2006 MERCEDES-BENZ CLS500 jump start

Contents
DOT, Tire Identification Number
(TIN) ............................................. 327
Maximum tire load ....................... 328
Maximum tire inflation pressure .. 329
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 329
Tire ply material ........................... 331
Tire and loading terminology ........ 332
Rotating tires ............................... 335
Winter driving .................................... 336
Winter tires .................................. 336
Block heater* (Canada only) ........ 337
Snow chains................................. 337
Maintenance ...................................... 339
Maintenance service indicator
message....................................... 339
Calling up the maintenance
service indicator........................... 340
Resetting the maintenance
service indicator........................... 341
Vehicle care ....................................... 342
Cleaning and care of vehicle ........ 342
Practical hints.................................. 351
What to do if … ................................... 352
Lamps in instrument cluster ......... 352
Lamp in center console................. 362
Vehicle status messages in the
multifunction display..................... 363
Where will I find ...? ............................ 398
First aid kit .................................... 398
TIREFIT* ........................................ 398
Spare wheel .................................. 398
Vehicle tool kit .............................. 399
Luggage box ................................. 401
Unlocking/locking in an emergency... 402
Unlocking the vehicle.................... 402
Locking the vehicle ....................... 403
Fuel filler flap emergency release . 404
Manually unlocking the gear
selector lever ................................ 404
Opening/closing in an emergency ..... 406
Power tilt/sliding sunroof ............. 406
Resetting activated head restraints .... 407
Replacing SmartKey batteries ............ 408
SmartKey ...................................... 408
SmartKey with KEYLESS-GO* ....... 409Replacing bulbs .................................. 411
Bulbs............................................. 411
Replacing bulbs for front lamps .... 414
Replacing bulbs for rear lamps ..... 416
Replacing wiper blades ...................... 417
Removing wiper blades ................. 417
Installing wiper blades .................. 418
Flat tire............................................... 419
Preparing the vehicle .................... 419
Sealing tires with TIREFIT ............. 419
Mounting the spare wheel ............ 423
MOExtended system* ................... 429
Battery ............................................... 431
Disconnecting the battery ............ 432
Removing the battery ................... 433
Charging and reinstalling the
battery .......................................... 433
Reconnecting the battery ............. 434
Jump starting...................................... 435
Towing the vehicle.............................. 437
Installing towing eye bolt .............. 439
Fuses.................................................. 441
Aids for replacing fuses ................ 441
Main fuse box in passenger
compartment ................................ 442
Fuse box in trunk .......................... 442

37 Getting started
Unlocking
For information on starting the engine us-
ing the SmartKey, see “Starting with the
SmartKey” (
page 50).SmartKey with KEYLESS-GO*
Pressing the KEYLESS-GO start/stop but-
ton on the gear selector lever corresponds
to turning the SmartKey to the various
starter switch positions.
If you firmly depress the brake pedal dur-
ing pressing KEYLESS-GO start/stop but-
ton, the engine starts automatically.
KEYLESS-GO start/stop button1USA only
2Canada only
The SmartKey with KEYLESS-GO must be
located in the vehicle.
Make sure the gear selector lever is set
toP.

Do not depress the brake pedal.
!If the SmartKey can still not be turned,
the battery may not be sufficiently
charged.

Check the battery and charge it if
necessary (
page 433).


Get a jump start (
page 435).
To prevent accelerated battery dis-
charge or a completely discharged
battery, always remove the SmartKey
from the starter switch when the en-
gine is not in operation.
iThe function of the SmartKey overrules
the KEYLESS-GO function.

51 Getting started
Driving
Starting difficulties
If the engine does not start as described,
carry out the following steps:
If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.

If you are starting the engine with
KEYLESS-GO: Close any doors that
may be open to allow for better detec-
tion of the SmartKey with
KEYLESS-GO.
Or:
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO.

Repeat the starting procedure
(page 49). Remember that extended
starting attempts can drain the battery.

Get a jump start (
page 435).If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.

Notify an authorized Mercedes-Benz
Center.
Parking brake
1Release handle
2Parking brake pedal

Release the parking brake pedal by
pulling on handle1.
The warning lamp; (USA only) or
3(Canada only) in the instrument
cluster goes out.Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could release the parking brake, which
could result in an accident and/or serious
injury.

266 Controls in detailUseful featuresThe Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest
Mercedes-Benz Center. For services such
as labor and/or towing, charges may ap-
ply. Refer to the Roadside Assistance Man-
ual for more information.
These programs are only available in the
USA:

Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.
iThe indicator lamp on the Roadside
Assistance button• remains illumi-
nated in red for approximately
10 seconds during the system
self-check after switching on the igni-
tion (together with the SOS button and
the Information button¡).
See system self-check (
page 263) if
the indicator lamp does not come on in
red or stays on longer than
approximately 10 seconds.
If the indicator lamp on the Roadside
Assistance button• is flashing
continuously and there was no voice
connection to the Response Center
established, then the Tele Aid system
could not initiate a Roadside Assis-
tance call (e.g. the relevant cellular
phone network was not available). The
message
Call failed
appears in the
multifunction display.
Roadside Assistance calls can be
terminated using thet button on
the multifunction steering wheel or the
END Button on the COMAND System.

351 Practical hints
What to do if …
Where will I find ...?
Unlocking/locking in an emergency
Opening/closing in an emergency
Resetting activated head restraints
Replacing SmartKey batteries
Replacing bulbs
Replacing wiper blades
Flat tire
Battery
Jump starting
Towing the vehicle
Fuses

431 Practical hints
Battery
Battery
Your vehicle is equipped with two batter-
ies:

Auxiliary battery (back-up battery; sta-
bilizes the electrical system if the main
battery is discharged; located in engine
compartment).


Main battery (starter and electrical
consumers; located in the trunk under
the luggage box).

Remove the luggage box (
page 401).
1Positive terminal cover
2Negative terminal
Warning!
G
Jump starting must only be done using the
main battery in the trunk.Warning!
G
Failure to follow these instructions can
result in severe injury or death.
Observe all safety instructions and precau-
tions when handling automotive batteries
(page 299).
Never lean over batteries while connecting,
you might get injured.
Battery fluid contains sulfuric acid. Do not
allow this fluid to come in contact with eyes,
skin or clothing. In case it does, immediately
flush affected area with water and seek
medical help if necessary.
A battery will also produce hydrogen gas,
which is flammable and explosive. Keep
flames or sparks away from battery, avoid
improper connection of jumper cables,
smoking etc.!Never loosen or detach battery termi-
nal clamps while the engine is running
or the SmartKey is in the starter switch.
Otherwise the alternator and other
electronic components could be se-
verely damaged.
Have the battery checked regularly by
an authorized Mercedes-Benz Center.
Refer to Maintenance Booklet for main-
tenance intervals or contact your
authorized Mercedes-Benz Center for
further information.

435 Practical hints
Jump starting
Jump starting
If the battery is discharged, the engine can
be started with jumper cables and the bat-
tery of another vehicle. Observe the follow-
ing:

Jump starting should only be performed
when the engine and catalytic convert-
er are cold.


Do not start the engine if the battery is
frozen. Let the battery thaw out first.


Only jump start from batteries with the
same voltage rating (12 V). Jump start-
ing with a more powerful battery could
damage the vehicle’s electrical system,
which will not be covered by the
Mercedes-Benz Limited Warranty.


Use only jumper cables with sufficient
cross-section and insulated terminal
clamps.
Warning!
G
Failure to follow these directions will cause
damage to the electronic components, and
can lead to a battery explosion and severe
injury or death.
Never lean over batteries while connecting
or jump starting, you might get injured.
Battery fluid contains sulfuric acid. Do not
allow this fluid to come in contact with eyes,
skin or clothing. In case it does, immediately
flush affected area with water, and seek
medical help if necessary.
A battery will also produce hydrogen gas,
which is flammable and very explosive. Keep
flames or sparks away from battery, avoid
improper connection of jumper cables,
smoking, etc.
Attempting to jump start a frozen battery
can result in it exploding, causing personal
injury.
Read all instructions before proceeding.
!Do not tow-start the vehicle.!Jump starting must only be performed
on the main battery installed in the
trunk.
Avoid repeated and lengthy starting
attempts.
Do not attempt to start the engine
using a battery quick charge unit.
If the engine does not run after several
unsuccessful starting attempts, have it
checked at the nearest authorized
Mercedes-Benz Center.
Excessive unburned fuel generated by
repeated failed starting attempts may
damage the catalytic converter and
may present a fire risk.
Make sure the jumper cables do not
have loose or missing insulation.
Make sure the cable clamps do not
touch any other metal part while the
other end is still attached to a battery.

436 Practical hintsJump starting

Always make sure the jumper cables
are not on or near pulleys, fans or other
parts that move when the engine is
started or running.
The main battery is located in the trunk un-
derneath the luggage box (
page 401).

Make sure the two vehicles do not
touch.

Turn off all electrical consumers.

Apply parking brake.

Shift gear selector lever to positionP.

Connect positive terminals1 and3
of the batteries with the jumper cable.
Clamp cable to charged battery3
first.
1Positive terminal of discharged battery
2Negative terminal of discharged bat-
tery
3Positive terminal of charged battery
4Negative terminal of charged battery

Start engine of the vehicle with the
charged battery and run at idle speed.

Connect negative terminals4 and2
of the batteries with the jumper cable.
Clamp cable to charged battery4
first.

Start the engine of the disabled vehi-
cle.
Now you can again turn on the electrical
consumers. Do not turn on the lights under
any circumstances.

Remove the jumper cables first from
negative terminals2 and4 and then
from positive terminals1 and3.
Now you can turn on the lights.

Have the battery checked at the near-
est authorized Mercedes-Benz Center.
Warning!
G
Keep flames or sparks away from battery.
Do not smoke.
Observe all safety instructions and precau-
tions when handling automotive batteries
(page 299).
!Never invert the terminal connections!
iThe message
Malfunction - electric
consumers switched off
may appear
in the instrument cluster. It will disap-
pear as soon as the battery is suffi-
ciently charged.
