Operating range of the door lock/
unlock functionThe operating range of the door lock/unlock
function by pushing the door handle requestswitch or the lift gate request switch is shown in
the illustration.
131.5 in (0.8 m) from the door handle request
switch
231.5 in (0.8 m) from the lift gate request
switch

If you are too close to the door or door glass,
the Intelligent Key may not operate.

If the Intelligent Key is in the operating range,
it is possible for anyone who does not carry
the Intelligent Key to lock/unlock the doors by
pushing the door handle request switch or
the lift gate request switch.
Operating range for engine start
functionThe operating range for starting the engine is
inside the vehicle.

If the Intelligent Key is on the instrument
panel, inside the glove box or door pocket, or
the corner of interior compartment, it may not
be possible to start the engine.

If the Intelligent Key is near the door or door
glass outside the vehicle, it may be possible
to start the engine.
SPA1948
SPA1949
3-16
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


WARNING SIGNALSTo help prevent the vehicle from moving unex-
pectedly by erroneous operation of the Intelli-
gent Key or to help prevent the vehicle from
being stolen, a chime or buzzer sounds from
inside and outside the vehicle and a warning
light comes on in the instrument panel.
When a chime or beep sounds or the warning
light comes on, be sure to check the vehicle and
Intelligent Key.Audible reminder and warning when
locking the doorsWhen the chime or buzzer sounds from inside
and outside the vehicle, check for the following:

The ignition switch is turned to the LOCK
position.

The Intelligent Key is not left inside the
vehicle.

Doors are closed securely.

The selector lever is in the P position.
Audible reminder and warning when
the engine stopsWhen the P position selecting warning light
B
in the instrument panel blinks in red:

Make sure the selector lever is in the P
position.
When the chime sounds intermittently:

Make sure the selector lever is in the P
position and the ignition switch is turned to
the LOCK position.
If the chime sounds continuously when the
driver’s door is opened, check the following:
The selector lever is in the P position and the
ignition switch is turned to the LOCK posi-
tion.

The mechanical key or the valet key is not
inserted into the ignition switch.

The warning chime may stop when one of the
following is performed.
•Returning the ignition switch to the LOCK
position.
•Removing the mechanical key or the valet
key.
•Closing the doors.
Alarm and warning when the engine
startsWhen the key warning light
A
is blinking in red
and the outside buzzer sounds, make sure the
Intelligent Key is inside the vehicle.
Warning for low battery power
This warning is to let you know that the
battery of the Intelligent Key will run down
soon. Replace it with a new one. Refer to the
“8. Maintenance and do-it-yourself” section
for battery replacement.
•The green blinking key warning light
A
goes out about 30 seconds after the
SPA2175
Pre-driving checks and adjustments
3-17


05.8.26/Z50-D/V5.0


TROUBLE-SHOOTING GUIDE
Symptom Possible Cause Remedy
When pushing the door
handle request switch or the
lift gate request switchThe outside buzzer sounds for approxi-
mately 2 seconds.The doors cannot be locked.Take out the Intelligent Key from the vehicle
and push the door handle request switch or
the lift gate request switch.
Turn the ignition switch to the LOCK posi-
tion and push the door handle request
switch or the lift gate request switch while
carrying the Intelligent Key with you.
Close all the doors securely and push the
door handle request switch or the lift gate
request switch while carrying the Intelligent
Key with you.
When closing the doorsThe outside buzzer sounds for approxi-
mately 10 seconds.The ignition switch is not turned to the
LOCK position.Turn the ignition switch to the LOCK posi-
tion.
The key warning light in the instrument
panel blinks in red and the outside
buzzer sounds 3 times.The Intelligent Key is not in the vehicle. Be sure to carry the Intelligent Key with you.
The outside buzzer sounds for approxi-
mately 3 seconds and all doors unlock.The Intelligent Key has been left in the ve-
hicle.Take out the Intelligent Key from the vehicle
and close the door.
When locking the doorsThe outside buzzer sounds for approxi-
mately 3 seconds and all doors unlock.The Intelligent Key has been left in the trunk
room.Take out the Intelligent Key from the vehicle
and close the door.
When opening the driver’s
doorA warning chime sounds continuously.The ignition switch is not in the LOCK posi-
tion, or the mechanical key or valet key is
inserted into the ignition switch.Turn the ignition switch to the LOCK posi-
tion.
Remove the mechanical key or valet key
from the ignition switch.
When stopping the engineThe P position warning light in the in-
strument panel blinks in red.The selector lever is not in the P position.Make sure that the selector lever is in the P
position.
When turning the ignition
switchA warning chime sounds continuously.The ignition switch is not turned to the
LOCK position.Turn the ignition switch to the LOCK posi-
tion.
When starting the engineThe key warning light in the instrument
panel blinks in green.The battery charge is low.Replace the battery with a new one. See
“BATTERY REPLACEMENT” on page 8-24.
When pushing the ignition
switchThe key warning light in the instrument
panel comes on in red.The Intelligent Key is not in the vehicle.If the key warning light comes on in red
even while you are carrying the Intelligent
Key, the battery is completely discharged.
Replace the battery with a new one. See
“BATTERY REPLACEMENT” on page 8-24.
Pre-driving checks and adjustments
3-19


05.8.26/Z50-D/V5.0


OPERATION WITH THE
MECHANICAL KEY AND VALET KEYIf the Intelligent Key cannot be used because its
battery is discharged, use the metal key to lock
or unlock the doors and use the mechanical key
or the valet key, which is registered to the
NISSAN Vehicle Immobilizer System compo-
nents, to start the engine.Removing the mechanical key
Release the lock knobat the back of the
intelligent key and remove the mechanical
key.
To install the mechanical key to the intelligent
key, securely lock the lock knoband then
check that the mechanical key will not move.
CAUTION
Be sure to carry the Intelligent Key with
the mechanical key installed in it.Locking/unlocking the doors with the
key (mechanical key and valet key)The doors can be locked/unlocked by inserting
the mechanical and valet key into the key cylin-
der in the driver’s door in the same way as the
ordinary key.Starting the engine with the
mechanical key and valet key1. Securely depress the brake pedal.
2. Insert the mechanical key or the valet key into
the ignition switch.
3. Turn the ignition switch to the START posi-
tion and start the engine.
4. After starting the engine, release the switch.
For important safety information, see the “5.
Starting and driving” section.
Windows open/close with the
mechanical keySee “Opening and closing windows” on the
previous page.
SPA1951
Pre-driving checks and adjustments
3-23


05.8.26/Z50-D/V5.0


1. Pull the hood lock release handle
1
located
below the instrument panel; the hood will
then spring up slightly.
2. Move the lever
2
at the front of the hood
with your fingertips and raise the hood.
3. When closing the hood, slowly close the
hood and make sure it locks into place.
WARNING

Make sure the hood is completely
closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.

If you see steam or smoke coming
from the engine compartment, to
avoid injury do not open the hood.
The power door lock system allows you to
lock or unlock all doors including the lift gate
simultaneously.

Push the opener switch and pull up the lift
gate to open.
WARNING
Do not drive with the lift gate open. This
could allow dangerous exhaust gases to
be drawn into the vehicle. See “Precau-
tions when starting and driving”
SPA1578
SPA1947
HOODLIFT GATE3-24
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


FUEL-FILLER CAPThe fuel-filler cap is a ratcheting type. Turn the
cap counterclockwise
A
to remove.
To tighten, turn the cap clockwise until ratchet-
ing clicks are heard.
Put the fuel-filler cap on the cap holder
Bwhile
refueling.
WARNING

Gasoline is extremely flammable andhighly explosive under certain condi-
tions. You could be burned or seri-
ously injured if it is misused or mis-
handled. Always stop the engine and
do not smoke or allow open flames
or sparks near the vehicle when refu-
eling.

Fuel may be under pressure. Turn the
cap a third of a turn, and wait for any
“hissing sound” to stop to prevent
fuel from spraying out and possibly
causing personal injury. Then remove
the cap.
Do not attempt to top off the fuel
tank after the fuel pump nozzle shuts
off automatically.
Continued refueling may cause fuel
overflow, resulting in fuel spray and
possibly a fire.

Use only an original equipment type
fuel-filler cap as a replacement. It has
a built-in safety valve needed for
proper operation of the fuel system
and emission control system. An in-
correct cap can result in a serious
malfunction and possible injury. It
could also cause the
malfunc-
tion indicator lamp to come on.

Do not fill a portable fuel container in
the vehicle or trailer. Static electricity
can cause an explosion of flammable
liquid, vapor or gas in any vehicle or
trailer. To reduce the risk of serious
injury or death when filling portable
fuel containers:
— Always place the container on the
ground when filling.
— Do not use electronic devices
SPA1581A
Pre-driving checks and adjustments
3-27


05.8.26/Z50-D/V5.0


section and “Pedal position adjustment” and
“Outside mirrors” earlier in this section.
3. Turn the ignition ON.
4. Push the SET switch and, within 5 seconds,
push the memory switch (1 or 2) fully for at
least 1 second.
The indicator light for the pushed memory
switch will come on and stay on for approxi-
mately 5 seconds after pushing the switch.
After the indicator light goes off, the selected
positions are stored in the selected memory
(1 or 2).
If memory is stored in the same memory switch,
the previous memory will be deleted.
Linking a remote keyless entry to a
stored memory positionA remote keyless entry can be linked to a stored
memory position with the following procedure.
1. Follow the steps for storing a memory posi-
tion.
2. While the indicator light for the memory
switch being set is illuminated for 5 seconds,
push the unlock button on the remote keyless
entry. The indicator light will blink. After the
indicator light goes off, the remote keyless
entry is linked to that memory setting.With the key removed from the ignition switch,
push the unlock button on the keyfob. The
driver’s seat, pedals (Brake and Accelerator)
and outside mirrors will move to the memorized
position.
Confirming memory storage
Turn the ignition switch to the ON position
and push the SET switch. If the main memory
has not been stored, the indicator light will
come on for approximately 0.5 seconds.
When the memory has stored the position,
the indicator light will stay on for approxi-
mately 5 seconds.Selecting the memorized position1. Set the sift selector lever to the P (Park)
position.
2. Turn the ignition ON.
3. Push the memory switch (1 or 2) fully for at
least 1 second.
The driver’s seat, pedals (Brake and Accel-
erator) and outside mirrors will move to the
memorized position with the indicator light
flashing, and then the light will stay on for
approximately 5 seconds.SYSTEM OPERATIONThe automatic drive positioner system will notwork or will stop operating under the following
conditions:

when the vehicle speed is above 4 MPH (7
km/h).

when any two or more of the memory
switches and the SET switch is simulta-
neously pushed while the automatic drive
positioner is operating.

when the adjusting switch for the driver’s
seat, pedals and outside mirror are operated
while the automatic drive positioner is oper-
ating.

when the memory switch (1 or 2) and the
SET switch is not pushed for at least 1
second.

when the seat has been already moved to the
memorized position.

when no seat position is stored in the
memory switch.

when the engine is started while moving the
automatic drive positioner.

when the shift selector lever is moved from
the P position to any other position (However,
it will not be cancelled if the switch is pushed
while the seat is returning to the previous
positions (entry/exit function).).
3-34
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


d. You have had an accident involv-
ing damage to the exhaust system,
underbody, or rear of the vehicle.
THREE-WAY CATALYSTThe three-way catalyst is an emission control
device installed in the exhaust system. Exhaust
gases in the converter are burned at high tem-
peratures to help reduce pollutants.
WARNING

The exhaust gas and the exhaust sys-
tem are very hot. Keep people, ani-
mals or flammable materials away
from the exhaust system compo-
nents.

Do not stop or park the vehicle over
flammable materials such as dry
grass, waste paper or rags. They may
ignite and cause a fire.
CAUTION

Do not use leaded gasoline. Deposits
from leaded gasoline will seriously
reduce the three-way catalyst’s abil-
ity to help reduce exhaust pollutants.

Keep your engine tuned up. Malfunc-
tions in the ignition, fuel injection, or
electrical systems can cause overrich
fuel flow into the three-way catalyst,
causing it to overheat. Do not keep
driving if the engine misfires, or if
noticeable loss of performance or
other unusual operating conditions
are detected. Have the vehicle in-
spected promptly by a NISSAN
dealer.

Avoid driving with an extremely low
fuel level. Running out of fuel could
cause the engine to misfire, damag-
ing the three-way catalyst.

Do not race the engine while warm-
ing it up.

Do not push or tow your vehicle to
start the engine.
TIRE PRESSURE MONITORING
SYSTEM (TPMS) (if so equipped)Each tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle plac-
ard or tire inflation pressure label. (If your vehicle
has tires of a different size than the size indicated
on the vehicle placard or tire inflation pressure
label, you should determine the proper tire infla-
tion pressure for those tires.)
As an added safety feature, your vehicle has
been equipped with a tire pressure monitoring
system (TPMS) that illuminates a tire pressure
telltale when one or more of your tires is signifi-
cantly under-inflated. Accordingly, when the low
tire pressure telltale illuminates, you should stop
and check your tires as soon as possible, and
inflate them to the proper pressure. Driving on a
significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-
inflation also reduces fuel efficiency and tire
tread life, and may affect the vehicle’s handling
and stopping ability.
Please note that the TPMS is not a substitute for
proper tire maintenance, and it is the driver’s
responsibility to maintain correct tire pressure,
even if under-inflation has not reached the level
Starting and driving
5-3


05.8.26/Z50-D/V5.0
