IN CASE OF AN EMERGENCY
337
When boosting, use the battery of matching or higher quality.
Any other battery may be difficult to jump start with.
If jump starting is difficult, charge the battery for several
minutes.
2. If required, remove all the vent plugs from the booster
battery. Lay a cloth over
the open vents on the booster battery.
(This helps reduce the explosion hazard, personal injuries and
burns.)
If the booster battery is an extended maintenance interval
battery, it is not necessary to remove the vent plugs.
3. If the engine in the vehicle with the booster battery is not
running, start it and let it run for about 5 minutes. During jump
starting, run the engine at about 2000 rpm with the accelerator
pedal lightly depressed.
4. Locate positive (+) and negative ( −) terminals of each
battery. Connect the jumper cables in the exact order (
1 2
3 4) shown in the illustration.
1 Connect a positive (red) jumper cable clamp to the
positive (+) terminal of the discharged battery.
2Connect the clamp at the other end of the positive (red)
cable to the positive (+) terminal of the booster battery.
3Connect a negative (black) cable clamp to the negative
(−) terminal of the booster battery.
4Connect the clamp at the other end of the negative (black)
cable to a solid, stationary, unpainted metallic point (e.g.
engine hanger) away from the battery. Do not connect it
to or near any part that moves when the engine is
cranked.
CAUTION
When making the connections, to avoid serious injury,
do not lean over the battery or accidentally let the
jumper cables or clamps touch anything except the
correct battery terminals or the ground.
5. Charge the discharged battery with the jumper cables
connected for approximately 5 minutes. At this time, run the
engine in the vehicle with the booster battery at about 2000
rpm with the accelerator pedal lightly depressed.
6. Start your engine in the normal way. After starting, run it at
about 2000 rpm for several minutes with the accelerator pedal
lightly depressed.
7. Carefully disconnect the cables in the exact reverse order:
the negative cable and then the positive cable.
8. Carefully dispose of the battery cover cloths which may now
contain sulfuric acid.
9. If removed, replace all the battery vent plugs.
If the cause of your battery discharging is not apparent (for
example, lights left on), you should have it checked at your
Lexus dealer.
If the first start attempt is not successful...
Check that the clamp on the jumper cables are tight. Recharge
the discharged battery with the jumper cables connected for
several minutes and restart your engine in the normal way.
If another attempt is not successful, the battery may be
depleted. Have it checked at your Lexus dealer.

IN CASE OF AN EMERGENCY
338
IF YOU CANNOT INCREASEENGINE SPEED
If engine speed does not increase when the accelerator
pedal is depressed, the electronic throttle control system
may be faulty. Move the vehicle to a safe place by means
of creeping and call a Lexus dealer for assistance:
1. Depress the brake pedal and shift to the “D” position.
2. Gradually release the brake pedal, and the vehicle starts to
move by creeping. After arriving at a safe place, stop the
vehicle and call a Lexus dealer for assistance.
CAUTION
 The above method of moving the vehicle is for
emergency. Use it only for moving minimum
distances to a safe place.
 Be especially careful to prevent erroneous pedal
operation.
IF YOUR VEHICLE OVERHEATS
If your engine coolant temperature gauge indicates
overheating, if you experience a loss of power, or if you
hear a loud knocking or pinging noise, the engine has
probably overheated.
When the engine overheats
Pull safely off the road, stop the vehicle and turn on your
emergency flashers. Put the transmission in “P” and apply the
parking brake.
A: If steam is coming from your engine:
Turn off the engine. Leave the hood closed until there is no sign
of steam or coolant. Your engine could have been seriously
damaged already. Call your Lexus dealer for assistance.
CAUTION
To help avoid personal injury, keep the hood closed until
there is no steam. Escaping steam or coolant is sign of
very high pressure.

IN CASE OF AN EMERGENCY
339
B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place − well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission
in “P”.
4. Have everyone get out of the vehicle on the side away
from traffic.
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Turn off the active height control suspension by
pushing the active height control switch.
 Follow jacking instructions.
 Do not put any part of your body under a vehicle
supported by a jack. Personal injury may occur.
 Do not start or run the engine while your vehicle
is supported by the jack.

IN CASE OF AN EMERGENCY
350
IF YOUR VEHICLE BECOMESSTUCK
If your vehicle becomes stuck in snow, mud, sand, etc.
then you may attempt to rock the vehicle free by moving
it forward and backward.
Turn off the active traction control system to become
unstuck to allow the tires to spin enough to remove the
vehicle from the obstruction. (For details, see “Vehicle
stability control system” on page 290.)
CAUTION
Do not attempt to rock the vehicle free by moving it
forward and backward if people or objects are anywhere
near the vehicle. During the rocking operation the
vehicle may suddenly move forward or backward as it
becomes unstuck, causing injury or damage to nearby
people or objects.
NOTICE
If you rock your vehicle, observe the following
precautions to prevent damage to the transmission and
other parts.
 Do not depress the accelerator pedal while shifting
the selector lever or before the transmission is
completely shifted to forward or reverse gear.
 Do not race the engine and avoid spinning the
wheels.
 If your vehicle remains stuck after rocking the vehicle
several times, consider other ways such as towing.

IN CASE OF AN EMERGENCY
355
(d) Emergency towing
40x600a
If towing is necessary, we recommend you to have it done
by your Lexus dealer or a commercial tow truck service.
If towing service is not available in an emergency, your
vehicle may be temporarily towed by a cable or chain
secured to the emergency towing hook. Use extreme
caution when towing the vehicle.
NOTICE
Never tow a vehicle from the rear with four wheels on the
ground. This may cause serious damage to the
transmission.
A driver must be in the vehicle to steer it and operate the
brakes.
Towing in this manner may be done only on hard −surfaced
roads for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing hook
and towing cable or chain. The hook and towing cable
or chain may break and cause serious injury or damage.
NOTICE
 Do not use front and rear eyelets. It is not designed
for towing.
 Use only a cable or chain specifically intended for
use in towing vehicles. Securely fasten the cable or
chain to the towing hook provided.
Before towing, check that the center differential is unlocked.
(The indicator light must be off with the ignition on.) Release
the parking brake and put the transmission in “N”. The ignition
key must be in “ACC” (engine off) or “ON” (engine running).

IN CASE OF AN EMERGENCY
356
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.
Emergency towing hook precautions:
Before emergency towing, check that the hook is not broken
or damaged and that the installation bolts are not loose.
 Fasten the towing cable or chain securely to the hook.
 Do not jerk the hook. Apply steady and even force.
 To avoid damaging the hook, do not pull from the side or at
a vertical angle. Always pull straight ahead.
CAUTION
If the emergency towing hook is used to get out when
your vehicle becomes stuck in the mud, sand or other
condition from which the vehicle cannot be driven out
under its own power, make sure to observe the
precautions mentioned below. Otherwise, excessive
stress will be put on the hook and the towing cable or
chain may break, causing serious injury or damage.
If the towing vehicle can hardly move, do not forcibly
continue the towing. Contact your Lexus dealer or a
commercial tow truck service for assistance.
 Tow the vehicle as straight ahead as possible.
 Keep away from the vehicle during towing.
Tips for towing a stuck vehicle:
The following methods are effective to use when your
vehicle is stuck in the mud, sand or other condition from
which the vehicle cannot be driven out under its own
power. Use extreme caution when towing the vehicle. In
addition, keep away from the vehic les and towing cable or
chain when towing.
 Remove the sand and soil in the front and the back of the
tires.
 Place stones or wood under the tires.

IN CASE OF AN EMERGENCY
359
Those standards were based
on comprehensive and periodic
evaluations of the relevant scientific literature. Over 120
scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the
available body of research to develop the ANSI Standard
(C95.1).
The design of the Lexus Link System complies with the FCC
guidelines in addition to those standards.
Information for using the Lexus Link System
The Lexus Link System is a subscription −based service. To
obtain any of the Lexus Link services you must have enrolled
with the Lexus Link Call Center and have an active
subscription. It is important to be aware that an active
subscription is required to receive safety and security services.
To learn more about your subscription status or how to renew
or extend your subscription, please push the “SERVICES”
button and speak to the Lexus Link Advisor, or you may dial toll
free 1 −800− 25 Lexus (Toll− Free) (1−800− 255−3987) and
select the option for Lexus Link. If you are not enrolled, you will
hear the explanation about the Lexus Link System. The actual
message is shown on “Audible voice prompts” on page 381.
If you push the “SERVICES” button again, you will be
connected to the Lexus Link Call Center for enrollment. To
cancel the enrollment call, push the phone button.
NOTICE
This system is only operational in GPS (Global
Positioning System) and cellular coverage areas.
Services may not be available in an area where the GPS
and cellular phone signals cannot be received.

IN CASE OF AN EMERGENCY
373
9. Say “Six”.
You will hear “Six”.
10. Say “Zero”.
You will hear “Zero”.
11. Say “Eight”.
You will hear “Eight”.
12. Say “Dial”.
Lexus Link sends tones. Voicemail will respond to 4608.
Automated system example:
1. Press the phone button.
You will hear “Lexus Link ready”.
2. Say “Call”.
You will hear “Nametag, please”.
3. Say “Business”.
You will hear “Calling business”. “To talk to engineering, press
1; to talk to sales, press 2; to talk to customer care, press 3.”
4. Press the PTT button.
You will hear “First digit to send, please”.
5. Say “One”.
You will hear “One”.
6. Say “Dial”.
Lexus
Link sends tone. The system will respond to the number
1.
INFORMATION
 To differentiate pound and star from other numbers
and commands, you must use the commands
“Pound key” and “Star key”.
 The Lexus Link voiceactivated keypad understands
only numbers, star key and pound key. It does not
understand stored nametags.
 You can erase the last number entered by saying
“Clear”.
