2006 MAZDA MODEL 3 HATCHBACK Quick Tips (in English)

ground clearance windshield wipers power steering bulb lights steering

Page 1 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) for 48 months or 50,000 miles,
whichever comes first
Mazda Service
Transportation Solution
Being without your Mazda may
put a crimp in your day.
If you do ever have to take your
Mazda in for repairs

for 48 months or 50,000 miles,
whichever comes first
Mazda Service
Transportation Solution
Being without your Mazda may
put a crimp in your day.
If you do ever have to take your
Mazda in for repairs don’t worry,
you’re covered. With the Mazda
Transportation Solution, you
will be given a loaner car at no
charge when your Mazda vehicle
is in for warranty repairs.
For all the details, see your
Mazda DealerThis Quick Tips®guide is provided
by Mazda North American
Operations to make your Mazda
ownership experience more
convenient. It is not intended to
replace your Owner’s Manual.
If you have any questions about
your vehicle, you are invited to
contact your local dealer.
Or if you need additional help,
feel free to call our
Customer Assistance Center
at 1-800-222-5500
Monday through Friday,
8 a.m.- 4 :45 p.m., Pacific
9 a.m.-5:45 p.m., Eastern/Central Mazda Driver’s Assurance Plan
Check out www.mymazda.com,
the website dedicated to you.
Manage your maintenance records,
receive valuable offers, see the latest
accessories and much more!
Mazda Roadside Assistance
Exhilaration, liberation and inspiration
are great reasons to drive a
Mazda car, truck, SUV or minivan.
In addition to all the other great
standard features, you also get peace
of mind, our Emergency Roadside
Assistance Plan, it’s just a phone
call away, 24 hours a day, 365
days a year, call 1-800-866-1998
Mazda ‘’bumper-to-bumper”
Limited Warranty
We design and build every Mazda
to give you driving pleasure now
and far down the road. We’re so
confident in our quality that we
cover the entire vehicle against
defects in materials and workmanship
©2005 Calcar, Quick Tips®is a trademark
of Calcar, made in USA 5/05 97.859M DOT
Mazda North American Operations reserves
the right to change product specifications at
any time without incurring obligations.
9999-95-038C-06QT
DRIVER ASSURANCE
Unleaded
Gasoline
87-octane
minimum
15-gallon/
55-liter tank
2.0L/2.3L
2006
Reference
Guide for
Controls and
Functions
Quick Tips®
®
MAZDA3MAZDA3

Page 2 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) DRIVER’S VIEW
Always check the Owner’s Manual for more operating information and safety features
1. Power window switches*,
see Switches
2. Door locks*, see Locks
3. Mirror controls*, see Switch

Page 3 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Getting Started
MAZDA3 Quick Tips®are
designed to quickly familiarize
you with some important
fe

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Getting Started
MAZDA3 Quick Tips®are
designed to quickly familiarize
you with some important
features of your MAZDA3
The Driver’s View tab is your
index to the Quick Tips
®, locate
the item you would like to
learn more about and then
turn to the listed tab
This Getting Started section
contains important operating
tips about your MAZDA3
Items identified in blue text
call out important informationRemote
entry system*
Functions only
with ignition key
not inserted
To lock doors: Press
LOCK (1); pressing again within 5
seconds causes doors/liftgate to
re-lock, horn to beep onceand
hazard warning lights to flash
once if doors/liftgate properly closed
To unlock: Press UNLOCK (2) for
driver’s door, hazard warning
lights will flash twice, press again
within 5 seconds for all other doors
Panic alarm: Press (3); horn sounds,
parking lights flash; press any
button on transmitter to stop
After unlocking with the transmitter,
all doors or the liftgate will auto-
matically lock if a door or the liftgate
is not opened within about 30 seconds
Instrument panel lighting
With headlights ON:
To brighten/dim
turn thumbwheel
up/down
Headlights/parking lights
ON, ignition key must
be ON: Illumination
changes brightness
when dimmer switch (4) is pressed
(if equipped with black-out meter)
With headlights OFF
†, key ON:
Press instrument cluster dimmer
select button (4) to select
between 5 brightness settings
for instrument cluster
HID headlights leveling switch
Adjusts headlight angle
to compensate for
weight of passengers
and cargo, see
Owner’s Manual
approximately 66 lb., front
passenger air bag deactivation
indicator light illuminates,
air bag/pretensioner will not
deploy/activate in an accident
If the total seated weight
is greater than approximately
93 lb., light does not illuminate,
and the air bag/pretensioner will
deploy/activate in an appropriate
accident, see Owner’s Manual
for additional information on this
feature and the air bag system
Passenger sensing
operation
See Driver’s View
PAD indicator on dash will
illuminate when passenger air
bag is deactivated, child-restraint
seat with child that weighs a
combined total of 66 lbs. or less
will deactivate front passenger
air bag/pretensioner
See Owner’s Manual
Getting
Started
Getting
Started
4
WARNINGS: Never place
rear-facing infant-safety
seat in front of any air bag,
an infant is in serious danger
of being injured or killed
If you must install a forward-
facing child-safety seat in the
front seating position, move
vehicle seat as far back as possible
Tire Pressure Monitoring
System (TPMS)*
Warning light illuminates for
a few seconds with ignition on
If tire pressure is low, warning
light illuminates with audible
beep sound, adjust tire pressure
to correct specifications, perform
tire pressure adjustment before
driving, a digital tire pressure
gauge is recommended
Flashing warning light may indicate
malfunction, dealer inspection required
LOCK
UNLOCK1
2
3
Tilt/telescopic
steering-
wheel lever
Pull lever (5)
down to unlock
column, position
tilt angle and
length of steering
column position
Tip: Telescopic function allows
steering wheel to be adjusted
closer or farther according to
driver’s reach
WARNING: Do not adjust
steering-wheel while driving
Passenger air bag deactivation
indicator light
Front air bag deactivation indicator
light provides current status of
front passenger air bag and
pretensioner system
If total seated weight on front
passenger seat is less than
5
*Denotes optional equipment†See Owner’s Manual

Page 4 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) 21
AUTO
GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
AUTO*= With ignition switch
in ON position; headlights and
exterior lights automatically

21
AUTO
GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
AUTO*= With ignition switch
in ON position; headlights and
exterior lights automatically turn
ON/OFF depending on surrounding
darkness/lightness; rotate knob
(1) to third notch
High beams on/off: Push
forward/pull back to detent
To flash high beams: Pull back
slightly and release
Turn signals right/left: Move
lever up/down
= Fog lights* on: Rotate (2);
functions only with headlight
low beams on
Tip: Headlights switch off,
parking lights remain on,
if lights are left on and
switch is in lock position
or key removed
Cruise control*Operates above
19 mph
Press MAIN (3)
to turn system
on/off
To set speed: Accelerate to desired
speed and press SET/COAST (5)
To accelerate: Press and hold
RES/ACCEL (4); release button
at desired speed
To decelerate: Press and hold
SET/COAST (5); release button
at desired speed
Incremental acceleration: Press and
release (4); each tap = plus 1 mph
Incremental deceleration: Press and
release (5); each tap = minus 1 mph
To cancel: Press CANCEL (6) or
MAIN (3); tap brake pedal or
depress clutch pedal*
REAR
1
REA
R
13
INT
REAR
12
INT
Intermittent wiper: One click down
To change interval speed:
Rotate inner ring* (2)
Normal wiper speed: Two clicks down
High-speed wiper: Three clicks down
Auto*: One click down
Rain sensor senses rain amount
on windshield, then controls
wiper automatically
Rain sensor sensitivity is adjusted
from high sensitivity (+) to less
sensitivity (
-) by rotating ring (3)Rear window wiper/washer
(5-Door only)
To activate rear interval wiper:
Rotate knob (1) up to INT
To activate rear normal speed
wiper: Rotate knob (1) up to ON
To activate rear washer: Rotate
knob (1) to and release
Getting
Started
Getting
Started
Steering-
wheel
audio controls*
To increase/
decreasevolume:
Press (4)
Radio: Press (5) less than one
second to select next/previous
preset station, press (5) more
than one second until beep sound
is heard to seek next/previous station
Cassette*/CD: Press (5) to select
next selection/track, press (5)
to repeat current selection/track
Press (6) to select FM1, FM2, AM,
SAT 1*, 2*, 3*, CD and Cassette*
Press (7) to mute audio/NAVI system
Fuel filler doorLocated on
passenger side
/
/
Turn signal/lighting
control lever
OFF= Lights off
= Tail, parking and
dashboard lights on: Rotate
knob (1) to first notch
= Tail, parking, dashboard
and headlights on: Rotate
knob (1) to second notch
Wiper/washer control leverSingle wipe: Push lever up
Washer: Pull back, also
operates wipers
M
O
D
EVOL465
7
ON
OFF
SET
RES
CANCEL
SET
COAST
3
64
5
*Denotes optional equipment

Page 5 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) INSTRUMENT CLUSTER
Always check the Owner’s Manual for more operating information and safety features
WARNING LIGHTS
• Cruise control on*,see Getting Started
• Cruise control main
power on*,see

INSTRUMENT CLUSTER
Always check the Owner’s Manual for more operating information and safety features
WARNING LIGHTS
• Cruise control on*,see Getting Started
• Cruise control main
power on*,see Getting Started
• Tire Pressure Monitoring
System (TPMS)*,
see Getting Started
• Turn signals/hazard
warning on
• High beams on
• Engine oil-pressure
warning light
Stop car when safe and turn
off engine; check oil level
• Brake system
Parking brake on/low brake fluid
• Always fasten seat belts
• Security indicator light*
GAUGES
1. Fuel gauge
15-gallon/55-liter tank
(2.0L and 2.3L engines)
2. Odometer/Trip meter
3. Gear indicator (A/T only)*
Displays current gear
position
4. Tachometer
• Lights on
• Charging system
warning light
Charging system malfunction;
dealer inspection required
• Air bag/front seat belt
pretensioner system
If light flashes or stays on, the air
bags/front seat belt pretensioners
may not operate in an accident;
dealer inspection required
• Door ajar
• Power steering
malfunction
Dealer inspection required if light
remains on
• Check engine
Dealer inspection required
• OLow fuel5. Instrument cluster
dimmer select button*,
see Getting Started
6. Speedometer
7. Odometer/Trip meter
selector
Press to view odometer; press
again to reset trip odometer
A/B settings
Instrument
Cluster
Instrument
Cluster
nim/0001x
H
P
TRIPA80.0
RNDM8
C
F
E
5748
6
1 32
hpm
km/h
80220 200 180
160
140
120
100
60
40
20
0
0 20 40 6080100120
1400 1 2 3 4567
8
• Automatic
transaxle warning light*
Automatic transaxle malfunction;
dealer inspection required
• Anti-lock Brake
System (ABS)*
ABS malfunction, normal brakes
only; dealer inspection required
When brake pedal is pressed,
ABS automatically reduces
hydraulic pressure to any wheel
on the verge of locking up
You may feel a slight pulsing
of the brake pedal and hear a
clicking noise; this tells you the
ABS is functioning properly;
increase pressure on pedal
for maximum braking
Tips: Maintain constant
pressure on the brake pedal
Do not pump the brakes
8. Engine coolant
temperature gauge
Stop car if above normal
range, turn off engine, let
vehicle cool; check coolant
level when safe
CRUISE
MAIN CRUISE
*Denotes optional equipment

Page 6 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) LOCKS
Always check the Owner’s Manual for more operating information and safety features
Power windows*
Ignition must be on
All windows controlled from the
driver’s armrest; passenger doors
have

LOCKS
Always check the Owner’s Manual for more operating information and safety features
Power windows*
Ignition must be on
All windows controlled from the
driver’s armrest; passenger doors
have separate switches
1.Driver’s window: One-touch-
down; push down firmly and
release, window goes down
all the way; pull switch back
briefly to stop; press lightly and
hold for normal operation2.Passenger window
switches: Push down
and hold to open, pull
back and hold to close
3.Power window lockout switch:
Press down until it clicks, only
driver’s window operates;
press again and passenger
window switches function again
Locks
Switches
AUTO
1
3
2
Dual power mirrors*
Ignition must be in ACC or ON
To adjust left/right mirror:
Press control switch (1) left/right,
press switch (2) in direction of
desired mirror movement
Tip: To lock mirrors in
place, move control switch
to center position
Manual
mirrors
To adjust:
Move knob (3)
on door
1
23
Key
Operates ignition and
all locks
Tip: Use key number
plate to purchase a new
key; store in safe place
separate from vehicle
Remote
entry
system*,
see Getting
Started
Illuminated entry system
Activates interior lights when dome
light switch set to DOOR position;
lights off after driver’s door is
locked or ignition in ON positionPower door
locks*
Master
front door
locks
switches
To lock/unlock all doors:
Press bottom/top of switch (1)
To lock doors without key:
With door open, press bottom
of door lock switch, exit car,
close doors
To unlock: Use key to unlock
driver’s front door, rotate key to
counterclockwise position for
more than one second to unlock
other doors
Manual door locks
Lock button
To lock: Press front of button
(2) toward door handle
To unlock: Pull front of button
away from door handleChild-safety locks
Located at the edge of rear doors
To activate: Rotate childproof lock
(3) in direction of arrow using key
tip (doors open from outside only);
rotate in opposite direction
to deactivateWARNINGS: Since children
may access either rear door,
child-safety locks for both rear
doors should be activated
Never leave a child in car
with key in ignition
LOCKFERME3
LOCK UNLOCK
12
LOCK
UNLOCK
*Denotes optional equipment

Page 7 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) INTERIOR LIGHTS
Always check the Owner’s Manual for more operating information and safety features
Automatic
Transaxle*
Gearshift
must be in
Park or
Neutral to
start engine;
it must
be in Par

INTERIOR LIGHTS
Always check the Owner’s Manual for more operating information and safety features
Automatic
Transaxle*
Gearshift
must be in
Park or
Neutral to
start engine;
it must
be in Park
to remove
ignition key
P = Park
To move gearshift from Park:
Press firmly on brake pedal then
move the shift lever out of P
R = Reverse
N = Neutral
No gear engaged
D Drive (Overdrive)
For normal driving: Shifts through
all forward gears automatically
Interior
Lights
Transaxle
1. Map/reading light switch*
Press on/off
2. Interior light switch
DOOR = light on when door open
ON = light always on
OFF = light always off
3. Front interior light
4. Rear interior light5. Sunroof tilt switch*
Press rear of switch to tilt
rear of sunroof
Press front of switch to close
6. Sunroof slide switch*
Press rear of switch to
open sunroof
Press front of switch to close7. Cargo light* (5-Door)
ON = Light always on
OFF = Light always off
Cargo light* (4-Door)
Light on with trunk open
See Trunk/Cargo Area
Driver/passenger
covered visor mirrors
To access mirror: Lower visor
OFFDOOR
T
IL
TS
L
I
D
E
121
3356
ONOFFDOOR
2
47
ON
O
FF
M (Sport A/T
manual shift mode)
Move shifter from
D to M to engage
manual shift mode,
M will be illuminated
for manual mode on
shift position indicator located
in the instrument panel
Manual shifting of transmission
is achieved by moving shifter
back to upshift and forward to
downshift, move shifter from
M to D to engage automatic
shift mode
Gear indicator (A/T only)*
Illuminated numeral of gear indicator
located in the instrument panel
displays current gear in Automatic
and Manual shift modesManual
transaxle
Depress clutch
pedal to start
engine and
change gears
Ignition key
release button
(M/T only)
Press button (1)
to remove key
from ignition
Tips: Do not shift into
1st above 20 mph or clutch
failure could occur
Resting your foot on clutch
pedal while driving or using
the clutch to hold your vehicle
at a standstill while waiting
on a hill may reduce clutch life
P
R
N
D M
LOCKACCON
1
*Denotes optional equipment

Page 8 of 12

MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English) SEATS
Always check the Owner’s Manual for more operating information and safety features
Shoulder belt
height
adjustment
To raise:
Push adjuster
upward
To lower:
Pull button (1) and
slide downwa

SEATS
Always check the Owner’s Manual for more operating information and safety features
Shoulder belt
height
adjustment
To raise:
Push adjuster
upward
To lower:
Pull button (1) and
slide downward
WARNING: Make sure
adjuster locks in one of
its positions
Seat controls
1. Fore-aft adjustment
Lift lever and hold, slide seat,
release lever
2. Raise/lower seat
(Driver’s seat only)
Pull/push lever and release
3. Seat back angle
To adjust: Lift and hold lever,
lean forward or backward
to tilt seat, release lever
4. Lumbar support
adjustment*
(Driver’s seat only)
Pull lever forward
5. Head restraint
To raise/lower: Pull up/hold
release button (6) and
push down
Tip: Side-impact air bags*
deploy from outboard
side of front seatbacks
Seats
Seats
WARNINGS: Do not adjust
seats while driving
Safety belts must always be
worn when vehicle is in motion
Air bags are supplemental
and do not replace safety
belt usage
Always wear your safety belt
and properly secure children
12 and under in the rear seat
Never place rear-facing
infant-safety seat in front
of any air bag, an infant is
in serious danger of being
injured or killed
If you must install a forward-
facing child-safety seat in the
front seating position, move
vehicle seat as far back as possible
Use age appropriate child
restraints, see Owner’s Manual
and state or province laws
Split fold-down rear seatbacks
To fold: Push release knob (1),
push seatback down
To return and lock: Push seatback
firmly until latched, make sure seat-
belts are returned to original positions
Tip: 4-Door has seatback locks
as part of trunk security
WARNING: Lower seatback
slowly using both hands,
seatback is heavy and could
cause personal injury
Child-safety seat
To install in rear outboard
seats: Use dual locking mode
retractor seat belts; see
Owner’s Manual for proper
installation and child seat
tether and LATCH system
instructions
Safety belt emergency
locking mode
Belts lockonly on hard acceleration,
braking, cornering or impacts of
about 5 mph or more
Automatic locking mode
(front passenger and all
rear safety belts only)
Must be used when installing
child-safety seat
To activate: Pull belt fully out of
retractor, allow belt to retract until
click is heard; belt will only tighten
To disengage: Unbuckle belt and
allow belt to retract fully
4
6
21
3
5
1
1
1
*Denotes optional equipment

Load next 8 pages

Page: 1-8 9-16 next >

alternator drain bolt change time navigation system stop start ground clearance
