INSTRUMENT PANEL (Vehicles with navigation system)
PX602c

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xiiPage
1
Power window switches 39
. . . . . . . . . . . . . . . . . . . . . .
2 Power door lock switch 21
. . . . . . . . . . . . . . . . . . . . . .
3 Window lock switch 40
. . . . . . . . . . . . . . . . . . . . . . . . . .
4 Driving position memory switch 189
. . . . . . . . . . . . . .
5 Power quarter window switches 42
. . . . . . . . . . . . . .
6 Power rear view mirror control switches 194 . . . . . .
7 Roll sensing of curtain shield airbags off
switch 45, 146
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Headlight and turn signal switch 30
. . . . . . . . . . . . . .
9 Windshield wiper and washer switch 33
. . . . . . . . . .
10 Center differential lock switch 266
. . . . . . . . . . . . . . .
11 Power antenna switch 222
. . . . . . . . . . . . . . . . . . . . . . .
12 Emergency flasher switch 43
. . . . . . . . . . . . . . . . . . . .
13 Security indicator light 25
. . . . . . . . . . . . . . . . . . . . . . .
14 Outside temperature display 72
. . . . . . . . . . . . . . . . . .
15 Clock 71
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
16 Navigation system including air conditioning
controls (See the separate “Navigation System
Owner’s Manual”.)
17 Front passenger occupant classification
indicator light 157 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18 Front passenger’s seat belt reminder light 55 . . . . .
19 Audio system 218
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20 Glove box 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page
21 Tire pressure warning select switch
307
. . . . . . . . . .
22 Outside rear view mirror defogger switch 38 . . . . . .
23 Rear air conditioning switch 210
. . . . . . . . . . . . . . . . .
24 Power outlet 74
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25 Cigarette lighter 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26 Fourwheel drive control lever 266
. . . . . . . . . . . . . . .
27 Seat heater switches 44
. . . . . . . . . . . . . . . . . . . . . . . . .
28 Rear window defogger switch 37
. . . . . . . . . . . . . . . . .
29 Ashtray 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
30 Automatic transmission selector lever 259 . . . . . . . .
31 Damping mode select switch 287
. . . . . . . . . . . . . . . .
32 Active height control switch 279
. . . . . . . . . . . . . . . . .
33 Driving pattern selector switch 261
. . . . . . . . . . . . . . .
34 Second start mode selector switch 266
. . . . . . . . . . .
35 Cruise control switch 275
. . . . . . . . . . . . . . . . . . . . . . .
36 Telephone switches and speech command switch
(See the separate “Navigation System Owner’s
Manual”.)
37 Audio remote controls (Steering switches) 243 . . . .
38 Lexus night view system onoff knob 272
. . . . . . . .
39 Hood lock release lever 92
. . . . . . . . . . . . . . . . . . . . . .
40 Fuel filler door opener 93
. . . . . . . . . . . . . . . . . . . . . . . .
41 Tire pressure warning reset switch 305
. . . . . . . . . . .

PICTORIAL INDEX
xiii
INSTRUMENT PANEL (Vehicles without navigation system)
px609b

KEYS AND DOORS
26
17X504
Security indicator light (For vehicles with navigation
system)
17X505
 Security indicator light (For vehicles without navigation
system)
Setting the system
1. Turn the ignition key to the “LOCK” position and
remove it.
The engine immobilizer system causes the indicator light to
flash.
2. Close and lock all the doors and hood using an ignition
key or wireless remote control.
If you lock them with wireless remote control, the turn signals
flash once.*
NOTE: *The turn signals can be set not to flash. Ask your
Lexus dealer for details.
The flashing indicator light will remain on when all the doors
and hood are closed and locked.
3. After 30 seconds, the indicator starts flashing and the
system is set.
Cancelling the system
When you unlock any door using an ignition key or
wireless remote control, the system is cancelled.
If you unlock any door with wireless remote control, the turn
signals flash twice.* NOTE: *The turn signals can be set not to flash. Ask your
Lexus dealer for details.

222
GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
The following service reminder indicators go off after a few
seconds.

w73

w72a

218
214 wtracorw227
or

The following service reminder indicat
or goes off after about 6
seconds.
The anti −lock brake system warning light, vehicle stability
control system off indicator light and vehicle stability control
system and active traction control system warning light may
stay on for about 60 seconds after the ignition key is turned to
the “ON” position. It is normal if they go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.
TRIP INFORMATION DISPLAY (Vehicles without navigation system)
13x541z
The following information is shown with the ignition
switch turned on. Each time you push the “MODE” button,
the displayed information is changed.
 Average vehicle speed
 Driving distance after engine starting
 Available driving range
 Average fuel consumption after being refueled
 Current fuel consumption
The displayed trip information values indicate the general
driving condition and may not always reflect precise and actual
conditions.

INTERIOR EQUIPMENT
74
14X025a
 1Snuffer bridge
To use the ashtray, pull on the lid.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, close the lid completely.
To remove the ashtray, pull it out while pressing on the snuffer
bridge to release the catch.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always close the ashtray
completely after use.
POWER OUTLETS
Front
14X017a
14X029c
 Vehicles without
Navigation System
Vehicles with
Navigation System

STEERING WHEEL AND MIRRORS
197
Compass (vehicles without navigation
system)
16x271a
The compass indicates the direction in which the vehicle
is heading. The illustration shown above indicates that the
vehicle is heading north.Displays
Directions
N
NE
E
SE S
SW W
NWNorth
Northeast
East
Southeast South
Southwest West
Northwest
Pushing the “AUTO” button for longer than 3 seconds
turns on or off the compass display.
The compass may not show the correct direction in the
following conditions:
 The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
 The ignition switch is turned off immediately after turning.
 The vehicle is on an inclined surface.
 The vehicle is in a place where the earth’s magnetic field is
subject to interference by artificial magnetic fields
(underground parking, under a steel tower, between
buildings, roof parking, near a crossing, near a large
vehicle, etc.).
 The vehicle is magnetized. (There is a magnet or a metal
object on or near the inside rear view mirror.)
 The battery has been disconnected.
 Any door is open.
If the deviation is small, the compass works to calibrate the
direction automatically while the vehicle in motion.
For obtaining additional precision or for complete calibrating,
see “CALIBRATING THE COMPASS” below.

SECTION 2 – 1
201
AIR CONDITIONING AND AUDIO
