2006 CHRYSLER TOWN AND COUNTRY transmission oil

WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
17. Washer Fluid LightThis light turns on when the washer fluid level
falls below approximately 1/4 filled. The light will
remain on until fluid is added.
18. Transmission Range Indicator
This display indicator shows the automatic transaxle gear
selection. NOTE:
You must apply the brakes before shifting from
Park.
19. Oil Pressure Warning Light This light shows low engine oil pressure. The light
should turn on momentarily when the engine is
started. If the light turns on while driving, stop the
vehicle and shut off the engine as soon as possible. A
chime will sound for 4 minutes when this light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked under the hood.
20. High Beam Light This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or low
beam.
214 UNDERSTANDING YOUR INSTRUMENT PANEL

•Taxi, police, or delivery service (commercial ser-
vice). \b
•Off-road or desert operation.
NOTE: Most vehicles are operated under the conditions
listed for Schedule B.
Second is Schedule “A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule B.
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder and transmission, add as needed.
MAINTENANCE SCHEDULES 449
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

•Check all lights and all other electrical items for correct
operation.
At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints and front suspension compo-
nents.
•Check the automatic transmission fluid level.
•Check the coolant level, hoses, and clamps.
450 MAINTENANCE SCHEDULES
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 57, 000 60, 000 63, 000 66, 000 69, 000 72, 000
(Kilometers) (95 000) (100 000) (105 000) (110 000) (115 000) (120 000)
Change engine oil and engine oil filter. XXXXX X
Rotate Tires X X X
Inspect the brake linings. X X
Inspect the engine air cleaner filter, replace if
necessary. * X XXX X
Replace the engine air cleaner filter. X
Inspect the tie rod ends and boot seals. X
Inspect the PCV valveand replace if neces-
sary.* X
Inspect the serpentine drive belt on 3.3 liter
and 3.8 liter engines, replace if necessary. ‡ X
Change the automatic transmission fluid and
filter. \b X
Replace the air conditioning filter. X X
SCHEDULE “B” 455
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108, 000 111, 000 114, 000 117, 000 120, 000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter. X X X X X
Rotate Tires X X X
Inspect the brake linings. X X
Inspect the engine air cleaner filter, replace if neces-
sary. * XXXX
Replace the engine air cleaner filter. X
Inspect the tie rod ends and boot seals. X
Inspect the PCV valveand replace as necessary.* X
Inspect the serpentine drive belt on 3.3 liter and 3.8
liter engines, replace if necessary. ‡ X
Change the automatic transmission fluid and filter.
\b X
Replace the air conditioning filter. X X
458 SCHEDULE “B”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Compass Variance....................... 166
Computer, Trip/Travel .................... 167
Console, Overhead ....................... 163
Console, Removable ................... 189,190
Contract, Service ........................ 470
Coolant Pressure Cap ..................... 419
Cooling System ......................... 416
Adding Coolant (Antifreeze) .............. 418
Coolant Capacity ...................... 444
Coolant Level ...................... 417,420
Disposal of Used Coolant ................ 419
Drain, Flush, and Refill .................. 417
Inspection ........................... 420
Points to Remember .................... 420
Pressure Cap ......................... 419
Radiator Cap ......................... 419
Selection of Coolant (Antifreeze) ......417,444,445
Cruise Control (Speed Control) .............. 160
Cruise Light ........................... 216 Cup Holder
......................... 183,433
Customer Assistance ..................... 468
Daytime Running Lights ................... 151
Dealer Service .......................... 401
Defroster, Rear Window ................... 305
Defroster, Windshield ................84,285,296
Diagnostic System, Onboard ................ 399
Dimmer Control ........................ 150
Dipsticks Automatic Transmission ................. 426
Oil (Engine) .......................... 402
Disabled Vehicle Towing ................... 393
Disarming, Theft System ................... 27
Disposal Antifreeze (Engine Coolant) ............... 419
Engine Oil ........................... 406
Domelight ............................. 150
Door Ajar Light ......................... 210
INDEX 479
10

Temperature Gauge..................... 213
Exhaust Gas Caution ..............37,83,349,416
Exhaust System ......................... 415
Extender, Seat Belt ........................ 53
Exterior Folding Mirrors ................... 93
Filters Air Cleaner .......................... 407
Air Conditioning .................... 302,412
Automatic Transaxle .................... 427
Engine Oil ........................ 406,445
Engine Oil Disposal .................... 406
Flashers Hazard Warning ....................... 368
Turn Signal ..................... 210,440,442
Flat Tire Stowage ........................ 379
Fluid Capacities ......................... 444
Fluid Leaks ............................. 85 Fluid Level Checks
Automatic Transmission ................. 426
Brake ............................... 423
Power Steering ........................ 412
Fluids ................................ 445
Fluids, Lubricants and Genuine Parts .......... 445
Fog Light Service ........................ 441
Fog Lights .......................... 152,441
Fold in Floor (Stow n Go) Seating........... 124
Freeing A Stuck Vehicle ................... 392
Fuel ................................. 346
Adding ............................. 350
Additives ............................ 348
Clean Air ............................ 346
Filler Cap (Gas Cap) .................... 350
Gasoline ............................ 346
Gauge .............................. 209
Hoses .............................. 425
Light ............................... 209
INDEX 481
10
