2006 DODGE RAM 1500 GAS Owners Manual

40-20-40 Front Seat
As the name implies, the seat is divided into 3 segments.
The outboard seat portions are each 40% of the total
width of the seat. The back of the center portion (20%)
easily folds down to provide an armrest/center storage
compartment (if equipped). Each outboard seat is independently adjustable forward
or rearward and is equipped with a back recliner. The
manual forward or rearward seat adjustment handle is
found at the front edge of each seat cushion. Pull up on
the handle and slide the seat to get the most comfortable
position.
WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured. Adjust
any seat only while the vehicle is parked.
MANUAL SEAT ADJUSTER
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145
3

Reclining Seats (1500 Standard and Quad Cab
Models)
The recliner handle is on the outside of the seat cushion.
Pull up on the handle, as shown, to release the seat back
and adjust for comfort.
WARNING!
You can be seriously, even fatally, injured riding in a
seat with the seatback reclined. Do not ride with the
seatback reclined so that the shoulder belt is no
longer resting against your chest. If you ride in this
position, the shoulder harness will no longer be
restraining you. In a collision you could slide under
the seat belt and receive serious or fatal injuries.
Recline in a seat only when the vehicle is parked.
Seat Recliner Handle
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Reclining Seats (2500/3500/Mega Cab Models)
The recliner handle is on the outside of the seat cushion.
Pull up on the handle, as shown, to release the seat back
and adjust for comfort.WARNING!
You can be seriously, even fatally, injured riding in a
seat with the seatback reclined. Do not ride with the
seatback reclined so that the shoulder belt is no
longer resting against your chest. If you ride in this
position, the shoulder harness will no longer be
restraining you. In a collision you could slide under
the seat belt and receive serious or fatal injuries.
Recline in a seat only when the vehicle is parked.
Adjustable Head Restraints
Head restraints can reduce the risk of neck injury in the
event of impact from the rear. Pull up or push down on
the restraints so that the upper edge is as high as
practical, at least to the level of the ears.
MANUAL RECLINE LEVER
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147
3

To lower the head restraint, push in the button and then
push down on the head restraint.Manual Rotary Lumbar Support Adjustment — If
Equipped
Rotating the lumbar control knob on the left side of the
driver’s seatback and on the right side of the passenger’s
seatback increases or decreases the lumbar (lower back)
support.
HEAD RESTRAINT & SPACERS
Manual Lumbar Adjustment
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Power Seats (1500 Standard and Quad Cab
Models) — If Equipped
CAUTION!
Don’t put anything under a power seat. It may cause
damage to the seat controls.
Power Seat Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149
3

The power seat controls are on the outboard side of the
front seat cushions. One switch controls the seat move-
ment. The six-way switch can be moved forward or
backwards to get the most comfortable position. The
same switch can be moved up and down to control seat
height or to change the seat angle by tilting it up or
down.
Power Seat Switch Position
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Power Seats (2500/3500/Mega Cab Models) — If
Equipped
CAUTION!
Don’t put anything under a power seat. It may cause
damage to the seat controls or the Occupant Classi-
fication System.
PS SW. LOCATOR
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151
3

The power seat controls are on the outboard side of the
front seat cushions. Three switches control the seat move-
ment. The four-way switch in the center can be moved
forward or backwards to get the most comfortable posi-
tion. The same switch can be moved up and down to
control seat height. Change the seat angle by using the
two toggle switches, tilting it up or down.
Up, Down, Forward, and Rearward
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
