consumer information


05.8.26/Z50-D/V5.0


WARNING
A vehicle equipped with AWD (All-
Wheel Drive) should never be tested
using a two wheel dynamometer, similar
to the dynamometers used by some
states for emissions testing, or similar
equipment. Make sure you inform the
test facility personnel that your vehicle
is an AWD equipped vehicle before it is
placed on a dynamometer. Failure to do
so may result in transmission damage
or unexpected vehicle movement which
could result in serious vehicle damage
or personal injury.
Due to legal requirements in some states/
areas, your vehicle may be required to be in what
is called the “ready condition” for an
Inspection/Maintenance (I/M) test of the emis-
sion control system.
The vehicle is set to the “ready condition” when
it is driven through certain driving patterns.
Usually, the “ready condition” can be obtained
by ordinary usage of the vehicle.
If a powertrain system component is repaired orthe battery is disconnected, the vehicle may be
reset to a not “ready condition”. Before taking
the I/M test, check the vehicle’s inspection/
maintenance test readiness condition. Turn the
ignition switch ON without starting the engine. If
the Malfunction Indicator Lamp (MIL) comes on
steady for 20 seconds and then blinks for 10
seconds, the I/M test condition is “not ready”. If
the MIL does not blink after 20 seconds, the I/M
test condition is “ready”. If the MIL indicates the
vehicle is in a “not ready” condition, drive the
vehicle through the following pattern to set the
vehicle to the ready condition. If you cannot or
do not want to perform the driving pattern, a
NISSAN dealer can conduct it for you.
WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic
conditions and obey all traffic laws.
1. Start the engine. Allow the engine to idle until
the engine coolant temperature gauge needle
points between the C and H (normal operat-
ing temperature).
2. Accelerate the vehicle to 55 MPH (88 km/h),
then quickly release the accelerator pedalcompletely and keep it released for at least
10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 to 60 MPH (86 to 96 km/h) for at least 9
minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 minutes.
8. Stop the vehicle. Place the transmission se-
lector lever in the “P” or “N” position.
9. Turn the engine off.
10. Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the engine
until step 7 is completed.
READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)9-26
Technical and consumer information


05.8.26/Z50-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-31
Adjusting pedal position .......................................... 3-29
Aiming control, Headlights...................................... 2-25
Air bag system, Front passenger air bag
and status light .......................................................... 1-47
Air bag warning labels ............................................. 1-53
Air bag warning light .................................... 1-54, 2-13
Air cleaner housing filter.......................................... 8-17
Air conditioner
Air conditioner operation .................................. 4-23
Air conditioner service ........................... 4-23, 4-26
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant
and lubricant recommendations ............ 4-26, 9-6
Heater and air conditioner (automatic) ......... 4-23
In-cabin microfilter .............................................. 4-26
Alcohol, drugs and driving......................................... 5-6
All-wheel drive (AWD) ............................................. 5-24
All-wheel drive (AWD) LOCK indicator light ..... 2-14
All-wheel drive (AWD) warning light ...................... 2-9
All-wheel drive (AWD), AWD lock switch
operations.................................................................... 5-25
Anchor point locations
Top tether strap .................................................. 1-30
Antenna ........................................................................ 4-44
Anti-lock Brake System (ABS) .............................. 5-31
Anti-lock Brake System (ABS) waring light ....... 2-10Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Armrest ........................................................................... 1-9
Audible reminders ..................................................... 2-16
Audio operation precautions .................................. 4-28
Audio system .............................................................. 4-27
Autolight system ........................................................ 2-23
Automatic
Anti-glare inside mirror ...................................... 3-31
Automatic sunroof .............................................. 2-38
Drive positioner ................................................... 3-33
Seat positioner .................................................... 3-33
Avoiding collision and rollover .................................. 5-5
B
Back door (See lift gate)......................................... 3-24
Battery .......................................................................... 8-14
Battery saver system ......................................... 2-25
Battery replacement
Intelligent Key system .......................................... 3-8
Remote keyless entry system............................. 3-8
Before starting the engine ...................................... 5-12
Belts (See drive belts) ............................................. 8-16
Booster seats ............................................................. 1-34
Brake
Anti-lock brake system (ABS) ......................... 5-31
Brake booster ...................................................... 8-21Brake fluid............................................................. 8-13
Brake pedal check ............................................. 8-20
Brake system ....................................................... 5-30
Parking brake check .......................................... 8-20
Parking brake operation .................................... 5-21
Warning light ....................................................... 2-10
Break-in schedule ..................................................... 5-23
Brightness control, Instrument panel ................... 2-26
Bulbcheck/instrument panel .................................... 2-9
Bulbreplacement ...................................................... 8-27
C
Cabin air filter ............................................................. 4-26
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-44
Cargo (See vehicle loading information)............. 2-35
Cargo net .................................................................... 2-35
Cassette player (See audio system) .................... 4-40
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-42
Ceiling light ................................................................. 2-40
Cellular phone holder ............................................... 2-31
Charge warning light ................................................ 2-11
Child restraints ........................................................... 1-21
Booster seats ...................................................... 1-34
Installation on rear seat outboard or center
positions ................................................................ 1-23
LATCH system .................................................... 1-28


05.8.26/Z50-D/V5.0


Precautions on child restraints........................ 1-21
Top tether strap .................................................. 1-29
Top tether strap anchor point locations ....... 1-30
Child safety ................................................................. 1-12
Child safety rear door lock ........................................ 3-5
Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ......................................................... 4-4, 4-9, 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-41
Compact Disc (CD) player (See audio
system) ......................................................................... 4-35
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously Variable Transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-36
Cruise control............................................................. 5-21
Cruise main switch indicator light......................... 2-14
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside
mirror defroster switch ............................................. 2-22
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-24
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-25
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-23
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-36
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil pressure warning light ................... 2-11
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-12
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-27
Exhaust gas (Carbon monoxide).............................. 5-2


05.8.26/Z50-D/V5.0

10-2

New vehicle break-in ................................................ 5-23
NISSAN advanced air bag system ....................... 1-45
NISSAN Vehicle Immobilizer System ................... 2-18
NISSAN Vehicle Immobilizer System
Engine start .............................................. 5-10, 5-12
O
Odometer ....................................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine oil ........................................... 8-10
Checking engine oil level .................................... 8-9
Engine oil................................................................. 8-9
Engine oil viscosity ............................................... 9-5
Outside mirrors .......................................................... 3-32
Overheat, If your vehicle overheats ...................... 6-11
Owner’s Manual/Service Manual order
information................................................................... 9-27
P
Parking
Brake break-in ..................................................... 5-30
Brake check ......................................................... 8-20
Parking brake operation .................................... 5-21
Parking on hills .................................................... 5-29
Pedal position adjustment....................................... 3-29
Phone, Car phone or CB radio ............................. 4-44
Power
Front seat adjustment .......................................... 1-4
Power door lock .................................................... 3-3Power outlet ......................................................... 2-30
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Power windows................................................... 2-36
P position selecting warning light ......................... 2-13
Pre-tensioner seat belt system .............................. 1-52
Precautions
Audio operation ................................................... 4-28
Braking precautions ........................................... 5-30
Child restraints .................................................... 1-21
Cruise control ...................................................... 5-21
Driving safety .......................................................... 5-6
Maintenance ........................................................... 8-5
On-pavement and offroad driving ..................... 5-6
Seat belt usage ................................................... 1-10
Supplemental restraint system ........................ 1-39
When starting and driving .................................. 5-2
Push starting .............................................................. 6-10
R
Radio, Car phone or CB radio .............................. 4-44
Readiness for inspection/maintenance (I/M)
test (US only) ............................................................. 9-26
Rear center seat belt................................................ 1-17
Rear door lock, Child safety rear door lock.......... 3-5
Rear personal light .................................................... 2-41
Rear power point....................................................... 2-30
Rear seat adjustment .................................................. 1-5
Rear view monitor ..................................................... 4-19
Rear window and outside mirror defroster
switch ........................................................................... 2-22
Rear window wiper and washer switch .............. 2-21
Recorders, Event data ............................................. 9-27Registering your vehicle in another country ....... 9-10
Remote keyless entry
System, Except Intelligent Key system ............ 3-5
System, For Intelligent Key system ................ 3-20
Reporting safety defects (US only) ...................... 9-25
S
Safety
Child seat belts ................................................... 1-12
Reporting safety defects (US only)................ 9-25
Towing safety....................................................... 9-20
Safety chain ................................................................ 9-21
Seat adjustment
Front manual seat adjustment............................ 1-3
Front power seat adjustment ............................. 1-4
Rear seat adjustment ........................................... 1-5
Seat belt(s)
Child safety .......................................................... 1-12
Infants .................................................................... 1-13
Injured persons.................................................... 1-13
Larger children .................................................... 1-13
Pre-tensioner seat belt system ....................... 1-52
Precautions on seat belt usage ...................... 1-10
Pregnant women ................................................. 1-13
Rear center seat belt ......................................... 1-17
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-20
Seat belt hook ..................................................... 1-17
Seat belt maintenance ...................................... 1-20
Seat belt warning light and chime ................. 2-13
Seat belts ............................................................. 1-10
Shoulder belt height adjustment..................... 1-16
Small children ...................................................... 1-13


05.8.26/Z50-D/V5.0

10-5
