IN CASE OF AN EMERGENCY
355
(d) Emergency towing
40x600a
If towing is necessary, we recommend you to have it done
by your Lexus dealer or a commercial tow truck service.
If towing service is not available in an emergency, your
vehicle may be temporarily towed by a cable or chain
secured to the emergency towing hook. Use extreme
caution when towing the vehicle.
NOTICE
Never tow a vehicle from the rear with four wheels on the
ground. This may cause serious damage to the
transmission.
A driver must be in the vehicle to steer it and operate the
brakes.
Towing in this manner may be done only on hard −surfaced
roads for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing hook
and towing cable or chain. The hook and towing cable
or chain may break and cause serious injury or damage.
NOTICE
 Do not use front and rear eyelets. It is not designed
for towing.
 Use only a cable or chain specifically intended for
use in towing vehicles. Securely fasten the cable or
chain to the towing hook provided.
Before towing, check that the center differential is unlocked.
(The indicator light must be off with the ignition on.) Release
the parking brake and put the transmission in “N”. The ignition
key must be in “ACC” (engine off) or “ON” (engine running).

MAINTENANCE
388Battery
Your Lexus has a maintenance free battery. You do not have
to add distilled water. For longer life of the battery, however,
see page 450 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 421 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot.
See page 410 for additional
information.
Suspension fluid level
Make sure the suspension fluid level is correct. See page 423
for additional information.
Power steering fluid level
Check the level through the reservoir. The level should be in
the “HOT” or “COLD” range depending on the fluid
temperature. See page 422 for additional information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 255.)
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlights, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning
buzzers function properly.
Steering wheel
Check that it ha s the specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position. For folding −down rear
seatbacks, swing− up rear seat cushions and detachable third
seats, check that the latches lock securely.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.

ENGINE
404– COOLING SYSTEM
Capacity
15.4 L (16.3 qt., 13.6 lmp.qt.)
Coolant type“Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long− life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use “Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.6 − 12.8 V Fully charged
12.2 − 12.4 V Half charged
11.8 − 12.0 V Discharged
[Voltage that is checked 20 minutes after the key is removed with all the
lights turned off]
5A max.

ENGINE
411
62X002c
If the oil level is below or only slightly above the low line,
add engine oil of the same type as already in the engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil. The approximate quantity of oil needed to
raise the level between low and full on the dipstick is indicated
as follows.
1.5 L (1.6 qt., 1.3 lmp. qt.)
For the engine oil capacity, see “Specifications” on page 402.
When the level reaches within the correct range, return the
filler cap and turn the cap clockwise until you hear a click.
NOTICE
 Be careful not to spill engine oil on the vehicle
components.
 Avoid overfilling, or the engine could be damaged.
 Check the oil level on the dipstick once again after
adding the oil.

CHASSIS
423
NOTICE
Avoid overfilling, or the power steering could be
damaged.
 When adding the power steering fluid, avoid spilling
it. The generator under the power steering reservoir
could be damaged if fluid is spilled on it.
CHECKING SUSPENSION FLUID
AHC
63X007c
 1“MAX” line 2“MIN” line
Under the unloaded condition, check the Suspension
Fluid AHC in the following way.
1. Start the engine and put the vehicle height in the “LO” (Low)
mode and then “N” (Normal) mode.
2. Turn off the ignition switch about 30 seconds after the “N”
(Normal) mode indicator light comes on.
3. Make sure the fluid level is between “MAX” and “MIN”.
If the fluid level is lower than “MIN”, have suspension fluid AHC
filled by your Lexus dealer.

ELECTRICAL COMPONENTS
452
NOTICE
Make sure the engine and all accessories are turned
off before performing maintenance.
 When checking the battery, remove the ground cable
first and reinstall it last.
 Be careful not to cause a short circuit with tools.
 Take care no solution gets into the battery when
washing it.
If the battery terminal is disconnected or the battery is run
down...
 The variable gear ratio steering system is reset temporarily
and “VGRS” warning light flashes after you reconnect the
battery terminal. In this case, you should turn off the light
and return the system to normal. To return the system to
normal, see “Variable gear ratio steering system” on page
293.
 The moon roof may not operate automatically and the jam
protection function will not operate correctly after you
reconnect, replace or recharge the battery with the moon
roof slide −opened or tilted up. In any of these cases, you
should return the moon roof to normal. To return the moon
roof to normal, see “Moon roof” on page 95.
Checking battery condition
(a) Checking by fluid level lines
64X005c
 1 Upper line 2Lower line
The fluid (electrolyte) level must be between the upper and
lower lines.
When checking the fluid level, look at all six cells, not just one
or two.
If the level is lower than the lower line, have the battery
checked by your Lexus dealer.

BODY
4661. Rinse off loose dirt with a hose. Remove any mud or road
salt from the underside of the vehicle or the wheel wells.
2. Wash with a mild car
−wash soap, mixed according to the
manufacturer’s instructions. Use a soft cotton mitt and keep
it wet by dipping it frequently into the wash water. Do not rub
hard − let the soap and water remove the dirt.
Fuel filler door: Do not apply water (high −pressure car wash,
for example) at or near the fuel tank inlet with the fuel filler door
opened. If the water enters the air vent, you may experience
trouble with refueling or rough engine idling.
Plastic wheel ornaments: The plastic wheel ornaments are
damaged easily by organic substances. If any organic
substances splash an ornament, be sure to wash them of f with
water and check if the ornament is damaged.
Aluminum wheels: Use only a mild soap or neutral detergent.
Plastic bumpers and side moldings: Wash carefully. Do not
scrub with abrasive cleaners. The bumper and side molding
faces are soft.
Exterior lights: Wash carefully. Do not use organic
substances or scrub them with a hard brush. This may
damage the surfaces of the lights.
Road tar: Remove with turpentine or cleaners that are marked
safe for painted surfaces.
3. Rinse thoroughly − dried soap can cause streaking. In hot
weather you may need to rinse each section right after you
wash it. 4. To prevent water spots, dry the vehicle using a clean soft
cotton
towel. Do not rub or press hard − you might scratch the
paint.
NOTICE
 Do not use organic substances (gasoline, kerosene,
benzine or strong solvents), which may be toxic or
cause damage.
 Do not scrub any part of the vehicle with a hard brush,
which may cause damage.
Automatic car wash
NOTICE
To prevent damage to the antenna, make sure it is
retracted before driving your vehicle through an
automatic car wash.
Your vehicle may be washed in an automatic car wash, but
remember that the paint can be scratched by some types of
brushes, unfiltered washing water, or the washing process
itself. Scratching reduces paint durability and gloss, especially
on darker colors. The manager of the car wash should be able
to advise you whether the process is safe for the paint on your
vehicle.
