2006 INFINITI G35 format

WHEELS AND TIRES
Road wheel Type Position Size Offset in (mm)
Sedan Aluminum Ð 17 x 7JJ 1.77 (45)
Ð 18 x 7-1/2JJ 1.77 (45)
Coupe Aluminum Front 17 x 7-1/2JJ 1.18 (30)
Rear 17 x 8JJ 1.30 (33)
Front 18 x 8JJ 1.18 (30)
Rear 18 x 8JJ 1.18 (30)
Front 19 x 8JJ 1.18 (30)
Rear 19 x 8-1/2JJ 1.30 (33)
Tire Type Position Size Pressure (Cold)
Sedan Conventional Ð P215/55R17 93V 210 kPa (30 psi)
Ð 235/45R18 94W 230 kPa (33 psi)
Spare Ð T145/80D17 420 kPa (60 psi)
P215/55R17 93V*1 210 kPa (30 psi)
Coupe Conventional Front P225/50R17 93V 210 kPa (30 psi)
Rear P235/50R17 95V 210 kPa (30 psi)
Front 225/45R18 91W 240 kPa (35 psi)
Rear 245/45R18 96W 240 kPa (35 psi)
Front 225/40R19 89Y 240 kPa (35 psi)
Rear 245/40R19 94Y 240 kPa (35 psi)
Spare Ð T145/80D17 420 kPa (60 psi)
*1: Option for USA, conventional for Canada (for models with tire size P215/55R17
93V) DIMENSIONS AND WEIGHTS Sedan Coupe
Overall length in (mm) 186.9 (4,747) 182.2 (4,628)
Overall width in (mm) 69.0 (1,753) 71.5 (1,815)
Overall height in (mm) 57.7 (1,467)*1
58.4 (1,484)*2 54.8 (1,393)
55.1 (1,399)*3
Front tread in (mm) 59.1 (1,500)*1
59.3 (1,505)*2 60.4 (1,535)
Rear tread in (mm) 59.3 (1,505) 60.6 (1,540)*4
60.8 (1,545)*5
Wheelbase in (mm) 112.2 (2,850) 112.2 (2,850)
Gross vehicle weight rating lb (kg)
See the F.M.V.S.S./C.M.V.S.S.
certification label on the driver's
side lock pillar.Gross axle weight rating
Front lb (kg)
Rear lb (kg)
*1: For 2WD models
*2: For AWD models
*3: For 18 in and 19 in road wheel models
*4: For models with road wheel size Ð 17 x 8JJ and 19 x 8-1/2JJ [offset 1.30 in (33
mm)]
*5: For models with road wheel size Ð 18 x 8JJ [offset 1.18 in (30 mm)]
Technical and consumer information
9-9
w 06.1.4/V35-D/V5.0
X

When planning to travel in another
country, you should first find out if the
fuel available is suitable for your vehicle's
engine.
Using fuel with too low an octane rating
may cause engine damage. All gasoline
vehicles must be operated with unleaded
engine gasoline. Therefore, avoid taking
your vehicle to areas where appropriate
fuel is not available.
When transferring the registration of your
vehicle to another country, state, province
or district, it may be necessary to modify
the vehicle to meet local laws and regula-
tions.
The laws and regulations for motor ve-
hicle emission control and safety stan-
dards vary according to the country,
state, province or district; therefore, ve-
hicle specifications may differ.
When any vehicle is to be taken into an-
other country, state, province or district
and registered, its modifications, trans-
portation, and registration are the respon-
sibility of the user. INFINITI is not respon-
sible for any inconvenience that may re-
sult. VEHICLE IDENTIFICATION NUMBER
(VIN) PLATE The vehicle identification number plate is
attached as shown. This number is the
identification for your vehicle and is used
in the vehicle registration.
VEHICLE IDENTIFICATION NUMBER
(Chassis number) The number is stamped as shown. STI0038 STI0302
WHEN TRAVELING OR REGISTERING YOUR
VEHICLE IN ANOTHER COUNTRY VEHICLE IDENTIFICATION
9-10 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

ENGINE SERIAL NUMBER The number is stamped on the engine as
shown.
F.M.V.S.S./C.M.V.S.S.
CERTIFICATION LABEL The Federal Motor Vehicle Safety Stan-
dards (F.M.V.S.S.) or Canadian Motor Ve-
hicle Safety Standards (C.M.V.S.S.) certifi-
cation label is affixed as shown. This
label contains valuable vehicle informa-
tion, such as: Gross Vehicle Weight Rat-
ings (GVWR), Gross Axle Weight Rating
(GAWR), month and year of manufacture,
Vehicle Identification Number (VIN), etc.
Review it carefully. STI0303C STI0186B
Sedan STI0330A
Coupe
Technical and consumer information
9-11
w 06.1.4/V35-D/V5.0
X

EMISSION CONTROL INFORMATION
LABEL The emission control information label is
attached as shown.
TIRE AND LOADING INFORMATION
LABEL The cold tire pressures are shown on the
Tire and Loading Information label affixed
to the driver side center pillar. STI0317 STI0368A
Sedan STI0331A
Coupe
9-12 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

AIR CONDITIONER SPECIFICATION
LABEL The air conditioner specification label is
affixed inside of the hood as shown. STI0306
STI0332INSTALLING FRONT LICENSE PLATE
Technical and consumer information
9-13
w 06.1.4/V35-D/V5.0
X

Use the following steps to mount the li-
cense plate:
Before mounting the license plate, con-
firm that the following parts are enclosed
in the vinyl bag.
O License plate bracket
O J-nut x 2
O Screw x 2
O Screw grommet x 2
1. Temporarily place the license plate
bracket and mark the pilot hole points
q A
using holes
q B
while aligning the
towing hook hole of the front bumper
fascia.
2. Remove the license plate bracket.
3. Carefully drill two pilot holes
q A
using
a 0.39 in (10 mm) drill bit at the
marked locations. (Be sure that the
drill only goes through the fascia, or
damage to the nut may occur.)
4. Insert grommets into the hole on the
fascia.
5. Insert a flat-blade screwdriver into the
grommet hole to turn part
q C
90 de-
grees. 6. Insert a J-nut into the license plate
bracket before placing the license
plate bracket on the fascia.
7. Install the license plate bracket with
screws.
8. Install the license plate with bolts that
are no longer than 0.55 in (14 mm).
WARNING O It is extremely dangerous to ride in
a cargo area inside of a vehicle. In
a collision, people riding in these
areas are more likely to be seri-
ously injured or killed.
O Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat
belts.
O Be sure everyone in your vehicle is
in a seat and using a seat belt
properly.
TERMS It is important to familiarize yourself
with the following terms before loading
your vehicle:
O Curb Weight (actual weight of your
vehicle) - vehicle weight including:
standard and optional equipment,
fluids, emergency tools, and spare VEHICLE LOADING INFORMATION
9-14 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

tire assembly. This weight does not
include passengers and cargo.
O GVW (Gross Vehicle Weight) - curb
weight plus the combined weight of
passengers and cargo.
O GVWR (Gross Vehicle Weight Rating)
- maximum total combined weight of
the unloaded vehicle, passengers,
luggage, hitch, trailer tongue load
and any other optional equipment.
This information is located on the
F.M.V.S.S./C.M.V.S.S. label.
O GAWR (Gross Axle Weight Rating) -
maximum weight (load) limit speci-
fied for the front or rear axle. This
information is located on the
F.M.V.S.S./C.M.V.S.S. label.
O GCWR (Gross Combined Weight
Rating) - maximum total weight
rating of the vehicle, passengers,
cargo and trailer. O Vehicle Capacity Weight, Load limit,
Total load capacity - maximum total
weight limit specified of the load
(passengers and cargo) for the ve-
hicle. This is the maximum com-
bined weight of occupants and
cargo that can be loaded into the ve-
hicle. If the vehicle is used to tow a
trailer, the trailer tongue weight
must be included as part of the
cargo load. This information is lo-
cated on the Tire and Loading Infor-
mation label.
O Cargo capacity - permissible weight
of cargo, the subtracted weight of
occupants from the load limit. VEHICLE LOAD CAPACITY Do not exceed the load limit of your ve-
hicle shown as ªThe combined weight
of occupants and cargoº on the Tire and
Loading Information label. Do not ex-
ceed the number of occupants shown
as ªSeating Capacityº on the Tire and
Loading Information label.
To get ªthe combined weight of occu-
pants and cargoº, add the weight of all
occupants, then add the total luggage
weight to the value. Examples are
shown in the following illustration.
Technical and consumer information
9-15
w 06.1.4/V35-D/V5.0
X

Steps for determining correct load
limit 1. Locate the statement ªThe combined
weight of occupants and cargo
should never exceed XXX kg or XXX
lbsº on your vehicle's placard.
2. Determine the combined weight of
the driver and passengers that will
be riding in your vehicle.
3. Subtract the combined weight of the
driver and passengers from XXX kg
or XXX lbs.
4. The resulting figure equals the avail-
able amount of cargo and luggage
load capacity. For example, if the
XXX amount equals 1,400 lbs. and
there will be five 150 lb. passengers
in your vehicle, the amount of avail-
able cargo and luggage load ca-
pacity is 650 lbs. (1400 þ 750 (5 x
150) = 650 lbs.) or (640 þ 340 (5 x
70) = 300 kg.)
5. Determine the combined weight of
luggage and cargo being loaded on STI0445
