2006 MERCEDES-BENZ C350 4MATIC Owner's Manual

448 Technical dataFuels, coolants, lubricants, etc.Windshield washer and headlamp cleaning system*
Both the windshield washer and headlamp
cleaning system* are supplied from the
windshield washer fluid reservoir.
The washer fluid reservoir has a capacity of
approx.:

3.2 US qt (3.0 l) in vehicles without
headlamp cleaning system*


6.4 US qt (6.0 l) in vehicles with
headlamp cleaning system*

Refill the reservoir with MB Windshield
Washer Concentrate “S” and water
(or concentrate and commercially
available premixed windshield washer
solvent/antifreeze, depending on
ambient temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate “S”
and water:


1 part “S” to 100 parts water
(1.34floz [40ml]“S” to 1gallon [4.0l]
water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate “S”
and commercially available premixed
windshield washer solvent/antifreeze:


1 part “S” to 100 parts solvent
(1.34floz [40ml]“S” to 1gallon [4.0l]
solvent)
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

449 Technical terms
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
Accessory weight
(
page 331)
Air pressure
(page 331)
Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.
Aspect ratio
(page 331)
Bar
(page 331)
BAS
(Brake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking
situations. The system is activated
when it senses an emergency based on
how fast the brake is applied.Bead
(
page 331)
Bi-Xenon headlamps*
Headlamps which use an electric arc as
the light source and produce a more
intense light than filament headlamps.
Bi-Xenon headlamps produce low
beam and high beam.
CAC
(Customer A
ssistance C
enter)
Mercedes-Benz customer service
center, which can help you with any
questions about your vehicle and
provide assistance in the event of a
breakdown.
CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control
vehicle functions such as door locking
or windshield wiping depending on
vehicle settings and/or ambient
conditions.Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the
passenger compartment needed for
vehicle operation and monitoring.
Cold tire inflation pressure
(
page 331)
COMAND*
(Cockpit M
anagement and D
ata
System)
Information and operating center for
vehicle sound and communications
systems, including the radio and the
navigation system, as well as other
optional equipment (CD changer*,
telephone*, etc.).

450 Technical termsControl system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to
adjust settings.
Cruise control
Driving convenience system that
automatically maintains the vehicle
speed set by the driver.
Curb weight
(
page 331)
DOT
(Department o
f Transportation)
(
page 331)Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine
produced.
Engine oil viscosity
Measurement for the inner friction
(viscosity) of the oil at different temper-
atures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can
tolerate without becoming viscous, the
better the viscosity.
ESP
®(Electronic S
tability P
rogram)
Improves vehicle handling and
directional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the
system’s threshold to tighten the
seat belts.
->SRSFSS (Canada vehicles)
(F
lexible S
ervice S
ystem)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. FSS evaluates
engine temperature, oil level, vehicle
speed, engine speed, distance driven
and the time elapsed since your last
maintenance service, and calls for the
next maintenance service accordingly.
GAWR
(G
ross A
xle W
eight R
ating)
(
page 331)
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the gear selector
lever.

451 Technical terms
GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special
receivers. Employs CD digital maps for
navigation.
GVW
(G
ross V
ehicle W
eight) (
page 332)
GVWR
(G
ross V
ehicle W
eight R
ating)
(
page 332)
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision,
including the tachometer, speedo-
meter, engine temperature display and
fuel gauge.Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the
vehicle and should not be used for
normal acceleration needs.
Kilopascal (kPa)
(
page 332)
Locking knob
Knob on the door which indicates
whether the door is locked or un-
locked. Pushing the locking knob down
on an individual door from inside will
lock that door.Maintenance System (U.S. vehicles)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. The Maintenance
System in your vehicle tracks distance
driven and the time elapsed since your
last maintenance service, and calls for
the next maintenance service accord-
ingly.
Maximum tire inflation pressure
(
page 332)
Maximum load rating
(page 332)
Maximum loaded vehicle weight
(page 332)
Memory function*
Used to store three individual seat,
steering wheel and mirror positions.

452 Technical termsMON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized
method. It is an indication of a
gasoline’s ability to resist undesired
detonation (knocking). The average of
both the MON (Motor Octane Number)
and ->RON (Research Octane Number)
is posted at the pump, also known as
ANTI-KNOCK INDEX.
Multifunction display
Display field in the instrument cluster
used to present information provided
by the control system.
Multifunction steering wheel
Steering wheel with buttons for
operating the control system.
Normal occupant weight
(
page 332)OCS
(O
ccupant C
lassification S
ystem)
The system automatically turns the
front passenger front air bag on or off
based on the classified occupant size
category determined by weight sensor
readings from the seat.
Occupant distribution
(
page 332)
Overspeed range
Engine speeds within the red marking
of the tachometer dial. Avoid this
engine speed range, as it may result in
serious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.Power train
Collective term designating all
components used to generate and
transmit motive power to the drive
axles, including


engine


clutch/torque converter


transmission


transfer case


drive shaft


differential


axle shafts/axles
Production options weight
(
page 333)
Program mode selector switch
Used to switch the automatic
transmission* between standard
operationS and comfort operationC.

453 Technical terms
PSI
(P
ounds per s
quare i
nch) (
page 333)
Recommended tire inflation pressure
(
page 333)
Restraint systems
Seat belts, child restraints, lower
anchors and tethers for children
(LATCH). As independent systems,
their protective functions complement
one another.
Rim
(page 333)
RON
(Research O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line’s ability to resist undesired deto-
nation (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.Shift lock
When the vehicle is parked, this lock
prevents the transmission gear
selector lever from being moved out of
positionP without SmartKey turned
and brake pedal depressed.
Sidewall
(
page 333)
SRS
(Supplemental R
estraint S
ystem)
Air bags, air bag control unit (with
crash sensor), emergency tensioning
device. Though independent systems,
they are closely interfaced to provide
effective occupant protection.Tele Aid* System
(T
elematic A
larm I
dentification on
D
emand)
The Tele Aid system consists of three
types of response: automatic and
manual emergency, roadside assis-
tance and information. Tele Aid is
initially activated by completing a
subscriber agreement and placing an
acquaintance call.
The Tele Aid system is operational
provided that the vehicle’s battery is
charged, properly connected, not
damaged and cellular and GPS
coverage is available.

454 Technical termsTelematics*
A combination of the terms “tele-
communications” and “informatics”.
Tightening torque
Force times lever arm (e.g. a lug
wrench) with which threaded fasteners
such as wheel bolts are tightened.
TIN
(T
ire I
dentification N
umber)
(
page 333)
Tire load rating
(page 333)Tire ply composition and material used
(
page 333)
Tire speed rating
(page 333)
Traction
(page 334)
Tread
(page 334)
Treadwear indicators
(page 334)Uniform Tire Quality Grading Standards
(
page 334)
Vehicle capacity weight
(page 334)
Vehicle maximum load on the tire
(page 334)
VIN
(Vehicle I
dentification N
umber)
The number set by the manufacturer
and placed on the body to uniquely
identify each vehicle produced.

455 Index
A
ABS 25, 87, 449
Indicator lamp 350
Messages in display 360
Accelerator position,
automatic transmission* 165
Accessory weight 331
Accident
In case of 56
Active head restraints
see Head restraints
Additional turn signals 398
Air bags 63
Children 64
Front passenger front air bag off
indicator lamp 27, 80, 356
Front, Driver 67
Front, Passenger 67
Passenger 67
Safety guidelines 66
Side impact (front and rear*) 68
Window curtain 68
Air conditioning refrigerant 442Air conditioning system
Automatic climate control*
(Canada only) 186
Climate control 176
Air conditioning, Cooling
Automatic climate control*
(Canada only) 196
Climate control 183
Air distribution
Automatic climate control*
(Canada only) 190
Climate control 180
Air pressure see Tire inflation pressure
Air recirculation mode
Automatic climate control*
(Canada only) 192
Climate control 182
Air vents, Front
Automatic climate control*
(Canada only) 187
Climate control 177
Air vents, Rear
Automatic climate control*
(Canada only) 198
Climate control 185Air volume
Automatic climate control*
(Canada only) 191
Climate control 180
Alignment bolt (vehicle tool kit) 408, 449
Anticorrosion/antifreeze 446, 447
Antiglare, Rear view mirror 170
Anti-theft systems 93
Anti-theft alarm system* 93
Immobilizer 93
Tow-away alarm* 95
Aquaplaning see Hydroplaning
Armrest 258
Ashtrays 261
Aspect ratio 331
ATF (Automatic transmission fluid) 300
AUDIO menu (Control system) 136
Audio system 199
Audio and telephone, operation 199
Button and soft key operation 202
CD changer* with MP3 218
CD operation 216
