2006 GREAT WALL SAFE sensor

IN-5
Body lifting height and supporting position
wrong correct
Introduction
Body Lifting Height and Supporting Position
Jack lifting position
...........................................................................................................
Front......the front the beam center
Rear.....rear differential
Supporting position

safety bracket .............................................................................................
front
123456
123456
123456
123456
123456
12345
12345
12345
12345
b) The raised vehicle must be supported with the bracket; it is
dangerous to conduct the repairing work on the vehicle propped
up with one jack, even though such repairing can be finished in
short time.
12. The following items shall be taken notice to avoid the parts damage:
a) Do not open the covers of ECU and various computers where not
necessary absolutely. (if the IC terminal is touched, it be leaded
into static damage) .
b) Pull the hose at its ends when dismantling it, do not pull it at the
center section.
c) Pull the wire joint instead of the wire when pulling the joint
away.
d) Take notice to avoid of the drop of electric parts such as the
sensors or repeaters. In case those parts drop to the hard ground,
they must be changed instead of being reused.
e) Do not use the striking spanner to dismantle or mount the
thermostatic switch or thermostatic sensor.
f) Plug the needles of the multi-meter into the wire connector
carefully when checking its conductance and do not bend the
terminals.
g) Do not sheath the hose of the vacuum gauge into the very large
connector when using the gauge, instead, the stage joint shall be
used because once the hose expands, it is possible to lead into
the leakage.

MT-4Gearbox
Dismantle of Gear Box
3. Tear down the shifting ball of gear change lever
Loose the locking nuts by dextroroting the ball.
4. Tear down the glove box
Dismantle the four bolts of the glove box and put the glove box
into the suitable place.
5. Tear down the dust cover.
6. Tear down the gear change lever.
7. Raise the vehicle to discharge the oil in gearbox.
Warning: the reliability of vehicle shall be verified.
8. Tear down the drive shaft.
(See page PR-5)
9. Tear down the odometer sensor and the plugging
elements of backup switch
10. Tear down the vent pipe.
Tear down the heading exhaust pipe from branch exhaust pipe
Dismantle of gearbox
1. Disconnect the cathode wire from the cathode of storage
cell.
2. Tear down the setting bolts of fan cover.
Tear down 4

MT-8Gear Box
Mount of Gear Box
4WD:
(a) Mount the bracket and supporter of leg washers of rear
engine in 4WD vehicle;(SF)
(b) Mount and tighten the third beam of 4WD vehicle. (SF)
4. Remove the wooden spill.
5. Mount exhaust pipe.
Mount the exhaust pipe on the branch exhaust pipe.
Tightening moment
(62
3)N
m
6. Mount the wheel-brake cylinder of clutch.
Tightening moment
(18
2)N
m
7. Mount odometer sensor and plugging elements of backup
switch.
8. Connect the drive shaft.
(See page PR-12)
9. Add oil into the gearbox.
Lubricating oil grade: GL-5 85W/90
Volume: 2.4L(dry)
Remark: the Tightening moment of oil filling/draining
plug: (30
50)N
m
4WD
4WD

TF-3Transfer Box
Troubleshooting
Common troubles Causes Resolving approaches
Change the lubricant or supplement the
lubricant volume.
Guarantee the torque of all connecting
elements stand at the specified value.
Open the transfer case to check the
bearing and othe parts whether is weared
or daamaged,if this happened,change
the parts.
Difficulty in mechanic gearshift or
outplace gear engagement
Troubleshooting
Incorrect lubricant or insufficient
lubricant volume.
Looseness of connecting bolt or other
connecting element.
Noise from the transfer box bearing Noise, which is spreader by the transfer
box instead of clutch, engine, drive shaft
and other parts, occurs in each speed. No driving of front wheel in the four-
gear engagementDrive chain breakDisassemble and check the damage of
inner parts, and change the chain. Adjust or repair shift lever.Open the
transfer box to check the toggle fork and
guide shaft, and change the parts as
requirement.Open the transfer box to
check whether the parts is wearied or not,
and, if any, change the weary parts.Open
the transfer box to check whether the
parts is wearied or not, and, if any, change
the weary parts.Open the transfer box to
check whether the parts is wearied or not,
and, if any, change the weary parts. Overlarge loose fit clearance of the
shift toggle fork on the shift guide
shaft.
Wear of the shift toggle fork
assembly including pin and contact
roller.
Wear of the shift cam hub and the
liner.
Attainment of coupling gear Mechanic gearshift seizing at a certain
location Engagement failure of the mechanically
shift transfer boxDamage or unsuitable adjustment of
the shifting mechanism.
Damage or serious wear of the inner
shifting parts, or looseness or
attainment of the shift toggle fork
assembly on the guide shaft.
Unsuitable adjustment of shift lever.Adjust or repair the shift lever mechanism.
Change the seriously wearied parts.
Change the loose or weary parts. Refer to the vehicle manual for correct
operation.
Add the specified oil of given volume.
Open the rear cover of transfer box to check
and changer the damaged parts.
Open the rear cover of the transfer box to
check whether the sliding parts can slide
freely along the axle, if not, dismantle it and
change the damaged parts. Incorrect operation.
Lubricant of inferior quality or
insufficient volume.
Adhesive bonding of shift toggle fork.
Adhesive bonding of the sliding joint
cover, locking sleeve or gear. Mechanic gearshift failure under the
movement of shifting handleBreak or damage of the shift rocker
arm or shift lever.
Damage of the guide plate of shifting
cam;Change the damaged element.
Open the rear cover of the transfer box to
check the damaged element and change
it. Electric gearshift troubleDamage or failure of electrically
controlled element, electric module,
speed sensor, electric motor, electric
clutch, or built-in wire harness.
Damage or worn of shifting cam,
joint cover, locking sleeve, toggle
fork or shift guide axle.Adhesive
bonding shiftRefer to the vehicle usage manual to
diagnose the failure element and change
it as requirement.
Dismantle the weary or damaged parts
and change it as requirement.
Dismantle and check the free movement
of sliding element, and change it as
requirement

TF-9
5 4
3
1
6 2
1. rear body of transfer box
2. flange
3. oil seal
1. sensor bracket
2. bolt
3. speed sensor
4. o-ring
5. sensor assembly
6. bolt
7. gasket
8. rear body of transfer box2 1
5 3
4
4
6
7
8
Transfer Box
Disassembly of Transfer Box
4. gasket
5. nut
6. oil plug
Disassembly of Transfer Box
1. Brief instruction
In case the transfer box is required to be repaired for the
damaged specific element, it shall be taken apart to the degree
on which the damaged element is taken out. And the parts
taken apart from the transfer box, if it doesnít include the
damage element, can exist in the form of sub-assembly or
group instead the individual form, otherwise, the parts will be
taken apart individually.
2. Transfer Box Disassembly
Put the transfer box on the worktable and ensure the rear part
or the rear cover faces upward. Put the wooden block under the
front part of transfer box to keep the transfer box stands
horizontally. The disassembly process is as follows:
(a) Fasten the flange with the torque arm typed T-13-54-
002, screw off the nut to take down the gasket, then take
apart the flange and oil seal.
(b) Take down the two oil plugs from the transfer box body.
As for the electric gearshift transfer box, tear down the
electric shifting element according to the following
disassembly approach:
(a) Tear down the three bolts, gaskets, sensor and clip for
wire harness.
(b) Tear down the sensor assembly and take apart the O-
ring.
(c) Tear down the motor assembly.

TF-21
QR
NOP
NMSTN
UV
NOPQ
RS
(d) All of the following aligning conditions shall be satisfied
when the rear cover assembly is mounted on the transfer
box front housing:
a) Align the pin hole in the rear cover to the pin on the
housing.
b) Align the rear output shaft to the inner bearing in
cover rear hole.
c) Align the blind hole in the rear cover and the shift
guide shaft; ensure the return spring is not tilted.
Check the hole in velocity sensor of the rear cover
with a pen.
d) Align the shift shaft and the inner bearing in rear
cover.
(e) Screw up the nine bolts after locating the sign bolts
correctly.
(f) Encase the gear of odometer in the rear cover assembly
through the spline of the rear output shaft.
(g) Press the new oil seal in the cover assembly
NO
P
Q
Transfer Box
Transfer Box Assembly
1. bolt
2. wire harness
3. magnet
4. return spring
5. shift guide shaft
6. transfer box rear
body assembly
7. sign board
8. driving gear of Odometer
9. oil seal
10. transfer box front housing
1. locating pin
2. output shaft
3. shift shaft4. return spring
5. shift guide shaft
6. output shaft.12. Assembly of Rear Cover
Mount the aforesaid accomplished cover assembly on the
transfer box housing according to the following process:
(a) Mount the return spring on the shift guide shaft of the
transfer box.
(b) Mount the magnet in the groove of the housing.
(c) Coat the Letai glue 598 of 1.6mm on the coupling face of
housing, steer clear of the screwed hole when coating
continuously.
Notice: try to button the rear cover on the transfer box front
housing with the moderate force during the following process.
Not too much force is required when mounting the rear cover
on the front housing when all aligning conditions are satisfied,
in case the rear cover cannot be mounted on the front housing,
take down the rear cover assembly to check the aligning
condition
1. wire harness clip
2. motor assembly
3. bolt
4. sign board

TF-22
12
3 4
6
7
8
95
21
Transfer Box
Transfer Box Assembly
1. motor assembly
2. shift shaft
1. fixed sensor bracket
2. bolt
3. sensor assembly
4. velocity sensor
5. o-ring6. motor assembly
7. bolt
8. gasket
9. transfer box rear body
12. Mount the external electric shifting element (for the elec-
tric shift transfer box)
(a) Locate the motor assembly by aligning the triangle
groove on motor to the shift shaft.
(b) Move the motor to combine the shift shaft and keep it
close to the rear cover. Then run the motor clockwise
until the motor locates the correct place and the mooting
holes are aligned.
(c) Mount the O-ring on the velocity sensor and encase the
velocity sensor assembly in rear cover. A clip and three
bolts shall be mounted on the velocity sensor.
Fastening torque
(8
11)N
m
(d) Mount the bolts and gaskets on the end of motor clip.
Fastening torque
(8
11)N
m

TF-30Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Attachment for Inspection Maintenance or Change of Parts)
Change the parts and fittings as requirement
Attachment for Inspection Maintenance or Change of Parts
Checking items
Acceptance/Refusal
Parts (items)
All parts (including
all springs)Crack inspection, distortion inspection and ero-
sion inspectionAll parts with crack, all parts that are bended,
distorted or poor in round bouncing are refused.
All threaded partsThread inspection for buckle missing or other
damageThose parts cannot be threaded or bottomed in
overlap manner shall be refused.
Flange and fork
flangePlease refer to the paragraph of
inspection
to
check the spline.Please refer to the
inspection paragraph
for
spline inspection.
Velocity sensor, mo-
tor assembly
Parts of electric clutch
systemPlease refer to the part of electric appliance
Sliding bearing Inside surface inspection for the sliding bearing In the case that the bearing has pitting corrosion
or other damage, refuse it.
Ball bearingCheck visually the ball and track of the ball
bearing to see whether there is damage such as
adhesive bonding, pitting corrosion, etc.
Ensure that the bearing are all lubricated, run the
outer race of the bearing while holding the inner
one to feel whether there is poor running or
corrosion, the bearing shall be run smoothly
without excessive clearance.Refuse to use the damaged bearing;
Refuse to use the damaged or loose bearing; or
Check the axial clearance to see whether it
exceeds 0.23mm.
Needle bearing Check the bearing needle roller and track to see
whether there is damage such as adhesive
bonding, pitting corrosion, etc.Refuse to use the damaged bearing.
The rear cover, front
body and front hous-
ing of transfer boxCheck to see whether there is burr on the cou-
pling face or other damage that impedes assem-
bling or sealing.Clear away the burr according to the paragraph
of
inspection
, otherwise, change the dam-
aged element
Rear cover of trans-
fer boxCheck the bearing holeRefuse to use the assembly that has pitting
corrosion
Odometer gear Check the gear teeth referring to the Inspection
ParagraphRefer to the gear or chain sprocket inspection in

inspection paragraph
.
Clutch shell, joint
outer gear sleeve and
joint coverCheck the spline according to the Inspection
paragraphRefer to the spline inspection of
inspection
paragraph

Locking sleeveCheck the wear or damage of the toggle fork
grooveRefuse the parts with step slipping or damage.
Shift guide shaft Check the deformation situation
Check the burr or other damage on outer race
Check the wear of outer raceRefuse to use the bend shaft; clear away the burr
according to the
inspection
paragraph, oth-
erwise refuse to use.
Refuse to use the shaft with step slipping or
other damage.
Shift toggle forkCheck whether there is wear or damage at the
location where the toggle fork combines with
the shifting cam and gear sleeve.If any step slipping or damage is found, refuse
to use it.
