2006 JEEP LIBERTY wheel alignment

NOTE:Shifting into or out of 4L is possible with the
vehicle completely stopped, however difficulty may oc-
cur due to the mating clutch teeth not being properly
aligned. Several attempts may be required for clutch
teeth alignment and shift completion to occur. The pre-
ferred method is with the vehicle rolling 2 to 3 mph (3 to
5 km/h). Avoid attempting to engage or disengage 4L
with the vehicle moving faster than 2 to 3 mph (3 to 5
km/h).
Selec-Trac \bOperating Information/Precautions —
If Equipped
The Selec-Trac transfer case provides 5 mode positions -
normal 2-wheel drive mode, part-time 4-wheel drive
high range, full-time 4-wheel drive high range, neutral,
and 4-wheel drive low range.
This transfer case is equipped with an inter-axle differ-
ential which allows driving the vehicle in the 4 FULL
TIME position at all times on any given road surface including dry hard surfaced roads. The 4 FULL TIME
mode allows the front and rear wheels to rotate at
different speeds which eliminates driveline binding and
component wear that is normally associated with driving
the vehicle in the 4 PART TIME position on dry hard
surfaced roads. This feature provides the safety, security,
and convenience of operating in 4–wheel drive at all
times regardless of road conditions.
When additional traction is required the 4 PART TIME
and 4LO positions can be used to lock the front and rear
driveshafts together through the transfer case inter-axle
differential and force the front and rear driveshafts to
rotate at the same speed. This is accomplished by simply
moving the shift lever to these positions. The 4 PART
TIME and 4LO positions are intended for loose, slippery
road surfaces only. Driving in the 4 PART TIME and 4LO
positions on dry hard surfaced roads may cause in-
creased tire wear and damage to driveline components.
238 STARTING AND OPERATING

WARNING!
•Do not use a tire, wheel size or rating other than
that specified for your vehicle. Some combinations
of unapproved tires and wheels may change sus-
pension dimensions and performance characteris-
tics, resulting in changes to steering, handling, and
braking of your vehicle. This can cause unpredict-
able handling and stress to steering and suspension
components. You could lose control and have an
accident resulting in serious injury or death. Use
only the tire and wheel sizes with load ratings
approved for your vehicle.
•Never use a tire with a smaller load index or
capacity, other than what was originally equipped
on your vehicle. Using a tire with a smaller load
index could result in tire overloading and failure.
You could lose control and have an accident.
•Failure to equip your vehicle with tires having
adequate speed capability can result in sudden
tire failure and loss of vehicle control.
CAUTION!
Replacing original tires with tires of a different size
may result in false speedometer and odometer read-
ings.
Alignment and Balance
Poor suspension alignment may result in:
•Fast tire wear.
•Uneven tire wear, such as feathering and one-sided
wear.
•Vehicle pull to right or left.
Tires may also cause the vehicle to pull left or right.
Alignment will not correct this problem. See your autho-
rized dealer for proper diagnosis.
STARTING AND OPERATING 267
5

Improper alignment will not cause vehicle vibration.
Vibration may be a result of tire and wheel out-of-
balance. Proper balancing will reduce vibration and
avoid tire cupping and spotty wear.
TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF
EQUIPPED
Base System
The Tire Pressure Monitor System (TPMS) uses wireless
technology with wheel rim mounted electronic sensors to
monitor tire pressure levels (EXCLUDING THE SPARE
TIRE). Sensors, mounted to each wheel as part of the
valve stem, transmit tire pressure readings to the Re-
ceiver Module.
NOTE: It is particularly important, for you to check the
tire pressure in all of your tires regularly and to maintain
the proper pressure. The “Tire Pressure Monitoring Telltale Light” will
illuminate in the instrument cluster, and an au-
dible chime will be activated when one or more
tire pressures is low. The “Tire Pressure Monitoring
Telltale Light” will flash on and off for 10 to 60 seconds
when a system fault is detected. The flash cycle will
repeat every ten minutes or until the fault condition is
removed and reset.
The Tire Pressure Monitoring System (TPMS) consists of
the following components:
•Receiver Module
•4/5 Wheel Sensors
•Tire Pressure Monitoring Telltale Light
268 STARTING AND OPERATING

Turbo Cool Down....................... 220
Turn Signals ................... 1 17,173,357,360
Underhood Fuses ........................ 351
Uniform Tire Quality Grades ................ 399
Universal Transmitter ..................... 145
Unleaded Gasoline ....................... 276
Upholstery Care ........................ 347
Vacuum/Vapor Harnesses ................. 337
Vanity Mirrors ........................... 82
Variance, Compass ....................... 144
Vehicle Identification Number (VIN) ............ 7
Vehicle Loading ......................... 258
Vehicle Modifications/Alterations .............. 8
Vehicle Storage ......................... 355
Viscosity, Engine Oil ................... 321,322
Warning Flasher, Hazard .................. 300 Warning Lights (Instrument Cluster Description) . 173
Warnings and Cautions
..................... 6
Warranty Information ..................... 397
Washer, Adding Fluid ..................... 163
Washers, Windshield .................. 122,330
Washing Vehicle ......................... 345
Waxing and Polishing ..................... 345
Wheel Alignment and Balance ............... 267
Wheel Mounting ........................ 306
Wind Buffeting .......................... 34
Window Fogging ........................ 210
Windows .............................. 32
Power ............................... 32
Windshield Washers ...................... 122
Fluid ............................... 330
Windshield Wiper Blades .................. 330
Windshield Wipers ....................... 123
Wipers, Intermittent ...................... 123
INDEX 419
