FLAT TOWING
Towing your vehicle with all four wheels on the
ground is sometimes called flat towing. This
method is sometimes used when towing a vehicle
behind a recreational vehicle, such as a motor
home.
CAUTION
cFailure to follow these guidelines can
result in severe transmission damage.
cWhenever flat towing your vehicle, al-
ways tow forward, never backward.
cDO NOT tow any automatic transmis-
sion vehicle with all four wheels on the
ground (flat towing) . Doing so WILL
DAMAGE internal transmission parts
due to lack of transmission lubrication.
cFor emergency towing procedures refer
to “Towing recommended by NISSAN”
in the “In case of emergency” section of
this manual.
Automatic Transmission
To tow a vehicle equipped with an automatic
transmission, an appropriate vehicle dollyMUST
be placed under the towed vehicle’s drive
wheels.Alwaysfollow the dolly manufacturer’s
recommendations when using their product.
Manual Transmission
cAlways tow with the manual transmission in
Neutral.
cAfter towing 500 miles (805 km) , start and
idle the engine with the transmission in Neu-
tral for two minutes. Failure to idle the engine
after every 500 miles (805 km) of towing
may cause damage to internal transmission
parts.DOT (Department of Transportation) Quality
Grades: All passenger car tires must conform to
federal safety requirements in addition to these
grades.
Quality grades can be found where applicable on
the tire sidewall between tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature A
Treadwear
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course. For example, a tire graded
150 would wear one and one-half (1 1/2) times
as well on the government course as a tire graded
100. The relative performance of tires depends
upon the actual conditions of their use, however,
and may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction AA, A, B and C
The traction grades, from highest to lowest, are
AA, A, B, and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-
crete. A tire marked C may have poor traction
performance.
UNIFORM TIRE QUALITY GRADING
Technical and consumer information9-21
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X

If you believe that your vehicle has a de-
fect which could cause a crash or could
cause injury or death, you should immedi-
ately inform the National Highway Traffic
Safety Administration (NHTSA) in addi-
tion to notifying NISSAN.
If NHTSA receives similar complaints, it
may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot be-
come involved in individual problems be-
tween you, your dealer, or NISSAN.
To contact NHTSA, you may call the Ve-
hicle Safety Hotline toll-free at 1-888-
327-4236 (TTY: 1-800-424-9153); go
tohttp://www.safercar.gov; or write to:
Administrator, NHTSA, 400 Seventh
Street, SW., Washington, DC 20590.
You can also obtain other information
about motor vehicle safety from
http://www.safercar.gov.
You may notify NISSAN by contacting our
Consumer Affairs Department, toll-free, at
1-800-NISSAN-1.Due to legal requirements in some states and
Canadian Provinces, your vehicle may be re-
quired to be in what is called the “ready condi-
tion” for an Inspection/Maintenance (I/M) test of
the emission control system.
The vehicle is set to the “ready condition” when it
is driven through certain driving patterns. Usually,
the ready condition can be obtained by ordinary
usage of the vehicle.
If a powertrain system component is repaired or
the battery is disconnected, the vehicle may be
reset to a “not ready” condition. Before taking the
I/M test, check the vehicle’s
inspection/maintenance test readiness condi-
tion. Turn the ignition switch ON without starting
the engine. If the Malfunction Indicator Light
(MIL) comes on steady for 20 seconds and then
blinks for 10 seconds , the I/M test condition is
9not ready9. If the MIL does not blink after 20
seconds, the I/M test condition is9ready.9If the
MIL indicates the vehicle is in a9not ready9con-
dition, drive the vehicle through the following
pattern to set the vehicle to the ready condition. If
you cannot or do not want to perform the driving
pattern, a NISSAN dealer can conduct it for you.WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic con-
ditions and obey all traffic laws.
1. Start the engine when the engine coolant
temperature gauge needle points to C. Al-
low the engine to idle until the gauge needle
points between the C and H (normal oper-
ating temperature) .
2. Accelerate the vehicle to 55 MPH (88
km/h) , then quickly release the accelerator
pedal completely and keep it released for at
least 10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 - 60 MPH (86 - 96 km/h) for at least 9
minutes.
4. Stop the vehicle.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 through 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 min-
utes.
REPORTING SAFETY DEFECTS (US
only)READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST
Technical and consumer information9-23
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/21/05Ðskoniecz
X

8. Stop the vehicle. Place the transmission se-
lector lever in the P (Park) or N (Neutral)
position.
9. Turn the engine off.
10. Repeat steps1-8atleast one more time.
If steps 1 through 7 are interrupted, repeat the
preceding step. Any safe driving mode is accept-
able between steps. Do not stop the engine until
step 7 is completed.Your vehicle is equipped with a variety of comput-
ers that monitor and control a number of systems
to optimize performance and help service techni-
cians with diagnosis and repair. Depending on
the equipment on your vehicle, some of the com-
puters monitor emission control systems, braking
systems, engine systems, transmission systems,
tire pressure systems, and airbag systems. Some
data about vehicle operation may be stored in the
computers for use during servicing. Other data
may be stored if a crash event occurs. For ex-
ample, air bag readiness, air bag performance,
and seat belt use by the driver or passenger may
be recorded, depending on vehicle equipment.
These types of systems are sometimes called
Event Data Recorders.
Special equipment can be used to access the
electronic data that may be stored in the vehicle’s
computers (sounds are not recorded) . NISSAN
and NISSAN dealers have equipment to access
some of this data; others may also have this
equipment. The data may be retrieved during
routine vehicle servicing or for special research. It
might also be accessed with the consent of the
vehicle owner or lessee, in response to a request
by law enforcement, or as otherwise required or
permitted by law.A genuine NISSAN Service Manual is the best
source of service and repair information for your
vehicle. Filled with wiring diagrams, illustrations
and step-by-step diagnostic and adjustment pro-
cedures, this manual is the same one used by the
factory-trained technicians working at NISSAN
dealerships. Also available are genuine NISSAN
Owner’s Manuals, and genuine NISSAN Service
and Owner’s Manuals for older NISSAN models.
For USA
For current pricing and availability of genuine
NISSAN Service Manualsfor the 2000 model
year and later contact:
Tweddle Litho Company
1-800-450-9491
www.nissan-techinfo.com
For current pricing and availability of genuine
NISSAN Service Manualsfor the 1999 model
year and prior, see a NISSAN dealer, or contact:
Resolve Corporation
20770 Westwood Road
Strongsville, OH 44136
1-800-247-5321
For current pricing and availability of genuine
NISSAN Owner’s Manualsfor this model year
and prior, see a NISSAN dealer, or contact:
EVENT DATA RECORDERS OWNER’S MANUAL/SERVICE
MANUAL ORDER INFORMATION
9-24Technical and consumer information
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X

10 Index
A
Active head restraint...............1-8
Air bag (See supplemental restraint system). .1-34
Air bag system
Front (See supplemental front impact air
bag system).................1-41
Air bag warning light...........1-49, 2-13
Air cleaner housing filter............8-21
Air conditioner
Air conditioner operation..........4-15
Air conditioner service...........4-22
Air conditioner specification label.....9-11
Air conditioner system refrigerant and oil
recommendations..............9-6
Heater and air conditioner
controls................4-11, 4-20
Servicing air conditioner..........4-22
Air flow charts..................4-16
Alarm system
(See vehicle security system).........2-16
Anchor point locations.............1-26
Antenna.....................4-41
Anti-lock brake system (ABS).........5-19
Anti-lock brake warning light..........2-11
Armrests.....................1-7
Audible reminders................2-15
Audio system..................4-23
AM-FM-SAT radio with compact disc
(CD) changer................4-35
Compact Disc (CD) changer.......4-38FM-AM radio with compact disc (CD)
changer...................4-30
FM-AM radio with compact disc (CD)
player....................4-25
Radio....................4-23
Autolight switch.................2-22
Automatic
Automatic power window switch.....2-39
Automatic transmission fluid (ATF). . . .8-13
Automatic transmission position indicator
light.....................2-14
Driving with automatic transmission.....5-7
Transmission selector lever lock
release....................5-10
B
Battery......................8-17
Charge warning light............2-12
Before starting the engine............5-6
Belts (See drive belts).............8-19
Booster seats..................1-29
Brake
Anti-lock brake system (ABS).......5-19
Brake booster................8-26
Brake fluid..................8-15
Brake light (See stop light).........8-32
Brake pedal.................8-25
Brake system................5-18
Brake warning light.............2-12
Brake wear indicators........2-15, 8-26Parking brake check............8-25
Parking brake operation..........5-14
Self-adjusting brakes............8-26
Break-in schedule................5-16
Brightness control
Instrument panel..............2-24
Brightness/Contrast button..........4-10
Control panel buttons...........4-10
Bulb check/instrument panel..........2-11
Bulb replacement................8-32
C
Capacities and recommended
fuel/lubricants...................9-2
Car phone or CB radio.............4-41
Cargo (See vehicle loading information) . . .9-12
CD care and cleaning.............4-40
CD changer (See audio system)........4-38
Child restraint with top tether strap......1-25
Child restraints.......1-11, 1-12, 1-17, 1-24
Precautions on child restraints . . .1-17, 1-29
Top tether strap anchor point locations . .1-26
Child safety rear door lock............3-5
Chimes, audible reminders...........2-15
Cigarette lighter and ashtray..........2-29
Cleaning exterior and interior..........7-2
Clock............4-26, 4-30, 4-36, 4-40
(models with navigation system)......4-8
Clock set
Control panel buttons............4-8
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X

Clutch
Clutch fluid.................8-16
C.M.V.S.S. certification label..........9-10
Cold weather driving..............5-21
Console box...................2-33
Control panel buttons..............4-2
Controls
Heater and air conditioner
controls................4-11, 4-20
Coolant
Capacities and recommended
fuel/lubricants.................9-2
Changing engine coolant..........8-9
Checking engine coolant level........8-8
Engine coolant temperature gauge.....2-8
Corrosion protection...............7-5
Cruise control..................5-14
Cup holders...................2-32
D
Daytime running light system
(Canada only)..................2-24
Defroster switch
Rear window and outside mirror defroster
switch....................2-20
Dimensions and weights.............9-8
Dimmer switch for instrument panel......2-24
Display controls (see control panel buttons) . .4-2
Door locks....................3-3
Door open warning light............2-12
Drive belts....................8-19
Driving
Cold weather driving............5-21
Driving with automatic transmission.....5-7Driving with manual transmission.....5-11
Precautions when starting and driving . . .5-2
E
Economy - fuel.................5-16
Emission control information label.......9-11
Emission control system warranty.......9-22
Engine
Before starting the engine..........5-6
Capacities and recommended
fuel/lubricants.................9-2
Changing engine coolant..........8-9
Changing engine oil............8-10
Changing engine oil filter..........8-12
Checking engine coolant level........8-8
Checking engine oil level..........8-9
Engine compartment check locations. . . .8-8
Engine coolant temperature gauge.....2-8
Engine cooling system............8-8
Engine oil...................8-9
Engine oil and oil filter recommendation . .9-5
Engine oil pressure warning light.....2-12
Engine oil viscosity..............9-5
Engine serial number............9-10
Engine specifications.............9-7
Starting the engine..............5-6
Engine oil pressure gauge............2-9
English/Metric button..............4-8
Control panel buttons............4-8
ENTER button..................4-2
Enter button
Control panel buttons............4-2
Event data recorders..............9-24
Exhaust gas (Carbon monoxide)........5-2Eyeglass case..................2-31
F
Flashers
(See hazard warning flasher switch)......2-26
Flat tire......................6-2
Floor mat positioning aid.............7-5
Fluid
Automatic transmission fluid (ATF). . . .8-13
Brake fluid..................8-15
Capacities and recommended
fuel/lubricants.................9-2
Clutch fluid.................8-16
Engine coolant................8-8
Engine oil...................8-9
Power steering fluid.............8-15
Window washer fluid............8-16
F.M.V.S.S. certification label..........9-10
Fog light switch.................2-25
Front air bag system
(See supplemental restraint system).....1-41
Front seats....................1-2
Fuel
Capacities and recommended
fuel/lubricants.................9-2
Fuel economy................5-16
Fuel gauge..................2-8
Fuel octane rating..............9-4
Fuel recommendation............9-3
Fuel-filler door and cap...........3-12
Fuel-filler door lock opener lever......3-12
Fuel consumption gauge............2-10
FUEL ECON button...............4-4
10-2
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X

Fuel Econ button
Control panel buttons............4-4
Fuses......................8-26
Fusible links...................8-27
G
Garage door opener, HomeLinkTUniversal
Transceiver...................2-43
Gascap.....................3-12
Gauge
Engine coolant temperature gauge.....2-8
Engine oil pressure gauge..........2-9
Fuel consumption gauge..........2-10
Fuel gauge..................2-8
Odometer...................2-4
Speedometer.................2-4
Tachometer..................2-7
Trip computer.................2-5
Trip odometer.................2-4
Voltmeter..................2-10
General maintenance..............8-2
Glove box....................2-33
Glove box lock.................2-33
Grocery hooks.................2-36
H
Hazard warning flasher switch.........2-26
Head restraints..................1-7
Active head restraint.............1-8
Headlight and turn signal switch........2-21
Headlight control switch............2-21
Heated seats..................2-27Heater
Heater and air conditioner
controls................4-11, 4-20
Heater operation...........4-14, 4-21
HomeLinkTUniversal Transceiver.......2-43
Hood release...................3-9
Horn.......................2-26
I
Ignition switch..................5-4
Immobilizer system..........2-17, 3-2, 5-5
Important vehicle information label.......9-10
In-cabin microfilter...............8-21
Increasing fuel economy............5-16
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders)....................2-11
Inside mirror...................3-15
Instrument brightness control.........2-24
Instrument panel.................2-2
Instrument panel dimmer switch........2-24
Interior light...................2-41
Interior trunk lid release.............3-11
ISOFIX child restraints.............1-24
J
Jump starting...................6-6
K
Key ........................3-2Keyfob battery replacement..........8-29
Keyless entry system
(See remote keyless entry system).......3-5
L
Labels
Air conditioner specification label.....9-11
C.M.V.S.S. certification label........9-10
Emission control information label.....9-11
Engine serial number............9-10
F.M.V.S.S. certification label........9-10
Vehicle identification number (VIN) plate . .9-9
Warning labels (for SRS)..........1-48
LATCH (Lower Anchors and Tethers
for CHildren) System..............1-24
License plate
Installing the license plate.........9-12
Light
Air bag warning light.........1-49, 2-13
Brake light (See stop light).........8-32
Bulb check/instrument panel........2-11
Bulb replacement..............8-32
Charge warning light............2-12
Fog light switch...............2-25
Headlight and turn signal switch......2-21
Headlight control switch..........2-21
Interior light.................2-41
Light bulbs..................8-30
Low washer fluid warning light.......2-13
Passenger air bag and status light.....1-43
Spotlights (See map light).........2-42
Trunk light..................2-43
Warning/indicator lights and audible
reminders..................2-11
10-3
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X

Lights
Map lights..................2-42
Lock
Child safety rear door lock..........3-5
Door locks..................3-3
Fuel-filler door lock opener lever......3-12
Glove box lock...............2-33
Power door locks...............3-4
Trunk lid lock opener lever.........3-10
Low fuel warning light.............2-13
Low washer fluid warning light.........2-13
Luggage (See vehicle loading information) . .9-12
M
Maint (maintenance) button
Control panel buttons............4-4
Maint (Maintenance) button, control panel
display.......................4-4
Maintenance
General maintenance............8-2
Inside the vehicle...............8-3
Maintenance precautions..........8-5
Outside the vehicle..............8-2
Seat belt maintenance...........1-16
Under the hood and vehicle.........8-4
Malfunction indicator light...........2-14
Manual front seat adjustment..........1-2
Map lights....................2-42
Map pocket...................2-30
Meters and gauges................2-3
Instrument brightness control.......2-24
Mirror
Inside mirror.................3-15
Outside mirrors...............3-15Vanity mirror.................3-14
Multi-remote control system
(See remote keyless entry system).......3-5
N
NISSAN vehicle immobilizer
system................2-17, 3-2, 5-5
O
Octane rating (See fuel octane rating).....9-4
Odometer.....................2-4
Oil
Capacities and recommended
fuel/lubricants.................9-2
Changing engine oil............8-10
Changing engine oil filter..........8-12
Checking engine oil level..........8-9
Engine oil...................8-9
Engine oil and oil filter recommendation . .9-5
Engine oil viscosity..............9-5
Outside mirrors.................3-15
Overheat
If your vehicle overheats...........6-8
Owner’s manual order form..........9-24
Owner’s manual/service manual order
information....................9-24
P
Parking
Parking brake check............8-25Parking brake operation..........5-14
Parking/parking on hills...........5-17
Power
Power door locks...............3-4
Power outlet.................2-28
Power rear windows............2-39
Power steering fluid.............8-15
Power steering system...........5-18
Power windows...............2-38
Rear power windows............2-39
Precautions
Maintenance precautions..........8-5
Precautions on child restraints . . .1-17, 1-29
Precautions on seat belt usage.......1-9
Precautions on supplemental restraint
system....................1-34
Precautions when starting and driving . . .5-2
PREV button...................4-3
Prev button
Control panel buttons............4-3
Programmable features...........4-3, 4-6
Push starting...................6-8
R
Radio
Car phone or CB radio...........4-41
Compact Disc (CD) changer.......4-38
FM-AM radio with compact disc (CD)
changer...................4-30
FM-AM radio with compact disc (CD)
player....................4-25
Readiness for inspection maintenance (I/M)
test........................9-23
Rear power windows..............2-39
10-4
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X

Rear seat.....................1-6
Rear window and outside mirror defroster
switch......................2-20
Recorders
Event data..................9-24
Refrigerant recommendation..........9-6
Registering your vehicle in another country. . .9-9
Remote keyless entry system..........3-5
Reporting safety defects (US only)......9-23
S
Safety
Child safety rear door lock..........3-5
Child seat belts...........1-17, 1-29
Reporting safety defects (US only). . . .9-23
Seat adjustment
Front manual seat adjustment........1-2
Front power seat adjustment........1-4
Rear seat adjustment.............1-6
Seat belt
Child safety.................1-11
Infants and small children.........1-12
Injured Person................1-13
Larger children...............1-12
Precautions on seat belt usage.......1-9
Pregnant women..............1-13
Seat belt extenders.............1-16
Seat belt maintenance...........1-16
Seat belts...................1-9
Shoulder belt height adjustment......1-15
Three-point type with retractor.......1-13
Seat belt warning light.............2-13
Seatback pockets................2-31Seats
Adjustment..................1-2
Front seats..................1-2
Heated seats................2-27
Manual front seat adjustment........1-2
Rear seat...................1-6
Security system (NISSAN vehicle immobilizer
system) , engine start.........2-17, 3-2, 5-5
Self-adjusting brakes..............8-26
Service manual order form...........9-24
Servicing air conditioner............4-22
Setting button
SETTING button...............4-6
Shift lock release................5-10
Shifting
Automatic transmission...........5-8
Manual transmission............5-12
Shoulder belt height adjustment........1-15
Spark plug replacement............8-20
Speedometer...................2-4
Spotlights (See map light)...........2-42
SRS warning label...............1-48
Starting
Before starting the engine..........5-6
Jump starting.................6-6
Precautions when starting and driving . . .5-2
Push starting.................6-8
Starting the engine..............5-6
Startup Screen
Control panel buttons............4-3
Startup screen display..............4-3
Steering
Power steering fluid.............8-15
Power steering system...........5-18
Stop light....................8-32
Storage.....................2-30Storage tray...................2-35
Sunglasses case................2-31
Sunglasses holder...............2-31
Sunroof.....................2-40
Supplemental air bag warning light . . .1-49, 2-13
Supplemental front impact air bag system . .1-41
Supplemental restraint system
Information and warning labels.......1-48
Precautions on supplemental restraint
system....................1-34
Supplemental restraint system
(Supplemental air bag system).........1-34
Switch
Autolight switch...............2-22
Automatic power window switch.....2-39
Fog light switch...............2-25
Hazard warning flasher switch.......2-26
Headlight and turn signal switch......2-21
Headlight control switch..........2-21
Ignition switch................5-4
Power door lock switch...........3-4
Rear window and outside mirror defroster
switch....................2-20
Traction control system (TCS) off
switch....................2-28
Turn signal switch..............2-25
Windshield wiper and washer switch . . .2-19
T
Tachometer....................2-7
Temperature gauge
Engine coolant temperature gauge.....2-8
Theft (NISSAN vehicle immobilizer system) ,
engine start..............2-17, 3-2, 5-5
10-5
ZREVIEW COPYÐ2006 Altima(l30)
Owners ManualÐUSA_English(nna)
09/08/05Ðdebbie
X
