2006 INFINITI FX35 page 361

WARNING CHIME DI-69
C
D E
F
G H
I
J
L
M A
B
DI
Revision: 2006 December 2006 FX35/FX45
Terminals and Reference Value for Combination MeterNKS0030R
CONSULT-II Function (METER A/C AMP)NKS003HZ
Refer to DI-31, "CONSULT-II Function (METER A/C AMP)" in “UNIFIED METER AND A/C AMP”.
CONSULT-II Function (BCM)NKS003I0
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
DIAGNOSIS ITEMS DESCRIPTION
CONSULT-II BASIC OPERATION
Refer to GI-38, "CONSULT-II Start Procedure" .
DATA MONITOR
Operation Procedure
1. Touch “BUZZER” on “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch “ALL SIGNALS” or “SELECTION FROM MENU” on “DATA MONITOR” screen.
4. If “SELECTION FROM MENU” is selected, touch the desired monitor item. If “ALL SIGNALS” is selected, all items required to control are monitored.
Terminal
No. Wire
color Item Measuring condition
Reference value
Ignition
switch Operation or condition
5 B Ground ON — Approx. 0 V
6
7 G/Y Ignition power supply ON — Battery voltage
8 R/W Battery power supply OFF — Battery voltage
9LG Seat belt buckle switch
(Driver side) ON Unfastened (ON) Approx. 0 V
Fastened (OFF) Approx. 12 V
13 L/B TX communication line (To
unified meter and A/C amp.) ON —
14 PU RX communication line
(From unified meter and A/C
amp.) ON —
15 B Ground ON — Approx. 0 V
SKIA3361E
SKIA3362E
System Test item Diagnosis mode Description Reference
page
BCM BUZZER DATA MONITOR Displays BCM input data in real time.
DI-69
ACTIVE TEST Operation of electrical loads can be checked by sending driving
signal to them. DI-70
BCM SELF-DIAG RESULTS BCM checks the conditions and displays memorized error.
DI-70
ALL SIGNALS Monitors all items.
SELECTION FROM MENU Selects and monitors items.

EC-16
[VQ35DE]
INDEX FOR DTC
Revision: 2006 December 2006 FX35/FX45
P0139 0139 HO2S2 (B1) EC-294
P0150 0150 A/F SENSOR1 (B2)EC-230
P0151 0151 A/F SENSOR1 (B2)EC-240
P0152 0152 A/F SENSOR1 (B2)EC-249
P0153 0153 A/F SENSOR1 (B2)EC-258
P0157 0157 HO2S2 (B2)EC-270
P0158 0158 HO2S2 (B2)EC-281
P0159 0159 HO2S2 (B2)EC-294
P0171 0171 FUEL SYS-LEAN-B1EC-305
P0172 0172 FUEL SYS-RICH-B1EC-317
P0174 0174 FUEL SYS-LEAN-B2EC-305
P0175 0175 FUEL SYS-RICH-B2EC-317
P0181 0181 FTT SENSOREC-328
P0182 0182 FTT SEN/CIRCUITEC-334
P0183 0183 FTT SEN/CIRCUITEC-334
P0222 0222 TP SEN 1/CIRCEC-339
P0223 0223 TP SEN 1/CIRCEC-339
P0300 0300 MULTI CYL MISFIREEC-346
P0301 0301 CYL 1 MISFIREEC-346
P0302 0302 CYL 2 MISFIREEC-346
P0303 0303 CYL 3 MISFIREEC-346
P0304 0304 CYL 4 MISFIREEC-346
P0305 0305 CYL 5 MISFIREEC-346
P0306 0306 CYL 6 MISFIREEC-346
P0327 0327 KNOCK SEN/CIRC-B1EC-356
P0328 0328 KNOCK SEN/CIRC-B1EC-356
P0335 0335 CKP SEN/CIRCUITEC-361
P0340 0340 CMP SEN/CIRC-B1EC-368
P0345 0345 CMP SEN/CIRC-B2EC-368
P0420 0420 TW CATALYST SYS-B1EC-377
P0430 0430 TW CATALYST SYS-B2EC-377
P0441 0441 EVAP PURG FLOW/MONEC-383
P0442 0442 EVAP SMALL LEAKEC-388
P0443 0443 PURG VOLUME CONT/VEC-397
P0444 0444 PURG VOLUME CONT/VEC-405
P0445 0445 PURG VOLUME CONT/VEC-405
P0447 0447 VENT CONTROL VALVEEC-412
P0448 0448 VENT CONTROL VALVEEC-419
P0451 0451 EVAP SYS PRES SENEC-425
P0452 0452 EVAP SYS PRES SENEC-428
P0453 0453 EVAP SYS PRES SENEC-434
P0455 0455 EVAP GROSS LEAKEC-442
DTC*1
Items
(CONSULT-II screen terms) Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC EC-19
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
Alphabetical IndexNBS003KV
NOTE:

If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-156, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .

If DTC U1010 is displayed with other DTC, first perform the trouble diagnosis for DTC U1010.
Refer to EC-159, "
DTC U1010 CAN COMMUNICATION" .
Items
(CONSULT-II screen terms) DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3
A/F SENSOR1 (B1) P0130 0130 EC-230
A/F SENSOR1 (B1) P0131 0131EC-240
A/F SENSOR1 (B1) P0132 0132EC-249
A/F SENSOR1 (B1) P0133 0133EC-258
A/F SENSOR1 (B1) P2A00 2A00EC-604
A/F SENSOR1 (B2) P0150 0150EC-230
A/F SENSOR1 (B2) P0151 0151EC-240
A/F SENSOR1 (B2) P0152 0152EC-249
A/F SENSOR1 (B2) P0153 0153EC-258
A/F SENSOR1 (B2) P2A03 2A03EC-604
A/F SEN1 HTR (B1) P0031 0031EC-165
A/F SEN1 HTR (B1) P0032 0032EC-165
A/F SEN1 HTR (B2) P0051 0051EC-165
A/F SEN1 HTR (B2) P0052 0052EC-165
A/T INTERLOCK P1730 1730 AT- 1 4 1
A/T TCC S/V FNCTN P0744 0744AT- 1 2 7
APP SEN 1/CIRC P2122 2122EC-575
APP SEN 1/CIRC P2123 2123EC-575
APP SEN 2/CIRC P2127 2127EC-582
APP SEN 2/CIRC P2128 2128EC-582
APP SENSOR P2138 2138EC-596
ASCD BRAKE SW P1572 1572 EC-529 (Models with ICC),
EC-538
(Models with ASCD)
ASCD SW P1564 1564 EC-514
(Models with ICC),
EC-521
(Models with ASCD)
ASCD VHL SPD SEN P1574 1574 EC-546
(Models with ICC),
EC-548
(Models with ASCD)
ATF TEMP SEN/CIRC P0710 0710 AT- 1 3 4
BRAKE SW/CIRCUIT P1805 1805EC-551
CAN COMM CIRCUIT U1000
1000*4EC-156
CAN COMM CIRCUIT U10011001*4EC-156
CKP SEN/CIRCUIT P0335 0335 EC-361
CONTROL UNIT (CAN) U1010 1010EC-159
CLOSED LOOP-B1 P1148 1148EC-494
CLOSED LOOP-B2 P1168 1168EC-494
CMP SEN/CIRC-B1 P0340 0340EC-368
CMP SEN/CIRC-B2 P0345 0345EC-368
CTP LEARNING P1225 1225EC-510

EC-56
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 December 2006 FX35/FX45
HO2S2 (B1) P0138 0138 ××2×EC-281
HO2S2 (B1) P0139 0139 ××2×EC-294
A/F SENSOR1 (B2) P0150 0150 — ×2 ×EC-230
A/F SENSOR1 (B2) P0151 0151 — ×2 ×EC-240
A/F SENSOR1 (B2) P0152 0152 — ×2 ×EC-249
A/F SENSOR1 (B2) P0153 0153 ××2×EC-258
HO2S2 (B2) P0157 0157 ××2×EC-270
HO2S2 (B2) P0158 0158 ××2×EC-281
HO2S2 (B2) P0159 0159 ××2×EC-294
FUEL SYS-LEAN-B1 P0171 0171 — — 2 ×EC-305
FUEL SYS-RICH-B1 P0172 0172 — — 2 ×EC-317
FUEL SYS-LEAN-B2 P0174 0174 — — 2 ×EC-305
FUEL SYS-RICH-B2 P0175 0175 — — 2 ×EC-317
FTT SENSOR P0181 0181 — — 2 ×EC-328
FTT SEN/CIRCUIT P0182 0182 — — 2 ×EC-334
FTT SEN/CIRCUIT P0183 0183 — — 2 ×EC-334
TP SEN 1/CIRC P0222 0222 — — 1 ×EC-339
TP SEN 1/CIRC P0223 0223 — — 1 ×EC-339
MULTI CYL MISFIRE P0300 0300 — — 2 ×EC-346
CYL 1 MISFIRE P0301 0301 — — 2 ×EC-346
CYL 2 MISFIRE P0302 0302 — — 2 ×EC-346
CYL 3 MISFIRE P0303 0303 — — 2 ×EC-346
CYL 4 MISFIRE P0304 0304 — — 2 ×EC-346
CYL 5 MISFIRE P0305 0305 — — 2 ×EC-346
CYL 6 MISFIRE P0306 0306 — — 2 ×EC-346
KNOCK SEN/CIRC-B1 P0327 0327 — — 2 — EC-356
KNOCK SEN/CIRC-B1 P0328 0328 — — 2 —EC-356
CKP SEN/CIRCUIT P0335 0335 — — 2×EC-361
CMP SEN/CIRC-B1 P0340 0340 — — 2 ×EC-368
CMP SEN/CIRC-B2 P0345 0345 — — 2 ×EC-368
TW CATALYST SYS-B1 P0420 0420 ××2×EC-377
TW CATALYST SYS-B2 P0430 0430 ××2×EC-377
EVAP PURG FLOW/MON P0441 0441 ××2×EC-383
EVAP SMALL LEAK P0442 0442 ××2×EC-388
PURG VOLUME CONT/V P0443 0443 — — 2 ×EC-397
PURG VOLUME CONT/V P0444 0444 — — 2 ×EC-405
PURG VOLUME CONT/V P0445 0445 — — 2 ×EC-405
VENT CONTROL VALVE P0447 0447 — — 2 ×EC-412
VENT CONTROL VALVE P0448 0448 — — 2 ×EC-419
EVAP SYS PRES SEN P0451 0451 — — 2 ×EC-425
EVAP SYS PRES SEN P0452 0452 — — 2 ×EC-428
EVAP SYS PRES SEN P0453 0453 — — 2 ×EC-434
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Test limit
(GST only) Trip
Reference
page
CONSULT-II
GST*
2ECM*3

TROUBLE DIAGNOSIS EC-97
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 December 2006 FX35/FX45
Symptom Matrix ChartNBS003M0
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTOM Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel pump circuit 11232 22 3 2 EC-635
Fuel pressure regulator system334444444 4 EC-86
Fuel injector circuit 11232 22 2 EC-628
Evaporative emission system334444444 4 EC-39
Air Positive crankcase ventilation sys-
tem 33 4444444 41
EC-51
Incorrect idle speed adjustment 1 1 1 1 1 EC-77
Electric throttle control actuator 112332222 2 2 EC-562,
EC-573
IgnitionIncorrect ignition timing adjustment33111 11 1 EC-77
Ignition circuit 11222 22 2EC-649
Power supply and ground circuit22333 33 23 EC-149
Mass air flow sensor circuit
1
12 2
222 2 EC-188,
EC-197
Engine coolant temperature sensor circuit
3 33
EC-210,
EC-222
Air fuel ratio (A/F) sensor EC-240
EC-240
EC-249
EC-258
EC-604
Throttle position sensor circuit
22 EC-215
,
EC-339
,
EC-510
,
EC-512
,
EC-589
Accelerator pedal position sensor circuit 3 2 1 EC-484
,
EC-575
,
EC-582
,
EC-596
Knock sensor circuit 2 3 EC-356
Crankshaft position sensor (POS) circuit 2 2EC-361
Camshaft position sensor (PHASE) circuit 3 2EC-368
Vehicle speed signal circuit 2 3 3 3EC-466
Power steering pressure sensor circuit 2 3 3EC-472
