2006 MITSUBISHI LANCER IX Service Manual

Rear wiper motor removal steps
•Tailgate trim lower (Refer to GROUP
52A, Tailgate trim
P.52A-21.)
•Tailgate waterproof film (Refer to
GROUP 42, Tailgate
P.42-48.)
3.Rear wiper motor assembly
Rear washer nozzle removal steps
•High-mounted stop lamp assembly
(Refer to GROUP 54A, High-mounted
stop lamp
P.54A-84.)
4.Rear washer nozzle
Washer hose removal steps
•Front scuff plate, rear scuff plate, cowl
side trim and quarter trim (Refer to
GROUP 52A, Trims
P.52A-13.)
•Tailgate lower trim, tailgate proof film
(Refer to GROUP 52A, Tailgate trim
P.52A-21.)
•High-mounted stop lamp assembly
(Refer to GROUP 54A, High-mounted
stop lamp
P.54A-84.)
5.Rear washer hose
REAR WIPE R AN D W A SHER
EXTERIOR51-37
NOTE: For re moval a nd in st allation of the wiper an d
washer switch, refer to GROUP 54A, Colu mn switch
P.5 4 A - 89.
INSTALLA T ION SER VICE POINT S
>>A<< REAR WIPER ARM AND BLADE
ASSEMBL
Y INST ALLA TION
AC304536
A
AC
End of tailgate glass
Before inst alling the rear wiper arm and blad e
assembly
, ope rate the rear wip e r mo tor so that th e
motor stop
s at the predete r min ed p a rk position .
Inst
all the re ar wipe arm a nd blade assembly and
adjust the
rear wipe r blad e positio n so t hat the blad e
end stop
s at the pre determined positio n (st anda rd
position
) .
St andard va lue (A): 42 ± 5 mm
>>B<< W I PER BLADE INST ALLA TION
AC101090AD
Wiper blade Backing
Backing A
A
Section A – A
Wiper
blade Backing
CAUTION
Use a curved backing like that shown for the
backing of a wiper blade to ensure sustained
wiper wiping performance.
INSPECTION
M1511008600193
REAR WIPER MOTOR CHECK
AB304538
1234
1234
1234
AB
(A) Operation check
(B) Stop position check
Inspect the rear wiper motor is conducted by remov-
ing the harness connector with the motor attached to
the vehicle.
Wiper Motor Operation
Connect the battery to the rear wiper motor as shown
in the illustration (A) and check the motor operation.
Wiper Motor at Stop Position Operation
1. Connect the battery to the rear wiper motor as
shown in the illustration (A).

REAR WIPER AND WASHER
EXTERIOR51-38
2. Disconnect the battery cable from the rear windshield wiper motor while it is turning and then
check to see that the motor stops.
3. Re-connect the battery as shown in Figure (B).
4. Check to see that the rear windshield wiper motor runs and then stops at the automatic stop
position.
REAR WASHER MOTOR CHECK
1
2
AC005900
1.Remo ve th e rear washer t ank assembly with th e
wash er hose att a ched. T hen fill t he wash er t ank
with wa ter .
2.Check to see t hat t he wate r is vigor ously spra yed
when conn ecting the positive batt e ry te rmin al to
termina l number 2 and te rmin al nu mber 1 to th e
neg ative batt e ry te rmin al.
REAR WA SHER FLUI D EJECTION CHECK
CAUTION
Take care not to damage the nozzle when insert-
ing the flat-tipped screwdriver into it.
AC304544AC
Unit: mm
57 84 125
6
Section A – A
A
A
High-mounted
stop lamp Rear washer nozzle
Flat-tipped screwdriverCeramic line terminal
Washer nozzle
perpendicular
For the vertical aiming of washer nozzle, insert the
flat-tipped screwdriver into the nozzle and move it to
the arrow direction.
REAR WIPER AND WASHER SWITCH
CHECK
1
6
8
11 10 9 7
5 4
3
2
AC000417
Check continuity between the switch terminals.
Switch positionTester
connectionSpecified
condition
OFF4 − 6, 5 − 6Open circuit
Rear wiper switch4 − 6Less than 2
ohms
Rear washer
switch5 − 6

HEADLAMP WASHER
EXTERIOR51-39
HEADLAMP WASHER
TROUBLESHOOTINGM1511000700356
The headlamp washer is controlled by the Smart Wir-
ing System (SWS). For troubleshooting, refer to
GROUP 54B, Troubleshooting
P.54B-15 or GROUP
54C, Troubleshooting P.54C-4.
HEADLAMP WASHER
REMOVAL AND INSTALLATION
M1511009700063
AC304608AB
10N
2
4
56
8
7
1
9
11
9
1
10N
4.9 ± 0.7 N·m
4.9 ± 0.7 N·m
3
Removal steps
•Washer fluid draining
1.Headlamp washer hose connection
2.Under cover side panel (RH)
3.Splash shield mounting clip (RH)
4.Headlamp washer motor
connection
5.Headlamp washer joint
6.Headlamp washer hose
7.Headlamp washer motor
Removal steps (Continued)

HEADLAMP WASHER
EXTERIOR51-40
INSPECTION
M1511009800082
HEADLAMP WASHER MOTOR CHECK
AC304136AB
12
1.Remove the he adla m p washer motor connector .
2.Check to se e tha t the wat e r is vigorou sly sp rayed
when con nect i ng th e positive ba ttery terminal to
te rmin al nu mber 1 and terminal n u mb er 2 to the
n egative ba ttery terminal.
8.Headlamp wa s h er gasket
•Fr o n t b u m p er ( R ef er to P.51-3).
9.Head lam p wa sh er a c tu ator
assembly
10.O-rin g
11.Headlamp w a s h er hose assembly
Remo val st ep s ( C o n tinue d)

MARK
EXTERIOR51-41
MARK
REMOVAL AND INSTALLATIONM1511011801435
AC504923
11 22
3
AC


3
Removal
>>A<<1.Front three-diamond mark (Refer to
P.51-4)
>>A<<2.Rear three-diamond mark
>>A<<3.Lancer mark
INST ALLA T ION SER VICE POINT
>>A<< MARK APPLICA T ION
1.In st allation positio n
Atta ch each ma rk to the po sition shown in the
i
llu strati on.

AC304163

2. Three-diamond mark

Centre line
of vehicleCentre line
of vehicle
Trunk lid
press linePress line
112 mm
53 ± 1 mm
AC
AC304164

3. Lancer mark
Rear combination
lamp terminal
Trunk lid terminalTailgate terminal
33 mm 24 mm 45 ± 1 mm
13 ± 1 mm 19 ± 1 mm

AB
MARK
EXTERIOR51-42
2.
In st allation procedure
(1)U se 3 M A T D Pa rt number 890 6 or eq uivalen t
to clean the mark inst allation surface s on the
body .
CAUTION
When attaching the marks, the ambient tempera-
ture should be 20 − 38°C and the air should be
completely free of dust. If the ambient tempera
-
ture is lower than 20°C, the marks and the places
on the vehicle body where the marks are to be
attached should be heated to 20
− 38°C.
(2) Peel off the protection sheet on the back of the marks to paste it on the installation position.

DOOR MIRROR
EXTERIOR51-43
DOOR MIRROR
GENERAL INFORMATIONM1511000100536
DOOR MIRROR OPERATION
Remote Controlled Mirror Operation
•The mirror on the door mirror moves up/down
and left/right by operating the remote controlled
door mirror switch when the ignition switch is in
the "ON" or "ACC" position.
Heated Door Mirror operation
•The defogger relay switch is activated (ON) by
turning on the A/C-ECU built-in defogger switch
when the ignition switch is in the "ON" position.
When the defogger relay is turned ON, power is
supplied to the defogger and door mirror, and the
heater of the door mirror (heated door mirror)
starts operations. The defogger comes with a
timer function and will automatically turn OFF the
switch approximately 11 minutes after the defog
-
ger switch is turned ON. The heated door mirror
operations are also terminated along with the
defogger, at this time.
SERVICE SPECIFICATION
M1511000300347
ItemStandard value
Heated door mirror operation current Ω5.9 − 7.8
SPECIAL TOOL
M1511000601103
ToolNumberNameUse
MB990784
MB990 784Ornament removerRemoval of remote controlled
mirror switch
TROUBLESHOOTING
DIAGNOSIS TROUBLESHOOTING FLOW
M151 1 0146 0016 9
Refe r to GROUP 00 − How to Use T r o ubleshoot-
ing/Inspectio n Service Point s P.00-5.
TR OUBLE SYM PT OM CHARTM151 1 0150 0016 0
SymptomInspection
procedureReference
page
All heated door mirrors do not operate1P.51-44
The right or left heated door mirror does not operate2P.51-45

DOOR MIRROR
EXTERIOR51-44
SYMPTOM PROCEDURES
Inspection Procedure 1: All Heated Door Mirrors do not Operate
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White \
Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Gray R : Red P : Pink V :\
Violet REAR WINDOW
DEFOGGER RELAY
REAR WINDOW
DEFOGGER
REMOTE
CONTROLLED
MIRROR (LH)
REMOTE
CONTROLLED
MIRROR (RH)
MIRROR
HEATER MIRROR
HEATER
NOTELH drive vehicles
RH drive vehicles
COMM
ENT S ON TROUBL E SYMPT O M
The heated do or mirrors shou ld works for approxi-
mately 11 minu tes whe n the re ar defo gger switch is
turned o
n . If th e mirror hea ter doe s no t work fo r the
specified period, th
e defo gger relay circuit (heated
door mirror p
o wer sup p ly circuit) may be d e fective .
PROBABLE CAUSE
•Damaged h a rness wire and connector
DIAGNOSIS PROCEDURE
STEP 1 . Check the rear wind ow de fogger .
Check that th e rear window def ogger system shou ld
wo
rk normally .
Q:Is t h e che c k r esu lt n o rmal?
YES : Go to S t ep 2 .
NO : Tr oublesh oot the rear win dow defog ger
(Refer to
GROUP 55 ,
T
r oublesh ootin g
P.55B-54).
