GENERAL INFORMATION
MULTIPOINT FUEL INJECTION (MPI) <4A9>13A-7
Throttle position sensor This sensor detects the position of the throttle valve
and inputs it into the engine-ECU or
engine-CVT-ECU . Based on the voltage that
is output by this sensor, the engine-ECU or
engine-CVT-ECU effects throttle valve
feedback control.
Accelerator pedal position sensor This sensor detects the position of the accelerator
and inputs it into the engine-ECU or
engine-CVT-ECU . Based on the voltage that
is output by this sensor, which determines the
accelerator position (and the intention of the driver),
the engine-ECU or engine-CVT-ECU
effects appropriate fuel injection and throttle valve
position controls.
Camshaft position sensorThis sensor detects the top-dead-center (TDC) of the
compression stroke of each cylinder.
Crank angle sensorThis sensor detects the crank angle and inputs it into
the engine-ECU or engine-CVT-ECU .
The engine-ECU or engine-CVT-ECU
effects injector control and other controls in
accordance with the signals received from this
sensor.
Detonation sensorThis sensor, which contains a piezoelectric element,
detects the vibration of the cylinder block that results
from knocking. The engine-ECU or
engine-CVT-ECU detects only the knocking
of the engine from these vibrations, in order to retard
the ignition timing in accordance with the strength of
the knocks.
Alternator FR terminalThis terminal is used for detecting the duty cycle ratio
that energizes the alternator field coil.
Inhibitor switch This is a contact point type switch that inputs a signal
into the engine-CVT-ECU to determine whether the
shift lever is in the neutral position.
Stop lamp switchThis is a contact point type switch that detects how
the brake pedal is depressed.
Actuators
Engine control relayThis relay turns ON and OFF the engine-ECU
or engine-CVT-ECU power circuit.
Throttle valve control servo relayThis relay turns ON and OFF the actuation power
circuit for the throttle valve control servo in the
engine-ECU or engine-CVT-ECU .
InjectorThe injectors inject fuel in accordance with the
injection signals received from the engine-ECU
or engine-CVT-ECU .
Ignition coil (with power transistor)Applies ignition coil primary current intermittently in
accordance with the ignition signals received from
the engine-ECU or engine-CVT-ECU ,
in order to generate high voltage for ignition.
Name Function

GENERAL INFORMATION
MULTIPOINT FUEL INJECTION (MPI) <4G1>13B-6
Camshaft position sensorThis sensor detects the top-dead-center (TDC) of the
compression stroke of each cylinder.
Crank angle sensorThis sensor detects the crank angle and inputs it into
the engine-ECU. The engine-ECU effects injector
control and other controls in accordance with the
signals received from this sensor.
Detonation sensorThis sensor, which contains a piezoelectric element,
detects the vibration of the cylinder block that results
from knocking. The engine-ECU detects only the
knocking of the engine from these vibrations, in order
to retard the ignition timing in accordance with the
strength of the knocks.
Alternator FR terminalThis terminal is used for detecting the duty cycle ratio
that energizes the alternator field coil.
Stop lamp switchThis is a contact point type switch that detects how
the brake pedal is depressed.
Actuators
Engine control relayThis relay turns ON and OFF the engine-ECU power
circuit.
Throttle valve control servo relayThis relay turns ON and OFF the actuation power
circuit for the throttle valve control servo in the
engine-ECU.
InjectorThe injectors inject fuel in accordance with the
injection signals received from the engine-ECU.
Ignition coil (with power transistor)Applies ignition coil primary current intermittently in
accordance with the ignition signals received from
the engine-ECU, in order to generate high voltage for
ignition.
Fuel pump relayControls the power supplied to the fuel pump in
accordance with the signals received from the
engine-ECU.
A/C compressor relayControls the operation of the A/C compressor in
accordance with the signals received from the
engine-ECU.
Purge control solenoid valveControls the flow rate of the purge air introduced into
the inlet manifold in accordance with the signals
received from the engine-ECU.
Alternator G terminalControls the amount of current generated by the
alternator in accordance with the signals received
from the engine-ECU.
Cooling fan control relayControls the speed of the cooling fan in accordance
with the signals received from the engine-ECU.
Throttle valve control servoControls the throttle valve position in accordance with
the signals received from the engine-ECU.
ECU
Name Function

GENERAL INFORMATION
ENGINE ELECTRICAL16-2
GENERAL INFORMATION
M2160000100038
The electronic device is basically the same as that in
the conventional 4G1 engine.
The employed alternator is a lightweight type in
which the electronic voltage regulator for detecting
the battery voltage is built.
The employed starter motor is a small planetary gear
reduction drive type.
The employed spark plug is a long reach type with
iridium.
The employed ignition coil is a plug top type in which
the powertrain per cylinder is built.

MANUAL TRANSMISSION
MANUAL TRANSMISSION22-2
MANUAL TRANSMISSION
GENERAL INFORMATIONM2220000100592
Due to the addition of vehicles with M/T, a
"GETRAG" F5MG type transmission has been
adopted.
SPECIFICATIONS
Transmission modelF5MGAF5MGB
Engine model4A94G1
Transmission type5-speed, floor-shift
Transmission gear ratio1st3.3083.538
2nd1.9131.913
3rd1.2581.344
4th0.9431.027
5th0.7630.833
Reverse3.2313.357
Final reduction ratio4.1583.737
Transmission fluidSpecified
lubricantsDia-Queen wide gear oil G-1 SAE 75W-90 API GL-4
Quantity L1.75

TECHNICAL FEATURES
GENERAL00-9
ENGINE
M2000020000579
<4A9>
The newly-developed 4A9 engine has been installed
to realise small-size, light-weight, high-performance,
and better fuel economy with the state-of-the-art
technologies such as the aluminium die-cast cylinder
block, direct attack driven-type DOHC MIVEC, timing
chain-type cam drive, and rear exhaust.
MAJOR SPECIFICATIONS
Item4A91
Total displacement mL1,499
Bore × Stro ke mm75 × 84.8
Compression ratio10.0
Compression chamberPentroof-type
Va l v e t i m i n gIntake openingBTDC 31° − ATDC 19°
Intake closingABDC 21° − ABDC 71°
Exhaust openingBBDC 39°
Exhaust closingATDC 5°
Maximum output kW (PS)/rpm77 (105)/6,000
Maximum torque N⋅m (kg⋅m)/rpm141 (14.4)/4,000
Fuel systemElectronically controlled multipoint fuel injection
Ignition systemElectronic-controlled 4-coil
<4G1>
Based on the 4G1 engine fitted on the existing COLT,
the power performance leading the compact car field
has been secured by Turbocharger.
MAJOR SPECIFICATIONS
Item4G15 (with Intercooler Turbocharger)
Total displacement mL1,468
Bore × Stro ke mm75 × 82.0
Compression ratio9.0
Compression chamberPentroof-type
Va l v e t i m i n gIntake openingBTDC 34° − ATDC 6°
Intake closingABDC 30° − ABDC 70°
Exhaust openingBBDC 50°
Exhaust closingATDC 10°
Maximum output kW (PS)/rpm113 (154)/6,000
Maximum torque N⋅m (kg⋅m)/rpm210 (21.4)/3,500
Fuel systemElectronically controlled multipoint fuel injection
Ignition systemElectronic-controlled 4-coil

TECHNICAL FEATURES
GENERAL00-11
CVT
The F1C1A transmission is adopted for the CVT.
This transmission is basically the same as conven
-
tional transmission.
The ATF warmer (ATF cooler) is adopted.
SPECIFICATIONS
ItemSpecification
Transmission modelF1C1A
Engine model4A91
Torque converterTy p e3-element, 1-stage, 2-phase type
Lock-upProvided
Stall torque ratio2.0
Transmission typeForward automatic continuously variable (steel belt type),
1st in reverse
Gear ratioForward2.319 − 0.445
Reverse2.588
ClutchA pair of multi-plate system
BrakeA pair of multi-plate system
Manual control systemP-R-N-D-Ds-L (smart shift)
FunctionVariable speed controlYe s
Line pressure controlYe s
Direct engagement controlYe s
N-D/N-R controlYe s
Shift pattern controlYe s
Self-diagnosisYe s
FailsafeYe s
Oil pumpTy p eExternal gear pump
ConfigurationBuilt-in (chain drive)
Control methodElectronic control (INVECS-III)

TECHNICAL FEATURES
GENERAL00-14
SUSPENSION
M2000023000460
AC405092AB

Lower arm
Front axle No.1
crossmember Stabilizer bar
Coil spring
Strut assembly
Front axle No.1
crossmember
Lower arm Strut assembly
Coil spring
Stabilizer bar
Shock absorber Coil spring
Torsion beam
and arm assembly
<4A9> <4G1>
•The
MacPherso n Strut suspe nsio n with comp ati-
ble characteristics of high rig idity and lig ht weight
has bee n adopted for the fron t suspension to
realise suf ficien t driving comfort.
•H-shaped to rsion bea m type suspe nsion has
bee n int roduced for t he rear suspension. This
suspe nsion has larg e suspen sion stro ke and pro
-
vides suf ficient driving comfort. With it s comp act
design , spe cio us interior sp ace has been
reserved.

GENERAL INFORMATION
FRONT SUSPENSION33-4
SPECIFICATIONS
SUSPENSION SYSTEM
ItemSpecification
Suspension typeMacPherson strut with coil spring
WHEEL ALIGNMENT
ItemSpecification
Camber − 0 °30'
Caster 4A92°35'
4G12°40'
Kingpin inclination 13°20'
Toe-inAt the centre of tyre tread mm0
Toe-angle (per wheel)0°
COIL SPRING
<4A9>
ItemSpecification
Wire diameter mm12
Average outside diameter mm133 − 149 − 154
Free length mmCVT331
5MT301
<4G1>
ItemSpecification
Wire diameter mm13
Average outside diameter mm133 − 150 − 154
Free length mm300
