2006 NISSAN MURANO ECO mode

Turn the Volume control knobto adjust the
volume.
AUDIO button/knob:
Push the AUDIO button to change the selecting
mode as follows.
BASS→TREBLE→FADE→BALANCE→
BASS
To adjust Bass, Treble, Fader and Balance, push
the AUDIO button until the desired mode BASS,
TREBLE, FADE or BALANCE appears in the
display. Turn the AUDIO knobto adjust Bass
and Treble to the desired level. Use the Tuning
knobalso to adjust Fader or Balance modes.
Fader adjusts the sound level between the front
and rear speakers and Balance adjusts the
sound between the right and left speakers.
After 10 seconds, the radio or CD display
reappears. Once the sound quality is set to the
desired level, push the AUDIO button repeatedly
until the radio or CD display appears.
Display text:
To indicate the text, push the AUDIO knob
during CD or satellite radio playing.
BASS→TREBLE→FADE→BALANCE→
Display mode
To change the indicated text in display mode,turn the tuning knobwithin 2 seconds.
Display select:
Display CD text
To indicate the CD text, push the
button
while the CD is playing.
The text will change as follows:
Display FM text
To indicate the FM PS name, push the
button while the FM radio is playing.
The name will change as follows:
ON→OFF→ON
When no data is available, “NO TEXT” will
appear.
Display satellite radio text
To indicate the satellite radio text, push thebutton while the satellite radio is playing.
The text will change as follows:
When no data is available, “----” will appear.FM-AM-SAT radio operation
FM/AM/SAT radio select:
The satellite radio mode will be skipped unless
the optional satellite receiver and antenna are
installed, and an XM
or SIRIUS
TM
satellite radio
service subscription is active.
Pushing the RADIO button will change the band
as follows:
AM→FM→SAT (Satellite)
When the RADIO button is pushed while the
ignition switch is in the ACC or ON, the radio will
come on at the station last played.
The last station played will also come on when
the power knobis turned to ON.
If a compact disc is playing when the RADIO
button is pushed, the compact disc will auto-
matically be turned off and the last radio station
played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
change from stereo to monaural reception.
4-34
Display screen, heater, air conditioner and audio systems


05.8.26/Z50-D/V5.0


POWER/Volume control:
Turn the ignition switch to ACC or ON, and then
push the POWER button while the system is off
to call up the mode (radio, tape or CD) which
was playing immediately before the system was
turned off. When no CD or tape is loaded, the
radio will come on. While the system is on,
pushing the POWER button turns the system
off.
To turn the radio off, push the POWER button.
Turn the Volume control knobto adjust the
volume.
This vehicle hasSpeed Sensitive control Vol-
ume (SSV) for audio. The audio volume
changes as the driving speed changes.
AUDIO button/knob:
Push the AUDIO button to change the selecting
mode as follows.
BASS→TREBLE→FADE→BALANCE→
SSV→NR (when cassette playing)
To adjust Bass, Treble, Fader and Balance, push
the AUDIO button until the desired mode BASS,
TREBLE, FADE or BALANCE appears in the
display. Turn the AUDIO knobto adjust Bass
and Treble to the desired level. Use the Tuning
knobalso to adjust Fader or Balance modes.
Fader adjusts the sound level between the frontand rear speakers and Balance adjusts the
sound between the right and left speakers.
To change the SSV mode to OFF, LOW, MID or
HIGH, turn the Tuning knobto right or left.
To change the NR (Dolby) mode to OFF or ON,
turn the Tuning knobto right or left while cas-
sette tape is playing. When Dolby is ON, the
display indicates the
mark.
Dolby noise reduction is manufactured under
license from Dolby Laboratories Licensing Cor-
poration. Dolby NR and the double-D symbol
“
” are trademarks of Dolby Laboratories
Licensing Corporation.
After 10 seconds, the radio, cassette tape or CD
display reappears. Once the sound quality is set
to the desired level, push the AUDIO button
repeatedly until the radio, cassette tape or CD
display appears.
Display text:
To indicate the text, push the AUDIO knob
during CD or satellite radio playing.
BASS→TREBLE→FADE→BALANCE→
SSV→Display mode
To change the indicated text in display mode,
turn the tuning knobwithin 2 seconds.
Display select:
Display CD text
To indicate the CD text, push the
button
while the CD is playing.
The text will change as follows:
Display MP3/WMA text
To indicate the MP3/WMA text, push the
button while the CD is playing.
The text will change as follows:
Display FM text
To indicate the FM PS name, push the
button while the FM radio is playing.
The name will change as follows:
ON→OFF→ON
When no data is available, “NO TEXT” will
appear.
4-38
Display screen, heater, air conditioner and audio systems


05.8.26/Z50-D/V5.0


Display satellite radio text
To indicate the satellite radio text, push the
button while the satellite radio is playing.
The text will change as follows:
When no data is available, “----” will appear.FM-AM-SAT radio operation
FM/AM/SAT radio select:
The satellite radio mode will be skipped unless
the optional satellite receiver and antenna are
installed, and an XM
or SIRIUS
TM
satellite radio
service subscription is active.
Pushing the RADIO button will change the band
as follows:
AM→FM→SAT (Satellite)
When the RADIO button is pushed while the
ignition switch is in the ACC or ON, the radio will
come on at the station last played.
The last station played will also come on when
the power knobis turned to ON.
If a compact disc or tape is playing when the
RADIO button is pushed, the compact disc ortape will automatically be turned off and the last
radio station played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
change from stereo to monaural reception.
TUNE (Tuning):
WARNING
The radio should not be tuned while
driving so full attention may be given to
vehicle operation.
To tune the radio, turn the TUNE knobto the
right or left.
Use these buttons for manual tuning.
SEEK tuning:
Push the SEEK button
or
for less
than 0.5 second to tune from high to low or low
to high frequencies and stop at the next broad-
casting station (channel).
Push the SEEK button
or
for more
than 0.5 second, to fast tune from high to low or
low to high frequencies.
SCANtuning:
Push the SCAN tuning button to tune from low
to high frequencies and stop at each broadcast-
ing station (channel) for 5 seconds. Pushing the
button again during this 5 seconds period will
stop SCAN tuning and the radio will remain
tuned to that station (channel).
If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next station
(channel).
Station memory operations:
Eighteen (18) stations can be set for the FM, AM
and SAT band to the A, B and C preset button.
1. Choose preset channel A, B or C using the
preset select button.
2. Tune to the desired station using the SEEK,
SCAN or TUNE button and keep pushing any
of the desired station memory buttons (1 to
6) until a beep sound is heard. (The radio
mutes when the select button is pushed.)
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same manner.
If the battery cable is disconnected, or if the fuse
blows, the radio memory will be erased. In that
Display screen, heater, air conditioner and audio systems
4-39


05.8.26/Z50-D/V5.0


1. Volume control switch
2. MODE select switch
3. POWER on/off switch
4. Memory change⋅Seek and APS switchSTEERING SWITCH FOR AUDIO
CONTROL (if so equipped)The audio system can be operated using the
controls on the steering wheel.POWER on/off switchWith the ignition switch turned to the ACC or
ON position, push the POWER on/off switch to
turn the audio system on or off.
MODE select switchPush the mode select switch to change the
mode in the sequence of FM, AM, SAT, CD and
Tape.Volume control switchPush up or down the volume control switch to
increase or decrease the volume.
Tuning
Memory change (radio):
Push the tuning switch
or
for less
than 1.5 seconds to change the radio frequency.
Seek tuning (radio):
Push the tuning switch
or
for more
than 1.5 seconds to seek the next or previous
radio station.
APS (Automatic Program Search) FF,
APS REW (tape and CD):
Push the tuning switch
or
for less
than 1.5 seconds to return to the beginning of
the present program or skip to the next program.
Push several times to skip back or skip through
programs.
This system searches for the blank intervals
between selections. If there is a blank interval
within one program or there is no interval be-tween programs, the system may not stop in the
desired or expected location.
FF REW (tape or CD):
Push the tuning switch
or
for more
than 1.5 seconds to rewind or fast forward the
tape or to change the playing disc up or down.
To stop the FF or REW function, push the
or
button for less than 1.5 seconds
again.
SAA1330
Display screen, heater, air conditioner and audio systems
4-43


05.8.26/Z50-D/V5.0


ANTENNA
Placing the antennaYou can adjust the antenna positions manually.
Removing the antennaYou can remove the antenna if necessary.
Hold the bottom of the antenna and remove by
turning counterclockwise.
CAUTION

Be sure that antenna is removed be-
fore the vehicle enters an automatic
car wash.

Be sure to fold down the antenna
before the vehicle enters a garage
with a low ceiling.When installing a CB, ham radio or car phone in
your NISSAN, be sure to observe the following
cautions, otherwise the new equipment may
adversely affect the Engine control system and
other electronic parts.
WARNING

A cellular telephone should not be
used while driving so full attention
may be given to vehicle operation.
Some jurisdictions prohibit the use
of cellular telephones while driving.

If you must make a call while your
vehicle is in motion, the hands free
cellular phone operational mode (if
so equipped) is highly recommended.
Exercise extreme caution at all times
so full attention may be given to
vehicle operation.

If a conversation in a moving vehicle
requires you to take notes, pull off
the road to a safe location and stop
your vehicle before doing so.
SAA1236
CAR PHONE OR CB RADIO
4-44
Display screen, heater, air conditioner and audio systems


05.8.26/Z50-D/V5.0


5 Starting and drivingPrecautions when starting and driving ............................. 5-2
Exhaust gas (Carbon monoxide) .................................. 5-2
Three-way catalyst ........................................................... 5-3
Tire pressure monitoring system (TPMS)
(if so equipped) ............................................................... 5-3
Avoiding collision and rollover ...................................... 5-5
On-pavement and offroad driving precautions
(AWD) ................................................................................. 5-6
Drinking alcohol/drugs and driving .............................. 5-6
Driving safety precautions.............................................. 5-6
Ignition switch (Except for Intelligent Key equipped
model) ....................................................................................... 5-9
Key positions ..................................................................... 5-9
NISSAN Vehicle Immobilizer System (NVIS) ......... 5-10
Ignition switch (Intelligent Key System equipped
model)..................................................................................... 5-10
Ignition switch positions .............................................. 5-11
NISSAN Vehicle Immobilizer System (NVIS) ......... 5-12
Before starting the engine ................................................ 5-12
Starting the engine ............................................................. 5-12
Driving the vehicle ............................................................... 5-13
CVT (Continuously Variable Transmission)............. 5-13
M-CVT (CVT with Manual shift mode)..................... 5-16
Parking brake........................................................................ 5-21Cruise control ....................................................................... 5-21
Precautions on cruise control .................................... 5-21
Cruise control operations ............................................ 5-22
Break-in schedule .............................................................. 5-23
Increasing fuel economy .................................................... 5-24
Using all-wheel drive (AWD) (if so equipped) ............ 5-24
AWD lock switch operations...................................... 5-25
AWD warning light ........................................................ 5-27
Parking/parking on hills...................................................... 5-29
Power steering ..................................................................... 5-30
Brake system ........................................................................ 5-30
Braking precautions ...................................................... 5-30
Anti-lock brake system (ABS) .................................... 5-31
Vehicle dynamic control (VDC) system
(if so equipped) .................................................................. 5-32
Cold weather driving .......................................................... 5-34
Freeing a frozen door lock .......................................... 5-34
Antifreeze ......................................................................... 5-34
Battery .............................................................................. 5-34
Draining of coolant water ............................................ 5-34
Tire equipment................................................................ 5-34
Special winter equipment ............................................ 5-35
Driving on snow or ice ................................................. 5-35
Engine block heater (if so equipped) ....................... 5-36


05.8.26/Z50-D/V5.0


ON (Normal operating position) (3)
This position turns on the ignition system and the
electrical accessories.
START (4)
This position activates the starter motor, starting
the engine.NISSAN VEHICLE IMMOBILIZER
SYSTEM (NVIS)The NISSAN Vehicle Immobilizer System (NVIS)
will not allow the engine to start without the use
of the registered NISSAN Vehicle Immobilizer
System key.
If the engine fails to start using the registered
NVIS key, it may be due to interference caused
by another NVIS key, an automated toll road
device or automated payment device on the key
ring. Restart the engine using the following
procedures:
1. Leave the ignition switch in the ON position
for approximately 5 seconds.
2. Turn the ignition switch to the OFF or LOCK
position and wait approximately 10 seconds.
3. Repeat step 1 and 2 again.
4. Restart the engine while holding the device
(which may have caused the interference)separate from the registered NVIS key.
If this procedure allows the engine to start,
NISSAN recommends placing the registered
NVIS key on a separate key ring to avoid inter-
ference from other devices.
The ignition lock is designed so that the ignition
switch cannot be turned to LOCK and removed
until the selector lever is moved to the P (Park)
position.
When turning the ignition switch, make sure the
selector lever is in the P position.
If the selector lever is not returned to the P
position, the ignition switch cannot be moved
toward LOCK.
When the ignition switch cannot be turned
toward the LOCK position while keeping the
Intelligent Key, proceed as follows:
1. Move the selector lever into the P position.
SSD0417
IGNITION SWITCH (Intelligent Key
System equipped model)
5-10
Starting and driving


05.8.26/Z50-D/V5.0


CAUTION
Do not operate the starter for more than
15 seconds at a time. If the engine does
not start, turn the key off and wait 10
seconds before cranking again, other-
wise the starter could be damaged.
4.Warm-up
Allow the engine to idle for at least 30
seconds after starting. Do not race the en-
gine while warming it up. Drive at moderate
speed for a short distance first, especially in
cold weather.
In cold weather, keep the engine running for
a minimum of2-3minutes before shutting it
off. Starting and stopping the engine over a
short period of time may make the vehicle
more difficult to start.
CVT (Continuously Variable
Transmission)
Gate type shiftThe CVT in your vehicle is electronically con-
trolled by a transmission control module to pro-
duce maximum power and smooth operation.
Shown on the following pages are the recom-
mended operating procedures for this transmis-
sion. Follow these procedures for maximum ve-
hicle performance and driving enjoyment.Starting the vehicleAfter starting the engine, fully depress the foot
brake pedal before shifting the selector lever to
the R (Reverse), N (Neutral), D (Drive), S (Sec-
ond) or L (Low) position. Be sure the vehicle is
fully stopped before attempting to shift the se-
lector lever.
This CVT model is designed so that the
foot brake pedal must be depressed be-
fore shifting from P (Park) to any drive
position while the ignition switch is ON.
The selector lever cannot be moved out of
P (Park) position and into any of the other
shift range if the ignition switch is turned
to the LOCK, OFF or ACC position or if the
key is removed from the switch.1. Keep the foot brake pedal depressed and
shift into a driving range.
2. Release the parking brake and foot brake,
then gradually start the vehicle in motion.
WARNING

Do not depress the accelerator pedal
while shifting from P (Park) or N
(Neutral) to R (Reverse), or D (Drive)
or manual shift mode. Failure to do
so could cause you to lose control
and have an accident.

Cold engine idle speed is high, so use
caution when shifting into a forward
or reverse range before the engine
has warmed up.

On slippery roads, do not downshift.
This may cause a loss of control.

Never shift to P (Park) or R (Reverse)
while the vehicle is moving. Failure to
do so could cause you to lose control
and have an accident.
DRIVING THE VEHICLE
Starting and driving
5-13


05.8.26/Z50-D/V5.0
