8. Mount the inner oil seal óon the steering knuckle.
Check the oil seal visually, if any deformation or glue lack is
found, change the oil seal
Mount of Steering Knuckle
1. Mount the lower ball stud on the steering knuckle;
Connect the lower ball stud and the steering knuckle with
bolts, and screw up the bolts according to the specified torque.
Fastening torque
(70-90)N
m
2. Mount on the steering knuckle
(a) Coat the lubricant HP-R on the drive shaft.
(b) Press down the lower arm to mount on the steering
knuckle.
(c) Mount on the groove nut of lower ball stud and screw up
the nut according to the specified torque, and then mount
on the split pin.
Fastening torque
(132-152)N
m
(d) Mount on the groove nut of upper ball stud and screw up
the nut according to the specified torque, and then mount
on the split pin.
Fastening torque
(132-152)N
m
Suspension System and Automobile Axle (SF/4WD)
Front Wheel Hub and Steering Knuckle (Steering Knuckle)

SA-53
3. Mount the stabilizer rod on the lower arm.
Fastening torque
(20-26)N
m
4. Mount the vibration damper on the lower arm.
Fastening torque
(127-147)N
m
5. Mount the steering knuckle arm and the brake oil pipe
bracket on the steering knuckle, and coat the sealing
agent 1271 on the bolt thread.
Fastening torque
180N
m
6. Mount on the dust cover and the brake shell.
Align the locating hole of dust cover and the groove of the
steering knuckle so as to guarantee the dust cover and the
steering knuckle are concentric.
Fastening torque
(25-29)N
m
7. Mount the front wheel hub and the front brake disc as well
as the brake caliper.
8. Check the height of the brake liquid level and, if required,
add the brake liquid, exhaust the gas of the braking
system.
Suspension System and Automobile Axle (SF/4WD)
Front Wheel Hub and Steering Knuckle (Steering Knuckle)

SA-57
1. Support up the front of vehicle to tear down the front
wheel and the steering knuckle.
2. Drain off lubricant in the front speed reducer.
3. Disconnect the front speed reducer flange and the drive
shaft.
Notice: Mark the assembly marks on the speed reducer
and the drive shaft before disconnecting them.
4. Tear down the front speed reducer.
5. Tear down the flange and dust cover:
(a) Loosen the riveted position on main-tooth nut with the
hammer and chisel.
Front Speed Reducer
Change of driving bevel gear oil seal of front speed reducer
front speed reducer and
differential assembly
oil-guard tray

driving bevel gear oil seal
flange and dust cover
140-210


Parts that cannot be reused after being used
specified torque
N
M
main-tooth nut
Suspension System and Automobile Axle (SF/4WD)
Front Speed Reducer (Change of Driving Bevel Gear Oil Seal of Front Speed Reducer)

BR-4Braking System
Notice and Troubleshooting
Troubleshooting (continued)
Trouble Causes Inspection items
There are quack-
quack noises
without using the
brake.Alien materials such as stone is reeled inside the wheel shell
Nuts on hub is loose;
The brake pedal or vacuum booster pushrod is adjusted
improperly;
The wheel bearing is worn or damaged or lubricated
insufficiently;
(disc type brake)
The outer end edge of brake pad support plate or brake pad
is dog-eared;
The silent pad is poor in properties;
The sliding liner is worn;
The mounting bolt is loose
The piston returns incompletely
(drum type brake)
There is loose or redundant part.Clear away the alien materials
Tighten the nut to the specified torque; and
change it in case the bolt hole is enlarged;
Check and adjust
Check, lubricate or change
Check repair or change
Check and make change according to real
situation
Check and make change according to real
situation
Check and tighten according to the necessity.
Check, repair or change
Check, take out or repair.
There is continuous
screaming noise
without using brakeThe brake pedal or vacuum booster pushrod is adjusted
improperly
The vacuum booster, master cylinder or wheel-brake cylinder
returns incompletely.
(Disc type brake)
The piston is rusted or seized;
The brake pad in brake caliper locates improperly;
There is friction between the brake disc and brake caliper
shell;
The brake pad support plate is mounted improperly;
There is interference between the abrasion indicating lamp
of brake pad and the brake disc due to the brake pad
abrasion;
(Drum type brake)
The pressure spring of brake shoe is soft rigidity, damaged
or unsuitable;
There is crack on the brake bottom plate flange;
There is interference of brake bottom plate with the brake
drum after it is bending or warping.
The brake drum interferes with the brake bottom plate or
with brake shoe due to it is processed improperly;
Other brake parts

There is loose or redundant part in braking system;
The brake liner is polished due to it is adjusted over-tightly;
The wheel bearing is worn, damaged or lubricated
insufficiently.Check and adjust
Check, repair or change
Check and add the lubricant according to
the necessity;
Repair or change
Repair or change
Repair or change
Change
Change
Repair or change
Repair or change
Change the brake drum
Check, maintain and change according to
the necessity;
Check, maintain and change according to
the necessity;
Check, maintain and change according to
the necessity;

BR-15
5. Brake disc measurement
(See page BR-17)
6. Measure the radial run-out of the brake disc;
(See BR-18)
7. Mount the lock plate of brake pad.
8. Mount the new brake pad.
(a) Mount the silent pad cluster on brake pads of both the
inner and outer sides;
Remark: Pollution of oil stain or coat is not allowed on the
work faces of brake pad or brake disc.
(b) Draw out a little brake liquid from the liquid container to
prevent the brake liquid overflowing from the liquid
container;
(c) Press in the piston with the hammer lever or similar tool.
9. Mount the wheel-brake cylinder;
Mount and screw up the hex bolts (the hex bolts shall be coated
with the thread locking sealing agents.
Fastening torque
(38-50)N
m
Remark: only one brake pad can be changed in one time so as
to prevent the piston of other wheel being shot out.
Braking System
Front Brake (Dr)

BR-16
10. Mount the front wheel;
Screw up the fixing nut of wheel.
Fastening torque
(135
150)N
m
Disassembly of Wheel-brake Cylinder
1. Take apart the brake pipeline.
(a) Tear down the brake pipeline. And block the outlet with
a clean cork.
(b) Tear down the brake oil pipe bracket from the wheel-
brake cylinder.
2. Tear down the wheel-brake cylinder from the caliper
bracket.
Tear down the two hex bolts and the wheel-brake cylinder.
3. Tear down the brake pad:
(a) Two brake pad;
(b) Two silent pad cluster;
(c) Four brake pad lock plate.
Pump Disassembly of Wheel brake
1. Take apart the following parts:
(a) Two sliding sleeve;
(b) Four sliding sleeve dust cover;
(c) Two sliding liner.
Braking System
Front Brake (Dr)

BR-18
3. Measure the bouncing value of the brake disc face;
Remark: verify the bearing is aligned correctly before
measuring.
The bouncing value of max face: 0.11mm
4. Change the brake disc according to the requirements
(a) Tear down the calipers body from the steering knuckle.
(b) Tear down the hub and the brake disc (See Page SA-11).
(c) Mount the new brake disc and screw up the connecting
bolts according to the specified torque.
Fastening torque
(60
79)N.m
(d) Mount the hub and brake disc assembly (see page SA-12);
(e) Mount the caliper bracket on the steering knuckle and
screw up the bolts according to the specified torque.
Fastening torque
(85
105)N.m
Cylinder Assembly of Wheel-brake
1. Preparation
All parts shall be washed, dried and cleared away the alien
materials before the assembly. And coat moderate vacuum
silicon base grease on the work faces of sliding sleeve dust
cover, sliding sleeve and the sliding liner; and plaster the
moderate rubber lubricant on the work faces of piston, piston
dust cover and the rectangular sealing ring.
2. Encase the piston sealing ring and piston in the caliper body;
(a) Screw the vent screw in the vent hole of calipers.
Fastening torque
(8
13)N.m
(b) Coat moderate rubber lubricant on the work face rectan-
gular sealing ring and encase the caliper body in groove.
(c) Encase the piston in the caliper body.
3. Encase the piston dust cover and the dust cover
snapping ring in the wheel-brake cylinder.
Braking System
Front Brake (Dr)

BR-19
4. Mount the sliding liner, sliding sleeve dust cover and
sliding sleeve.
(a) Encase the sliding liner and sliding sleeve dust cover in
the wheel-brake cylinder.
(b) Ensure the sliding sleeve dust cover in the ring groove of
wheel-brake cylinder hard.
(c) Encase the sliding sleeve in the sliding sleeve dust cover.
(d) Ensure the sliding sleeve dust cover in the ring groove of
sliding sleeve.
Mount of Brake Calipers
1. Mount the brake pad;
2. Mount the wheel-brake cylinder:
(a) Mount the wheel-brake cylinder;
(b) Mount and tighten the two assembling bolts (the bolts
shall be coated with the thread locking sealing agent).
Fastening torque
(38
50)N.m
3. Connect the brake pipeline.
Connect the brake pipeline with the calipers.
Fastening torque
(21
2)N.m
4. Observe the height of brake liquid level and, if
necessary, add in the brake liquid and exhaust the air
in braking system.
Notice: prevent the brake liquid from spraying on the
brake disc when exhausting air.
5. Check to see whether there is leakage of brake liquid. Braking System
