2006 CHRYSLER TOWN AND COUNTRY trip computer

▫To Accelerate For Passing ...............162

Overhead Console — If Equipped ...........163
▫ Courtesy/Reading Lights ................163
▫ Sunglass Storage ......................164
▫ Compass/Temperature Display ...........164
▫ Mini-Trip Computer ...................167
▫ Electronic Vehicle Information Center (EVIC) —
If Equipped .........................168
▫ Customer Programmable Features —
If Equipped .........................169

Garage Door Opener — If Equipped .........173
▫ Programming HomeLink ................174
▫ Canadian Programming/Gate Programming . . 176
▫ Using HomeLink .....................177 ▫
Erasing HomeLink Buttons ..............177
▫ Reprogramming a Single HomeLink Button . . . 178
▫ Security ............................178

Power Sunroof — If Equipped .............179
▫ Express Open Feature ..................179
▫ Wind Buffeting .......................180
▫ Sunroof Maintenance ...................181

Electrical Power Outlets — If Equipped .......181
▫ Electrical Outlet Use With Engine Off .......182

Convenience Tray Drawer And Cup Holders . . . 183
▫ Instrument Panel Cup Holders ............183
▫ Convenience Tray And Optional Smoker’s
Package Kit .........................184
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

On steep hills a greater speed loss or gain may occur so
it may be preferable to drive without speed control.
WARNING!
Speed Control can be dangerous where the system
can’t maintain a constant speed. Your vehicle could
go too fast for the conditions, and you could lose
control. An accident could be the result. Don’t use
Speed Control in heavy traffic or on roads that are
winding, icy, snow-covered, or slippery.
OVERHEAD CONSOLE — IF EQUIPPED
The overhead console can contain courtesy/reading
lights, an optional universal garage door opener
(HomeLink ), storage for sunglasses, compass/
temperature display, a mini-trip computer, optional elec-
tronic vehicle information center (EVIC), power sliding
door switches and an optional power liftgate switch.Courtesy/Reading Lights
At the forward end of the console are two courtesy/
reading lights.
Press the lens to turn these lights on. Press a second time
to turn the lights off.
Overhead Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163
3

Automatic Compass Calibration
This compass is self calibrating which eliminates the
need to manually set the compass. When the vehicle is
new, the compass may appear erratic and the “CAL”
symbol will be displayed. After completing three 360°
turns in an area free from large metal or metallic objects,
the “CAL” symbol will turn off and the compass will
function normally.
Manual Compass Calibration
If the compass appears erratic and the “CAL” symbol
does not appear, you must put the compass into the
Calibration Mode manually.
To put into a Calibration Mode: Turn on the ignition
switch and set the display to Comp/Temp. Press the
RESET button on vehicles equipped with a Compass/
Mini Trip Computer for at least 10 seconds until the “CAL” symbol appears. On vehicles equipped with
Compass/Temp press and hold the C/T and US/M
buttons for 10 seconds. Release the RESET button and
complete three 360° turns in an area free from large metal
objects. The “CAL” symbol will turn off and the compass
will function normally.
CAUTION!
Do not place any external magnets, such as magnetic
roof mount antennas, in the vicinity of the compass.
Do not use magnetic tools when servicing the over-
head console.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

To set the variance:Turn the ignition switch ON and set
the display to Comp/Temp. On vehicles equipped with a
Compass/Mini Trip Computer press the RESET button
for approximately 5 seconds. On vehicles equipped with
Compass/Temp press and hold the C/T and US/M
buttons for 5 seconds. The “VAR” symbol will light and
the last variance zone number will be displayed. Press
the STEP button on vehicles equipped with a Compass/
Mini Trip Computer or the US/M button on vehicles
equipped with Compass/Temp to select the proper vari-
ance zone as shown in the map. Press the RESET button
on vehicles equipped with a Compass/Mini Trip Com-
puter or the C/T button on vehicles equipped with
Compass/Temp to set the new variance zone and resume
normal operation.Mini-Trip Computer
This displays information on the following:
•Average Fuel Economy (ECO AVG)
Shows the average fuel economy since the last reset.
•Distance To Empty (DTE)
Shows the estimated distance that can be travelled with
the fuel remaining in the tank. This estimated distance is
determined using the MPG for the last few minutes.
•Trip Odometer (ODO)
Shows the distance travelled since the last reset.
•Elapsed Time (ET)
Shows the accumulated ignition ON time since the last
reset.
•Off Mode
Shows a blank display.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167
3

•Step Button
Push this button to cycle through all the Compass/Mini-
trip Computer displays.
•US/M Button
Press this button to convert the display from U.S. to
metric.
To Reset The Display
Pressing the Reset button once will clear the resettable
function currently being displayed. Resettable functions
are average fuel economy, trip odometer and elapsed
time. Pressing the reset button twice within four seconds
will clear all resettable functions. Reset will only occur if
a resettable function is currently being displayed.
Electronic Vehicle Information Center (EVIC) — If
Equipped
The Electronic Vehicle Information Center, when the
appropriate conditions exist, displays the following
WARNING messages and symbols. Each message is
accompanied by a single chime:
•TURN SIGNALS ON (with graphic)
•PERFORM SERVICE
•DOOR AJAR (one or more, with graphic)
•LIFTGATE AJAR (with graphic)
•WASHER FLUID LOW (with graphic)
•1,2,3 OR 4 LOW TIRE(S) PRESSURE (Refer to ”Tire
Pressure Monitor System” in the “Starting And Oper-
ating, Tire Section”)
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•CHECK TPM SYSTEM (Refer to ”Tire Pressure Moni-
tor System” in the “Starting And Operating, Tire
Section”)
•MEMORY SEAT DISABLED (Not in Park) — If
Equipped
•ADJUSTABLE PEDAL DISABLED/CRUISE EN-
GAGED
•ADJUSTABLE PEDAL DISABLED/VEHICLE IN RE-
VERSE
•REAR PARK ASSIST (Shown in Reverse only with a
single chime) — If Equipped
NOTE: Tire pressure menu items are available only on
vehicles equipped with the Tire Pressure Monitor Sys-
tem.
Customer Programmable Features — If Equipped
Press the “MENU” button until one of the display choices
following appears:
Language
When in this display you may select one of five lan-
guages for all display nomenclature, including the trip
computer functions. Press the “STEP” button while in
this display selects English, Francaise, Deutsch, Italiano,
or Espanol. As you continue the displayed information
will be shown in the selected language.
Rear Park Assist — If Equipped
When this feature is selected the system scans for objects
behind the vehicle using four sensors located in the rear
bumper. Objects can be detected from up to 71 inches
(180 cm). Pressing the “STEP” button while in this
display will disable/enable the Rear Park Assist System.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169
3

Compass Variance....................... 166
Computer, Trip/Travel .................... 167
Console, Overhead ....................... 163
Console, Removable ................... 189,190
Contract, Service ........................ 470
Coolant Pressure Cap ..................... 419
Cooling System ......................... 416
Adding Coolant (Antifreeze) .............. 418
Coolant Capacity ...................... 444
Coolant Level ...................... 417,420
Disposal of Used Coolant ................ 419
Drain, Flush, and Refill .................. 417
Inspection ........................... 420
Points to Remember .................... 420
Pressure Cap ......................... 419
Radiator Cap ......................... 419
Selection of Coolant (Antifreeze) ......417,444,445
Cruise Control (Speed Control) .............. 160
Cruise Light ........................... 216 Cup Holder
......................... 183,433
Customer Assistance ..................... 468
Daytime Running Lights ................... 151
Dealer Service .......................... 401
Defroster, Rear Window ................... 305
Defroster, Windshield ................84,285,296
Diagnostic System, Onboard ................ 399
Dimmer Control ........................ 150
Dipsticks Automatic Transmission ................. 426
Oil (Engine) .......................... 402
Disabled Vehicle Towing ................... 393
Disarming, Theft System ................... 27
Disposal Antifreeze (Engine Coolant) ............... 419
Engine Oil ........................... 406
Domelight ............................. 150
Door Ajar Light ......................... 210
INDEX 479
10

Reading............................. 163
Rear Servicing ........................ 442
Rear Tail ............................ 442
Seat Belt Reminder ..................... 212
Security Alarm (Theft Alarm) .............. 213
Service ........................... 438,439
Service Engine Soon (Malfunction Indicator) . . . 215
Side Marker .......................... 442
Theft Alarm (Security Alarm) .............. 213
Turn Signal ..................... 153,440,442
Voltage ............................. 212
Warning (Instrument Cluster Description) ..... 209
Washer Fluid ......................... 214
Load Leveling System .................... 197
Loading Vehicle ................... 194,352,353
Capacities ........................... 353
Tires ............................... 328
Locks Door ................................ 17 Lower Anchors and Tether for CHildren (LATCH) . 74
Lubrication, Body
....................... 414
Luggage Rack (Roof Rack) ................. 195
Lumbar Support ........................ 124
Maintenance, Airbag ...................... 68
Maintenance Free Battery .................. 409
Maintenance Procedures ................... 402
Maintenance Schedule .................... 448
Schedule “A” ......................... 461
Schedule “B” ......................... 451
Maintenance, Sunroof ..................... 181
Malfunction Indicator Light (Check Engine) . . 215,400
Manual, Service ......................... 472
Map/Reading Lights ..................... 163
Memory Feature (Memory Seat) ............. 143
Memory Seat ......................... 95,143
Mini-Trip Computer ...................... 167
Mirrors ................................ 92
INDEX 485
10
