2006 HONDA CIVIC SEDAN Owner's Manual (in English)

The under-hood f use box is on the
driver’s side, next to the brake f luid
reservoir. To open it, push the tabs
as shown.If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
and , or the diagram on the
f use box lid, which f use or f uses
control that device. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
the cause. Replace any blown f uses,
and check if the device works.
Thefusesareintwofuseboxes.The
interior f use box is underneath the
steering column. 235 236
Fuses
Checking and Replacing Fuses
232
INTERIOR
UNDER-HOOD
TAB
FUSE LABEL
——y

y
(#yy

Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box.Check each of the large f uses in
the under-hood f use box by
looking through the top at the wire
inside. Remove the screw with a
Phillips-head screwdriver.
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the under-hood
fuse box.
1.
2. 3. 4.
CONT INUED
Fuses
T aking Care of t he Unexpect ed
233
FUSE PULLER
BLOWN
FUSE
BLOWN
——y
y
(#yy

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied mechanic.
Look f or a blown wire inside the
f use. If it is blown, replace it with
oneof thesparefusesof thesame
rating or lower. If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
If the driver’s power window f use is
removed, the AUTO f unction of the
driver’s window will be disabled. To
reset the AUTO f unction, see page
.
6.
5. 94
On LX and EX models
Fuses
234
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
——y
y
(#yy

µ
µ
µ
µ
µÎ
Î
CONT INUED
No. Amps. Circuits Protected
No. Amps. Circuits Protected
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 50 A
40 A
20 A
20 A
30 A
30 A
40 A
10 A
15 A
15 A
7.5 A 15 A
15 A
7.5 A 15 A
7.5 A 10 A Headlight Main
Power Window Main
Not Used
Sub Fan Motor
Main Fan Motor (A/T)
Main Fan Motor (M/T)
Rear Defogger
Blower
Hazard
FI Sub
Stop and Horn
Not Used
Not Used
IGPS Oil Level
Not Used
Not Used
IG Coil
FI Main
MG Clutch
DBW
Interior Light
Back Up
1
2
3 100 A
70 A
80 A
50 A
30 A
30 A Main Fuse
EPS
Option Main
Ignition Switch Main
ABS
ABS
If equipped
:
Fuse Locations
T aking Care of t he Unexpect ed
235
UNDER-HOOD FUSE BOX
——y
y
(#yy

µ
µµ
µ
µ
Î
Î Î
Î Î
Î Î
Î
Î
No. No.No.
Amps. Amps. Circuits Protected
Circuits Protected Circuits Protected
Amps.
:
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16 17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
7.5 A
15 A
10 A
7.5 A
(15 A)
(20 A) 7.5 A
7.5 A
10 A
10 A
10 A
7.5 A
7.5 A 10 A ODS
MET ER
SRS
Right Headlight High
Left Headlight High
Small (Interior)
Small (Exterior)
Right Headlight Low
Power Window
Fuel Pump
Alternator
ABS Unit
Heated Seat
Fog Lights
Not Used
Not Used Left Headlight Low
Headlight High Main
Small (Main)
Not Used
Headlight Low Main
(HAC)
STS
Moonroof
Door Lock
Driver’s Power Window
HAC Option
Rear ACC Socket
ACC
Passenger’s Power Window
Not Used
Right Rear Power Window
Left Rear Power Window
Not Used
ACC Radio
(HAC)
Daytime Running Light
Wiper
10 A
20 A
15 A
20 A
(7.5 A)
(7.5 A) (20 A) 20 A
20 A
(20 A)
(15 A) 15 A
20 A
20 A
20 A
7.5 A
(10 A) 7.5 A30 A
If equipped
Fuse Locations
236
INTERIOR FUSE BOX
——y
y
(#yy

µµ
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
The operator
loads your vehicle on the back of a
truck. Therearetwowaystotowyour
vehicle: If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
Release the parking brake.
Shif t the transmission to neutral.
Release the parking brake.
Start the engine.
ShifttoD,thentoN.
Turn of f the engine. With the f ront wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
If your vehicle is equipped with a
f ront spoiler, remove it bef ore
towing so it is not damaged.
The tow
truck uses two pivoting arms that go
under the tires (f ront) and lif t them
of f the ground. The other two tires
remain on the ground.
Manual Transmission:
Automatic Transmission:
CONT INUED
Flat -bed Equipment
Wheel-lif t Equipment
This is the best way to trans-
port your vehicle.
T his is an
acceptable way to tow your
vehicle.
Emergency Towing
T aking Care of t he Unexpect ed
237
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
vehicle must be transported with the
f ront wheels of f the ground.
——y
y
(#yy

If you decide to tow your vehicle
with all f our wheels on the ground,
make sure you use a properly-
designed and attached tow bar.
Prepare the vehicle for towing as
described above, and leave the
ignition switched in the
ACCESSORY (I) position so the
steering wheel does not lock. Make
sure the radio and any items plugged
into the accessory power socket are
turned of f so they do not run down
the battery.
Emergency Towing
238
Trying to lif t or tow your vehicle by the
bumpers will cause serious damage.
The bumpers are not designed to
support the vehicle’s weight.The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.
——y
y
(#y
y

Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle, and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
