CHECKING BULBS Apply the parking brake and turn the igni-
tion key to ON without starting the en-
gine. The following lights will come on:
, or , , ,
The following lights come on briefly and
then go off:
, or , , , , , , ,
If any light fails to come on, it may indi-
cate a burned-out bulb or an open circuit
in the electrical system. Have the system
repaired promptly.
WARNING LIGHTS
All-wheel drive (AWD)
warning light (AWD models) The light comes on when the ignition
switch is turned to ON. It turns off soon
after the engine is started.WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS
Instruments and controls
2-9
w 06.1.4/V35-D/V5.0
X

XENON HEADLIGHTS
WARNING HIGH VOLTAGE
O When xenon headlights are on, they pro-
duce a high voltage. To prevent an elec-
tric shock, never attempt to modify or
disassemble. Always have your xenon
headlights replaced at an INFINITI
dealer.
O Xenon headlights provide considerably
more light than conventional headlights.
If they are not correctly aimed, they
might temporarily blind an oncoming
driver or the driver ahead of you and
cause a serious accident. If headlights
are not aimed correctly, immediately
take your vehicle to an INFINITI dealer
and have the headlights adjusted
correctly. When the xenon headlight is initially
turned on, its brightness or color varies
slightly. However, the color and bright-
ness will soon stabilize.
O The life of xenon headlights will be
shortened by frequent on-off opera-
tion. It is generally desirable not to
turn off the headlights for short inter-
vals (for example, when the vehicle
stops at a traffic signal). Even when the
daytime running lights are active
(Canada only), the xenon headlights do
not turn on. This way the life of the
xenon headlights is not reduced.
O If a xenon headlight bulb is close to
burning out, the brightness will drasti-
cally decrease, the light will start
blinking, or the color of the light will
become reddish. If one or more of the
above signs appear, contact an INFINITI
dealer.
HEADLIGHT SWITCH
Lighting
q 1
Turn the switch to the position:
The front park, side marker, tail, li-
cense plate and instrument lights will
come on.
q 2
Turn the switch to the position:
Headlights will come on and all the
other lights remain on. SIC2227
Type AHEADLIGHT AND TURN SIGNAL SWITCH
Instruments and controls
2-21
w 06.1.13/V35-D/V5.0
X

HEADLIGHTS
Replacing the xenon headlight
bulb Xenon headlight bulb:
WARNING HIGH VOLTAGE
When xenon headlights are on, they produce
a high voltage. To prevent an electric shock,
never attempt to modify or disassemble. Al-
ways have your xenon headlights replaced
at an INFINITI dealer. For additional informa-
tion, see ªHeadlight and turn signal switchº
in the ª2. Instruments and controlsº section.
If replacement is required, see an INFINITI
dealer. EXTERIOR AND INTERIOR LIGHTS Item Wattage (W) Bulb No.
Front turn signal light* 21 T20
Front park light* 5 T10
Front side marker light 3.8 T10
Front fog light Sedan: 60/55
Coupe: 55 Sedan: H4
Coupe: H1
Rear combination light
Turn signal 21 T20
Stop/Tail* (LED) Ð
Side marker light* Sedan: (LED)/Coupe: 3.8 Sedan: Ð/Coupe: T10
Back-up light 18 T16
License plate light 5 T10
High-mounted stop light* (LED) Ð
Map light 8 Ð
Rear personal light (Sedan) 8 Ð
Step light 5 Ð
Trunk light 3.4 158
Vanity mirror light 1.32 Ð
*: See an INFINITI dealer for replacement.
Maintenance and do-it-yourself
8-33
w 06.1.4/V35-D/V5.0
X

Replacement procedures All other lights are either type A, B, C or
D. When replacing a bulb, first remove the
lens and/or cover. MDI0006
SDI1733
Front side marker light SDI1570A
Sedan Ð Rear turn signal light
8-34 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

To replace a back-up light
1. Remove all the clips
q A
, the handle
q B
and inside release handle
q C
to re-
move the trunk lid finisher.
2. Remove the connector from bulb
socket
q 1
.
3. Turn the bulb socket counterclockwise
q 2
and remove the bulb.
SDI1510A
Sedan Ð Back-up light
Maintenance and do-it-yourself
8-35
w 06.1.4/V35-D/V5.0
X
