For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xiiPage
1Driving position memory switches
198
. . . . . . . . . . .
2Power window switches 40
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 41
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 204 . . . . . .
6Side vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 30, 32, 33 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switches 33
. . . . . . . . . . . . . . . . . . . .
9Center vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 43
. . . . . . . . . . . . . . . . . . . . .
11Audio system 232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multiinformation display 63
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 214
. . . . . . . . . .
14Rear window defogger switch 38
. . . . . . . . . . . . . . . . . .
15Front passenger’s seat belt reminder light 55 . . . . . .
16“AIRBAG ON” and “AIRBAG OFF”
indicator lights 169. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Glove box 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Ashtray 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
19Cigarette lighter 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Seat heater switches 44
. . . . . . . . . . . . . . . . . . . . . . . . . . Page
21Fourwheel drive control lever
356
. . . . . . . . . . . . . . .
22Automatic transmission selector lever 349 . . . . . . . .
23Parking brake lever 347
. . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock switch 356
. . . . . . . . . . . . . . .
25Power outlet (12 VDC) 81
. . . . . . . . . . . . . . . . . . . . . . . . .
26Downhill assist control switch 377
. . . . . . . . . . . . . . .
27Electronic modulated suspension
control switch 371 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Rear height control air suspension
switches 366. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Ignition switch 345
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30“2nd STRT” (second start) switch 355
. . . . . . . . . . . .
31Tire pressure warning system
selector switch 393 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Cruise control switch 362
. . . . . . . . . . . . . . . . . . . . . . .
33Audio remote control switches 250
. . . . . . . . . . . . . . .
34Instrument panel light control dial 74
. . . . . . . . . . . . . .
35Hood lock release lever 100
. . . . . . . . . . . . . . . . . . . . .
36Fuel filler door opener 101
. . . . . . . . . . . . . . . . . . . . . . .
37“RSCA OFF” (roll sensing of curtain
shield airbags off) switch 174 . . . . . . . . . . . . . . . . . . . .
38Outside rear view mirror defogger switch 39 . . . . . . .
39Power outlet (115 VAC) main switch 82
. . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xivPage
1Driving position memory switches
198
. . . . . . . . . . .
2Power window switches 40
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 41
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 204 . . . . . .
6Side vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 30, 32, 33 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switches 33
. . . . . . . . . . . . . . . . . . . .
9Center vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 43
. . . . . . . . . . . . . . . . . . . . .
11Rear view monitor/navigation system display
including air conditioning controls and audio
system
(For the navigation system, see the separate
“Navigation System Owner’s Manual”.) 358 . . . . . . .
12Multiinformation display 63
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls
See the separate
. . . . . . . . .
“Navigation System Owner’s Manual”.
14Rear window defogger switch 38
. . . . . . . . . . . . . . . . . .
15Front passenger’s seat belt reminder light 55 . . . . . .
16“AIRBAG ON” and “AIRBAG OFF”
indicator lights 169. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Glove box 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Audio system
See the separate
. . . . . . . . .
“Navigation System Owner’s Manual”.
19Ashtray 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. Page
20Cigarette lighter
80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Seat heater switches 44
. . . . . . . . . . . . . . . . . . . . . . . . . .
22Fourwheel drive control lever 356
. . . . . . . . . . . . . . .
23Automatic transmission selector lever 349 . . . . . . . .
24Parking brake lever 347
. . . . . . . . . . . . . . . . . . . . . . . . .
25Center differential lock switch 356
. . . . . . . . . . . . . . .
26Power outlet (12 VDC) 81
. . . . . . . . . . . . . . . . . . . . . . . . .
27Downhill assist control switch 377
. . . . . . . . . . . . . . .
28Electronic modulated suspension
control switch 371 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Rear height control air suspension
switches 366. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Ignition switch 345
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31“2nd STRT” (second start) switch 355
. . . . . . . . . . . .
32Tire pressure warning system
selector switch 393 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
33Cruise control switch 362
. . . . . . . . . . . . . . . . . . . . . . .
34Speech command switch
See the separate
. . . . . . . . .
“Navigation System Owner’s Manual”.
35Audio remote control switches 250
. . . . . . . . . . . . . . .
36Instrument panel light control dial 74
. . . . . . . . . . . . . .
37Hood lock release lever 100
. . . . . . . . . . . . . . . . . . . . .
38Fuel filler door opener 101
. . . . . . . . . . . . . . . . . . . . . . .
39“RSCA OFF” (roll sensing of curtain
shield airbags off) switch 174 . . . . . . . . . . . . . . . . . . . .
40Outside rear view mirror defogger switch 39 . . . . . . .
41Power outlet (115 VAC) main switch 82
. . . . . . . . . . . .

PPY021
PICTORIAL INDEX
xx
EXTERIOR VIEW
Page
1Rear window defogger38
. . . . . . . . . . .
2Back door 25
. . . . . . . . . . . . . . . . . . . . . .
3Fuel filler door 101
. . . . . . . . . . . . . . . . .
4Moon roof 103
. . . . . . . . . . . . . . . . . . . . .
5Windshield wiper and
washer 33, 558 . . . . . . . . . . . . . . . . . . . .
6Outside rear view mirror 203 . . . . . . . .
7Side door 20
. . . . . . . . . . . . . . . . . . . . . . .
8Tire and wheel 523
. . . . . . . . . . . . . . . . .
9Headlights 30, 559
. . . . . . . . . . . . . . . . .
10Hood 100
. . . . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each Section.

SECTION 1 – 2
29
INSTRUMENTS AND CONTROLS
Switches
Headlight switch30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Headlight dimmer and turn signal switch 32
. . . . . . . . . . . . . . . . . . . . .
Fog light switch 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Windshield wiper and washer switch 33
. . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer switch 37
. . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirror defogger switch 39
. . . . . . . . . . . . . . . . . . . . .
Power window switches 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 43
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat heater switches 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.

SWITCHES
39
OUTSIDE REAR VIEW MIRRORDEFOGGER SWITCH
To turn the electric outside rear view mirror defogger on,
push the switch.
The ignition key must be in the “ON” position.
The thin heater wires on the heater panels in the outside rear
view mirrors will quickly clear the surface. Keep your hands off
the mirror faces when the switch is on. An indicator light will
illuminate to indicate the defogger is operating.
The system will automatically shut off when the defogger has
operated about 5 minutes.
CAUTION
Since the mirror surfaces can get hot, do not touch them
when the switch is on.
If further defrosting or defogging is desired, simply actuate the
switch again. When the surface has cleared, push the switch
once again to turn the defogger of f. Continuous use may cause
the battery to discharge, especially during stop −and−go
driving. The defogger is not designed to dry rain water or to
melt snow.
If the outside rear view mirrors are heavily coated with ice, use
a spray de −icer before operating the switch.
NOTICE
To prevent the battery from being discharged, turn the
switch off when the engine is not running.

OCCUPANT RESTRAINT SYSTEMS
198
DRIVING POSITION MEMORYSYSTEM
A microcomputer will memorize the position of the driver’s
seat, and the positions of the tilt and telescopic steering, and
outside rear view mirrors. Two dif ferent driving position profiles
can be entered into the computer’s memory.
Recording the driving position in the computer’s memory can
only be done when the ignition key is in the “ON” position and
the selector lever is in the “P” position.
Setting the driving position
1. Adjust the driver’s seat, tilt and telescopic steering and
outside rear view mirrors to the desired position.
2. While pushing the “SET” button, push button “1” or “2”
until the signal beeps. The beep sound means that the positions are recorded in the
computer’s memory.
By repeating these two steps and pressing the remaining
button,
the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
When you push button “1” or “2”, the driving position will
be automatically adjusted to the position recorded for that
button.

SECTION 1 – 7
201
INSTRUMENTS AND CONTROLS
Steering wheel and mirrors
Tilt and telescopic steering wheel202
. . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors 203
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 206
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirrors 211
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .

STEERING WHEEL AND MIRRORS
203
Automatic tiltaway steering column*
When the ignition key is removed, the steering column
moves forward away from the driver and also tilts up for
easy exit and entry.
When the key is inserted in the ignition switch, the steering
column returns to the previously set position.NOTE:
* This feature can be deactivated.
Ask your Lexus dealer for details.
OUTSIDE REAR VIEW MIRRORS
Adjust the mirror so that you can just see the side of your
vehicle in the mirror.
Be careful when judging the size or distance of any object seen
in the outside rear view mirror on the passenger’s side
because it is a convex mirror. Any object seen in a convex
mirror will look smaller and farther away than if seen in a normal
flat mirror.
When you push the outside rear view mirror defogger switch,
the heater panels in the outside rear view mirrors will quickly
clear the mirror surface. (See “Outside rear view mirror
defogger switch” on page 39.)
The rear view mirrors are rain clearing mirrors that clear the
driver’s rear view when it rains. (For details, see “Rain clearing
mirrors” on page 572.)
