2006 INFINITI G35 fog light

Dehumidified defrosting or
defogging 1. Push the front window defroster
button on. (The indicator light on
the button will come on.)
2. Turn the temperature control dial to
set the desired temperature.
O To quickly remove ice from the outside
of the windows, push the fan speed
control button + and set to the
maximum position.
O As soon as possible after the wind-
shield is clean, push the AUTO/ECON
button to return to the auto mode.
O When the front window defroster
button is pushed, the air condi-
tioner will automatically be turned on
at outside temperatures above 23ÉF
(þ5ÉC) to defog the windshield, and
the air recirculation mode will auto-
matically be turned off.
Outside air is drawn into the pas-
senger compartment to improve the
defogging performance. MANUAL OPERATION
Fan speed control Push the fan speed control button þ
or + to manually control the fan
speed.
Push the AUTO/ECON button to return to
automatic control of the fan speed.
Fresh air Push the outside air circulation button
to draw outside air into the passen-
ger compartment. The indicator light on
the button will come on.
Air recirculation Push the air recirculation button to
recirculate interior air inside the vehicle.
The indicator light on the button will
come on.
The air recirculation button will not be ac-
tivated when the air conditioner is in the
defroster mode. Air flow control (MODE) Pushing the MODE button selects the air
outlet to:
: Air flows from center and side
ventilators.
: Air flows from center and side
ventilators and foot outlets.
: Air flows mainly from foot outlets.
: Air flows from defroster and foot
outlets.
To turn the system off Push the OFF button.
DUAL BUTTON (if so equipped) You can set the temperature of the driver
and front passenger sides individually.
Pushing the DUAL button changes the set-
ting position as follows:
Driver/Passenger ! Driver ! Passenger
If selecting the Driver/Passenger position
again after the temperature is individually
set, the display will show the temperature
set for the driver side.
4-12 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X

Sedan 1. Front turn signal light
2. Front fog light/Park light/
Headlight (high-beam)
3. Headlight (low-beam)
4. Map light
5. Rear personal light
6. Front side marker light
7. Step light
8. Trunk light
9. High-mounted stop light
(if so equipped)
10. License plate light
11. Back-up light
12. Rear combination light
(Turn signal, Stop/Tail, Side marker)
SDI1952LIGHTS
Maintenance and do-it-yourself
8-31
w 06.1.4/V35-D/V5.0
X

Coupe 1. Front turn signal light
2. Front fog light/Park light
3. Headlight (low-beam/high-beam)
4. Map light
5. Front side marker light
6. Step light
7. High-mounted stop light
(if so equipped)
8. Trunk light
9. License plate light
10. Rear combination light
(Turn signal, Stop/Tail, Back-up, Side
marker)
SDI1953
8-32 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

HEADLIGHTS
Replacing the xenon headlight
bulb Xenon headlight bulb:
WARNING HIGH VOLTAGE
When xenon headlights are on, they produce
a high voltage. To prevent an electric shock,
never attempt to modify or disassemble. Al-
ways have your xenon headlights replaced
at an INFINITI dealer. For additional informa-
tion, see ªHeadlight and turn signal switchº
in the ª2. Instruments and controlsº section.
If replacement is required, see an INFINITI
dealer. EXTERIOR AND INTERIOR LIGHTS Item Wattage (W) Bulb No.
Front turn signal light* 21 T20
Front park light* 5 T10
Front side marker light 3.8 T10
Front fog light Sedan: 60/55
Coupe: 55 Sedan: H4
Coupe: H1
Rear combination light
Turn signal 21 T20
Stop/Tail* (LED) Ð
Side marker light* Sedan: (LED)/Coupe: 3.8 Sedan: Ð/Coupe: T10
Back-up light 18 T16
License plate light 5 T10
High-mounted stop light* (LED) Ð
Map light 8 Ð
Rear personal light (Sedan) 8 Ð
Step light 5 Ð
Trunk light 3.4 158
Vanity mirror light 1.32 Ð
*: See an INFINITI dealer for replacement.
Maintenance and do-it-yourself
8-33
w 06.1.4/V35-D/V5.0
X

Floor mat cleaning ............................................. 7-4
Fluid
Automatic transmission fluid (ATF)............. 8-13
Brake and clutch fluid ............................... 8-14
Brake fluid ................................................ 8-14
Capacities and recommended fuel/
lubricants ................................................... 9-2
Engine coolant............................................ 8-8
Engine oil .................................................. 8-10
Power steering fluid .................................. 8-13
Window washer fluid ................................. 8-15
FM-AM-SATELLITE radio with compact disc (CD)
changer ........................................................... 4-22
Fog light switch ............................................... 2-25
Front passenger air bag and status light.......... 1-44
Front power seat adjustment .............................. 1-2
Fuel
Capacities and recommended fuel/
lubricants ................................................... 9-2
Fuel economy ............................................ 5-22
Fuel economy information (display) ............ 4-4
Fuel-filler cap ............................................ 3-28
Fuel-filler door .......................................... 3-28
Fuel octane rating ....................................... 9-3
Fuel recommendation.................................. 9-3
Gauge ......................................................... 2-5
Fuses ............................................................... 8-25
Fusible links .................................................... 8-26
G
Garage door opener, HomeLink Universal
Transceiver ...................................................... 2-46
Gas cap ........................................................... 3-28 Gauge................................................................ 2-3
Engine coolant temperature gauge.............. 2-4
Fuel gauge .................................................. 2-5
Odometer.................................................... 2-3
Speedometer .............................................. 2-3
Tachometer ................................................. 2-4
General maintenance ......................................... 8-2
Glove box ........................................................ 2-35
Glove box (upper) ............................................ 2-35
Glove box lock ................................................. 2-35
Golf bag stowing ............................................. 2-39
H
Hands-Free Phone System, Bluetooth ............ 4-30
Hazard warning flasher switch ......................... 2-25
Head restraints .................................................. 1-8
Headlights
Bulb replacement...................................... 8-33
Headlight switch........................................ 2-21
Xenon headlights ...................................... 2-21
Heated seats ................................................... 2-26
Heater
Engine block heater .................................. 5-32
Heater and air conditioner (automatic) ...... 4-10
HomeLink Universal Transceiver .................... 2-46
Hood release ................................................... 3-24
Hook, Coat hook.............................................. 2-38
Horn ................................................................ 2-26
How to stop alarm, Vehicle security ................. 2-18 I
Ignition switch
(except Intelligent Key system) ................... 5-6
Automatic transmission models .......... 5-6, 5-12
Key positions .............................................. 5-8
Manual transmission models .............. 5-7, 5-16
Immobilizer system .......................................... 2-18
In-cabin microfilter ........................................... 4-13
Indicator lights ................................................. 2-14
INFINITI Vehicle Immobilizer System
Engine start ........................................ 5-8, 5-10
Inside
Automatic anti-glare mirror ....................... 3-32
Inspection/maintenance (I/M) test ................... 9-25
Instrument brightness control .......................... 2-24
Instrument panel ............................................... 2-2
Instrument pocket ............................................ 2-31
Intelligent Key system
Engine starting .......................................... 3-14
Key operating range .................................. 3-16
Key operation............................................. 3-11
Mechanical key and valet key ................... 3-23
Operating the engine................................. 3-14
Remote keyless operation ......................... 3-20
Trouble-shooting guide .............................. 3-19
Warning light............................................. 2-12
Warning signals ......................................... 3-17
Intelligent Key warning light............................. 2-12
Interior light replacement ................................ 8-33
Interior lights .................................................. 2-44
Interior trunk lid release .................................. 3-27
ISOFIX child restraint........................................ 1-25
10-3
w 06.1.5/V35-D/V5.0
X

J
Jump starting .................................................... 6-8
K
Keyless entry
With Intelligent Key system (See
Intelligent Key system).............................. 3-20
Without Intelligent Key system (See remote
keyless entry system).................................. 3-5
Keys .................................................................. 3-2
L
Labels
Air bag warning labels ............................... 1-51
Air conditioner specification label ............. 9-13
Emission control information label ............ 9-12
Engine serial number ................................. 9-11
F.M.V.S.S./C.M.V.S.S. certification label ..... 9-11
Tire and Loading Information label ............ 9-12
Vehicle identification number (VIN) ........... 9-10
LATCH (Lower Anthors and Tethers for
CHildren) system .............................................. 1-25
License plate, Installing front license plate ...... 9-13
Light
Air bag warning light.................................. 1-51
Bulb replacement ...................................... 8-31
Fog light switch......................................... 2-25
Headlight switch........................................ 2-21
Headlights Bulb replacement .................... 8-33
Interior lights ............................................ 2-44 Map lights ................................................ 2-44
Personal lights .......................................... 2-45
Replacement.............................................. 8-31
Room light ................................................ 2-44
Trunk light ................................................ 2-46
Vanity mirror light..................................... 2-46
Warning/indicator lights and audible
reminders ........................................... 2-9, 2-14
Xenon headlights ...................................... 2-21
Lights, Exterior and interior light
replacement..................................................... 8-33
Loading information (See vehicle loading
information) ..................................................... 9-14
Lock
Door locks .................................................. 3-3
Glove box lock .......................................... 2-35
Power door lock .......................................... 3-3
Trunk lid ................................................... 3-25
Low fuel warning light ...................................... 2-12
Low tire pressure warning light ........................ 2-12
M
Maintenance
Battery ...................................................... 8-16
General maintenance .................................. 8-2
Inside the vehicle ....................................... 8-4
Maintenance information (display) .............. 4-5
Maintenance precautions ............................ 8-5
Maintenance requirements.......................... 8-2
Outside the vehicle ..................................... 8-3
Seat belt maintenance ............................... 1-17
Under the hood and vehicle ....................... 8-4
Malfunction indicator lamp (MIL) ...................... 2-15 Map lights ....................................................... 2-44
Mechanical key (for Intelligent Key system) ..... 3-23
Memory storage, Automatic drive positioner .... 3-35
Meters and gauges ............................................ 2-3
Meters and gauges, Instrument brightness
control ............................................................. 2-24
Mirror
Automatic anti-glare inside mirror ............. 3-32
Outside mirror control ............................... 3-33
Outside mirrors ......................................... 3-33
N
New vehicle break-in........................................ 5-22
O
Odometer .......................................................... 2-3
Oil
Capacities and recommended fuel/
lubricants ................................................... 9-2
Changing engine oil and filter.................... 8-11
Checking engine oil level .......................... 8-10
Engine oil .................................................. 8-10
Engine oil viscosity ..................................... 9-5
Operating the engine (Intelligent Key
system) ............................................................ 3-14
Outside mirror control ..................................... 3-33
Outside mirrors................................................ 3-33
Overheat, If your vehicle overheats................... 6-11
Owner's Manual/Service Manual order
information ...................................................... 9-26
10-4
w 06.1.4/V35-D/V5.0
X

Shifting
Automatic transmission ...................... 5-6, 5-12
Manual transmission .......................... 5-7, 5-16
Shoulder belt guide .......................................... 1-17
Shoulder belt height adjustment ...................... 1-16
Side air bag system (See supplemental side
air bag and curtain side-impact air bag
systems) .......................................................... 1-48
SNOW mode switch ......................................... 2-27
Spark plugs ..................................................... 8-19
Speedometer ..................................................... 2-3
Starting
Before starting the engine ......................... 5-10
Jump starting .............................................. 6-8
Precautions when starting and driving ........ 5-2
Push starting............................................. 6-10
Starting the engine .................................... 5-11
Status light, Front passenger air bag ............... 1-44
Steering
Power steering fluid .................................. 8-13
Power steering system .............................. 5-25
Rear active steer (RAS) system .................. 5-29
Steering wheel switch for audio
controls .................................................... 4-28
Tilting steering wheel................................ 3-30
Storage ............................................................ 2-31
Stowing golf bags............................................ 2-39
Sun shade ....................................................... 2-42
Sun visors ....................................................... 3-32
Sunglasses holder ........................................... 2-32
Sunroof ........................................................... 2-42
Automatic sunroof..................................... 2-42
Supplemental air bag warning labels ................ 1-51
Supplemental air bag warning light.......... 1-51, 2-14 Supplemental restraint system ......................... 1-36
Precautions on supplemental restraint
system ...................................................... 1-36
Supplemental side and curtain side-impact
air bag systems ............................................... 1-48
Switch
Autolight switch ........................................ 2-22
Fog light switch......................................... 2-25
Hazard warning flasher switch .................. 2-25
Headlight switch........................................ 2-21
Ignition switch (except Intelligent Key
system) ....................................................... 5-6
Ignition switch automatic transmission
models ............................................... 5-6, 5-12
Ignition switch manual transmission
models ............................................... 5-7, 5-16
Power door lock switch ............................... 3-4
Rear window and outside mirror defroster
switch ....................................................... 2-20
Steering wheel switch for audio control .... 4-28
Turn signal switch..................................... 2-24
Vehicle Dynamic Control (VDC) off
switch ....................................................... 2-28
T
Tachometer........................................................ 2-4
Temperature gauge, Engine coolant
temperature gauge ............................................ 2-4
Theft (INFINITI Vehicle Immobilizer System),
Engine start ..................................................... 2-18
Three way catalyst ............................................. 5-3
Tilting steering wheel ...................................... 3-30 Tire
Flat tire ....................................................... 6-2
Pressure, Low tire pressure warning
light .......................................................... 2-12
Tire pressure monitoring system (TPMS) ..... 5-3
Uniform tire quality grading ...................... 9-23
Tires
Spare tire ................................................. 8-48
Tire and Loading Information label ............ 9-12
Tire chains ................................................ 8-44
Tire dressing ............................................... 7-3
Tire pressure............................................. 8-37
Tire pressure monitoring system
(TPMS) ................................................. 5-3, 6-2
Tire rotation .............................................. 8-45
Types of tires ............................................ 8-43
Wheel/tire size ........................................... 9-9
Wheels and tires ....................................... 8-37
Top tether strap child restraints ....................... 1-26
Towing
Flat towing ................................................ 9-22
Tow truck towing ....................................... 6-12
Towing a trailer ......................................... 9-18
Towing load/specification chart................. 9-18
Towing safety ............................................ 9-19
TPMS, Tire pressure monitoring system ............. 5-3
Trailer towing ................................................... 9-18
Transceiver, HomeLink Universal
Transceiver ...................................................... 2-46
Transmission
Automatic transmission fluid (ATF)............. 8-13
Driving with automatic transmission ... 5-6, 5-12
Driving with manual transmission ....... 5-7, 5-16
Transmission selector lever lock release .... 5-15
10-6
w 06.1.4/V35-D/V5.0
X
