The disc-type brakes self-adjust every time the
brake pedal is applied.
WARNING
See a NISSAN dealer and have it
checked if the brake pedal height does
not return to normal.Brake pad wear indicatorsThe disc brake pads on your vehicle have au-
dible wear indicators. When a brake pad re-
quires replacement, it will make a high pitched
scraping or screeching sound when the vehicle
is in motion whether or not the brake pedal is
depressed. Have the brakes checked as soon as
possible if the wear indicator sound is heard.
Under some driving or climate conditions, occa-
sional brake squeak, squeal or other noise may
be heard. Occasional brake noise during light to
moderate stops is normal and does not affect
the function or performance of the brake system.
Proper brake inspection intervals should
be followed.For additional information, see the
separate Service and Maintenance Guide.
BRAKE BOOSTERCheck the brake booster function as follows:
1. With the engine off, depress and release the
brake pedal several times. When brake pedal
movement (distance of travel) remains the
same from one pedal application to the next,
continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without de-
pressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradually
with each depression as the vacuum is re-
leased from the booster.
If the brakes do not operate properly, see a
NISSAN dealer.Some vehicles are equipped with engine com-
partment and passenger compartment fuse
boxes that use only type
A
fuses. Other ve-
hicles are equipped with typeA
fuses in the
engine compartment fuse box and type
Bfuses
in the passenger compartment fuse box.
Type
Afuses are provided as spare fuses. They
are stored in the passenger compartment fuse
box.
Type
A
fuses can be installed in the engine
compartment and passenger compartment fuse
boxes.
SDI1751
FUSES
Maintenance and do-it-yourself
8-21


05.8.26/Z50-D/V5.0


If a type
A
fuse is used to replace a type
B
fuse, the type
A
fuse will not be level with the
fuse pocket as shown in the illustration. This will
not affect the performance of the fuse. Make
sure the fuse is installed in the fuse box securely.
Type
B
fuses cannot be installed in the under-
hood fuse boxes. Only use type
A
fuses in the
underhood fuse boxes.
ENGINE COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and headlight
switch are OFF.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open
A, replace it with a new
fuse
B.
6. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
SDI1752
SDI1504
SDI1753
Type A
8-22
Maintenance and do-it-yourself


05.8.26/Z50-D/V5.0


engine stalling and hard hot starting are experi-
enced after using oxygenate-blend fuels, imme-
diately change to a non-oxygenate fuel or a fuel
with a low blend of MTBE.
Take care not to spill gasoline during refu-
eling. Gasoline containing oxygenates can
cause paint damage.E-85 fuelE-85 fuel is a mixture of approximately 85% fuel
ethanol and 15% unleaded gasoline. E-85 can
only be used in a Flexible Fuel Vehicle (FFV). Do
not use E-85 fuel in your vehicle. U.S. govern-
ment regulations require fuel ethanol dispensing
pumps to be identified by a small, square, or-
ange and black label with the common abbre-
viation or the appropriate percentage for that
region.Aftermarket fuel additivesNISSAN does not recommend the use of any
aftermarket fuel additives (for example, fuel in-
jector cleaner, octane booster, intake valve de-
posit removers, etc.) which are sold commer-
cially. Many of these additives intended for gum,
varnish or deposit removal may contain active
solvent or similar ingredients that can be harmful
to the fuel system and engine.
Octane rating tipsUsing unleaded gasoline with an octane
rating lower than recommended can cause
persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If you
detect a persistent heavy spark knock even
when using gasoline of the stated octane
rating, or if you hear steady spark knock
while holding a steady speed on level
roads, have your dealer correct the condi-
tion. Failure to correct the condition is
misuse of the vehicle, for which NISSAN is
not responsible.
Incorrect ignition timing will result in knocking,
after-run or overheating. This in turn may cause
excessive fuel consumption or damage to the
engine. If any of the above symptoms are en-
countered, have your vehicle checked at a
NISSAN dealer or other competent service fa-
cility.
However, now and then you may notice
light spark knock for a short time while
accelerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.
9-4
Technical and consumer information


05.8.26/Z50-D/V5.0


the proper equipment and to have it
installed.
Trailer lights should comply with federal and/or
local regulations. For assistance in hooking up
trailer lights, contact a NISSAN dealer or repu-
table trailer dealer.Trailer brakesIf your trailer is equipped with a braking system,
make sure it conforms to federal and/or local
regulations and that it is properly installed.
WARNING
Never connect a trailer brake system
directly to the vehicle brake system.Pre-towing tips
Be certain your vehicle maintains a level
position when a loaded and/or unloaded
trailer is hitched. Do not drive the vehicle if it
has an abnormal nose-up or nose-down con-
dition; check for improper tongue load, over-
load, worn suspension or other possible
causes of either condition.
Always secure items in the trailer to prevent
load shifts while driving.

Load the trailer so approximately 60% of the
trailer load is in the front half and 40% is in
the back half.

Check your hitch, trailer tire pressure, vehicle
tire pressure, trailer light operation, and trailer
wheel lug nuts every time you attach a trailer
to the vehicle.

Be certain your rear view mirrors conform to
all federal, state or local regulations. If not,
install any mirrors required for towing before
driving the vehicle.
Trailer towing tipsIn order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability, and braking per-
formance will be somewhat different than under
normal driving conditions.

Always secure items in the trailer to prevent
load shift while driving.

Avoid abrupt starts, acceleration or stops.

Avoid sharp turns or lane changes.

Always drive your vehicle at a moderate
speed. Some states or provinces have spe-cific speed limits for vehicles that are towing
trailers. Obey the local speed limits.

When backing up, hold the bottom of the
steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small corrections and back
up slowly. If possible, have someone guide
you when you are backing up.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so,
first block the wheels and apply the parking
brake, and then move the selector lever into
the P (Park) position. If you move the selector
lever to the P (Park) position before blocking
the wheels and applying the parking brake,
transmission damage could occur.

When going down a hill, shift into a lower
gear and use the engine braking effect.
When going up a long grade, downshift the
transmission to a lower gear and reduce
speed to reduce chances of engine overload-
ing and/or overheating.

If the engine coolant rises to an extremely
high temperature when the air conditioning
system is on, turn off the air conditioner.
Coolant heat can be additionally vented by
opening the windows, switching the fan con-
trol to high and setting the temperature con-
9-22
Technical and consumer information


05.8.26/Z50-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-31
Adjusting pedal position .......................................... 3-29
Aiming control, Headlights...................................... 2-25
Air bag system, Front passenger air bag
and status light .......................................................... 1-47
Air bag warning labels ............................................. 1-53
Air bag warning light .................................... 1-54, 2-13
Air cleaner housing filter.......................................... 8-17
Air conditioner
Air conditioner operation .................................. 4-23
Air conditioner service ........................... 4-23, 4-26
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant
and lubricant recommendations ............ 4-26, 9-6
Heater and air conditioner (automatic) ......... 4-23
In-cabin microfilter .............................................. 4-26
Alcohol, drugs and driving......................................... 5-6
All-wheel drive (AWD) ............................................. 5-24
All-wheel drive (AWD) LOCK indicator light ..... 2-14
All-wheel drive (AWD) warning light ...................... 2-9
All-wheel drive (AWD), AWD lock switch
operations.................................................................... 5-25
Anchor point locations
Top tether strap .................................................. 1-30
Antenna ........................................................................ 4-44
Anti-lock Brake System (ABS) .............................. 5-31
Anti-lock Brake System (ABS) waring light ....... 2-10Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Armrest ........................................................................... 1-9
Audible reminders ..................................................... 2-16
Audio operation precautions .................................. 4-28
Audio system .............................................................. 4-27
Autolight system ........................................................ 2-23
Automatic
Anti-glare inside mirror ...................................... 3-31
Automatic sunroof .............................................. 2-38
Drive positioner ................................................... 3-33
Seat positioner .................................................... 3-33
Avoiding collision and rollover .................................. 5-5
B
Back door (See lift gate)......................................... 3-24
Battery .......................................................................... 8-14
Battery saver system ......................................... 2-25
Battery replacement
Intelligent Key system .......................................... 3-8
Remote keyless entry system............................. 3-8
Before starting the engine ...................................... 5-12
Belts (See drive belts) ............................................. 8-16
Booster seats ............................................................. 1-34
Brake
Anti-lock brake system (ABS) ......................... 5-31
Brake booster ...................................................... 8-21Brake fluid............................................................. 8-13
Brake pedal check ............................................. 8-20
Brake system ....................................................... 5-30
Parking brake check .......................................... 8-20
Parking brake operation .................................... 5-21
Warning light ....................................................... 2-10
Break-in schedule ..................................................... 5-23
Brightness control, Instrument panel ................... 2-26
Bulbcheck/instrument panel .................................... 2-9
Bulbreplacement ...................................................... 8-27
C
Cabin air filter ............................................................. 4-26
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-44
Cargo (See vehicle loading information)............. 2-35
Cargo net .................................................................... 2-35
Cassette player (See audio system) .................... 4-40
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-42
Ceiling light ................................................................. 2-40
Cellular phone holder ............................................... 2-31
Charge warning light ................................................ 2-11
Child restraints ........................................................... 1-21
Booster seats ...................................................... 1-34
Installation on rear seat outboard or center
positions ................................................................ 1-23
LATCH system .................................................... 1-28


05.8.26/Z50-D/V5.0


Precautions on child restraints........................ 1-21
Top tether strap .................................................. 1-29
Top tether strap anchor point locations ....... 1-30
Child safety ................................................................. 1-12
Child safety rear door lock ........................................ 3-5
Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ......................................................... 4-4, 4-9, 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-41
Compact Disc (CD) player (See audio
system) ......................................................................... 4-35
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously Variable Transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-36
Cruise control............................................................. 5-21
Cruise main switch indicator light......................... 2-14
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside
mirror defroster switch ............................................. 2-22
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-24
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-25
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-23
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-36
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil pressure warning light ................... 2-11
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-12
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-27
Exhaust gas (Carbon monoxide).............................. 5-2


05.8.26/Z50-D/V5.0

10-2

New vehicle break-in ................................................ 5-23
NISSAN advanced air bag system ....................... 1-45
NISSAN Vehicle Immobilizer System ................... 2-18
NISSAN Vehicle Immobilizer System
Engine start .............................................. 5-10, 5-12
O
Odometer ....................................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine oil ........................................... 8-10
Checking engine oil level .................................... 8-9
Engine oil................................................................. 8-9
Engine oil viscosity ............................................... 9-5
Outside mirrors .......................................................... 3-32
Overheat, If your vehicle overheats ...................... 6-11
Owner’s Manual/Service Manual order
information................................................................... 9-27
P
Parking
Brake break-in ..................................................... 5-30
Brake check ......................................................... 8-20
Parking brake operation .................................... 5-21
Parking on hills .................................................... 5-29
Pedal position adjustment....................................... 3-29
Phone, Car phone or CB radio ............................. 4-44
Power
Front seat adjustment .......................................... 1-4
Power door lock .................................................... 3-3Power outlet ......................................................... 2-30
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Power windows................................................... 2-36
P position selecting warning light ......................... 2-13
Pre-tensioner seat belt system .............................. 1-52
Precautions
Audio operation ................................................... 4-28
Braking precautions ........................................... 5-30
Child restraints .................................................... 1-21
Cruise control ...................................................... 5-21
Driving safety .......................................................... 5-6
Maintenance ........................................................... 8-5
On-pavement and offroad driving ..................... 5-6
Seat belt usage ................................................... 1-10
Supplemental restraint system ........................ 1-39
When starting and driving .................................. 5-2
Push starting .............................................................. 6-10
R
Radio, Car phone or CB radio .............................. 4-44
Readiness for inspection/maintenance (I/M)
test (US only) ............................................................. 9-26
Rear center seat belt................................................ 1-17
Rear door lock, Child safety rear door lock.......... 3-5
Rear personal light .................................................... 2-41
Rear power point....................................................... 2-30
Rear seat adjustment .................................................. 1-5
Rear view monitor ..................................................... 4-19
Rear window and outside mirror defroster
switch ........................................................................... 2-22
Rear window wiper and washer switch .............. 2-21
Recorders, Event data ............................................. 9-27Registering your vehicle in another country ....... 9-10
Remote keyless entry
System, Except Intelligent Key system ............ 3-5
System, For Intelligent Key system ................ 3-20
Reporting safety defects (US only) ...................... 9-25
S
Safety
Child seat belts ................................................... 1-12
Reporting safety defects (US only)................ 9-25
Towing safety....................................................... 9-20
Safety chain ................................................................ 9-21
Seat adjustment
Front manual seat adjustment............................ 1-3
Front power seat adjustment ............................. 1-4
Rear seat adjustment ........................................... 1-5
Seat belt(s)
Child safety .......................................................... 1-12
Infants .................................................................... 1-13
Injured persons.................................................... 1-13
Larger children .................................................... 1-13
Pre-tensioner seat belt system ....................... 1-52
Precautions on seat belt usage ...................... 1-10
Pregnant women ................................................. 1-13
Rear center seat belt ......................................... 1-17
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-20
Seat belt hook ..................................................... 1-17
Seat belt maintenance ...................................... 1-20
Seat belt warning light and chime ................. 2-13
Seat belts ............................................................. 1-10
Shoulder belt height adjustment..................... 1-16
Small children ...................................................... 1-13


05.8.26/Z50-D/V5.0

10-5
