2006 NISSAN MURANO buttons

4 Display screen, heater, air conditioner and
audio systemsSafety note .............................................................................. 4-2
Control panel buttons — without navigation system .... 4-2
How to use joystick and “ENTER” button ................. 4-3
How to use “BACK” button .......................................... 4-3
How to use “TRIP” button ............................................. 4-3
How to use “FUEL ECON” button .............................. 4-3
Clock ................................................................................... 4-4
How to use “E/M” button .............................................. 4-4
How to use “MAINT” (Maintenance) button ............. 4-4
Maintenance notice ......................................................... 4-5
How to use “SETTING” button .................................... 4-6
“DAY/NIGHT” button.................................................... 4-10
Control panel buttons — with navigation system ....... 4-11
How to use joystick and “ENTER” button .............. 4-11
How to use “BACK” button........................................ 4-11
Setting up the start-up screen................................... 4-12
How to use the “TRIP” button ................................... 4-12
Maintenance notice ....................................................... 4-14
How to use the “SETTING” button .......................... 4-15
“DAY/NIGHT” button.................................................... 4-19
Rear view monitor (if so equipped) ................................ 4-19
How to read the displayed lines................................ 4-20Rear view monitor setting............................................ 4-20
Operating tips................................................................. 4-20
Ventilators .............................................................................. 4-21
Heater and air conditioner (Automatic) ......................... 4-23
Automatic operation ...................................................... 4-24
Manual operation ........................................................... 4-25
Operating tips................................................................. 4-25
In-cabin microfilter ......................................................... 4-26
Servicing air conditioner .................................................... 4-26
Audio system ........................................................................ 4-27
FM radio reception ........................................................ 4-27
AM radio reception ....................................................... 4-28
Satellite radio reception ............................................... 4-28
Audio operation precautions....................................... 4-28
FM-AM-SAT radio with CD player .......................... 4-33
FM-AM-SAT radio with cassette player and CD
changer ............................................................................ 4-37
CD care and cleaning .................................................. 4-42
Steering switch for audio control (if so
equipped)......................................................................... 4-43
Antenna ............................................................................ 4-44
Car phone or CB radio .................................................... 4-44


05.8.26/Z50-D/V5.0


WARNING

Positioning of the heating or air con-
ditioning controls and display con-
trols should not be done while driv-
ing, in order that full attention may
be given to the driving operation.

Do not disassemble or modify this
system. If you do, it may result in
accidents, fire, or electrical shock.

Do not use this system if you notice
any abnormality, such as a frozen
screen or lack of sound. Continued
use of the system may result in acci-
dent, fire or electric shock.

In case you notice any foreign object
in the system hardware, spill liquid
on it, or notice smoke or smell com-
ing from it, stop using the system
immediately and contact a NISSAN
dealer. Ignoring such conditions may
lead to accidents, fire, or electrical
shock.1. “TRIP” button
2. “FUEL ECON” button
3. Clock adjust button
4. “TRIP RESET” button5. “E/M” button
6. “DAY/NIGHT” button
7. “BACK” button
8. JOYSTICK and “ENTER” button
SAA1352
SAFETY NOTE
CONTROL PANEL BUTTONS —
WITHOUT NAVIGATION SYSTEM4-2
Display screen, heater, air conditioner and audio systems


05.8.26/Z50-D/V5.0


1. “DAY/NIGHT” button
2. “BACK” button
3. Joystick and “ENTER” button
4. “SETTING” button
5. “TRIP” buttonA: For Navigation system control buttons; refer
to the separate Navigation System Owner’s
Manual.
When you use this system, make sure the engine
is running.
If you use the system with the engine not
running (ignition ONor ACC) for a long
time, it will use up all the battery power,
and the engine will not start.
HOW TO USE JOYSTICK AND
“ENTER” BUTTONChoose an item on the display using the joystick
and push the “ENTER” button for operation.HOW TO USE “BACK” BUTTONThis has two functions.

Go back to the previous display (cancel).
If you push the “BACK” button during setup, the
setup will be canceled and/or the display will
return to the previous screen.
SAA1316
CONTROL PANEL BUTTONS —
WITH NAVIGATION SYSTEM
Display screen, heater, air conditioner and audio systems
4-11


05.8.26/Z50-D/V5.0


clean, push the AUTO button to return to the
auto mode.

When the
front defroster button is
pushed, the air conditioner will automatically
be turned on at outside temperatures above
23°F (−5°C) to defog the windshield, and the
air recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
MANUAL OPERATION
Fan speed controlTurn the fan control button
to manually
control the fan speed.
Push the AUTO button to return to automatic
control of the fan speed.
Air recirculationPush the air recirculation button
to recir-
culate interior air inside the vehicle. The indicator
light on the
button will come on.
The air recirculation
cannot be activated
when the air conditioner is in the front defrosting
mode
.
Fresh airPush the button
to draw outside air into
the passenger compartment. The indicator light
on the
button will come on.
Automatic intake air controlIn the AUTO mode, the intake air will be con-
trolled automatically. To manually control the
intake air, push the air recirculate
or fresh
air
button. To return to the automatic
control mode, push the indicator-illuminated but-
ton for about 2 seconds. The indicator lights
(both air recirculate and fresh air buttons) will
flash twice, and then the intake air will be
controlled automatically.
Air flow controlPushing the MODE manual air flow control
button selects the air outlet to:
: Air flows from center and side ventila-
tors.: Air flows from center and side ventila-
tors and foot outlets.: Air flows from foot outlets and side
ventilators.: Air flows from defroster, foot outlets
and side ventilators.
To turn the system offPush the OFF button.OPERATING TIPSWhen the engine coolant temperature and out-
side air temperature are low, the air flow from the
foot outlets may not operate for a maximum of
150 seconds. However, this is not a malfunction.
After the coolant temperature warms up, the air
flow from the foot outlets will operate normally.
Display screen, heater, air conditioner and audio systems
4-25


05.8.26/Z50-D/V5.0


TUNE (Tuning):
WARNING
The radio should not be tuned while
driving so full attention may be given to
vehicle operation.
To tune the radio, turn the TUNE knobto the
right or left.
Use these buttons for manual tuning.
SEEK tuning:
Push the SEEK button
or
for less
than 0.5 second to tune from high to low or low
to high frequencies and stop at the next broad-
casting station (channel).
Push the SEEK button
or
for more
than 0.5 second, to fast tune from high to low or
low to high frequencies.
SCANtuning:
Push the SCAN tuning button to tune from low
to high frequencies and stop at each broadcast-
ing station (channel) for 5 seconds. Pushing the
button again during this 5 seconds period will
stop SCAN tuning and the radio will remain
tuned to that station (channel).If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next station
(channel).
Station memory operations:
Eighteen (18) stations can be set for the FM, AM
and SAT band to the A, B and C preset button.
1. Choose preset channel A, B or C using the
preset select button.
2. Tune to the desired station using the SEEK,
SCAN or TUNE button and keep pushing any
of the desired station memory buttons (1 to
6) until a beep sound is heard. (The radio
mutes when the select button is pushed.)
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same manner.
If the battery cable is disconnected, or if the fuse
blows, the radio memory will be erased. In that
case, reset the desired stations.
Radio data system (RDS):
RDS stands for Radio Data System, and is a
data information service transmitted by some
radio stations on the FM band (not AM band)
and/or SATELLITE band encoded within a regu-
lar radio broadcast. Currently, most RDS sta-tions are in large cities, but many stations are
now considering broadcasting RDS data.
RDS can display:

Station call sign, such as “WHFR 98.3”.

Station name, such as “The Groove”.

Music or programming type such as “Classi-
cal”, “Country”, or “Rock”.

Traffic reports about delays or construction.
If the station broadcasts RDS information, the
RDS icon is displayed.
Category (CAT) button:
When the CAT button is pushed for less than
0.5 second, the AM/FM (Satellite) radio frequen-
cies (Category) will move to the next/previous
step (Category). Push and hold the button for
more than 0.5 second to move quickly through
the steps (Categories).
Compact disc (CD) player operationTurn the ignition switch to the ACC or ON
position and insert the compact disc into the slot
with the label side facing up. The compact disc
will be guided automatically into the slot and
start playing.
After loading the disc, the number of tracks on
Display screen, heater, air conditioner and audio systems
4-35


05.8.26/Z50-D/V5.0


Display satellite radio text
To indicate the satellite radio text, push the
button while the satellite radio is playing.
The text will change as follows:
When no data is available, “----” will appear.FM-AM-SAT radio operation
FM/AM/SAT radio select:
The satellite radio mode will be skipped unless
the optional satellite receiver and antenna are
installed, and an XM
or SIRIUS
TM
satellite radio
service subscription is active.
Pushing the RADIO button will change the band
as follows:
AM→FM→SAT (Satellite)
When the RADIO button is pushed while the
ignition switch is in the ACC or ON, the radio will
come on at the station last played.
The last station played will also come on when
the power knobis turned to ON.
If a compact disc or tape is playing when the
RADIO button is pushed, the compact disc ortape will automatically be turned off and the last
radio station played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
change from stereo to monaural reception.
TUNE (Tuning):
WARNING
The radio should not be tuned while
driving so full attention may be given to
vehicle operation.
To tune the radio, turn the TUNE knobto the
right or left.
Use these buttons for manual tuning.
SEEK tuning:
Push the SEEK button
or
for less
than 0.5 second to tune from high to low or low
to high frequencies and stop at the next broad-
casting station (channel).
Push the SEEK button
or
for more
than 0.5 second, to fast tune from high to low or
low to high frequencies.
SCANtuning:
Push the SCAN tuning button to tune from low
to high frequencies and stop at each broadcast-
ing station (channel) for 5 seconds. Pushing the
button again during this 5 seconds period will
stop SCAN tuning and the radio will remain
tuned to that station (channel).
If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next station
(channel).
Station memory operations:
Eighteen (18) stations can be set for the FM, AM
and SAT band to the A, B and C preset button.
1. Choose preset channel A, B or C using the
preset select button.
2. Tune to the desired station using the SEEK,
SCAN or TUNE button and keep pushing any
of the desired station memory buttons (1 to
6) until a beep sound is heard. (The radio
mutes when the select button is pushed.)
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same manner.
If the battery cable is disconnected, or if the fuse
blows, the radio memory will be erased. In that
Display screen, heater, air conditioner and audio systems
4-39


05.8.26/Z50-D/V5.0


INTELLIGENT KEY
CAUTION
Be careful not to allow children to swal-
low the battery and removed parts.
Replace the battery as follows:
1. Release the lock knobat the back of the
intelligent key and remove the mechanical
key.
2. Insert a flat-blade screwdriver
A
wrapped
with a cloth into the slit
B
of the corner and
twist it to separate the upper part from the
lower part.
3. Replace the battery with a new one.

Do not touch the internal circuit and electric
terminals as it could cause a malfunction.
Recommended battery: CR2025 or equiva-
lent
Make sure that the⊕side faces the
bottom of the case.
4. Close the lid securely as illustrated
12.
5. Push the buttons two or three times to check
its operation.See a NISSAN dealer if you need any assistance
for replacement.
If the battery is removed for any reason
other than replacement, perform step 5
above.

Be careful not to touch the circuit board
and the battery terminal.

An improperly disposed battery can
harm the environment. Always confirm
local regulations for battery disposal.

When changing batteries, do not let
dust or oil get on the Intelligent Key.
FCC Notice:
This equipment has been tested and found
to comply with the limits for a Class B
digital device pursuant to part 15 of the
FCC Rules (the certification number).
These limits are designed to provide rea-
sonable protection against harmful inter-
ference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruc-
tions, may cause harmful interference to
radio communications. However, there is
no guarantee that interference will not oc-
cur in a particular installation. If this equip-
ment does cause harmful interference to
SDI1792
Maintenance and do-it-yourself
8-25


05.8.26/Z50-D/V5.0


Precautions on child restraints........................ 1-21
Top tether strap .................................................. 1-29
Top tether strap anchor point locations ....... 1-30
Child safety ................................................................. 1-12
Child safety rear door lock ........................................ 3-5
Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ......................................................... 4-4, 4-9, 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-41
Compact Disc (CD) player (See audio
system) ......................................................................... 4-35
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously Variable Transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-36
Cruise control............................................................. 5-21
Cruise main switch indicator light......................... 2-14
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside
mirror defroster switch ............................................. 2-22
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-24
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-25
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-23
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-36
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil pressure warning light ................... 2-11
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-12
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-27
Exhaust gas (Carbon monoxide).............................. 5-2


05.8.26/Z50-D/V5.0

10-2
