2006 LEXUS LX470 ESP

STARTING AND DRIVING
293
VARIABLE GEAR RATIO STEERINGSYSTEM
The variable gear ratio steering system adjusts the wheel
turning angle depending on the vehicle speed and how
much you turn the steering wheel.
The vehicle wheel turning angle will be changed with a smaller
degree of wheel maneuvering when you are driving at very low
speed such as when putting your vehicle into a garage.
In the following cases, to prevent the system from overheating,
the system could be temporarily deactivated with the change
in the center position of the steering wheel. This is not a
malfunction. After the cause of the problem is eliminated, the
system will return to normal automatically after a few minutes.
 If you continue maneuvering the steering wheel when the
vehicle is stopped or running at very low speed
 If you continue driving holding the steering wheel to the
extreme right or left
 If you maneuver the steering wheel immediately after
starting the engine at less than about −30C (− 22F) While the system is not functioning, a larger degree of wheel
maneuvering is needed during driving at low speed. If the
center position of the steering wheel is changed frequently,
have your vehicle inspected at your Lexus dealer.
CAUTION
Take due care especially when driving at low speed as
the vehicle changes direction in greater proportion to
the steering wheel maneuvering.
NOTICE
Do not disconnect the battery with the steering wheel
turned, or the center position of the steering wheel
could be slightly and temporarily changed. However,
after driving for a short while, the system will return to
normal
and the center position of the steering wheel will
be in the appropriate position.
The light will flash if you disconnect and reconnect the battery
terminal. This is because the system is reset temporarily.
However, it is no problem to drive. To turn off the light, drive for
a short while. The system will be set automatically and return
to normal.

STARTING AND DRIVING
297
Driving over the steps such as the joints on the road.
 Driving on roads where the road surface is pitted or
has other differences in surface height.
Install all 4 tires of specified size at appropriate
pressure: The antilock brake system detects vehicle
speeds using the speed s ensors for respective wheels’
turning speeds. The use of tires other than specified
may fail to detect the accurate turning speed resulting
in a longer stopping distance.“ABS” warning light
31X506
The light comes on when the ignition key is turned to the “ON”
position. If the anti−lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti−lock brake system, the brake
assist system, the active traction control system and/or the
vehicle stability control system do/does not operate, but the
brake system still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti− lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.

STARTING AND DRIVING
301
The tire pressure warning light may turn on due to natural
causes such as natural air l
eaks or tire inflation pressure
changes caused by temperature. In this case, adjusting the
tire inflation pressure will turn off the light.
Pushing the tire pressure warning reset switch should not turn
off the tire pressure warning light. Adjusting the tire inflation
pressure will turn off the light.
The spare tire is also equipped with the tire pressure warning
valve and transmitter. The tire pressure warning light will turn
on if the tire inflation pressure of the spare tire is low. If a tire
goes flat, even though the flat tire is replaced with the spare
tire, the warning light does not turn off. Replace the spare tire
with the repaired tire and adjust the proper tire inflation
pressure. The tire pressure warning light will turn off after a few
minutes.
CAUTION
Each tire, including the spare (if provided), should be
checked monthly when cold and inflated to the inflation
pressure recommended by the vehicle manufacturer on
the vehicle placard or tire inflation pressure label (tire
and load information label). (If your vehicle has tires of
a different size than the size indicated on the vehicle
placard or tire inflation pressure label (tire and load
information label), you should determine the proper tire
inflation pressure for those tires.)
As an added safety feature, your vehicle has been
equipped with a tire pressure monitoring system
(TPMS–tire pressure warning system) that illuminates a
low tire pressure telltale (tire pressure warning light)
when one or more of your tires is significantly
underinflated. Accordingly, when the low tire pressure
telltale (tire pressure warning light) illuminates, you
should stop and check your tires as soon as possible,
and inflate them to the proper pressure. Driving on a
significantly underinflated tire causes the tire to
overheat and can lead to tire failure. Underinflation
also reduces fuel efficiency and tire tread life, and may
affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning
system) is not a substitute for proper tire maintenance,
and it is the driver’s responsibility to maintain correct
tire pressure, even if underinflation has not reached
the level to trigger illumination of the TPMS low tire
pressure telltale (tire pressure warning light).

STARTING AND DRIVING
304For vehicles sold in U.S.A.
This device complies with
Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
NOTICE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
 Consult the dealer or an experienced radio / TV
technician for help.
FCC WARNING:
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.
For vehicles sold in Canada
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.

DRIVING TIPS
313
Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.
 If you drive through deep water over about 500 mm
(20 in.) in depth, put the vehicle height in the HI (High)
mode with the active height select switch and then
turn off the active height control suspension by
pushing the height control switch. Drive your vehicle
at 30 km/h (19 mph) or lower speed.OFFROAD DRIVING PRECAUTIONS
When driving your vehicle off −road, please observe the
following precautions to ensure your driving enjoyment and to
help prevent the closure of areas to off −road vehicles.
a. Drive your vehicle only in areas where off −road vehicles are
permitted to travel.
b. Respect private property. Get owner’s permission before
entering private property.
c. Do not enter areas that are closed. Honor gates, barriers
and signs that restrict travel.
d. Stay on established roads. When conditions are wet,
driving techniques should be changed or travel delayed to
prevent damage to roads.
For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertaining to driving your
vehicle off −road, consult the following organizations.
 State and Local Parks and Recreation Departments
 State Motor Vehicle Bureau
 Recreational Vehicle Clubs
 U.S. Forest Service and Bureau of Land Management

DRIVING TIPS
314
CAUTION
Always observe the following precautions to help
minimize the risk of serious personal injury or damage
to your vehicle:
Drive carefully when off the road. Do not take
unnecessary risks by driving in dangerous places.
 Do not grip the steering wheel spokes when driving
offroad. A bad bump could jerk the wheel and injure
your hands. Keep both hands and especially your
thumbs on the outside of the rim.
 Always check your brakes for effectiveness
immediately after driving in sand, mud, water or
snow.
 After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, paper,
rags, stone, sand, etc. adhering or trapped on the
underbody. Clear off any such matter from the
underbody. If the vehicle is used with these materials
trapped or adhering to the underbody, a breakdown
or fire could occur.
 In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing
a seat belt. Therefore, the driver and all passengers
should fasten their seat belts whenever the vehicle is
moving.
 When driving offroad or in rugged terrain, do not
drive at excessive speeds, jump, make sharp turns,
strike objects, etc. This may cause loss of control or
vehicle rollover causing death or serious injury. You
are also risking expensive damage to your vehicle’s
suspension and chassis.
NOTICE
 If driving through water, such as when crossing
shallow streams, first check the depth of the water
and the bottom of the river bed for firmness. Drive
slowly and avoid deep water.
 Take all necessary safety measures to ensure that
water damage to the engine or other components
does not occur.
 Water entering the engine air intake will cause severe
engine damage.
 Water entering the automatic transmission will cause
deterioration in shift quality, locking up of your
transmission accompanied by vibration, and
ultimately damage.
 Water can wash the grease from wheel bearings,
causing rusting and premature failure, and may also
enter the differentials, transmission and transfer
case, reducing the gear oil’s lubricating qualities.
 Sand and mud that has accumulated in brake drums
and around brake discs may affect braking ef ficiency
and may damage brake system components.

DRIVING TIPS
322
Brakes and safety chains
Lexus recommends trailers with brakes that conform to
any applicable federal and state/provincial regulations.
 A safety chain must always be used between the towing
vehicle and the trailer. Leave sufficient slack in the
chain for turns. The chain should cross under the
trailer tongue to prevent the tongue from dropping to
the ground in case it becomes damaged or separated.
For correct safety chain procedures, consult your
Lexus dealer.
CAUTION
If the total trailer weight exceeds 453 kg (1000 lb.),
trailer brakes are required.
 Never tap into your vehicle’s hydraulic system as it
will lower its braking effectiveness.
 Never tow a trailer without using a safety chain
securely attached to both the trailer and the vehicle.
If damage occurs to the coupling unit or hitch ball,
there is possible danger of the trailer wandering over
into another lane.
Tires
Ensure that your vehicle’s tires are properly inflated. Adjust
the tire inflation pressure to the recommended cold tire
inflation pressure indicated below:
Tire inflation pressure, kPa (kgf/cm
2 or bar, psi)
Front 220 (2.2, 32)
Rear 240 (2.4, 35)
 The trailer tires should be inflated to the pressure
recommended by the trailer manufacturer in respect to the
total trailer weight.

DRIVING TIPS
325
Trailer towing tips
When towing a trailer, your vehicle will handle differently
than when not towing. The three main causes of
vehicletrailer accidents are driver error , excessive speed
and improper trailer loading. Keep these in mind when
towing:
 Before starting out, check the operation of the lights and all
vehicle −trailer connections. After driving a short distance,
stop and recheck the lights and connections. Practice
turning, stopping and backing with a trailer in an area away
from traffic until you learn the feel.
 Backing with a trailer is difficult and requires practice. Grip
the bottom of the steering wheel and move your hand to the
left to move the trailer to the left. Move your hand to the right
to move the trailer to the right. (This procedure is generally
opposite to that when backing without a trailer.) Also, just
turn the steering wheel a little at a time, avoiding sharp or
prolonged turning. Have someone guide you when backing
to reduce the risk of an accident.
 Because stopping distance may be increased,
vehicle− to−vehicle distance should be increased when
towing a trailer. For each 16 km/h (10 mph) of speed, allow
at least one vehicle and trailer length between you and the
vehicle ahead. Avoid sudden braking as you may skid,
resulting in jackknifing and loss of control. This is especially
true on wet or slippery surfaces.
 Avoid jerky starts or sudden acceleration.
Avoid jerky steering and sharp turns. The trailer could hit
your vehicle in a tight turn. Slow down before making a turn
to avoid the need of sudden braking.
 Remember that when making a turn, the trailer wheels will
be closer than the vehicle wheels to the inside of the turn.
Therefore, compensate for this by making a larger than
normal turning radius with your vehicle.
 Crosswinds and rough roads will adversely affect handling
of your vehicle and trailer, causing sway. Pay attention to
the rear from time to time to prepare yourself for being
passed by large trucks or buses, which may cause your
vehicle and trailer to sway. If swaying happens, firmly grip
the steering wheel and reduce speed immediately but
gradually. Never increase speed. If it is necessary to
reduce speed, brake slowly. Steer straight ahead. If you
make no extreme correction with the steering or brakes,
your vehicle and trailer will stabilize.
 Be careful when passing other vehicles. Passing requires
considerable distance. After passing a vehicle, do not
forget the length of your trailer and be sure you have plenty
of room before changing lanes.
 In order to maintain efficient engine braking and electrical
charging performance, do not use overdrive. T ransmission
must be “4” position.
