2006 MERCEDES-BENZ CLS500 wiper fluid

54 Getting startedDrivingThe combination switch resets automati-
cally after major steering wheel move-
ments.
Windshield wipers
The combination switch is located on the
left of the steering column.Combination switch1Single wipe
Wiping with windshield washer fluid
2Switching on windshield wipers
Switch on the ignition (
page 36).Switching on windshield wipers

Turn the combination switch to the
desired position depending on the
intensity of the rain.
0Windshield wipers off
IIntermittent wiping (interval depen-
dent on wetness of windshield)
IINormal wiper speed
IIIFast wiper speed
iTo signal minor directional changes
such as changing lanes, press combi-
nation switch only to point of resis-
tance and release. The corresponding
turn signals will flash three times.
!Do not operate the wipers when the
windshield is dry. Dust that accumu-
lates on a windshield might scratch the
glass and/or damage the wiper blades
when wiping occurs on a dry wind-
shield. If it is necessary to operate the
wipers in dry weather conditions, al-
ways operate the wipers with wind-
shield washer fluid (
page 55).


55 Getting started
Driving
Intermittent wiping
Intermittent wiping interval is dependent
on wetness of windshield.
Turn the combination switch to
positionI.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.Single wipe

Press the combination switch briefly in
direction of arrow1.
The windshield wipers wipe one time
without washer fluid.
Wiping with windshield washer fluid

Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system*”
(
page 300).
!Do not leave windshield wipers in inter-
mittent setting when the vehicle is tak-
en to an automatic car wash or during
windshield cleaning. Windshield wipers
will operate in the presence of water
sprayed on the windshield, and wind-
shield wipers may be damaged as a
result.
iIntermittent wiping is interrupted when
the vehicle is at a standstill and a front
door is opened. This protects persons
getting into or out of the vehicle from
being sprayed.
Intermittent wiping will be continued
when

all doors are closed
and


the gear selector lever is in
positionD orR
or


the wiper setting is changed using
the combination switch

191 Controls in detail
Good visibility
Good visibility
For information on windshield wipers, see
“Windshield wipers” (
page 54).
Headlamp cleaning system*
The button is located on the left side of the
dashboard.
1Headlamp washer button
Switch on the ignition (
page 36).

Press button1.
The headlamps are cleaned with a
high-pressure water jet.For more information on filling up the
washer reservoir, see the “Operation” sec-
tion (
page 300).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 44).
Auto-dimming mirrors
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when


the ignition is switched on
and


incoming light from headlamps falls on
the sensor in the interior rear view mir-
ror.
The rear view mirrors will not react if


reverse gear is engaged


the interior lighting is turned on
iThe headlamps are cleaned automati-
cally if:

the lights are switched on
and


the windscreen is wiped with wind-
screen washer fluid fifteen times
If the ignition is switched off, the auto-
matic headlamp cleaning mode is reset
and counting is resumed from 0.

496 IndexW
Warning lamps see Lamps, indicator and
warning
Warning sounds
Distance warning function* 235
Distronic* 229
Parking brake 52
Parktronic* 245
Seat belt telltale 70
Warranty coverage 445
Washing the vehicle 342
Wear pattern, Tires 335
Weights, Vehicle 460
Wheel
Change 423
Removing 425
Tightening torque 429
Wheels, Tires and 301
Window curtain air bags 70
Windows see Power windows
Windows, cleaning 347Windshield
Cleaning wiper blades 347
Defogging 206
Windshield washer fluid 300
Messages in display 396
Refilling 300
Wiping 55
Windshield wipers 54
Fast wiper speed 54
Intermittent wiping 54
Replacing wiper blades 417, 418
Wiping with windshield washer
fluid 55
Winter driving
Block heater* (Canada only) 337
Snow chains 337
Tires 336
Winter driving instructions 285
Winter tires 336
Wood trims, cleaning 350X
Xenon headlamps*
Bi-Xenon* 472
