2006 LEXUS LX470 fuse

61X004m
INTRODUCTION
396
ENGINE COMPARTMENT OVERVIEW
1 Engine oil filler cap
2 Engine oil level
dipstick
3 Brake fluid reservoir
4 Fuse box
5 Battery
6 Washer fluid tank
7 Condenser
8 Radiator
9 Engine coolant
reservoir
10 Power steering fluid
reservoir
11 Suspension fluid
reservoir

INTRODUCTION
399
Checking brake fluid
Parts (if level is low):
FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking power steering fluid
Parts (if level is low):
Automatic transmission fluid DEXRON
II or III
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking suspension fluid AHC
Parts (if level is low):
Suspension fluid AHC
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking battery condition
Tools:
Warm water
 Baking soda
 Grease
 Conventional wrench (for terminal clamp bolts)
Checking and replacing the blade type fuses
Parts (if replacement is necessary):
Fuse with same amperage rating as original
Checking the cartridge type fuses
Parts (if replacement is necessary):
Genuine Lexus fuse or equivalent with same amperage
rating as original
Adding washer fluid
Parts:
Water
 Washer fluid containing antifreeze (for winter use)
Tools:
 Funnel

SECTION 6 – 4
445
SERVICE PROCEDURES AND
SPECIFICATIONS
Electrical components
Specifications446
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Checking battery condition 450
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery recharging precautions 453
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking and replacing the blade type fuses 454
. . . . . . . . . . . . . . . .
Checking the cartridge type fuses 456
. . . . . . . . . . . . . . . . . . . . . . . . . .
Adding washer fluid 458
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Replacing light bulbs 458
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

ELECTRICAL COMPONENTS
446
SPECIFICATIONS
FUSE LOCATIONS
64X001K
 1Engine compartment
2Driver’s side kick panel
3Passenger’s side kick panel FUSES
64X500
64X604

Engine compartment

ELECTRICAL COMPONENTS
447
64x502b
Driver’s side kick panel
64X501b
Passenger’s side kick panel
No.FuseAMPERECIRCUIT
1 ABS NO.240Anti− lock brake system
2 ABS NO.150Anti−lock brake system
3 AHC50Active height control suspension
(AHC)
4 WIPS7.5No circuit
5 TOWING30Trailer lights
6 MIR HTR15Outside rear view mirror
defogger
7 RR HTR10Rear air conditioning system
8 HAZTRN15Emergency flashers, Turn signal
lights
9 ALTS7.5Charging system
10 NVIR20Lexus night view system
11 FR FOG15Fog lights
12 TOWING
BRK30Trailer lights
13 HEAD
CLNER20Headlight cleaner
14 FRIG10Charging system
15 PANEL7.5Instrument panel light
16 TOWING TAIL30Trailer lights

ELECTRICAL COMPONENTS
448
No.FuseAMPERECIRCUIT
17 TAIL15Parking lights, Tail lights
18 BAT30All components in “ECU−B2”
19 TEL7.5Lexus Link System
20 AMP30Audio system
21 EFI or
ECD No.125Multiport fuel injection
system/Sequential multiport fuel
injection system
22 AM215All components in “IGN”
23 ETCS10Multiport fuel injection
system/Sequential multiport fuel
injection system
24 HORN10Horns
25 HEAD
(RHLWR)10Right− hand headlight (low
beam)
26 HEAD
(LHLWR)10Left− hand headlight (low beam)
27 HEAD
(RHUPR)20Right− hand headlight (high
beam)
28 HEAD
(LHUPR)20Left− hand headlight (high beam)
29 AIR PUMP50Multiport fuel injection
system/Sequential multiport fuel
injection system
30 A/F HTR15Multiport fuel injection
system/Sequential multiport fuel
injection system
No.FuseAMPERECIRCUIT
31 PWR
OUTLET15Power outlets
32 CIG15Cigarette lighter
33 ACC7.5Instrument panel light
34 AM17.5Multiport fuel injection
system/Sequential multiport fuel
injection system
35 DEFOG20Rear window defogger
36 AHCB15Active height control suspension
(AHC)
37 FUEL HTR20Fuel heater
38 POWER HTR7.5Power heater
39 AHCIG20Active height control suspension
(AHC)
40 EFI or
ECD No.210Emission control system
41 GAUGE 110Gauges and meters
42 ECUIG 110Multiport fuel injection
system/Sequential multiport fuel
injection system
43 ECUB110Navigation system
44 DBL
LOCK15Double lock system

ELECTRICAL COMPONENTS
449
45 A/C15Air conditioning systemNo.FuseAMPERECIRCUIT
46 STOP15Stop lights
47 OBD27.5On−board diagnosis system
48 IDLE UP7.5Idle− up system
49 LH SEAT30Power seat system
50 DOOR25Power door lock system, Power
windows
51 SUN
ROOF25Electronic moon roof
52 RR
WIPER15Rear wiper system
53 ECUB210Power door lock system, Power
window
54 DIFF20Four− wheel drive system
55 WASHER15Windshield washer
56 RADIO10Audio system
57 DOME10Interior lights
58 VGRS40Variable gear ratio steering
system
59 P/W (FL)20Power window
60 P/W (RL)20Power window
61 WIPER25Windshield wiper
62 ECUIG 210Rear air conditioning system

ELECTRICAL COMPONENTS
450
No.FuseAMPERECIRCUIT
63 SEATHTR15Seat heater
64 GAUGE 210Back− up lights
65 MET7.5Gauges and meters
66 IGN7.5Multiport fuel injection
system/Sequential multiport fuel
injection system
67 SECURITY7.5Theft deterrent system
68 P/W (RR)20Power window
69 P/W (FR)20Power window
70 BATT
CHARGE30Trailer charging system
71 TIL & TEL20Tilt and telescopic steering
72 RR A/C30Rear air conditioning system
73 RH SEAT30Power seat system
CHECKING BATTERY CONDITION
Precautions
CAUTION
BATTERY PRECAUTIONS
The battery produces flammable and explosive
hydrogen gas.
 Do not cause a spark by contacting the battery
terminals with tools.
 Do not smoke or light a match near the battery.
The electrolyte contains poisonous and corrosive
sulfuric acid.
 Avoid contact with eyes, skin or clothes.
 Never inhale or swallow electrolyte.
 Wear protective safety glasses when working near
the battery.
 Keep children away from the battery.
EMERGENCY MEASURES
 If electrolyte gets in your eyes, flush your eyes with
clean water for at least 15 minutes and get immediate
medical attention. If possible, continue to apply
water with a sponge or cloth while traveling to the
medical office.
