2006 HONDA PILOT turn signal bulb

If a brake light does not work, theindicator comes on
when you push the brake pedal with
the ignition switch in the ON (II)
position.
A burned out brake light is a hazard
when drivers behind you cannot tell
you are braking. Have your brake
lights repaired right away.
When you press the hazard warning
button, both turn signal indicators
blink. All turn signals on the outside
of the vehicle should f lash. The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see pages and ).
Replace the bulb as soon as possible,
since other drivers cannot see that
you are signaling. The appropriate indicator comes on
in this display if the tailgate or any
door is not closed tightly.
All of the indicators in the monitor
display come on f or a f ew seconds
when you turn the ignition switch to
the ON (II) position.
249 252
Turn Signal and
Hazard Warning
Indicators
Brake L amp Indicator Door and Tailgate Open Monitor
Instrument Panel Indicators
66
BRAKE LAMP

To remove the f ront turn signal
bulb, push it in slightly and turn it
counterclockwise.
Install the new bulb into the
socket and reinstall it.Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise. To remove a bulb, pull it straight
out of its socket.
Install the new bulb into the
socket.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise. Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
1. 4.
5.
3. 2. 1.2.
3.
4.
5.
Lights
Replacing a Front T urn Signal
Bulb
Replacing a Parking L ight/Front
Side Marker L ight Bulbs
Maint enance
249

If you are changing the bulb on
the driver’s side, start the engine,
turn the steering wheel all the way
to the left, and turn off the engine.
If you are changing the bulb on
the passenger’s side, turn the
steering wheel to the right.
Use a f lat-tipped screwdriver to
remove the three holding clips
f rom the inner f ender.Pull the inner f ender cover away
f rom the f ender.
Remove the socket from the turn
signal assembly by turning it one-
quarter turn counterclockwise.Pull the burned out bulb straight
out of its socket.
Push the new bulb straight into
the socket until it bottoms.
Insert the socket back into the
turn signal assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Put the inner f ender cover in place.
Install the three holding clips.
Lock each clip in place by pushing
on the center.
1.
4.5.
3.
2. 6.
7.
8.
Lights
Replacing a Side T urn Signal Bulb
250

CONT INUED
............................
Capacities Chart .288
.............
Carbon Monoxide Hazard . 57
.............................
Carrying Cargo .193
..............
CAUTION, Explanation of . ii
..........................
CD Changer .131, 134
.......................................
CD Player .130
...
Accessories and Modif ications . 191
ACCESSORY (Ignition Key .......................................
Position) .81
............
Accessory Power Sockets . 101
...........................
AC Power Outlet .102
....................
Additives, Engine Oil . 239
...............
AdvancedAirbagSystem . 30
.............................
Airbag (SRS) .11, 25
..........
Airbag System Components . 25
..............
Air Conditioning System . 106
.....................
Rear A/C Control .113
.......................
Air Pressure, Tires .258
......................................
Antif reeze .242
...............
Anti-lock Brakes (ABS) . 209
...............................
Indicator .63, 210
...................................
Operation .209
..............
Anti-thef t, Audio System . 139
.
Anti-thef t Steering Column Lock . 81
................................
Audio System .115
...
Automatic Seat Belt Tensioners . 23
...
Automatic Lighting Off Feature . 76
.............
Automatic Speed Control . 175
..............
Automatic Transmission . 200
..........................
Capacity, Fluid .288 ...............
Checking Fluid Level . 244
.......................................
Shif ting .200
.
Shif t Lever Position Indicator . 200
................
Shif t Lever Positions . 201
....................
Shif t Lock Release . 203
Battery Charging System ...........................
Indicator .62, 276
............................
Jump Starting .272
..............................
Maintenance .262
............................
Specif ications .289
..............................
Bef ore Driving .185
..................................
Belts, Seat .10, 21
...........................
Beverage Holders .99
..................................
Booster Seats .54
Brakes ...........
Anti-lock System (ABS) . 209
.............
Break-in, New Linings . 186
....................
Bulb Replacement .252
...........................................
Fluid .246
.........................................
Parking .97
.................
System Indicator . 63,278
........................
Wear Indicators .209 .............................
Braking System .208
.................
Break-in, New Vehicle . 186
..
Brightness Control, Instruments . 76
........................
Brights, Headlights .75
Bulb Replacement ..........................
Back-up Lights .252
.....................
Brake Lights .252, 253
................
Front Parking Lights . 249
........
Front Side Marker Lights . 249
.................................
Headlights .248
........
High-mount Brake Lights . 253
.................................
Rear Bulbs .252
............................
Specif ications .289
.............
Turn Signal Light . 249,252
..............................
Bulbs, Halogen .248
Index
A
B
C
INDEX
I

........................................
Headlights .75
........................................
Aiming .248
..............
Automatic Lighting Off . 76
............
Daytime Running Lights . 76
..................
High Beam Indicator . 67
...........
High Beams, Turning on . 75
............
Low Beams, Turning on . 75
.........................
Reminder Chime .76
........
Replacing Halogen Bulbs . 248
...................................
Turning on .75
...................................
Headphones .172
..............................
Head Restraints .91
.................................
Heated Mirror .93
.....................................
Heater, Seat .86
.....................
Heating and Cooling .106
.............
High Altitude, Starting at . 199
.................
High-Low Beam Switch . 75
..............
High-mount Brake Light . 253
HomeLink Universal ................................
Transceiver .180
.......................
Hood, Opening the .188
...
Identif ication Number, Vehicle . 286Ignition
..............................................
Keys .79
...........................................
Switch .81
............
Timing Control System . 294
........................
Immobilizer System .79
...
Important Handling Inf ormation . iii
.........
Important Safety Precautions . 8
.........
Indicators, Instrument Panel . 61
...............................
Inf ant Restraint .43
......................................
Inf ant Seats .43
...................
Inf lation, Proper Tire . 257
...................................
Inside Mirror .92
.............................
Inspection, Tire .258
Installing a Child Seat .........................................
LATCH .47
..........
Tether Anchorage Points . 51
........................
Instrument Panel .5 ,61
........
Instrument Panel Brightness . 76
........................................
Introduction .i
.................
Jacking up the Vehicle . 268
.......................................
Jack, Tire .267
................................
Jump Starting .272 ..................................................
Keys .79
.......................
Label, Certif ication .286
.................
Lane Change, Signaling . 75
........................
Lap/Shoulder Belts .22
...........
LATCH Anchorage System . 47
.......................................
Lights .75, 102
....................
Bulb Replacement .248
.......................................
Indicator .61
.........................................
Parking .75
..................................
Turn Signal .75
....................................
Load Limits .194
......
LOCK (Ignition Key Position) . 81
Locks .......
Anti-thef t Steering Column . 81
............................
Fuel Fill Door .187
....................................
Glove Box .99
....................
Lockout Prevention . 82
.................................
Power Door .82
........................
Low Coolant Level .189
.........................
Low Fuel Indicator .67
...
Low Oil Pressure Indicator . 62,276
Index
I JK
L
IV

CONT INUED
...............................
Signaling Turns .75
.....................................
Snow Tires .260
................................
Sound System .115
Spare Tire ......................................
Inf lating .266
............................
Specif ications .289
....................
Specif ications Charts . 288
................................
Speed Control .175
..........
SRS, Additional Inf ormation . 25
...
Additional Safety Precautions . 37
.............................
Airbag Service .36
How the Side Airbag Of f ........................
Indicator Work .34
..
How the SRS Indicator Works . 33
How Your Front Airbags .........................................
Work .28
...
How Your Side Airbags Work . 31
........................
SRS Components .25
.............................
SRS Indicator .33 ,63
....
START (Ignition Key Position) . 81
.......................
Starting the Engine .199
In Cold Weather at High ..................................
Altitude .199
................
With a Dead Battery . 272
..............
State Emissions Testing . 296
........
Steam Coming f rom Engine . 274Steering Wheel
..................................
Adjustment .78
.............
Anti-theft Column Lock . 81
...............................
Buttons .138, 175
...................
Stereo Sound System . 115
....................
Storing Your Vehicle .263
........................
Sunglasses Holder .100
........................................
Sun Visor .101
Supplemental Restraint System ......................................
Servicing .36
.........................
SRS Indicator .33 ,63
...................
System Components . 25
..................................
Synthetic Oil .240
......
Taillights, Changing Bulbs in . 252
.
Taking Care of the Unexpected . 265
Technical Descriptions ......
DOT Tire Quality Grading . 290
.....
Emissions Control Systems . 293
..........
State Emissions Testing . 296
Three Way Catalytic ...............................
Converter .295
.......................
Temperature Gauge .71
........
Temperature, Inside Sensor . 114....................
Temperature, Outside . 71
...................
Tensioners, Seat Belts . 23
........
Testing of Readiness Codes . 296
..............
Tether Anchorage Points . 51
............................
Thef t Protection .139
..
Three Way Catalytic Converter . 295
..........................
Time, Setting the .140
..................
Tilt the Steering Wheel . 78
....................................
Timing Belt .245
....................................
Tire Chains .261
.........
Tire, How to Change a Flat . 267
Tire Pressure Monitoring ........................
System (TPMS) .205
Index
INDEX
T
VII
