2006 GMC ENVOY Get To Know Guide

17
FourWheel Drive (if equipped)
Envoy’s fourwheel drive system rotary
controls are located on the instrument
panel. Your vehicle will have one of the
above transfer case knobs.
Shift into 4HI, 4 , A4WD or AUTO
• Turn the knob to 4HI, 4 , A4WD or
AUTO. This can be done at any
speed except when shifting from 4LO
or 4 .
Shift into 2HI or 2
• Turn the knob to 2HI or 2 . This can
be done at any speed except when
shifting from 4LO or 4 .
Shift into or out of 4LO or 4
• With the ignition in RUN and the vehi
cle stopped or moving less than 3
mph (4.8 km/h), shift the transmission
into Neutral.
• Turn the knob to 4LO (4 ), 2HI (2 ),
4HI (4 )or A4WD (AUTO), preferably
with the vehicle moving 1 to 2 mph
(1.6 to 3.2 km/h).
• Wait for the indicator lamp to stop
flashing and remain illuminated; then
shift your transmission into gear.
Shift into NEUTRAL (N)
• Place the transfer case in Neutral
only when towing your vehicle. See
Section 4 of your Owner Manual for
towing information.
See Sections 2, 4 and 5 of your Owner Manual.
StabiliTrak®– Stability Control
System
StabiliTrak combines antilock brake,
traction control, and stability control sys
tems that help the driver maintain direc
tional control of the vehicle in most driv
ing conditions. The system is designed
to help keep the vehicle on the driver’s
intended path by using throttle and
brake intervention.
When activated, the system will apply
braking to individual wheels and may
reduce engine power as necessary to
help you maintain directional control of
the vehicle. You may also hear a noise
or vibration, or feel a reduction in accel
eration, while the system is active. This
is normal.
StabiliTrak is automatically turned on
when the vehicle is started and does not
require any driver input. It is recom
mended to leave the system on at all
times for normal driving. It may be nec
essary to turn off the system if the vehi
cle is stuck in sand, mud or snow.
To turn off StabiliTrak, press and hold
the (StabiliTrak) button on the trans
mission shift handle for five seconds.
STABILITRAK OFF will be displayed on
the DIC. Press the button again to turn
the system back on.
See Section 4 of your Owner Manual.

Getting to Know YourEnvoy18
Luggage Carrier (if equipped)
Slide the crossrails to desired
position
• Pull up the lever on each side of the
crossrail. This will release the cross
rail and allow you to slide it.
• When the crossrail is where you want
it, press down on the levers to lock it
in place.
Reduce wind noise when the roof
luggage carrier is not in use
• Position the rear crossrail at the
rearmost position and the front
crossrail above the rearmost portion
of the rear door opening (above the
Cpillar).
See Section 2 of your Owner Manual.
Note:Never carry anything on the vehi
cle roof that is longer or wider than the
luggage carrier itself. (Examples: ply
wood, paneling, a mattress.) The load
could be violently torn off, causing you
or others to have a collision.
Loading cargo that weighs more than
220 pounds (100 kg) on the luggage
carrier may damage your vehicle.

19
Notes

Getting to Know YourEnvoy20
Roadside Assistance
My GMLink
1800GMC8782 (18004628782)
TTY: 18888892438
As the proud owner of a new GMC
vehicle, you are automatically enrolled inthe GMC Roadside Assistance program.
The tollfree number is staffed by a team
of technically trained advisors, who are
available 24 hours a day, 365 days a
year.
Roadside Assistance provides stranded
owners with overthephone roadside
repairs, location of the nearest GMC
dealer or the following special services:
• Flat Tire Assistance
The GMC Owner Center at My GMLink
is a complimentary service for GMC
owners, a onestop resource to enhance
your GMC ownership experience.
Exclusive member benefits include
online service reminders, vehicle main
tenance tips, online owner manual, spe
cial privileges and more. Sign up today
at www.mygmlink.com. • Vehicle Identification Number (VIN)
• Vehicle license plate number
GMC reserves the right to limit services
or reimbursement to an owner or driver
when, in GMC’s judgment, the claims
become excessive in frequency or type
of occurrence.
Roadside Assistance and OnStar
(if equipped)
If your vehicle is OnStarequipped,
press the blue OnStar button and the
vehicle will send your current GPS loca
tion to an OnStar Advisor who will speak
to you, assess your condition, contact
Roadside Assistance and relay your
exact location so you will get the help
you need.
Certain restrictions, precautions and safety procedures apply to your vehicle. Please read your Owner
Manual for complete instructions. All information contained herein is based on information available at
the time of printing and is subject to change without notice. Copyright 2005 by GM Corp.
All rights reserved.
