2006 CHRYSLER TOWN AND COUNTRY Owners Manual

CAUTION!
Do not place any article under a power seat or
impede its ability to move as it may cause damage to
the seat controls. Seat travel may become limited if
movement is stopped by an obstruction in the seat’s
path.
Adjustable Head Restraints — If Equipped
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Pull up or push down
on the head restraint so that the upper edge is as high as
practical. To raise the head restraint, pull up on the head
restraint. To lower the head restraint, depress the release
tab located at the base of the head restraint and push
down on the head restraint.
Heated Seats — If Equipped
This feature heats the front driver and passenger seats.
The controls for the heated seats are located on the
instrument panel above the radio. You may choose LOW,
Adjustable Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
3

HIGH or No Heat. The switch position as well as an
indicator light will show when the LOW or HIGH heat is
ON.Manual Reclining Seats — If Equipped
The recliner mechanism control is on the outboard side of
the seat. To recline, lean forward slightly, lift the lever,
then push back to the desired position and release the
lever. Lean forward and lift the lever to return the
seatback to its normal position. Using body pressure, lean
forward and rearward on the seat to be sure the seatback
has latched.
Heated seat switches
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt and
be seriously or fatally injured. Use the recliner only
when the vehicle is parked.
Manual Reclining Seat Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
3

Manual Lumbar — If Equipped
The lumbar adjustment handle is located inboard under
the armrest. To increase the support, rotate the handle
down.
Stow ’n Go Seating
On vehicles equipped with Stow ’n Go seating, the
second and third row seats may be folded into the floor
for convenient storage.
To Fold Second Row Seats
1. Lower the head restraint and raise the armrests on the
second row seat.
2. Slide the storage bin locking mechanism to the
 Lockedposition and then pull up on the storage bin
latch to open the cover.
Manual Lumbar Control
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Pull up on the seatback recliner lever located on the
outboard side of the seat and fold the seatback down. To
assure the seatback is latched in the folded position,
additional downward pressure on the seatback may be
required when folding. NOTE:
The cupholder must be in the closed position
before the seat can be tumbled into the floor.
Load Floor HandleSeatback Release Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
3

4. Pull rearward on the release strap located at the rear of
the seat and tumble the seat forward into the storage bin.
5. Close the storage bin cover.To Unfold Second Row Seats
1. Slide the storage bin locking mechanism to the
 Lockedposition and then pull up on the storage bin
latch to open the cover.
2. Pull up on the handle to lift the seat out of the storage
bin and push the seat rearward to latch the seat anchors.
Seat Release Strap
Seat Handle
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Pull up on the seatback recliner lever located on the
outboard side of the seat, to return the seatback to its full
upright position.
4. Close the storage bin cover and adjust the head
restraint to the desired position.To Fold Third Row Seats
1. Lower the head restraint to its full down position.
2. Pull release strap marked “1” located on the rear of the
seat to lower the seatback.
Seatback Release Lever
Release Strap 1
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127
3

3. Pull release strap marked “2” to release the anchors. 4. Pull release strap marked “3” and tumble the seat rearward into the storage bin.
Release Strap 2
Release Strap 3
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
