2006 FIAT DUCATO Owners Manual

1
WELCOME ABOARD
Thank you for selecting Fiat and congratulations on choosing a Ducato. A light commercial vehicle designed to
ensure large load capacity with first class safety and reliability, able to offer great driving comfort and be a real friend
to the environment. The functionality of its every detail, its versatility, engine performance, wealth of equipment
and options, safety systems and totally recyclable components contribute to making Ducato the only light com-
mercial vehicle of its kind.
You will see this for yourself when you sit in your Ducato and take to the road.
And you will realise it later when you discover that thanks to its terrific qualities you have everything you need
to hand, even when you are driving under the worst conditions.
Before you set off, however, you should read this booklet carefully. It is an indispensable guide to all your Duca-
to’s features and will give you first-class advice for high quality driving. Above all, it will be able to provide you
with valuable tips for your own safety, the vehicle’s well-being and about how to protect the environment.
The enclosed Warranty Booklet lists the Services that Fiat offers its Customers:
• the Warranty Certificate with terms and conditions for maintaining its validity
• the range of additional services available to Fiat Customers.
Enjoy your read, happy driving and let your work become a real pleasure.
In this Owner Handbook you will find all the versions and contents (optional included)
of Fiat Ducato. Take into account only the information regarding the equipment
and version you have purchased.

2
MUST BE READ!
REFUELLING
Petrol engines:only refuel with unleaded petrol with octane rating (RON) no less than 95.
Diesel engines:only refuel with diesel fuel conforming to the European specification EN590.
STARTING THE ENGINE
Make sure the handbrake is pulled up; put the gear lever to neutral; press the clutch pedal down to the floor
without touching the accelerator; then:
automatic gearbox:for operation and use, strictly follow instructions and warnings contained at paragraph
“Automatic gearbox” in section “Getting the best out of your vehicle”.
petrol engines:turn the ignition key to AVV and release it as soon as the engine starts.
diesel engines:turn the ignition key to MARand wait for the instrument panel warning light mand Y
to go out; then turn the ignition key to AVV and release it as soon as the engine starts.
PARKING OVER INFLAMMABLE MATERIAL
When functioning normally, the catalytic converter reaches high temperatures. For this reason do not park
the vehicle over inflammable material, grass, dry leaves, pine needles, etc.: fire hazard.
K


3
ELECTRICAL ACCESSORIES
If, after buying the vehicle, you decide to add electrical accessories (that will gradually drain the battery), visit
a Fiat Dealership. They can calculate the overall electrical requirement and check that the vehicle’s electric
system can support the required load.

CODE card
Keep the code card in a safe place, not in the vehicle. You should always keep the electronic code written on
the CODE card with you in case you need to carry out an emergency start-up procedure.
SCHEDULED SERVICING
Correct maintenance of the vehicle is essential for ensuring it stays in tip-top condition and safeguards its safe-
ty features, its environmental friendliness and low running costs for a long time to come.
THE OWNER HANDBOOK CONTAINS…
…information, tips and important warnings regarding the safe, correct driving of your vehicle, and its mainte-
nance. Pay particular attention to the symbols "(personal safety) #(environmental protection) (vehicle
well-being).

The signs you see on this page are very important. They highlight those parts of the handbook where, more than
anywhere else, you should stop for a minute and read carefully.
As you can see, each sign has a different symbol to make it immediately and easy to identify the subjects in the
different areas:
THE SIGNS TO HELP YOU DRIVE CORRECTLY
4
Personal safety.
Important. Total or partial failure to
follow these instructions can place dri-
ver, passengers or others in serious
danger. Environmental protection.
This shows you the correct proce-
dures to follow to ensure that the ve-
hicle does not harm the environment. Vehicle well-being.
Important. Total or partial failure to
follow these instructions will result in
the risk of serious damage to the ve-
hicle and may invalidate the warranty
as well.

5GETTING TO KNOW YOUR VEHICLE
G G
E E
T T
T T
I I
N N
G G
T T
O O
K K
N N
O O
W W
Y Y
O O
U U
R R
V V
E E
H H
I I
C C
L L
E E
DASHBOARD
The presence and the position of the instruments and warning lights may vary according to the vehicle version.
1Side air vents - 2Direction indicators and light stalk - 3Instrument panel - 4Windscreen wiper stalk -
5Central air vents - 6Writing/reading desk - 7Sound system compartment - 8Central button panel -9Central air vents -
10Oddment trays/passenger’s airbag - 11Side air vents - 12Bottle holder - 13Current socket - 14Ashtray - 15Air dis-
tribution - 16Air temperature - 17Air recirculation -18Cigar lighter - 19Fan control - 20Gear shift lever - 21Ignition
switch - 22Steering wheel adjustment lever - 23Horn - 24Airbag - 25Oddment trays
fig. 1F0D0080m

6GETTING TO KNOW YOUR VEHICLE
fig. 2F0D0246m
The presence and the position of the instruments and warning lights may vary according to the vehicle version.
1Side air vent - 2Oddment trays/passenger’s airbag - 3 Central air vents - 4Central button panel - 5Sound system com-
partment - 6Writing/reading desk - 7Direction indicators and light stalk - 8Instrument panel - 9Windscreen wiper stalk -
10Oddment trays - 11Ignition switch - 12Airbag - 13Horn - 14Steering wheel adjustment lever - 15Gear shift lever -
16Air distribution - 17Current socket - 18Ashtray - 19Air temperature - 20Air recirculation - 21Cigar lighter - 22Fan
control - 23Bottle holder

7GETTING TO KNOW YOUR VEHICLE
SYMBOLS
Special coloured labels have been at-
tached near or actually on some of
the components of your Ducato.
These labels bear symbols that remind
you of the precautions to be taken as
regards that particular component.KEYS fig. 3
The following keys are provided with
the vehicle:
– two keys Awith metal insert and
power-assisted opening if the vehicle
is not equipped with remote control;
– key Aand key Bif the vehicle is fit-
ted with a door lock remote control.
– Key Ais the key that is used nor-
mally. It will:
– start the engine;
– lock/unlock the front doors;
– lock/unlock the side sliding doors;
– lock/unlock the rear doors;
– lock/unlock the fuel filler cap.
fig. 3
F0D0128m
THE FIAT CODE
SYSTEM
To further protect your vehicle from
theft, it has been fitted with an engine
immobiliser system (Fiat CODE)
which is automatically activated when
the ignition key is removed.
An electronic device, in fact, is fitted
in each ignition key grip. The device
modulates a signal when the engine is
started through a special aerial built
into the ignition switch. The modulate
signal, which changes each time the
engine is started, is the password by
means of which the control unit
recognises the key and enables to
start the engine.
