NOTE:The power window switches, radio, power
sunroof, and power outlets will remain active for up to 45
seconds after the ignition switch has been turned off.
Opening either front door will cancel this feature.
WARNING!
Leaving children in a vehicle unattended is danger-
ous for a number of reasons. A child or others could
be injured. Children should be warned not to touch
the parking brake, brake pedal or the gear selector
lever. Don’t leave the keys in the ignition. A child
could operate power windows, other controls, or
move the vehicle.
CAUTION!
An unlocked car is an invitation to thieves. Always
remove key from the ignition and lock all doors
when leaving the vehicle unattended.
Key-In-Ignition Reminder
If you open the driver’s door and the key is in the ignition
switch, a chime will sound to remind you to remove the
key.
SENTRY KEY
The Sentry Key Immobilizer System prevents unautho-
rized operation of the vehicle by disabling the engine.
The system will shut the engine off after 2 seconds of
running if an invalid key is used to start the vehicle. This
system utilizes ignition keys which have an electronic
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

chip (transponder) embedded into them. Only keys that
have been programmed to the vehicle can be used to start
and operate the vehicle.
The Sentry Key Immobilizer System does not need to be
armed or activated. Operation of the system is automatic
regardless of whether or not the vehicle is locked or
unlocked. During normal operation, the Theft Alarm/
Immobilizer Light will come on for three (3) seconds
immediately after the ignition switch is turned on for a
bulb check. Afterwards, if the bulb remains on, this
indicates a problem with the electronics.
If the bulb begins to flash after the bulb check, this
indicates that an invalid key has been used to start the
vehicle. Both of these conditions will result in the engine
being shut off after two (2) seconds of running.
Keep in mind that a key which has not been programmed
is also considered an invalid key even if it is cut to fit the
ignition lock cylinder for that vehicle. If the Theft Alarm/Immobilizer Light comes on during
normal vehicle operation (vehicle has been running for
longer than 10 seconds), a fault has been detected in the
electronics and the vehicle should be serviced as soon as
possible.
NOTE:
•The Sentry Key Immobilizer System is not compatible
with remote starting systems. Use of these systems
may result in vehicle starting problems and loss of
security protection.
•Exxon/Mobil Speed Pass,™ additional Sentry Keys, or
any other transponder equipped components on the
same keychain will
notcause a key-related (transpon-
der) fault unless the additional part is physically held
against the ignition key being used when starting the
vehicle. Cell phones, pagers, or other RF electronics
will not cause interference with this system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
Replacement Keys
NOTE: Only keys that have been programmed to the
vehicle electronics can be used to start the vehicle. Once
a Sentry Key has been programmed to a vehicle, it can
not be programmed to any other vehicle.
At the time of purchase, the original owner is provided
with a four digit PIN number. This number is required
for dealer replacement of keys. Duplication of keys may
be performed at an authorized dealer or by using the
Customer Key Programming procedure. This procedure
consists of programming a blank key to the vehicle
electronics. A blank key is one which has never been
programmed. NOTE: When having the Sentry Key Immobilizer
System serviced, bring all vehicle keys with you to the
dealer.Customer Key Programming
You can program new sentry keys to the system if you
have two valid sentry keys by performing the following
procedure:
1. Cut the additional Sentry Key Transponder blank(s) to
match the ignition switch lock cylinder key code.
2. Insert the first valid key into the ignition switch and
turn the ignition switch ON for at least 3 seconds but no
longer than 15 seconds. Turn the ignition switch OFF and
remove the first key.
3. Insert the second valid key and turn the ignition
switch ON within 15 seconds. After ten seconds a chime
will sound and the Theft Alarm Light will begin to flash.
Turn the ignition switch OFF and remove the second key.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

VEHICLE THEFT ALARM
This system monitors the vehicle doors and ignition
switch for unauthorized entry or operation. When the
alarm is activated, the system provides both audible and
visual signals. The horn will pulse, headlights/park
lights will flash, the Vehicle Theft Alarm/Immobilizer
light, located above the driver’s center instrument panel
vent will flash, and the vehicle will not start. If the alarm
is triggered and no action is taken to disarm it, the system
will turn off the horn after three minutes and after 15
minutes of light only operation the system will then
rearm itself.
To arm the system: Remove the key from the ignition
switch and either:
1. Press a power door lock switch while the driver’s or
passenger’s door is open.
2. Press the LOCK button on the keyless entry transmit-
ter. After the last door is closed, or if all doors are closed, the
system will arm itself in about 16 seconds. During that
time, the Vehicle Theft Alarm/Immobilizer light will
flash. If it does not illuminate, the system is not arming.
If you open a door during this arming period, the system
will cancel the arming process. You must repeat one of
the previously described arming sequences to rearm the
system.
To disarm the system:
Press the UNLOCK button on the
keyless entry transmitter. Also, using a valid sentry key
and moving the ignition switch to the ON/START posi-
tion will disarm the system. If you disarm the system and
access the liftgate area, the system must be rearmed, as
described previously, when closing the liftgate. If some-
thing has triggered the system in your absence, the horn
will sound three times when you disarm the system.
Check the vehicle for tampering.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Pressing the MENU button will change the displayed
programming features. Pressing the STEP button will
display the available choices. Pressing the MENU button
a second time accepts a selected choice.
When the appropriate conditions exist, the Electronic
Vehicle Information Center (EVIC) displays the following
messages.
•LEFT/RIGHT TURN SIGNAL ON (with a continuous
warning chime)
•INVALID KEY & FOB (with a single chime)
•PARK ASSIST DISABLED
•SERVICE PARK ASSIST SYSTEM
•SERVICE IMMOBILIZER (with a single chime)
•KEY FOB BATTERY LOW (with a single chime)
•KEY & FOB PROGRAMMED (with a single chime)
•PROGRAM KEY & FOB
•MEMORY #1/#2 POSITION SET (with a single chime)
•MEMORY #1/#2 POS SELECTED
•MEMORY SYSTEM DISABLED VEHICLE NOT IN
PARK (with a single chime)
•SET INHIBITED DUE TO MOTION (with a single
chime)
•FOB LINKED (with a single chime)
•FOB UNLINKED (with a single chime)
•PARK BRAKE ENGAGED (with a single chime)
•LOW BRAKE FLUID (with a single chime)
•LOW FUEL (with a single chime)
•MENU IN PARK ONLY
•LIST # ALERT MESSAGES
UNDERSTANDING YOUR INSTRUMENT PANEL 177
4

Illuminated Entry........................ 15
Immobilizer (Sentry Key) ................... 12
Indicator, Traction Control ................. 171
Infant Restraint .......................... 65
Information Center, Vehicle ................. 176
Instrument Cluster ................. 166,167,168
Instrument Panel and Controls .............. 165
Instrument Panel Lens Cleaning ............. 375
Integrated Power Module .................. 377
Interior Appearance Care .................. 374
Interior Lights ....................... 126,127
Intermittent Wipers (Delay Wipers) ........... 131
Introduction ............................. 4
Jack Location ........................... 321
Jack Operation ....................... 320,324
Jacking Instructions ...................... 324
Jump Starting .......................... 327 Key, Programming
........................ 14
Key, Replacement ........................ 14
Key, Sentry (Immobilizer) ................... 12
Key-In Reminder ......................... 12
Keyless Entry System ...................... 20
Keys .................................. 11
Knee Bolster ............................ 50
Lap/Shoulder Belts ....................... 35
LATCH
(Lower Anchors and Tether for CHildren) .....61,63
Latches Hood ............................... 123
Lead Free Gasoline ...................... 296
Life of Tires ............................ 289
Liftgate ................................ 28
Lights .............................. 73,125
Airbag ........................ 49,59,72,175
Anti-Lock ........................... 169
INDEX 429
10

Security Alarm (Theft Alarm)................ 26
Selection of Coolant (Antifreeze) ..........359,387
Sentry Key (Immobilizer) ................... 12
Sentry Key Programming ................... 14
Service Assistance ....................... 414
Service Contract ......................... 416
Service Engine Soon Light (Malfunction Indicator) . 173
Service Manuals ........................ 418
Setting the Clock ........................ 186
Shoulder Belts ........................... 35
Signals, Turn ..................... 169,384,385
Slippery Surfaces, Driving On ............... 329
Snow Chains (Tire Chains) ................. 294
Snow Tires ............................ 295
Spare Tire ....................... 286,287,322
Spark Plugs ............................ 349
Speed Control (Cruise Control) .............. 138
Speedometer ........................... 169
Starting ............................... 258 Engine Fails to Start
.................... 259
Starting and Operating .................... 258
Starting Procedures ...................... 258
Steering Linkage ............................. 355
Power ........................... 271,354
Shaft Seal ............................ 355
Tilt Column .......................... 133
Steering Wheel Mounted Sound System Controls ............................. 229
Storage ............................ 155,380
Storage, Vehicle ...................... 252,380
Storing Your Vehicle ...................... 380
Sun Roof .............................. 149
Sun Visor Extension ....................... 83
Sunglasses Storage ....................... 142
Sunroof Maintenance ..................... 151
Supplemental Restraint System - Airbag ........ 45
Synthetic Engine Oil ...................... 348
INDEX 435
10
