2006 MERCEDES-BENZ C55AMG ESP

428 Technical data
Engine
ModelC 55 AMG (203.076)1
1The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special
bodies and special equipment.
Engine113
Mode of operation4-stroke engine, gasoline injection
No. of cylinders8
Bore3.82 in (97.00 mm)
Stroke3.60 in (92.00 mm)
Total piston displacement331.8 cu in (5 439 cm3)
Compression ratio11:1
Output acc. to SAE J 1349362 hp/5 750 rpm2
(270 kW/5 750 rpm)
2Premium fuel required. Performance may vary with fuel octane rating.
Maximum torque acc. to SAE J 1349376 lb-ft/4 000 rpm
(510 Nm/4 000 rpm)
Maximum engine speed6 700 rpm
Firing order1-5-4-2-6-3-7-8
Poly-V-belt2 380 mm

429 Technical data
Rims and Tires
Rims and Tires
!
Only use tires which have been tested
and approved for your vehicle by
Mercedes-Benz. Tires approved by
Mercedes-Benz are developed to pro-
vide best possible performance in con-
junction with the driving safety
systems on your vehicle such as ABS or
ESP
®. Tires specially developed for
your vehicle and tested and approved
by Mercedes-Benz can be identified by
finding the following on the tire’s side-
wall:

MO = Mercedes-Benz Original
equipment tires
AMG vehicles:
Does not apply to all approved tires
on AMG vehicles. For information
on tested and approved tires for
AMG vehicles, contact an autho-
rized Mercedes-Benz Center.
Using tires other than those approved
by Mercedes-Benz may result in dam-
age that is not covered by the
Mercedes-Benz Limited Warranty.
!
Using tires other than those approved
by Mercedes-Benz can have detrimen-
tal effects, such as

poor handling characteristics

increased noise

increased fuel consumption
Moreover, tires and rims not approved
by Mercedes-Benz may, under load,
exhibit dimensional variations and dif-
ferent tire deformation characteristics
that could cause them to come into
contact with the vehicle body or axle
parts. Damage to the tires or the vehi-
cle may be the result.
i
Further information on tires and rims is
available at any authorized
Mercedes-Benz Center. A placard with
the recommended tire inflation
pressures is located on the driver’s
door B-pillar. Some vehicles may have
supplemental tire inflation pressure
information for driving at high speeds
(
page 316) or for vehicle loads less
than the maximum loaded vehicle
condition (
page 316). If such infor-
mation is provided, it can be found on
the placard located on the inside of the
fuel filler flap. The tire inflation pres-
sure should be checked regularly and
should only be adjusted on cold tires.
Follow tire manufacturer’s mainte-
nance recommendation included with
vehicle.

436 Technical data
Fuels, coolants, lubricants, etc.
Capacities
Vehicle components and their respectivelubricants must match. Therefore only use
products tested and approved by
Mercedes-Benz. Please refer to the Factory Approved
Service Products pamphlet, or inquire at
your Mercedes-Benz Center.
CapacityFuels, coolants, lubricants, etc.
Engine with oil filter9.0 US qt (8.5 l)Approved engine oils
Automatic transmission9.3 US qt (8.7 l)MB Automatic Transmission Fluid
Rear axle1.5 US qt (1.4 l)Hypoid gear oil SAE 85 W 90
Power steeringapprox. 1.1 US qt (1.0 l)MB Power Steering Fluid (Pentosin CHF 11S)
Front wheel hubsapprox. 2.1 oz (60 g) eachHigh temperature roller bearing grease
Brake system0.5 US qt (0.5 l)MB Brake Fluid (DOT 4+)
Cooling systemapprox. 12.8 US qt (12.0 l)MB 325.0 Anticorrosion/antifreeze agent
Fuel tank
including
a reserve of16.4 US gal (62.0 l)
2.6USgal (10.0l)Premium unleaded gasoline:
Minimum Posted Octane 91
(Avg. of 96 RON/86 MON)
Air conditioning systemR-134a refrigerant and special PAG lubricant oil
(never R-12)
Windshield washer3.2 US qt (3.0 l)MB Windshield Washer Concentrate1
1Use MB Windshield Washer Concentrate “MB SummerFit” and water for temperatures above freezing point or MB Windshield Washer Concentrate “MB SummerFit”
and commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point. Follow suggested mixing ratios (page 442).
Windshield washer and headlamp
cleaning system*6.4 US qt (6.0 l)

438 Technical data
Fuels, coolants, lubricants, etc.
Premium unleaded gasolineGasoline additives
A major concern among engine
manufacturers is carbon build-up caused
by gasoline. Mercedes-Benz recommends
only the use of quality gasoline containing
additives that prevent the build-up of
carbon deposits.
After an extended period of using fuels
without such additives, carbon deposits
can build up especially on the intake valves
and in the combustion area, leading to
engine performance problems such as:

Warm-up hesitation

Unstable idle

Knocking/pinging

Misfire

Power loss
Warning!G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious
injury. Whenever you are around gasoline,
avoid inhaling fumes and skin contact, extin-
guish all smoking materials. Never allow
sparks, flame or smoking materials near
gasoline!
!
To maintain the engine’s durability and
performance, premium unleaded gaso-
line must be used. If premium unleaded
is not available and low octane fuel is
used, follow these precautions:

Have the fuel tank only partially
filled with unleaded regular and fill
up with premium unleaded as soon
as possible.

Avoid full throttle driving and abrupt
acceleration.

Do not exceed an engine speed of
3 000 rpm if the vehicle is loaded
with a light load such as two
persons and no luggage.

Do not exceed2/3 of maximum
accelerator pedal position if the
vehicle is fully loaded or operating
in mountainous terrain.

444 Technical terms
CAN system
(C
ontroller Area Network)
Data bus network serving to control
vehicle functions such as door locking
or windshield wiping depending on
vehicle settings and/or ambient
conditions.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the
passenger compartment needed for
vehicle operation and monitoring.
Cold tire inflation pressure
(
page 331)
Collapsible tire
An especially compact spare tire that
must be inflated with a provided air
pump before using. It should only be
used to bring the vehicle to the nearest
service station.COMAND*
(C
ockpit Management and Data
System)
Information and operating center for
vehicle sound and communications
systems, including the radio and the
navigation system, as well as other
optional equipment (CD changer*,
telephone*, etc.).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to
adjust settings.
Cruise control
Driving convenience system that
automatically maintains the vehicle
speed set by the driver.
Curb weight
(
page 332)DOT
(D
epartment of Transportation)
(
page 332)
Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine
produced.
Engine oil viscosity
Measurement for the inner friction
(viscosity) of the oil at different temper-
atures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can
tolerate without becoming viscous, the
better the viscosity.
ESP
®
(Electronic Stability Program)
Improves vehicle handling and
directional stability.

447 Technical terms
Production options weight
(
page 333)
Program mode selector switch
Used to switch the automatic
transmission* between standard
operationS, comfort operationC and
manual operationM.
PSI
(P
ounds per square inch) (page 333)
Recommended tire inflation pressure
(
page 333)
Restraint systems
Seat belts, belt tensioners, air bags
and child restraint systems. As inde-
pendent systems, their protective
functions complement one another.
Rim
(
page 333)RON
(R
esearch Octane Number)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line’s ability to resist undesired deto-
nation (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Shift lock
When the vehicle is parked, this lock
prevents the transmission gear
selector lever from being moved out of
positionP without SmartKey turned
and brake pedal depressed.
Sidewall
(
page 333)SRS
(S
upplemental Restraint System)
Seat belts, emergency tensioning
device and air bags. Though indepen-
dent systems, they are closely inter-
faced to provide effective occupant
protection.
Tele Aid* System
(T
elematic Alarm Identification on
D
emand)
The Tele Aid system consists of three
types of response: automatic and
manual emergency, roadside assis-
tance and information. Tele Aid is
initially activated by completing a
subscriber agreement and placing an
acquaintance call.
The Tele Aid system is operational
provided that the vehicle’s battery is
charged, properly connected, not
damaged and cellular and GPS
coverage is available.

453 Index
Driving
Abroad 290
Hydroplaning 287
In winter 288
Instructions 42, 283
Problems 52
Safety systems 82
Systems 245
Through standing water 289
Driving safety systems
ABS 82
BAS 84
ESP
®84
E
Easy-entry/exit feature 39, 148
Electrical fuses see Fuses
Electrical outlet 263
Electrical system, Technical data 434
Electronic Stability Program see ESP
®
Emergency calls
911 calls 235
Tele Aid* calls 266, 267, 271
Emergency operation
(Limp-Home Mode) 168Emergency operations
Gear selector lever, Unlocking 388
Locking/unlocking the vehicle 386
Power tilt/sliding sunroof*,
Manual operation 389
Remote door unlock 272
Trunk lid, Releasing from inside 102
Trunk lid, Unlocking 387
Emergency Tensioning Device see ETD
Emergency, in case of
Battery, Jump starting 415
First aid kit 350, 380
Flat tire, Changing 404
Fuses 420
Hazard warning flasher 119
Instrument cluster,
Indicator lamps 350–356
Roadside Assistance 12, 268
Towing the vehicle 417
Emission control 291
Information label 426
System warranties 10Engine
Belt layout 427
Block heater (Canada only) 337
Brake-in recommendations 282
Cleaning 343
Compartment 297
Malfunction indicator lamp 25, 352
Maximum engine speed 428
Number 426
Starting 46
Technical data 428
Turning 56
Engine coolant see coolant
Engine number 444
Engine oil 298, 437
Adding 300
Additives 437
Changing 436
Checking level 299
Consumption 298
Display messages 299
Filler neck 301
Messages in display 299, 371, 372
Recommended engine and
oil filter 371
Viscosity 444

454 Index
ESP®84, 444
Messages in display 361–362
Warning lamp 25, 354
ETD 70, 445
Safety guidelines 64
Exterior lamp switch 48, 114
Exterior rear view mirrors 40
Parking position 170
F
Fahrenheit see Temperature display
mode 137
Filler neck, Engine oil 301
First aid kit 380
Flat tire 404
Jacking up the vehicle 405
Lowering the vehicle 410
Mounting the spare wheel 404
Preparing the vehicle 404
Spare wheel with collapsible tire 383
Flexible Service System see FSSFluids
Automatic transmission fluid 301,
436
Brake fluid 295, 437
Capacities 436
Engine coolant 295, 439
Engine oil 298, 437
Power steering fluid 436
Windshield washer and headlamp
cleaning system* 304, 442
Fog lamps 117, 118
Message in display 374, 376
Replacing bulbs 395, 396
Front air bags 65
Front lamps see Headlamps
Front passenger front air bag 65
Front passenger front air bag off indicator
lamp 27, 75, 357
Front seat head restraints see Head
restraints 106
FSS (Flexible Service System) (Canada
vehicles) 338, 445Fuel 293, 438
Additives 438
Capacities, Fuel tank 436
Filling the tank 293
Fuel filler flap and cap, Multifunction
display messages 353, 373
Fuel gauge 25
Fuel reserve warning lamp 354
Requirements, Octane rating 439
Technical data 436, 438
Fuel consumption statistics
After start 150
Since last reset 151
Fuel filler flap 293
Fuel reserve warning lamp 25
Fuel tank
Capacity 436
Filler flap 293
Fuels, coolants, lubricants etc.
Capacities 436
