2006 GMC CANYON Owner's Manual

Power Seats
If your vehicle has this
feature, there is a control
on the outboard side
of the front seat(s).
Horizontal Control:Raise or lower the front of the seat
by raising or lowering the front of the control.
Raise or lower the rear of the seat by raising or lowering
the rear of the control.
Raise or lower the entire seat by raising or lowering the
whole control.
Move the seat forward or rearward by moving the whole
control toward the front or the rear of the vehicle.
Vertical Control:This control reclines the seatbacks.
SeeReclining Seatbacks on page 1-5for more
information.
Manual Lumbar
If your vehicle has this
feature, there is a knob
located on the outboard
side of the driver’s seat.
Turn the top of the knob toward the front of the vehicle
to increase lumbar support. Turn the top of the knob
toward the rear of the vehicle to decrease lumbar
support.
1-3

Power Lumbar
If your vehicle has this
feature, the control is
located on the outboard
side of the seat(s).
Press and hold the front of the control until you have
the desired lumbar support. To decrease lumbar
support, press and hold the rear of the control.
Heated Seats
If your vehicle has this
feature, the controls are
located on the outboard
side of the front seats.
This feature will heat the cushion and back of the seats.
Press the top of the switch to turn the heat to the
high setting. Press the bottom of the switch to turn the
heat to the low setting. Put the switch in the center
position to turn the heat off.
The ignition must be on for the heated seat feature to
work. The seat will heat to the last setting if the ignition
has been turned off and then turned back on.
The passenger’s safety belt must be engaged for the
heated seat feature to work on the passenger’s seat.
1-4

Reclining Seatbacks
If your seats have manual reclining seatbacks, the lever
is located on the outboard side of the seat(s).
To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position, then
release the lever to lock the seatback in place.{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
3. Push and pull on the seatback to make sure it is
locked.
1-5

To return the seatback to an upright position, do the
following:
1. Pull up on the lever fully without applying pressure
to the seatback and the seatback will return to the
upright position.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
2. Push and pull on the seatback to make sure it is
locked.If your vehicle has power
reclining seatbacks, use
the vertical power seat
control located on the
outboard side of the seat.
Press the control toward the rear of the vehicle to
recline the seatback. Press the control toward the front
of the vehicle to raise the seatback.
1-6

{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job because it
will not be against your body. Instead, it will be
in front of you. In a crash, you could go into it,
receiving neck or other injuries.
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there, not
at your pelvic bones. This could cause serious
internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
Do not have a seatback reclined if your vehicle is
moving.
1-7

Head Restraints
Your front seats may have adjustable head restraints.
If your vehicle has rear seats, they may have adjustable
head restraints.
Pull up on the head
restraint to raise it.
To lower the head
restraint, press the button
located on top of the
seatback and push down
on the head restraint.
Adjust the head restraint so that the top of the restraint
is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
1-8

Seatback Latches
Your vehicle may have front seatbacks that fold forward
for easy access to the rear seats or the storage area
behind the seats.
To fold the seatback
forward, push the lever on
the side of the seat
rearward and pull the
seatback forward.{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
To return the seatback to the upright position, push the
seatback all the way back until it latches. If the
seatback was reclined before being folded forward,
it will return to the reclined position.
1-9

Rear Seats
Rear Seat Operation (Crew Cab)
The rear seatback(s) in the crew cab can be folded
forward.
To fold the rear seatback(s) forward, do the following:
1. Disconnect the rear center safety belt latch from the
mini buckle by inserting the tip of the safety belt
tongue into the slot on the buckle. Let the belt
retract.2. Pull the loop, located
on the outboard side of
the seatback, forward
until you hear a click.
3. Fold the seatback(s) forward.
1-10
