2006 LEXUS LX470 key

SWITCHES
31
When you turn on the headlights, the lights automatically turn
off about 30 seconds after any of the doors is opened and
closed with the ignition switch turned to the “ACC” or “LOCK”\
position.* To
turn them on again, turn the ignition switch to the
“ON” position, or turn the headlight switch off and then twist the
knob until the first or second clickstop. If you are going to park
for over one week, make sure the headlight switch is off.
When the headlight switch is on with all the side doors and
back door locked, pushing the “LOCK” button on the wireless
remote control key turns off the headlights.
NOTE: *The time before turning off the lights can be
changed. Ask your Lexus dealer for details. Daytime Running Light System
The headlights turn on at reduced intensity when the parking
brake is released with the engine started, even with the light
switch in the “OFF” position. They will not go off until the
ignition switch is turned off.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Twist
the knob to the second clickstop to turn on the headlights
to full intensity for driving at night.
When setting the knob to the third clickstop (“AUTO”), the
headlights will automatic ally adjust to full intensity and/or turn
on the other lights depending on the darkness of the
surroundings. Likewise, as the surroundings become brighter,
the headlights will turn to reduced intensity, ultimately turning
off the other lights.
NOTICE
To prevent the battery from being discharged, do not
leave the lights on longer than necessary when the
engine is not running.

SWITCHES
32
HEADLIGHT DIMMER AND TURNSIGNAL SWITCH
12X002a
For high beam, push the lever forward. Pull it back for low
beam. For the headlight flasher, pull it further back.
A blue light in the instrument cluster indicates high beam or
headlight flasher is on.
The headlight flasher works even when the headlight switch is
off.
12X003a
For signaling turns, move the lever up or down in the
conventional manner.
The ignition key must be in the “ON” position.
The turn signal is self −cancelling after a turn, but after a lane
change, you may have to cancel it by hand. You can also signal
a lane change by moving the turn signal lever partway and
holding it there.
If the green light in the instrument cluster flashes faster than
normal, it indicates that the front or rear turn signal bulb has
burned out. If this indicator light does not come on, the fuse
or the indicator light itself has probably failed.

SWITCHES
36
REAR WINDOW WIPER ANDWASHER SWITCH
12X009b
 1Washer on during wiping 2Washer on
To turn the wipers on, twist the knob at the end of the lever.
The ignition key must be in the “ON” position.
There are 2 settings:
“LO” position: Intermittent operation
“HI” position: Normal operation
If you stop the vehicle with the rear window wiper switch in the
“ON” position, the wiper speed automatically changes from low
speed to intermittent operation speed. If you shift the selector lever
to the “R” position while the
windshield wipers are operating or for 17 seconds after the
windshield wipers stop operating, the rear window wiper will
activate once.*
NOTE: *This feature can be deactivated. Ask your Lexus
dealer for details.
To make the washer squirt, twist the knob downward to
position 2.
The rear wiper will automatically make 3 wipes and then a
single wipe later to sweep the rear window completely.
To make the washer squirt while operating in “ON”
position, twist the knob upward to position 1.
The knob automatically returns from these positions after you
release it.
If the rear window wiper is off, it will operate a couple of times
after the washer squirt.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes very low.
For information on adding washer fluid, see “Adding washer
fluid” on page 458.
NOTICE
Do not operate the rear window wiper if the rear window
is dry. It may scratch the glass.

SWITCHES
37
HEADLIGHT CLEANER SWITCH(CANADA ONLY)
12X015d
To spray fluid on the headlights, push the switch with the
headlights on.
The ignition key must be in the “ON” position.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes very low.
For information on adding washer fluid, see “Adding washer
fluid” on page 458.
NOTICE
Do not turn the headlight cleaner on with the washer
fluid tank empty. It may cause the cleaner motor to
overheat.
REAR WINDOW DEFOGGER SWITCH
12X514a
To turn the electric rear window defogger on, push the
switch.
The ignition key must be in the “ON” position.
The thin heater wires on the inside of the rear window will
quickly clear the surface. An indicator light will illuminate to
indicate the defogger is operating.
The system will automatically shut off when the defogger has
operated about 15 minutes.
If further defrosting or defogging is desired, simply actuate the
switch again. When the surface has cleared, push the switch
once again to turn the defogger off. Continuous use may cause
the battery to discharge, especially during stop− and−go
driving. The defogger is not designed to dry rain water or to
melt snow.

SWITCHES
38
NOTICE
When cleaning the inside of the rear window, be
careful not to scratch or damage the heater wires or
connectors.
 To prevent the battery from being discharged, turn
the switch off when the engine is not running.
OUTSIDE REAR VIEW MIRROR
DEFOGGER SWITCH
12X500a
To turn the electric outside rear view mirror defogger on,
push the switch.
The ignition key must be in the “ON” position.
The thin heater wires on the heater panels in the outside rear
view mirrors will quickly clear the surface. Keep your hands off
the mirror faces when the switch is on. An indicator light will
illuminate to indicate the defogger is operating.
The system will automatically shut off when the defogger has
operated about 15 minutes.

SWITCHES
39
CAUTION
Since the mirror surfaces can get hot, do not touch them
when the switch is on.
If further defrosting or defogging is desired, simply actuate the
switch again. When the surface has cleared, push the switch
once again to turn the defogger off. Continuous use may cause
the battery to discharge, especially during stop− and−go
driving. The defogger is not designed to dry rain water or to
melt snow.
If the outside rear view mirrors are heavily coated with ice, use
a spray de −icer before operating the switch.
NOTICE
To prevent the battery from being discharged, turn the
switch off when the engine is not running.
POWER WINDOW SWITCHES
12X006f
 1
For driver’s window
2For front passenger’s window
3For left rear window
4For right rear window
To raise or lower the windows, use the switch on each
door. The passengers’ windows can also be controlled by
the switches on the driver’s door.
The power windows work when the ignition key is in the “ON”
position.
Retained accessory power: Even if the ignition key is turned
to the “ACC” or “LOCK” position with all the doors closed, t\
he
window can be operated until either of the front doors is
opened (or for about 45 seconds).

SWITCHES
40
12L010
Operating the switches
To raise or lower the window, pull the switch halfway up
or push it halfway down.
Automatic operation: To fully raise or lower the window
automatically, pull the switch fully up or push it fully down.
To stop the window partway, lightly push or pull the switch in
the opposite direction and then release it.
Operating the window lock switch
12X007g
 Indicator light
With the window lock switch pressed in, only the driver’s
window can be raised or lowered.
The indicator lights on the switch tell you which of the switches
can be operated.
Even with the window lock switch pressed in, the windows will
be opened from outside the vehicle using an ignition key or
wireless remote control.

SWITCHES
41
Operating the windows from outside the
vehicle
The windows can be operated using an ignition key.*NOTE: *This feature can be deactivated. Ask your Lexus
dealer for details.
11x507
Insert the ignition key into the keyhole on the driver’s side.
To close the windows: Turn the key in the locking direction
and hold it.
After the door is locked, the windows begin to close. To stop
in the middle, return the key.
To open the windows: Turn the key in the unlocking direction
and hold it.
After the door is unlocked, the windows begin to open. To stop
in the middle, return the key.
This function will work even with the window lock switch
pressed in.
Jam protection function
If something gets caught between the window and window
frame during automatic raising operation, retained accessory
power raising operation or raising operation using the ignition
key from outside, the window stops and is lowered.
If the window receives a strong impact, this function may work
even if nothing is caught.
CAUTION
To avoid serious personal injury, you must do the
following.
 Before you close the power windows, always make
sure there is nobody around the power windows. You
must also make sure the heads, hands and other
parts of the bodies of all occupants are kept
completely inside the vehicle. If someone’s neck,
head or hands get caught in a closing window, it
could result in death or serious injury. When anyone
closes the power windows, make sure he or she
operates the windows safely.
 When small children are in the vehicle, never let them
use the power window switches without supervision.
Use the window lock switch to prevent them from
making unexpected use of the switches.
