CAUTION O Do not store the main sun visor before
storing the extension sun visor.
O Do not pull the extension sun visor forc-
edly downward.
1. To block out glare from the front,
swing down the main sun visor
q 1
.
2. To block glare from the side, remove
the main sun visor from the center
mount and swing it to the side
q 2
.
3. Draw out the extension sun visor
q 3
from the main sun visor to block from
further glare.
AUTOMATIC ANTI-GLARE INSIDE
MIRROR (if so equipped) The inside mirror is designed so that it
automatically changes reflection ac-
cording to the intensity of the headlight
of the following vehicle.
When the inside mirror is in the ªIº
(AUTO) position
q 1
, excessive glare from
the headlights of the vehicle behind you
will be reduced. The AUTO indicator light
q A
(green) will be on. When the switch of
the inside mirror is in the ª q º (OFF) posi-
tion
q 2
, the inside mirror will operate nor-
mally.SPA2176 SPA2157
SUN VISORS MIRRORS
3-32 Pre-driving checks and adjustments
w 06.1.4/V35-D/V5.0
X

8 Maintenance and do-it-yourself Maintenance requirements ............................... 8-2
General maintenance........................................ 8-2
Explanation of general maintenance
items .......................................................... 8-3
Maintenance precautions .................................. 8-5
Engine compartment check locations................ 8-7
Engine cooling system ..................................... 8-8
Checking engine coolant level..................... 8-8
Changing engine coolant............................. 8-9
Engine oil ....................................................... 8-10
Checking engine oil level........................... 8-10
Changing engine oil and filter ................... 8-11
Automatic transmission fluid........................... 8-13
Power steering fluid ........................................ 8-13
Brake and clutch fluid..................................... 8-14
Brake fluid................................................. 8-14
Clutch fluid ............................................... 8-15
Window washer fluid ....................................... 8-15
Battery ............................................................ 8-16
Jump starting ............................................. 8-18
Drive belts ...................................................... 8-19
Spark plugs .................................................... 8-19
Replacing spark plugs ............................... 8-20 Air cleaner...................................................... 8-20
Windshield wiper blades ................................. 8-21
Cleaning .................................................... 8-21
Replacing .................................................. 8-22
Parking brake and brake pedal....................... 8-23
Checking parking brake............................. 8-23
Checking brake pedal................................ 8-23
Brake booster ........................................... 8-24
Fuses .............................................................. 8-25
Engine compartment.................................. 8-25
Passenger compartment ............................ 8-27
Keyfob battery replacement ............................ 8-28
Keyfob (except Intelligent Key) .................. 8-28
Intelligent Key ........................................... 8-29
Lights.............................................................. 8-31
Headlights................................................. 8-33
Exterior and interior lights......................... 8-33
Wheels and tires ............................................ 8-37
Tire pressure ............................................. 8-37
Tire labeling .............................................. 8-41
Types of tires ............................................ 8-43
Tire chains ................................................ 8-44
Changing wheels and tires ........................ 8-45
w 06.1.4/V35-D/V5.0
X

EXPLANATION OF GENERAL
MAINTENANCE ITEMS Additional information on the following
items with ª*º is found later in this sec-
tion.
Outside the vehicle The maintenance items listed here should
be performed from time to time, unless
otherwise specified.
Doors and engine hood: Check that all
doors and the engine hood operate prop-
erly. Also ensure that all latches lock se-
curely. Lubricate hinges and latches if
necessary. Make sure that the secondary
latch keeps the hood from opening when
the primary latch is released.
When driving in areas using road salt or
other corrosive materials, check lubrica-
tion frequently.
Lights*: Clean the headlights on a regular
basis. Make sure that the headlights,
stop lights, tail lights, turn signal lights,
and other lights are all operating properly
and installed securely. Also check head-
light aim.
Road wheel nuts (lug nuts): When
checking the tires, make sure no wheel nuts are missing, and check for any loose
wheel nuts. Tighten if necessary.
Tires*: Check the pressure with a gauge
often and always prior to long distance
trips. If necessary, adjust the pressure in
all tires, including the spare, to the speci-
fied pressure. Check carefully for damage,
cuts or excessive wear.
Tire rotation*:
Sedan: The tires should be rotated every
7,500 miles (12,000 km) to minimize tire
wear variation.
Coupe: The tires cannot be rotated.
Tire, wheel alignment and balance: If the
vehicle should pull to either side while
driving on a straight and level road, or if
you detect uneven or abnormal tire wear,
there may be a need for wheel alignment.
If the steering wheel or seat vibrates at
normal highway speeds, wheel balancing
may be needed.
O For additional information regarding
tires, refer to ªImportant Tire Safety
Informationº (US) or ªTire Safety Infor-
mationº (Canada) in the Warranty In-
formation Booklet. Windshield: Clean the windshield on a
regular basis. Check the windshield at
least every six months for cracks or other
damage. Have a damaged windshield re-
paired by a qualified repair facility.
Windshield wiper blades*: Check for
cracks or wear if they do not wipe prop-
erly.
Maintenance and do-it-yourself
8-3
w 06.1.4/V35-D/V5.0
X

HEADLIGHTS
Replacing the xenon headlight
bulb Xenon headlight bulb:
WARNING HIGH VOLTAGE
When xenon headlights are on, they produce
a high voltage. To prevent an electric shock,
never attempt to modify or disassemble. Al-
ways have your xenon headlights replaced
at an INFINITI dealer. For additional informa-
tion, see ªHeadlight and turn signal switchº
in the ª2. Instruments and controlsº section.
If replacement is required, see an INFINITI
dealer. EXTERIOR AND INTERIOR LIGHTS Item Wattage (W) Bulb No.
Front turn signal light* 21 T20
Front park light* 5 T10
Front side marker light 3.8 T10
Front fog light Sedan: 60/55
Coupe: 55 Sedan: H4
Coupe: H1
Rear combination light
Turn signal 21 T20
Stop/Tail* (LED) Ð
Side marker light* Sedan: (LED)/Coupe: 3.8 Sedan: Ð/Coupe: T10
Back-up light 18 T16
License plate light 5 T10
High-mounted stop light* (LED) Ð
Map light 8 Ð
Rear personal light (Sedan) 8 Ð
Step light 5 Ð
Trunk light 3.4 158
Vanity mirror light 1.32 Ð
*: See an INFINITI dealer for replacement.
Maintenance and do-it-yourself
8-33
w 06.1.4/V35-D/V5.0
X

Floor mat cleaning ............................................. 7-4
Fluid
Automatic transmission fluid (ATF)............. 8-13
Brake and clutch fluid ............................... 8-14
Brake fluid ................................................ 8-14
Capacities and recommended fuel/
lubricants ................................................... 9-2
Engine coolant............................................ 8-8
Engine oil .................................................. 8-10
Power steering fluid .................................. 8-13
Window washer fluid ................................. 8-15
FM-AM-SATELLITE radio with compact disc (CD)
changer ........................................................... 4-22
Fog light switch ............................................... 2-25
Front passenger air bag and status light.......... 1-44
Front power seat adjustment .............................. 1-2
Fuel
Capacities and recommended fuel/
lubricants ................................................... 9-2
Fuel economy ............................................ 5-22
Fuel economy information (display) ............ 4-4
Fuel-filler cap ............................................ 3-28
Fuel-filler door .......................................... 3-28
Fuel octane rating ....................................... 9-3
Fuel recommendation.................................. 9-3
Gauge ......................................................... 2-5
Fuses ............................................................... 8-25
Fusible links .................................................... 8-26
G
Garage door opener, HomeLink Universal
Transceiver ...................................................... 2-46
Gas cap ........................................................... 3-28 Gauge................................................................ 2-3
Engine coolant temperature gauge.............. 2-4
Fuel gauge .................................................. 2-5
Odometer.................................................... 2-3
Speedometer .............................................. 2-3
Tachometer ................................................. 2-4
General maintenance ......................................... 8-2
Glove box ........................................................ 2-35
Glove box (upper) ............................................ 2-35
Glove box lock ................................................. 2-35
Golf bag stowing ............................................. 2-39
H
Hands-Free Phone System, Bluetooth ............ 4-30
Hazard warning flasher switch ......................... 2-25
Head restraints .................................................. 1-8
Headlights
Bulb replacement...................................... 8-33
Headlight switch........................................ 2-21
Xenon headlights ...................................... 2-21
Heated seats ................................................... 2-26
Heater
Engine block heater .................................. 5-32
Heater and air conditioner (automatic) ...... 4-10
HomeLink Universal Transceiver .................... 2-46
Hood release ................................................... 3-24
Hook, Coat hook.............................................. 2-38
Horn ................................................................ 2-26
How to stop alarm, Vehicle security ................. 2-18 I
Ignition switch
(except Intelligent Key system) ................... 5-6
Automatic transmission models .......... 5-6, 5-12
Key positions .............................................. 5-8
Manual transmission models .............. 5-7, 5-16
Immobilizer system .......................................... 2-18
In-cabin microfilter ........................................... 4-13
Indicator lights ................................................. 2-14
INFINITI Vehicle Immobilizer System
Engine start ........................................ 5-8, 5-10
Inside
Automatic anti-glare mirror ....................... 3-32
Inspection/maintenance (I/M) test ................... 9-25
Instrument brightness control .......................... 2-24
Instrument panel ............................................... 2-2
Instrument pocket ............................................ 2-31
Intelligent Key system
Engine starting .......................................... 3-14
Key operating range .................................. 3-16
Key operation............................................. 3-11
Mechanical key and valet key ................... 3-23
Operating the engine................................. 3-14
Remote keyless operation ......................... 3-20
Trouble-shooting guide .............................. 3-19
Warning light............................................. 2-12
Warning signals ......................................... 3-17
Intelligent Key warning light............................. 2-12
Interior light replacement ................................ 8-33
Interior lights .................................................. 2-44
Interior trunk lid release .................................. 3-27
ISOFIX child restraint........................................ 1-25
10-3
w 06.1.5/V35-D/V5.0
X

J
Jump starting .................................................... 6-8
K
Keyless entry
With Intelligent Key system (See
Intelligent Key system).............................. 3-20
Without Intelligent Key system (See remote
keyless entry system).................................. 3-5
Keys .................................................................. 3-2
L
Labels
Air bag warning labels ............................... 1-51
Air conditioner specification label ............. 9-13
Emission control information label ............ 9-12
Engine serial number ................................. 9-11
F.M.V.S.S./C.M.V.S.S. certification label ..... 9-11
Tire and Loading Information label ............ 9-12
Vehicle identification number (VIN) ........... 9-10
LATCH (Lower Anthors and Tethers for
CHildren) system .............................................. 1-25
License plate, Installing front license plate ...... 9-13
Light
Air bag warning light.................................. 1-51
Bulb replacement ...................................... 8-31
Fog light switch......................................... 2-25
Headlight switch........................................ 2-21
Headlights Bulb replacement .................... 8-33
Interior lights ............................................ 2-44 Map lights ................................................ 2-44
Personal lights .......................................... 2-45
Replacement.............................................. 8-31
Room light ................................................ 2-44
Trunk light ................................................ 2-46
Vanity mirror light..................................... 2-46
Warning/indicator lights and audible
reminders ........................................... 2-9, 2-14
Xenon headlights ...................................... 2-21
Lights, Exterior and interior light
replacement..................................................... 8-33
Loading information (See vehicle loading
information) ..................................................... 9-14
Lock
Door locks .................................................. 3-3
Glove box lock .......................................... 2-35
Power door lock .......................................... 3-3
Trunk lid ................................................... 3-25
Low fuel warning light ...................................... 2-12
Low tire pressure warning light ........................ 2-12
M
Maintenance
Battery ...................................................... 8-16
General maintenance .................................. 8-2
Inside the vehicle ....................................... 8-4
Maintenance information (display) .............. 4-5
Maintenance precautions ............................ 8-5
Maintenance requirements.......................... 8-2
Outside the vehicle ..................................... 8-3
Seat belt maintenance ............................... 1-17
Under the hood and vehicle ....................... 8-4
Malfunction indicator lamp (MIL) ...................... 2-15 Map lights ....................................................... 2-44
Mechanical key (for Intelligent Key system) ..... 3-23
Memory storage, Automatic drive positioner .... 3-35
Meters and gauges ............................................ 2-3
Meters and gauges, Instrument brightness
control ............................................................. 2-24
Mirror
Automatic anti-glare inside mirror ............. 3-32
Outside mirror control ............................... 3-33
Outside mirrors ......................................... 3-33
N
New vehicle break-in........................................ 5-22
O
Odometer .......................................................... 2-3
Oil
Capacities and recommended fuel/
lubricants ................................................... 9-2
Changing engine oil and filter.................... 8-11
Checking engine oil level .......................... 8-10
Engine oil .................................................. 8-10
Engine oil viscosity ..................................... 9-5
Operating the engine (Intelligent Key
system) ............................................................ 3-14
Outside mirror control ..................................... 3-33
Outside mirrors................................................ 3-33
Overheat, If your vehicle overheats................... 6-11
Owner's Manual/Service Manual order
information ...................................................... 9-26
10-4
w 06.1.4/V35-D/V5.0
X

Transmitter
With Intelligent Key system (See
Intelligent Key system).............................. 3-20
Without Intelligent Key system (See remote
keyless entry system).................................. 3-5
Traveling or registering your vehicle in another
country ............................................................ 9-10
Trip computer information (display) ................... 4-5
Troubleshooting guide
Audio system ............................................ 4-20
Bluetooth Hands-Free Phone System ....... 4-41
Intelligent Key system .............................. 3-19
Trunk
Interior trunk lid release ........................... 3-27
Light ......................................................... 2-46
Secondary trunk lid release ...................... 3-27
Trunk lid ................................................... 3-25
Turn signal switch ........................................... 2-24
U
Underbody cleaning ........................................... 7-3
Uniform tire quality grading ............................. 9-23
Up-shift indicator (MT models).......................... 5-17
Up-shift indicator setting (MT models) ............... 2-3
V
Valet key (for Intelligent Key system) ............... 3-23
Vanity mirror light ........................................... 2-46
Vehicle
Dimensions and weights ............................. 9-9
Identification number (VIN)........................ 9-10
Loading information .................................. 9-14 Recovery (freeing a stuck vehicle).............. 6-15
Security system ......................................... 2-17
Vehicle Dynamic Control (VDC) off
switch ....................................................... 2-28
Vehicle Dynamic Control (VDC) system ...... 5-28
Ventilators ......................................................... 4-9
Voice command (See Bluetooth Hands-Free
Phone System) ................................................ 4-36
W
Walk-in mechanism ............................................ 1-4
Warning labels, Air bag warning labels ............. 1-51
Warning light
Air bag warning light ......................... 1-51, 2-14
All-wheel drive (AWD) warning light ............ 2-9
Anti-lock brake warning light..................... 2-10
Brake warning light ................................... 2-10
Door open warning light ............................ 2-11
Intelligent Key warning light ...................... 2-12
Low fuel warning light ............................... 2-12
Low tire pressure warning light ................. 2-12
Seat belt warning light and chime ............. 2-13
Warning lights ................................................... 2-9
Warning, Hazard warning flasher switch .......... 2-25
Warning, Tire pressure monitoring system
(TPMS) ........................................................ 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders .......................................................... 2-9
Warranty, Emission control system warranty.... 9-24
Washer switch, Windshield wiper and washer
switch .............................................................. 2-19
Washing ............................................................ 7-2
Waxing .............................................................. 7-2 Weights (See dimensions and weights) ............. 9-9
Wheel/tire size .................................................. 9-9
Wheels and tires.............................................. 8-37
Cleaning aluminum alloy wheels ................. 7-3
Wheels, Rear active steer (RAS) system ........... 5-29
Window washer fluid ........................................ 8-15
Window(s)
Automatic adjusting function ..................... 2-41
Cleaning ..................................................... 7-3
Power windows ......................................... 2-39
Windshield wiper and washer switch ............... 2-19
Wiper
Windshield wiper and washer switch......... 2-19
Wiper blades ............................................. 8-21
X
Xenon headlights ............................................. 2-21
10-7
w 06.1.13/V35-D/V5.0
X
