GAUGES, METERS AND SERVICE REMINDER INDICATORS
78At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the engine switch is
selected in “ACC” or “OFF” mode.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle’s emission control system and
OBD (On
−Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see “Emissions inspection and maintenance (I/M)
programs” on page 497.
(h) Master Warning Light
If any system malfunctions, this warning light comes on or
flashes together with a warning tone, and a warning message
appears on the multi−information display. When the cause of
the problem is eliminated, the warning tone and message on
the display will turn off.
(i) ”ABS” Warning Light
The light comes on when the engine switch is selected in
“IG−ON” mode.
GS430—If the anti−lock brake system and the brake assist
system work properly, the light turns of f in a few seconds after
the engine is started. Thereafter, if either system malfunctions,
the light comes on again.
GS300—If the anti−lock brake system and the brake assist
system work properly, the light turns of f in a few seconds after
the engine switch is selected in “IG−ON” mode. Thereafter, if
either system malfunctions, the light comes on again.
When the “ABS” warning light is on, the anti− lock brake system
and the brake assist system do not operate, but the brake
system still operates conventionally.
If either of the following conditions occur, this indicates a
malfunction somewhere in the components monitored by
the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on when the engine switch is
selected in “IG −ON” mode.
 The light remains on after the engine is started (GS430), or
remains on after the engine switch is selected in “IG −ON”
mode (GS300).
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
79
CAUTION
If the “ABS” warning light remains on together with the
brake system warning light (red), immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.
GS430 only—Either of the following conditions may
occur, but does not indicate a malfunction:
 The light may stay on for about 60 seconds after the engine
is started. It is normal if it turns off after a while.
 Depressing the brake pedal repeatedly may turn on the
light. It is normal if it turns off after a few seconds.
(j) Open Door Warning Light
This light remains on until all the doors are completely closed.
(k) Adaptive Front Lighting System Off
Indicator Light
This light comes on when yo u turn off the Adaptive Front
Lighting System (AFS) by pushing the “AFS OFF” switch.
If there is a problem somewhere in the Adaptive Front Lighting
System (AFS) or automatic headlight leveling system, the light
flashes. At this time, both systems do not operate properly.
Although it is no problem to continue driving, have your vehicle
checked by your Lexus dealer as soon as possible.
(l) Low tire pressure warning light
This light comes on when the engine switch is selected in
“IG−ON” mode. If the tire pressure warning system works
properly and tire inflation pressure is appropriate, the light
goes off after a few seconds.
This light comes on or flashes in the following cases when the
engine switch is selected in “IG −ON” mode.
 When the low tire inflation pressure is detected while
driving...
If any tire has low inflation pressure, the light comes on.
The light goes off after the tire inflation pressure is adjusted
to a specified level.
 When initializing the system...
If initialization is completed, the light blinks three times.
 When the system malfunctions...
If the system malfunctions, the light blinks.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
80Although it is no problem to continue driving, have your
vehicle
checked by your Lexus dealer as soon as possible.
(m) Electric Power Steering System Warning
Light
The light comes on when the engine switch is selected in
“IG−ON” mode. If the electric power steering system works
properly, the light turns off after a few seconds. If the system
has malfunctions, the light comes on again.
If the following conditions occur, this indicates a
malfunction somewhere in the components monitored by
the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on when the engine switch is
selected in “IG −ON” mode or remains on.
 The light stays on while you are driving.
The warning light turning on while racing the engine for a long
time may not indicate malfunction. To turn off the light, restart
the engine and start driving.
CAUTION
If the electric power steering system warning light
comes on, take your vehicle to your Lexus dealer as
soon as possible. In this case, more effort is required
for the steering wheel to turn than usual. Drive your
vehicle while firmly gripping the steering wheel.
(n) PreCollision System Warning Light
The light warns that there is a problem somewhere in the
pre−collision system.
The light comes on when the engine switch is selected in
“IG−ON” mode. If the system works properly, the light goes off
after a few seconds.
If the light does not come on when the engine switch is selected
in “IG−ON” mode, have your vehicle checked by your Lexus
dealer.
(o) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(p) Key Reminder Buzzer
This buzzer acts as a reminder to turn off the engine when you
bring out the electronic key from the vehicle with the engine
switch in “IG−ON” or “ACC” mode.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
81
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Select the engine switch in “IG−ON” mode.
The following service reminder indicators should come on.

or
(red)
or
or

(yellow)
WG10
WG6 WG7 WG8
The following service reminder indicators go off after a few
seconds.
WG6
WG8 WG10
GS300 only—The above and following service reminder
indicators go off after a few seconds.
(yellow)

or
The following service reminder indicator goes off after about 6
seconds.
The lights other than the slip indicator light may stay on for
about 60 seconds after the engine is started. It is normal if they
go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
85
Trunk Open Warning
G13007
When any door, hood or trunk is open with the engine
switch in “IGON” mode, a message appears to let you
know which door, the hood or trunk is open. If you
continue driving in this condition, the master warning
light flashes and a warning tone sounds when the vehicle
speed exceeds 5 km/h (3 mph).
If any of the above warning messages appears, stop your
vehicle and close the door, hood or trunk securely.
 Moon Roof Warning
G13013
If the driver’s door is opened with the engine switch
turned off and the moon roof opened, the master warning
light flashes, a warning tone sounds and the above
message appears.
When you leave your vehicle, be sure to close the moon roof.
Parking Brake Release Warning
G13009
If you start driving with the parking brake applied, the
master warning light flashes, a warning tone sounds and
the above message appears when the vehicle speed
exceeds 5 km/h (3 mph).
If the above warning message appears, stop your vehicle and
release the parking brake.
 Headlight Leveling System Failure Warning
G13010
If there is a problem in the automatic headlight leveling
system, the master warning light comes on, a warning
tone sounds and the above message appears.
If the above warning message appears, have your vehicle
checked by your Lexus dealer as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
86
Rear Lights System Failure Warning
G13011
If there is a problem in the rear lights system (tail lights,
license plate light, stop lights, rear side marker light, high
mounted stoplight), the master warning light comes on, a
warning tone sounds and the above message appears.
If the above warning message appears, have your vehicle
checked by your Lexus dealer as soon as possible.
 Low Washer Fluid Warning
G13020
When the fluid level in the tank becomes very low, the
master warning light flashes, a warning tone sounds and
the above message appears.
Fill the tank as soon as possible.
 Low Engine Oil Pressure Warning
G13012
When the engine oil pressure becomes too low, the
master warning light flashes, a warning tone sounds and
the above message appears.
If this message appears while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The message may appear when the oil level is extremely low.
It is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle while this warning message is
displayed even for one block. It may ruin the engine.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
87
Low Engine Oil Level Warning
G13022
When the engine oil level is too low, the master warning
light comes on, a warning tone sounds, and the above
message appears.
Add oil as soon as possible. (For instructions, see “Checking
the engine oil level” on page 522.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this message
may appear due to the movement of engine oil in the engine.
In normal conditions, due to engine oil consumption, this
message may a ppear earlier than the specified service interval
of the scheduled maintenance. This is because the engine oil
is consumed to the low level within the scheduled maintenance
interval and does not indicate a problem. (For detailed
information, see “Facts about engine oil consumption” on page
520.)
NOTICE
Continued engine operation with low engine oil will
damage the engine.
 Engine Oil Maintenance Reset Warning (U.S.A.
only)
G13033
This message indicates that the engine oil maintenance
data has been reset. After replacing the engine oil, be sure
to reset the maintenance data.
To reset the data, perform the following operations:
1. Push the “ODO TRIP” switch in the switch box to
change the display to blank.
2. Turn the engine switch off.
3. Turn the engine switch on with the trip meter “RESET”
switch held down.
4. Keep pushing the “RESET” switch for longer than 7
seconds after the engine switch is turned on.
After the above operation, the master warning light comes
on, a warning tone sounds and the above message
appears to inform you that the engine oil maintenance
data has been reset.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
88
Engine Oil Replacement Reminder (U.S.A. only)
G13035
If the driving range exceeds 4,500 miles after the engine
oil maintenance data is reset, the master warning light
comes on, a warning tone sounds and the above message
appears for about 15 seconds when you select the engine
switch in “IGON” mode.
This message indicates that the engine oil should be replaced
soon. If the message appears, it is recommended to inspect
the engine oil with the engine switch off. For details about
inspection, see “Checking the engine oil level” on page 522.
If the engine oil level is low, engine oil should be replaced.
Have it replaced at your Lexus dealer.
After the engine oil replacement, reset the engine oil
maintenance data and make sure the “OIL MAINT RESET”
appears on the display.
NOTICE
The warning message on the display is based on the
driving range after the engine oil maintenance data
reset. This is not based on the monitoring of dirty
condition of the engine oil.
 Engine Oil Replacement Warning (U.S.A. only)
G13034
If the driving range exceeds 5,000 miles after the engine
oil maintenance data is reset, the master warning light
comes on, a warning tone sounds and the above message
appears.
This message indicates that the engine oil should be replaced
as soon as possible. If the message appears, it is
recommended to inspect the engine oil with the ignition off. For
details about inspection, see “Checking the engine oil level” on
page 522.
If the engine oil level is low, engine oil should be replaced.
Have it replaced at your Lexus dealer.
After the engine oil replacement, reset the engine oil
maintenance data and make sure the “OIL MAINT RESET”
appears on the display.
NOTICE
The warning message on the display is based on the
driving range after the engine oil maintenance data
reset. This is not based on the monitoring of dirty
condition of the engine oil.
