2006 MERCEDES-BENZ C55AMG rear view mirror

41 Getting started
Adjusting
The buttons are located above the exterior
lamp switch.
1Adjustment button
2Passenger-side exterior rear view
mirror button
3Driver’s side exterior rear view mirror
button
Switch on the ignition (page 33).
Press button3 for the driver’s side
exterior rear view mirror or button2
for passenger-side exterior rear view
mirror.
Push adjustment button1 up, down,
left, or right according to the desired
setting.For more information, see “Rear view mir-
rors” (
page 169).
!
If an exterior rear view mirror was
forcibly pushed forward (hit from the
rear) or forcibly pushed rearward (hit
from the front), reposition it by
applying firm pressure until it snaps
into place. The mirror housing is now
properly positioned and you can adjust
the mirror in the usual manner.
i
At low ambient temperatures, the
exterior rear view mirrors will be
heated automatically.
i
The memory function (page 111) lets
you store the settings for the exterior
rear view mirrors together with the set-
tings for the steering wheel and the
driver’s seat position.

111 Controls in detail
Memory function
Memory function
Prior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach and comfort. The head re-
straint should also be adjusted for proper
height. See also the section on air bags
(
page 61) for proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small chil-
dren should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian Mo-
tor Vehicle Safety Standards 213
and 210.2.With the memory function you can store up
to three different settings.
The following settings are stored for the
driver’s seat when using the buttons on the
driver’s door:

Driver’s seat, backrest and head
restraint position

Steering wheel position

Exterior rear view mirrorsThe following settings are stored for the
front passenger seat when using the but-
tons (if so equipped depending on vehicle
equipment configuration) on the passen-
ger door:

Front passenger seat, backrest and
head restraint position
Warning!G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.

112 Controls in detail
Memory function
The memory button and memory position
switch are located on the door.
1Memory button
2Memory position switch
Switch on the ignition (page 33).
or
Open the respective door.
Storing positions into memory
Adjust the seat, steering wheel and
exterior rear view mirrors to the
desired position (
page 35).
Turn memory position switch2 to the
desired memory position.
Press memory button1.
Release memory button1 and press
memory position switch2 within
3 seconds.
All settings are stored to the selected
position.
Recalling positions from memory
Turn memory position switch2 to the
desired memory position.
Press and hold memory position
switch2 until the seat, steering wheel
and exterior rear view mirrors have
completely moved to the stored
positions.
!
Do not operate the power seats using
the memory button if the seat backrest
is in an excessively reclined position.
Doing so could cause damage to front
or rear seats.
i
Releasing the memory position switch
stops movement to the stored
positions immediately.

113 Controls in detail
Memory function
Storing exterior rear view mirror
parking position
For easier parking, you can adjust the
passenger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position feature, see “Activating exterior
rear view mirror parking position”
(
page 170).1Memory button
2Adjustment button
3Passenger-side exterior rear view
mirror button
Stop the vehicle in a safe location.
Switch on the ignition (page 33).
Press button3.
The passenger-side exterior rear view
mirror is selected.
Adjust the exterior rear view mirror
with button2 so that you see the rear
wheel and the road curb.
Press memory button1.
Within 3 seconds, press bottom of ad-
justment button2.
The parking position is stored if the
mirror does not move.
i
If the mirror does move, repeat the
above steps. After the setting is stored,
you can move the mirror again.

137 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus. Detailed instructions on making individual
settings can be found on the following
pages.
Instrument clusterTime/DateLightingVehicleConvenience
Select speedometer
display modeTime synchronization with head
unit*Set daytime running lamp
mode (USA only)Set automatic lock-
ingActivate easy-entry/exit
feature
Select languageSet time (hours)Set locator lightingSet parking position for
exterior rear view mirror
Select display (speed
display or outside
temperature) for status
indicatorSet time (minutes)Set night security
illumination
Select automatic time change
(Daylight Saving Time (DST)
summer/Standard time winter)Set interior lighting de-
layed shut-off
Set date (month)
Set date (day)
Set date (year)

148 Controls in detail
Control system
Press buttonj ork repeatedly
until the message
Automatic door lk.
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the automatic central locking
On or Off.Convenience submenu
Access the
Convenience submenu via the
Settings menu. Use the Convenience
submenu to change the settings for a
number of convenience features.
The following functions are available:Activate easy-entry/exit feature
Use this function to activate and
deactivate the easy-entry/exit feature
(
page 39).
FunctionPage
Activate easy-entry/exit feature148
Set parking position for exterior
rear view mirror149
Warning!G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To cancel steering wheel movement, do one
of the following:

Move steering column stalk
(
page 38).

Press memory position switch
(
page 112).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.


149 Controls in detail
Control system
Move the selection marker with
buttonæ orç to the
Convenience submenu.
Press buttonj ork repeatedly
until the message
Easy-entry feature
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the easy-entry feature
On or Off.Set parking position for exterior rear
view mirror
Use the
Mirror set. parking aid function
to select whether the passenger-side
exterior rear view mirror should be turned
downward during parking maneuvers when
reverse gearR is engaged. For additional
information, see “Activating exterior rear
view mirror parking position”
(
page 170).
Move the selection marker with
buttonæ orç to the
Convenience submenu.
Press buttonj ork repeatedly
until the message
Mirror set.
parking aid
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
function
On or Off.

169 Controls in detail
Good visibility
Good visibility
For information on the windshield wipers,
see “Windshield wipers” (
page 50).
Headlamp cleaning system*
The button is located on the left side of the
dashboard.
1Headlamp washer button
Switch on the ignition (page 33).
Press button1.
The headlamps are cleaned with a
high-pressure water jet.For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system*”
(
page 304).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 40).
Auto-dimming rear view mirrors
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when

the ignition is switched on
and

incoming light from headlamps falls on
the sensor in the interior rear view
mirror.
The rear view mirror will not react if

reverse gearR is engaged

the interior lighting is turned on
i
The headlamps will automatically be
cleaned when you have

switched on the headlamps
and

operated the windshield wipers
with windshield washer fluid
15 times
When you switch off the ignition, the
counter resets.
