IN CASE OF EMERGENCY
3JUMP STARTING
D010C01A-EAT If Engine Turns Over Normally but Does Not Start
1. Check fuel Level. 2. Check all connectors at ignition coil and spark plugs(For Gasoline En-gine) or check all connectors atglow plug and glow plug relay (For Diesel Engine). Replace any that may be discon-nected or loose.
3. Check fuel line in the engine com-
partment.
4. If engine still refuses to start, call a Hyundai dealer or seek other quali-fied assistance. D010C01AD010D01A-EAT If the Engine Stalls Whilst Driving
1. Reduce your speed gradually, keep-
ing a straight line. Move cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Try to start the engine again. If your
vehicle will not start, contact a Hyundai dealer or seek other quali- fied assistance.
CAUTION:
Personal injury and damage to the vehicle may occur if jump starting is not performed correctly. If anydoubt exists as to how this opera- tion should be performed, seek as- sistance from qualified personnel.
SD030A2-E
!
Discharged battery
Booster batteryHLC4001

5
VEHICLE MAINTENANCE REQUIREMENTS
3SCHEDULED MAINTENANCE
AF040C4-E In order to ensure the continued safety, reliability and longevity of the vehicle, the following maintenance service operations should be performed at the time or mileage intervals specified. It is recommended that all routine maintenance services are entrusted to a Hyundai dealer to ensure that the manufacturers recommended procedures are employed and that only genuine Hyundai replacement parts are used. Incorrect mainte- nance techniques or the use of non genuine replacement parts may invalidate the vehicle warranty. F030B03A-EAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary
Note : (1) EVERY 6,000 MILES OR 6 MONTHS : "R" (2) EVERY 25,000 MILES : "R"
ENGINE CONTROL SYSTEM MAINTENANCE (PETROL)
1 ENGINE OIL & FILTER See Note (1)
2 DRIVE BELT (WATER PUMP, ALTERNATOR & A/CON)
3 FUEL FILTER (MPI)
4 FLUID LEAKS
5 TIMING BELT
6 VENTILATION HOSES
7 AIR CLEANER FILTER
8 SPARK PLUGS
NO. DESCRIPTION60 72
5060
4048
3036
2024
1012
MILES X 1000 MONTHS
R
I I
R
R
I
R I I
R
I
R I
R
R
II I
R
II
R
R
I I
See Note (2)

5VEHICLE MAINTENANCE REQUIREMENTS
6MAINTENANCE UNDER SEVERE USAGE CONDITIONS
F040A07A-EAT The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals.
R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary
SEVERE DRIVING CONDITIONS
A - Repeatly driving short distance of less than 5miles(8km) in normal temperature or less than 10miles(16km) in freezing temperature
B - Extensive engine idling or low speed driving for long distances
C - Driving on rough, dusty, muddy, unpaved, graveled or salt-spread roads
ENGINE OIL AND FILTER AIR CLEANER FILTER SPARK PLUGSTIMING BELTBRAKE PADS REAR BRAKE LININGS AND CYLINDERS SUSPENSION AND STEERING SYSTEMMANUAL TRANSAXLE OILAUTOMATIC TRANSAXLE FLUIDPOLLEN FILTER(FOR EVAPORATOR AND BLOWER UNIT)
EVERY 4,500 MILES OR 6 MONTHS MORE FREQUENTLY
MORE FREQUENTLY EVERY 37,000 MILES OR 48 MONTHSMORE FREQUENTLYMORE FREQUENTLY MORE FREQUENTLY EVERY 60,000 MILESEVERY 27,000 MILES
MORE FREQUENTLY
MAINTENANCE OPERATIONMAINTENANCE ITEM
R R R RI I I
R R R A, B, C, F, H, G, I, K A, B, C, F, H, I, JC, E B, H D, E, F, GC, D, G, H C, D, G, H C, D, E, FA, C, D, E, F, G, H, I, J A, C, E, F, G, H, I C,E
MAINTENANCE INTERVALS
DRIVING
CONDITION
D - Driving in areas using salt or other corrosive materials or in
very cold weather
E - Driving in sandy areas
F - Driving in heavy traffic area over 90°F(32°C)
G - Driving on uphill, downhill, or mountain road
H - Towing a Trailer, or using a camper, or roof rack
I - Driving as a patrol car, taxi, other commercial use or vehicle towing
J - Driving over 100 MPH(170 Km/h) K - Frequently driving in stop-and-go conditions
Petrol Diesel

5VEHICLE MAINTENANCE REQUIREMENTS
8
6ZF070C1-A
o Coolant
The engine coolant should be changed
at the intervals specified in the main- tenance schedule. F060H01A-AAT
o Air cleaner filter
A Genuine Hyundai air cleaner filter is
recommended when the filter is re- placed.
6ZF060J1-A
o Spark plugs
(For Petrol Engine)
Make sure to install new spark plugs
of the correct heat range.
6ZF070B1-A
o Cooling system
Check the cooling system part, such as radiator, coolant reservoir, hoses and connections for leakage and dam- age. Replace any damaged parts.
6ZF060G1-A o Vapour hose and fuel filler cap The vapour hose and fuel filler cap should be inspected at those intervals specified in the maintenance sched- ule. Make sure that a new vapourhose or fuel filler cap is correctly re- placed. 6ZF060F1-A
o Vacuum, crankcase
ventilation hoses
Inspect the surface of hoses for evi-
dence of heat and/or mechanical dam-age. Hard and brittle rubber, cracking, tears, cuts, abrasions, and excessiveswelling indicate deterioration. Par- ticular attention should be paid to ex- amining those hose surfaces nearestto high heat sources, such as the exhaust manifold.
Inspect the hose routing to assure
that the hoses do not come in contactwith any heat source, sharp edges or moving component which might causeheat damage or mechanical wear. Inspect all hose connections, such as clamps and couplings, to make surethey are secure, and that no leaks are present. Hoses should be replaced immediately if there is any evidence ofdeterioration or damage.
6ZF060E1-A o Timing belt Replace timimg belt and inspect all associated parts related for damage and deformation. Replace any dam- aged parts immediately.

6OWNER MAINTENANCE
12SPARKING PLUG REPLACEMENT
G060A01L Prior to installing a sparking plug, the gap between the centre and outer elec- trodes must be checked and adjusted as necessary.Adjustment is facilitated by bending the outer electrode towards or away from the centre electrode. Under no circum-stances should attempts be made to adjust the position of the centre elec- trode.
4. Insert the sparking plug into the cyl-
inder head and using a suitable plug socket, slowly rotate the sparkingplug, (being careful not to cross- thread), until the plug contacts the seating area. Tighten the plug withthe plug socket by a further 1/2 to 3/ 4 of a turn only.
3. Clean around the base of the plug to
be removed, and install the plugsocket ensuring that the ceramic insulator does not become damaged.Turn the socket counterclockwise to remove the plug.
CAUTION:
Sparking plugs must only be cleaned using purpose designed equipment.Wire brushing may damage the cen- tre electrode insulator causing mis- firing to occur. Only the correct gradeof sparking plug should be used. Use of an incorrect grade may result in serious engine damage.
!
SG060A1-E (Petrol Engine Only) This operation should only be performed when the engine is cold.
1. Remove the centre cover from the
engine rocker cover (DOHC Engine only).
2. Remove plug lead from the sparking
plug to be replaced, pulling the leadby the rubber cap. (Pulling the lead may damage the carbon conductor.) 0.039~0.043 in. (1.0 ~ 1.1 mm )
G060C01A
HLC5023

6
OWNER MAINTENANCE
13AIR CLEANER ELEMENT REPLACEMENT
CHAMPION NGKRC10YC4 BKR5ES-11
5. Replace the plug lead ensuring that
the cap is pushed firmly into place. Confirm that the cap is correctly seated by lightly pulling upon it.
NOTE: When replacing the spark plug, genu- ine Hyundai replacement parts are recommended. Recommended Spark Plugs :
G060C03A SG070A2-E To replace the air cleaner element, remove the air intake ducting from theair flow sensor body and unfasten the spring clips holding the air flow sensor top to the body. Lift out the air flowsensor followed by the air cleaner ele- ment. Replacement of the element is the reverse of the above.
!
CAUTION:
o The air flow sensor is a precision engineered electronic measuring device and therefore care should be exercised that the air flow sen-sor is not damaged during re- placement of the element.
o When removing the air cleaner element, be careful that dust ordirt does not enter the air intake. These may result in damage to theair cleaner element
To ensure maximum filtration perfor-mance and continued engine perfor- mance, only genuine Hyundai replace- ments should be used.
G070A01A-D
