Maintenance Minder
235
Maintenance Sub Items
Rotate tires
Replace air cleaner element
Replace dust and pollen filter
Inspect drive belt
Replace transmission and transfer fluid
Replace spark plugs
Replace timing belt and inspect water pump
Inspect valve clearance
Replace engine coolant
Replace VTM-4 rear differential fluid
:
If the message ‘‘SERVICE OIL’’ does not appear more than 12 months after
the display is reset, change the engine oil every year.
See information on maintenance and emissions warranty on page .
Independent of the maintenance minder display, replace the brake fluid
every 3 years.
Inspect idle speed every 160,000 miles (256,000 km).
Adjust the valves during services A, B, 1, 2, or 3 only if they are noisy.
NOTE: 1:
233
Maintenance Main Items
Replace engine oil
Replace engine oil and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect these items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections
A
B
1
2
3
4
5
61
1
If you drive in dusty conditions, replace every 15,000 miles
(24,000 km).
If you drive primarily in urban areas that have high concentrations
of soot in the air from industry and from diesel-powered vehicles,
replace every 15,000 miles (24,000 km).
Driving in mountainous areas at very low vehicle speeds or trailer
towing results in higher transmission and transfer temperatures or
frequently fully loaded. This requires transmission and transfer
fluid changes more frequently than recommended by the
Maintenance Minder. If you regularly drive your vehicle under
these conditions, have the transmission and transfer fluid changed
every 30,000 miles (48,000 km).
If you drive regularly in very high temperatures (over 110°F, 43°C),
in very low temperatures (under 20°F, 29°C), or towing a trailer,
replace every 60,000 miles (U.S.) /100,000 km
Driving in mountainous areas at very low vehicle speeds or trailer
towing results in higher level of mechanical (shear) stress to fluid
or frequently fully loaded. This requires differential fluid changes
more frequently than recommended by the Maintenance Minder.
If you regularly drive your vehicle under these conditions, have the
differential fluid changed at 7,500 miles (12,000 km), then every
15,000 miles (24,000 km).
Symbol
Symbol
Maintenance Minder
µµÎ
Î
Î
Î
µ
ÎÎ Î
Î
Specif ications
288
Dimensions
Weights
Air Conditioning
Battery Capacities1.93 US gal (7.3
)
2.43 US gal (9.2)
4.5 US qt (4.3
)
4.2 US qt (4.0
)
5.3 US qt (5.0
)
20.34 US gal (77.0
)
188.0 in (4,775 mm)
76.5 in (1,943 mm)
ND-OIL8
24.7 26.5 oz (700 750 g) HFC-134a (R-134a)
Length
Width
Height
Wheelbase
Track
66.3 in (1,685 mm)
106.3 in (2,700 mm) 70.5 in (1,790 mm)
Gross vehicle weight rating
Gross combined weight
rating (GCWR) See the tire information label atta-
ched to the driver’s doorjamb.
9,700 lbs (4,400 kg)
Equipped with transmission fluid cooler and power steering
fluid cooler.
The GCWR must be reduced 2 percent for every 1,000 feet (305
meters) of elevation.
Refrigerant type
Charge quantity
Lubricant type 77.5 in (1,968 mm)
71.7 in (1,821 mm)
70.1 in (1,780 mm)
71.3 in (1,811 mm)
66.5 in (1,690 mm)
66.5 in (1,690 mm)
66.7 in (1,694 mm)
12 V 72 AH/20 HR
Capacity Excluding the oil remaining in the engine 0.193 US gal (0.73
)
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity: 2.79 US qt (2.64
)
4.8 US qt (4.5
)
Fuel tank
Engine
coolant
Engine oil
Automatic
transmission
fluid
Rear
differential
fluid (4WD)
Windshield
washer
reservoir
8.3 US qt (7.9
)
3.5 US qt (3.3
)
8.9 US qt (8.4
)
4.0 US qt (3.8
)
Approx.
1:
2:
1:
2: Front
Rear
4WD
2WD
LX
EX
LX
EX
LX
EX
Front
Rear
4WD
2WD Change
Total
Change
Including
filter
Without
filter
Total
Change
Total
Change 4WD
2WD
4WD
2WD
2
1 1
2
Service Inf ormation Summary
Gasoline:
Fuel Tank Capacity:
Recommended Engine Oil:Power Steering Fluid:
Rear Differential Fluid: Brake Fluid:Tire Pressure (measured cold):
Automatic Transmission Fluid: 32 psi (220 kPa , 2.2 kgf/cm
)
60 psi (420 kPa , 4.2 kgf/cm
)
Honda Power Steering Fluid
preferred, or another brand of
power steering fluid as a
temporary replacement. Do not
use ATF (see page ).
Honda Heavy Duty Brake Fluid
DOT 3 preferred, or a DOT 3 or
DOT 4 brake fluid as a temporary
replacement (see page ). Compact Spare Tire: Front/Rear:
Honda VTM-4 Differential Fluid
(see page ).
API Premium grade 5W-20
detergent oil (see page ).
Oil change capacity (including
filter):
4.5 US qt (4.3
)
Honda ATF-Z1 (Automatic
Transmission Fluid) preferred, or
aDEXRON
III ATF as a
temporary replacement (see page ).
Unleaded gasoline, pump octane
number of 87 or higher.
239
244 247
246
245
20.34 US gal (77.0)
