WARNING
Overloading or improper loading of a
trailer and its cargo can adversely affect
vehicle handling, braking and perfor-
mance and may lead to accidents.
CAUTION

Do not tow a trailer or haul a heavy
load for the first 500 miles (800 km).Your engine, axle or other parts
could be damaged.

For the first 500 miles (800 km) that
you tow a trailer, do not drive over 50
mph (80 km/h) and do not make
starts at full throttle. This helps the
engine and other parts of your ve-
hicle wear in at the heavier loads.
Your new vehicle was designed to be used
primarily to carry passengers and cargo. Re-
member that towing a trailer will place additional
loads on your vehicle’s engine, drive train, steer-
ing, braking and other systems.
MAXIMUM LOAD LIMITS
Maximum trailer loadsNever allow the total trailer load to exceed the
value specified in the Towing Load/Specification
Chart found later in this section. The total trailer
load equals trailer weight plus its cargo weight.

When towing a trailer load of 1,000 lbs. (454
kg) or more, trailers with a brake system
MUST be used.
The maximum GCWR (Gross Combined Weight
Rating) should not exceed the value specified inthe following Towing Load/Specification Chart.
The GCWR equals the combined weight of the
towing vehicle (including passengers and cargo)
plus the total trailer load.
Towing loads greater than specified or using
improper towing equipment could adversely af-
fect vehicle handling, braking and performance.
The ability of your vehicle to tow a trailer is not
only related to the maximum trailer loads, but
also the places you plan to tow. Tow weights
appropriate for level highway driving may have to
be reduced on very steep grades or in low
traction situations (for example, on slippery boat
ramps).
Temperature conditions also can affect towing.
For example, towing a heavy trailer in high
outside temperatures on graded roads can af-
fect engine performance and cause overheating.
The transmission high fluid temperature protec-
tion mode, which helps reduce the chance of
transmission damage, could activate and auto-
matically decrease engine power. Vehicle speed
may decrease to 40 to 50 MPH (65 to 80 km/h)
under high load. Plan your trip carefully to ac-
count for trailer and vehicle load, weather, and
road conditions.
CA0009
TOWING A TRAILER9-18
Technical and consumer information


05.8.26/Z50-D/V5.0


WARNING
Overheating can result in reduced en-
gine power and vehicle speed. Also,
when the high temperature mode oper-
ates, vehicle speed may be gradually
reduced. The reduced speed may be
lower than other traffic, which could
increase the chance of a collision. Be
especially careful when driving. If nec-
essary, pull to the side of the road at a
safe place and allow the engine to cool
or the transmission to return to normal
operation.
CAUTION
Vehicle damage resulting from im-
proper towing procedures is not cov-
ered by NISSAN warranties.Tongue loadKeep the tongue load between 9 to 11 percent
of the total trailer load within the maximum
tongue load limits shown in the following TowingLoad/Specifications Chart. If the tongue load
becomes excessive, rearrange cargo to allow for
proper tongue load.
Maximum gross vehicle weight/
maximum gross axle weightThe gross vehicle weight of the towing vehicle
must not exceed the gross vehicle weight rating
(GVWR) shown on the F.M.V.S.S. certification
label. The gross vehicle weight equals the com-
bined weight of the unloaded vehicle, passen-
gers, luggage, hitch, trailer tongue load and any
other optional equipment. In addition, front or
rear gross axle weight must not exceed the
gross axle weight rating (GAWR) shown on the
F.M.V.S.S. certification label.
TI1012M
Technical and consumer information
9-19


05.8.26/Z50-D/V5.0


the proper equipment and to have it
installed.
Trailer lights should comply with federal and/or
local regulations. For assistance in hooking up
trailer lights, contact a NISSAN dealer or repu-
table trailer dealer.Trailer brakesIf your trailer is equipped with a braking system,
make sure it conforms to federal and/or local
regulations and that it is properly installed.
WARNING
Never connect a trailer brake system
directly to the vehicle brake system.Pre-towing tips
Be certain your vehicle maintains a level
position when a loaded and/or unloaded
trailer is hitched. Do not drive the vehicle if it
has an abnormal nose-up or nose-down con-
dition; check for improper tongue load, over-
load, worn suspension or other possible
causes of either condition.
Always secure items in the trailer to prevent
load shifts while driving.

Load the trailer so approximately 60% of the
trailer load is in the front half and 40% is in
the back half.

Check your hitch, trailer tire pressure, vehicle
tire pressure, trailer light operation, and trailer
wheel lug nuts every time you attach a trailer
to the vehicle.

Be certain your rear view mirrors conform to
all federal, state or local regulations. If not,
install any mirrors required for towing before
driving the vehicle.
Trailer towing tipsIn order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability, and braking per-
formance will be somewhat different than under
normal driving conditions.

Always secure items in the trailer to prevent
load shift while driving.

Avoid abrupt starts, acceleration or stops.

Avoid sharp turns or lane changes.

Always drive your vehicle at a moderate
speed. Some states or provinces have spe-cific speed limits for vehicles that are towing
trailers. Obey the local speed limits.

When backing up, hold the bottom of the
steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small corrections and back
up slowly. If possible, have someone guide
you when you are backing up.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so,
first block the wheels and apply the parking
brake, and then move the selector lever into
the P (Park) position. If you move the selector
lever to the P (Park) position before blocking
the wheels and applying the parking brake,
transmission damage could occur.

When going down a hill, shift into a lower
gear and use the engine braking effect.
When going up a long grade, downshift the
transmission to a lower gear and reduce
speed to reduce chances of engine overload-
ing and/or overheating.

If the engine coolant rises to an extremely
high temperature when the air conditioning
system is on, turn off the air conditioner.
Coolant heat can be additionally vented by
opening the windows, switching the fan con-
trol to high and setting the temperature con-
9-22
Technical and consumer information


05.8.26/Z50-D/V5.0


WARNING
A vehicle equipped with AWD (All-
Wheel Drive) should never be tested
using a two wheel dynamometer, similar
to the dynamometers used by some
states for emissions testing, or similar
equipment. Make sure you inform the
test facility personnel that your vehicle
is an AWD equipped vehicle before it is
placed on a dynamometer. Failure to do
so may result in transmission damage
or unexpected vehicle movement which
could result in serious vehicle damage
or personal injury.
Due to legal requirements in some states/
areas, your vehicle may be required to be in what
is called the “ready condition” for an
Inspection/Maintenance (I/M) test of the emis-
sion control system.
The vehicle is set to the “ready condition” when
it is driven through certain driving patterns.
Usually, the “ready condition” can be obtained
by ordinary usage of the vehicle.
If a powertrain system component is repaired orthe battery is disconnected, the vehicle may be
reset to a not “ready condition”. Before taking
the I/M test, check the vehicle’s inspection/
maintenance test readiness condition. Turn the
ignition switch ON without starting the engine. If
the Malfunction Indicator Lamp (MIL) comes on
steady for 20 seconds and then blinks for 10
seconds, the I/M test condition is “not ready”. If
the MIL does not blink after 20 seconds, the I/M
test condition is “ready”. If the MIL indicates the
vehicle is in a “not ready” condition, drive the
vehicle through the following pattern to set the
vehicle to the ready condition. If you cannot or
do not want to perform the driving pattern, a
NISSAN dealer can conduct it for you.
WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic
conditions and obey all traffic laws.
1. Start the engine. Allow the engine to idle until
the engine coolant temperature gauge needle
points between the C and H (normal operat-
ing temperature).
2. Accelerate the vehicle to 55 MPH (88 km/h),
then quickly release the accelerator pedalcompletely and keep it released for at least
10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 to 60 MPH (86 to 96 km/h) for at least 9
minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 minutes.
8. Stop the vehicle. Place the transmission se-
lector lever in the “P” or “N” position.
9. Turn the engine off.
10. Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the engine
until step 7 is completed.
READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)9-26
Technical and consumer information


05.8.26/Z50-D/V5.0


Your vehicle is equipped with a variety of com-
puters that monitor and control a number of
systems to optimize performance and help ser-
vice technicians with diagnosis and repair. De-
pending on the equipment on your vehicle, some
of the computers monitor emission control sys-
tems, braking systems, engine systems, trans-
mission systems, tire pressure systems and air
bag systems. Some data about vehicle operation
may be stored in the computers for use during
servicing. Other data may be stored if a crash
event occurs. For example, air bag readiness, air
bag performance, and seat belt use by the driver
or passenger may be recorded, depending on
vehicle equipment. These types of systems are
sometimes called Event Data Recorders.
Special equipment can be used to access the
electronic data that may be stored in the vehi-
cle’s computers (sounds are not recorded).
NISSAN and NISSAN dealers have equipment
to access some of this data; others may also
have this equipment. The data may be retrieved
during routine vehicle servicing or for special
research. It might also be accessed with the
consent of the vehicle owner or lessee, in re-
sponse to a request by law enforcement, or as
otherwise required or permitted by law.A genuine NISSAN Service Manual is the best
source of service and repair information for your
vehicle. Filled with wiring diagrams, illustrations
and step-by-step diagnostic and adjustment
procedures, this manual is the same one used by
the factory trained technicians working at autho-
rized NISSAN dealerships. Also available are
genuine NISSAN Owner’s Manuals, and genu-
ine NISSAN Service and Owner’s Manuals for
older NISSAN models.
In the USA:
For current pricing and availability of genuine
NISSAN Service Manualsfor the 2000 model
year and later, contact:
Tweddle Litho Company
1-800-450-9491
www.nissan-techinfo.com
For current pricing and availability of genuine
NISSAN Service Manualsfor the 1999 model
year and prior, see a NISSAN dealer, or contact:
Resolve Corporation
20770 Westwood Dr.
Strongsville OH 44136
1-800-247-5321For current pricing and availability of genuine
NISSAN Owner’s Manualsfor the model year
and prior, see a NISSAN dealer, or contact:
Resolve Corporation
20770 Westwood Dr.
Strongsville OH 44136
1-800-247-5321
In Canada:
To purchase a copy of a genuine NISSAN
Service Manual or Owner’s Manual please con-
tact your nearest NISSAN dealer. For the phone
number and location of a NISSAN Dealer in your
area call the NISSAN Satisfaction Center at
1-800-387-0122 and a bilingual NISSAN rep-
resentative will assist you.
Also available are Genuine NISSAN Service and
Owner’s Manuals for older NISSAN models.
IN THE EVENT OF A COLLISIONUnfortunately, accidents do occur. In this unlikely
event, there is some important information you
should know. Many insurance companies rou-
tinely authorize the use of non-genuine collision
parts in order to cut costs, among other reasons.
EVENT DATA RECORDERS
OWNER’S MANUAL/SERVICE
MANUAL ORDER INFORMATION
Technical and consumer information
9-27


05.8.26/Z50-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-31
Adjusting pedal position .......................................... 3-29
Aiming control, Headlights...................................... 2-25
Air bag system, Front passenger air bag
and status light .......................................................... 1-47
Air bag warning labels ............................................. 1-53
Air bag warning light .................................... 1-54, 2-13
Air cleaner housing filter.......................................... 8-17
Air conditioner
Air conditioner operation .................................. 4-23
Air conditioner service ........................... 4-23, 4-26
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant
and lubricant recommendations ............ 4-26, 9-6
Heater and air conditioner (automatic) ......... 4-23
In-cabin microfilter .............................................. 4-26
Alcohol, drugs and driving......................................... 5-6
All-wheel drive (AWD) ............................................. 5-24
All-wheel drive (AWD) LOCK indicator light ..... 2-14
All-wheel drive (AWD) warning light ...................... 2-9
All-wheel drive (AWD), AWD lock switch
operations.................................................................... 5-25
Anchor point locations
Top tether strap .................................................. 1-30
Antenna ........................................................................ 4-44
Anti-lock Brake System (ABS) .............................. 5-31
Anti-lock Brake System (ABS) waring light ....... 2-10Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Armrest ........................................................................... 1-9
Audible reminders ..................................................... 2-16
Audio operation precautions .................................. 4-28
Audio system .............................................................. 4-27
Autolight system ........................................................ 2-23
Automatic
Anti-glare inside mirror ...................................... 3-31
Automatic sunroof .............................................. 2-38
Drive positioner ................................................... 3-33
Seat positioner .................................................... 3-33
Avoiding collision and rollover .................................. 5-5
B
Back door (See lift gate)......................................... 3-24
Battery .......................................................................... 8-14
Battery saver system ......................................... 2-25
Battery replacement
Intelligent Key system .......................................... 3-8
Remote keyless entry system............................. 3-8
Before starting the engine ...................................... 5-12
Belts (See drive belts) ............................................. 8-16
Booster seats ............................................................. 1-34
Brake
Anti-lock brake system (ABS) ......................... 5-31
Brake booster ...................................................... 8-21Brake fluid............................................................. 8-13
Brake pedal check ............................................. 8-20
Brake system ....................................................... 5-30
Parking brake check .......................................... 8-20
Parking brake operation .................................... 5-21
Warning light ....................................................... 2-10
Break-in schedule ..................................................... 5-23
Brightness control, Instrument panel ................... 2-26
Bulbcheck/instrument panel .................................... 2-9
Bulbreplacement ...................................................... 8-27
C
Cabin air filter ............................................................. 4-26
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-44
Cargo (See vehicle loading information)............. 2-35
Cargo net .................................................................... 2-35
Cassette player (See audio system) .................... 4-40
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-42
Ceiling light ................................................................. 2-40
Cellular phone holder ............................................... 2-31
Charge warning light ................................................ 2-11
Child restraints ........................................................... 1-21
Booster seats ...................................................... 1-34
Installation on rear seat outboard or center
positions ................................................................ 1-23
LATCH system .................................................... 1-28


05.8.26/Z50-D/V5.0


Precautions on child restraints........................ 1-21
Top tether strap .................................................. 1-29
Top tether strap anchor point locations ....... 1-30
Child safety ................................................................. 1-12
Child safety rear door lock ........................................ 3-5
Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ......................................................... 4-4, 4-9, 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-41
Compact Disc (CD) player (See audio
system) ......................................................................... 4-35
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously Variable Transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-36
Cruise control............................................................. 5-21
Cruise main switch indicator light......................... 2-14
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside
mirror defroster switch ............................................. 2-22
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-24
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-25
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-23
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-36
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil pressure warning light ................... 2-11
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-12
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-27
Exhaust gas (Carbon monoxide).............................. 5-2


05.8.26/Z50-D/V5.0

10-2

F
F.M.V.S.S. certification label................................... 9-11
Filter
Air cleaner housing filter ................................... 8-17
Changing engine oil filter ................................. 8-11
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat towing .................................................................. 9-23
Floor mat cleaning ....................................................... 7-4
Fluid
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
CVT fluid ............................................................... 8-12
Engine coolant ....................................................... 8-8
Engine oil................................................................. 8-9
Power steering fluid ........................................... 8-12
Window washer fluid ......................................... 8-14
FM-AM-SAT radio with cassette player and
CD player .................................................................... 4-37
FM-AM-SAT radio with CD player ....................... 4-33
Fog light switch ......................................................... 2-27
Front manual seat adjustment .................................. 1-3
Front passenger air bag and status light ............ 1-47
Front power seat adjustment .................................... 1-4
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Fuel economy ...................................................... 5-24
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Fuel-filler cap ....................................................... 3-26
Fuel-filler door...................................................... 3-26Gauge ...................................................................... 2-5
Fuses ............................................................................ 8-21
Fusible links ................................................................ 8-23
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-43
Gas cap ....................................................................... 3-26
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Fuel gauge .............................................................. 2-5
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-4
General maintenance .................................................. 8-2
Glove box .................................................................... 2-33
H
Hazard indicator light ............................................... 2-16
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-8
Headlights
Aiming control ..................................................... 2-25
Bulbreplacement ............................................... 8-28
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-28
Heater
Engine block heater ........................................... 5-36
Heater and air conditioner (automatic) ......... 4-23
High beam indicator light ........................................ 2-14HomeLink
Universal Transceiver ......................... 2-43
Hood release .............................................................. 3-24
Horn .............................................................................. 2-28
I
Ignition knob(Intelligent Key system) .................. 3-13
Ignition switch
Except for Intelligent Key equipped
model ...................................................................... 5-9
Intelligent Key System equipped model ...... 5-10
Ignition switch key positions ..................................... 5-9
Immobilizer system .................................................... 2-18
In-cabin microfilter .................................................... 4-26
Indicator light ................................................................ 2-9
All-wheel drive (AWD) LOCK indicator
light......................................................................... 2-14
Continuously Variable Transmission (CVT)
indicator light ....................................................... 2-14
Cruise main switch indicator light .................. 2-14
Cruise set indicator light .................................. 2-14
Front passenger air bag status indicator
light......................................................................... 2-14
High beam indicator light ................................. 2-14
Malfunction indicator light ................................ 2-14
Security indicator light....................................... 2-15
Slip indicator light............................................... 2-15
Turn signal/hazard indicator light ................... 2-16
Vehicle dynamic control (VDC) off indicator
light......................................................................... 2-16
Inside
Automatic anti-glare mirror............................... 3-31
Mirror...................................................................... 3-30
Inspection/maintenance (I/M) test ........................ 9-26


05.8.26/Z50-D/V5.0

10-3
