2006 KIA AMANTI fuse

613
In case of an emergency
1
2
3
4
5
6
7
8
910
Driver-side knee bolster
Description Fuse rating Protected component
B/ALARM10A Burglar alarm
A/BAG 15A Air bag
C/LIGHTER 20A Cigar lighter
S/WARMER 10A Seat warmer
P/WDW(RH) 20A Power window (right)
P/HANDLE 15A Power steering wheel
T/SIG LP 15A Turn signal light
HTD GLASS 30A Defroster
TRUNK OPEN 15A Trunk lid opener
CLUSTER 10A Cluster
A/BAG IND 10A Air bag indicator
P/OUTLET 20A Electrical power socket
LAN UNIT 10A Lan unit
CURTAIN(RR) 10A Electric curtain (rear)
FOG LP(RR), PIC 15A Fog light (rear), Personal identifi- cation card
F/LID OPEN 15A Fuel filler lid opener
P/SEAT(RR) 30A Power seat (rear)
B/ALARM 10A Burglar alarm
STOP LP 15A Stop light
TRIP COMPUTER 10A Trip computer
B/UP LP 10A Back-up light
AV 10A Audio
H/LP 10A Headlight
Description Fuse rating Protected component
A/CON10A Air-conditioning system
P/WDW(LH) 20A Power window (left)
TAIL LP(RH) 10A Taillight (right)
BACK WARN’ G10A Back warning
DR LP 10A Door courtesy lamp
MIRROR HTD 10A Outside review mirror defroster
ENG SNSR 10A
Power train control system sensors
T/REDUCER10A Seat belt tension reducer
CLOCK 10A Clock
WIPER(FR) 20A Wiper (front)
EPS 10A Electronic power steering
TAIL LP(LH) 10A Tail light (left)
ROOM LP 10A Room lamp
AV, CLOCK 15A Audio, Clock
LAN UNIT 10A Lan unit
SHUNT CONN - Switch illumination
POWER/CONN - Power connector

In case of an emergency14
6
1
2
3
4
5
6
7
8
910
Power connectorYour vehicle is equipped with a
power connector to prevent battery
discharge if your vehicle is parked
without being operated for prolonged
periods. Use the following proce-
dures before parking the vehicle for
prolonged period. 1. Turn off the engine.
2. Turn off the headlights and tail
lights.
3. Open the driver-side knee bolster cover and pull up the
“POWER/CONN”.
✽ ✽NOTICE• If the power connector is pulled up
from the fuse panel, the warning
chime, AV system, clock and
intetrior lamps, etc., will not oper-
ate. Some items must be reset after
replacement. (Refer to “Items to
be reset···.” on page 7-36)
• Even though the power connector is pulled up, the battery can still
be discharged by operation of the
headlights or other electrical
devices.
1GHA403Power
connector

Index4
10Economical Operation, Suggestions for . . . . . . . . . . . 5-6
Electrical
Circuit Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Power socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-105
System (Specifications) . . . . . . . . . . . . . . . . . . . . . . 8-3
Electronic stability program . . . . . . . . . . . . . . . . . . . 4-29
Emergency In Case of an . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Roadside Assistance . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Emission Control System . . . . . . . . . . . . . . . . . . . . . . 5-3
Engine Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
Exhaust Gas Precautions . . . . . . . . . . . . . . . . . . . . . 5-3
Oil and Filter, Changing the . . . . . . . . . . . . . . . . . . 7-15
Oil and Oil Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Oil Level, Checking the . . . . . . . . . . . . . . . . . . . . . 7-15
Oil Pressure Warning . . . . . . . . . . . . . . . . . . . . . . . 4-37
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Starting the . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Exhaust Gas Precautions, Engine . . . . . . . . . . . . . . . . 5-3
Exterior Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
7-53
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2 Fan Speed Control Button . . . . . . . . . . . . . . . . . . . . . 4-58
Filler Lid, Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-89
Filter
Changing the Engine Oil and . . . . . . . . . . . . . . . . . 7-15
Engine Oil and Oil . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Finish Damage Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-54
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-53
Flasher, Hazard Warning . . . . . . . . . . . . . . . . . . 4-53, 6-2
Flat Tire, If You Have a . . . . . . . . . . . . . . . . . . . . . . . 6-20
Flooded Areas, Driving in . . . . . . . . . . . . . . . . . . . . . 5-12
Fluids, Lubricants and . . . . . . . . . . . . . . . . . . . . . . . . 7-28
Fuel Filler Lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-89
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Level Warning, Low . . . . . . . . . . . . . . . . . . . . . . . 4-39
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Fuse/Relay Panel Description . . . . . . . . . . . . . . . . . . 6-10
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 6-7 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Gasoline Engine (unleaded) . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Containing Acohol and Methanol . . . . . . . . . . . . . . . 5-2
Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-100
1
2
3
4
5
6
7
8
910
E
FG

Index6
10Label
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
Tire Specification/Pressure . . . . . . . . . . . . . . . . . . . 5-22
Vehicle Certification Number . . . . . . . . . . . . . . . . . 5-21
Lamp, door courtesy . . . . . . . . . . . . . . . . . . . . . . . . . 3-98
Lap/Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43 Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
Webbing, Cleaning the . . . . . . . . . . . . . . . . . . . . . . 7-57
Light Bulbs (Specifications) . . . . . . . . . . . . . . . . . . . . . . . 8-5
Bulb Replacement, Interior . . . . . . . . . . . . . . . . . . 7-47
Bulb Replacement, License Plate . . . . . . . . . . . . . . 7-58
Bulb Replacement, Rear Combination . . . . . . . . . . 7-48
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-97
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . 3-97
Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
3-97
Lighter, Cigarette . . . . . . . . . . . . . . . . . . . . . . . . . . 3-102
Lighting, Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
Lights, interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-97
Locks From inside the vehicle, operating door . . . . . . . . . 3-11
From outside the vehicle, operating door . . . . . . . . . 3-9
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
3-9
Low Fuel Level Warning . . . . . . . . . . . . . . . . . . . . . . 4-39
Low Brake Fluid Level Warning . . . . . . . . . . . . . . . . 4-39
Lubricant Specifications . . . . . . . . . . . . . . . . . . . . . . 7-51
Lubricants and Fluids . . . . . . . . . . . . . . . . . . . . . . . . 7-28
Lubrication, Body . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-28
Lumbar Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23 Main Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Aluminum Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . 7-56
Bright Metal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
Finish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-53
Normal - Schedule 1 . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Severe - Schedule 1 . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Service, Scheduled . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Underbody . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
When Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . 5-20
Malfunction Indicator . . . . . . . . . . . . . . . . . . . . . . . . 4-40
Mirror Day/Night Rearview . . . . . . . . . . . . . . . . . . . . . . . 3-94
Outside Rearview . . . . . . . . . . . . . . . . . . . . . . . . . 3-92
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-92
Mode selection Button . . . . . . . . . . . . . . . . . . . . . . . 4-60
Modifications, Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Night, Driving at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
1
2
3
4
5
6
7
8
910
L
MNO
