For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xPage
1
Power window switches 37, 57
. . . . . . . . . . . . . . . . . . .
2 Driving position memory switches 198
. . . . . . . . . . .
3 Window lock switch 58
. . . . . . . . . . . . . . . . . . . . . . . . . .
4 Door lock switch 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Side vents 268
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Engine switch 342
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Automatic air conditioning controls 254
. . . . . . . . . .
8 Audio system 274
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Clock 103 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
10 Center vents 268
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 Outside temperature display 106
. . . . . . . . . . . . . . . . .
12 Touch screen 215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Navigation system display (See the separate
“Navigation System Owner’s Manual”)
13 Security indicator light 40
. . . . . . . . . . . . . . . . . . . . . . .
14 Rear window and outside rear view
mirror defogger switch 56 . . . . . . . . . . . . . . . . . . . . . . .
15 Front passenger’s seat belt reminder light 76 . . . . .
16 Emergency flasher switch 60
. . . . . . . . . . . . . . . . . . . . Page
17 Glove box
110
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18 Trunk lid opener main switch 126
. . . . . . . . . . . . . . . .
19 Tire selector switch 442
. . . . . . . . . . . . . . . . . . . . . . . . .
20 Cigarette lighter 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
21 Cupholders 115
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22 Seat heater switches or Seat ventilator/heater
switches 61, 63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23 Traction control system off switch
(Twowheel drive models only) 419 . . . . . . . . . . . . . .
24 Driving pattern selector switch 353
. . . . . . . . . . . . . . .
25 Damping mode select switch
(GS430 only) 417 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26 Coin box 116
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27 Ashtray 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
28 Automatic transmission selector lever 353 . . . . . . .
29 Tire pressure warning system reset switch 440 . . . .
30 Hood lock release lever 124
. . . . . . . . . . . . . . . . . . . . .
31 Parking brake pedal 352
. . . . . . . . . . . . . . . . . . . . . . . . .
32 Switch box xix
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xiiPage
1
Power window switches 37, 57
. . . . . . . . . . . . . . . . . . .
2 Driving position memory switches 198
. . . . . . . . . . .
3 Window lock switch 58
. . . . . . . . . . . . . . . . . . . . . . . . . .
4 Door lock switch 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Side vents 268
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Engine switch 342
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Automatic air conditioning controls 254
. . . . . . . . . .
8 Audio system 274
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Clock 103 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
10 Center vents 268
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 Outside temperature display 106
. . . . . . . . . . . . . . . . .
12 Touch screen 215
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Security indicator light 40
. . . . . . . . . . . . . . . . . . . . . . .
14 Rear window and outside rear view
mirror defogger switch 56 . . . . . . . . . . . . . . . . . . . . . . .
15 Front passenger’s seat belt reminder light 76 . . . . .
16 Emergency flasher switch 60
. . . . . . . . . . . . . . . . . . . . Page
17 Glove box
110
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18 Trunk lid opener main switch 126
. . . . . . . . . . . . . . . .
19 Tire selector switch 442
. . . . . . . . . . . . . . . . . . . . . . . . .
20 Cigarette lighter 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
21 Cupholders 115
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22 Seat heater switches or Seat ventilator/heater
switches 61, 63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23 Traction control system off switch
(Twowheel drive models only) 419 . . . . . . . . . . . . . .
24 Driving pattern selector switch 353
. . . . . . . . . . . . . . .
25 Damping mode select switch
(GS430 only) 417 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26 Coin box 116
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27 Ashtray 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
28 Automatic transmission selector lever 353 . . . . . . .
29 Tire pressure warning system reset switch 440 . . . .
30 Hood lock release lever 124
. . . . . . . . . . . . . . . . . . . . .
31 Parking brake pedal 352
. . . . . . . . . . . . . . . . . . . . . . . . .
32 Switch box xix
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

G00001
PICTORIAL INDEX
xx
EXTERIOR VIEW
Page
1 Fuel filler door 128
. . . . . . . . . . . . . . . .
2 Rear window defogger 56
. . . . . . . . . .
3 Trunk lid 125
. . . . . . . . . . . . . . . . . . . . . .
4 Moon roof 132
. . . . . . . . . . . . . . . . . . . .
5 Windshield wiper
and washer 49, 579
. . . . . . . . . . . . . . . .
6 Outside rear view mirror 205 . . . . . . .
7 Door 35
. . . . . . . . . . . . . . . . . . . . . . . . . .
8 Tire and wheel 539
. . . . . . . . . . . . . . . .
9 Headlights 44, 584
. . . . . . . . . . . . . . . . .
10 Hood 124
. . . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each Section.

KEYS AND DOORS
20The doors cannot be locked using the entry function in the
following conditions:
G11029

Key reminder alarm
If you push the lock button on the outside door handle
with an electronic key left in the vehicle, an alarm sounds
for 2 seconds and the doors will not lock.
Before you push the lock button, make sure you are carrying
the electronic key.
INFORMATION
 Do not put an electronic key on the instrument panel,
rear package tray or floor, or in the glove box or
auxiliary box near the selector lever, which falls
outside of the effective range of the entry function.
As the alarm does not sound when a key is left in such
a place, you might accidentally lock the doors by
pushing the lock button on the outside door handle
and be locked out of the vehicle. Be sure to take the
electronic key with you.
 If you have the electronic key but bring it very close
to the window or outside door handle, the alarm
might activate. In this case, keep the electronic key
a certain distance away from the window or outside
door handle and then push the lock button again.
 If the electronic key is left in the vehicle, attempting
to lock the door by pushing in the lock button located
in the inside door handle and closing the door will
unlock all the doors and activate the alarm for 2
seconds.

KEYS AND DOORS
28For vehicles sold in Canada
This device complies with RSS− 210 of Industry
Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.
(c) Wireless remote control*
G11014
1 Locking the doors
2Unlocking the doors and opening the windows and
moon roof
3Unlocking the trunk lid
4Sounding an alarm
5Indicator light
NOTE:
*This feature can be deactivated as vehicle theft deterrent
measure in case of the loss of the electronic key.
Ask your Lexus dealer for details.
When you operate any button on the electronic key, push it
slowly and firmly. At this time, the indicator light flashes once.

KEYS AND DOORS
32OPERATING THE WINDOWS AND MOON ROOF
The windows and moon roof can be operated using an
electronic key from outside the vehicle.*
NOTE:
*The windows can be deactivated. The moon roof can be
set to slide open, tilt up or deactivated.
Ask your Lexus dealer for details.
G11017
Push the “UNLOCK” button until the windows and moon roof
start to move. When you release the button, the windows and
moon roof stop operating.
This function will work even with the window lock switch
pressed in. For vehicles sold in U.S.A.
This device complies with
Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
NOTICE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and
receiver.
 Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.

KEYS AND DOORS
36If a wrong key is used, the key cylinder rotates freely to isolate
inside
mechanism. So, door locking is protected from thieves.
The windows and moon roof can be opened and closed from
outside the vehicle using a mechanical key. For details, see
“Power window switches” on page 57 and “Moon roof” on page
132.
Locking with inside lock button
G11002
 1 Lock 2Unlock
Push in the lock button to lock and unlock the door.
The front doors can be opened by pulling the inside handles
even if the lock buttons are in the locked position.
CAUTION
Do not pull the inside handle of the front doors while
driving. The doors will open and an accident may occur.
Lexus strongly recommends that all children be placed
in the rear seat of the vehicle.

KEYS AND DOORS
42
Testing the system
1. Open all the windows.
2. Set the system as described above.
The front doors should be locked with entry function, wireless
remote control or a mechanical key. Make sure the indicator
light flashes.
3. Unlock one of the doors from the inside through one of
the opened windows.
The system should activate the alarm.
4. Unlock any of the doors with entry function, the
wireless remote control or a mechanical key to cancel the
system.
5. Repeat this operation for the other doors, trunk and
hood.
When testing the hood, also check that the system is activated
when the battery terminal is disconnected and then
reconnected.
If the system does not work properly, have it checked by your
Lexus dealer.
NOTICE
When disconnecting the battery, be sure to cancel the
theft deterrent system. Otherwise, the system could
activate an alarm and lock the unlocked door(s)
automatically.
